Fujitsu Siemens Computers 4312 FA Manuel utilisateur

4312 FA

4312 FA4312 FA

4312 FA

LCD-Bildschirm / Moniteur / Monitor / Skärm /

Beeldscherm / Billedskærm

BETRIEBSANLEITUNG

BETRIEBSANLEITUNGBETRIEBSANLEITUNG

BETRIEBSANLEITUNG

OPERATING MANUAL

OPERATING MANUALOPERATING MANUAL

OPERATING MANUAL

S26361-K841-V150-1-5E19 English

Contents

Introduction........................................................................................................................................1

Notational conventions ..............................................................................................................2

Important notes .................................................................................................................................2

Safety ........................................................................................................................................2

Cleaning notes...........................................................................................................................3

Transport notes .........................................................................................................................3

Manufacturer’s notes .................................................................................................................4

FCC Class B Compliance Statement.........................................................................................4

Important note on power cable ..................................................................................................5

Declaration of Conformity ..........................................................................................................5

Disposal and recycling...............................................................................................................6

Checking the contents of the consignment ........................................................................................6

Installing an ergonomic video workstation .........................................................................................7

Height adjustment and ability to turn..........................................................................................8

Connecting the monitor......................................................................................................................9

Operation of the monitor..................................................................................................................10

Switching the monitor on/off ....................................................................................................11

Notes on power management..................................................................................................11

Changing the monitor settings .................................................................................................12

Notes on ergonomic colour adjustment............................................................................................17

Technical data.................................................................................................................................18

VESA-DDC-compatible VGA interface.....................................................................................19

Preset operating modes...........................................................................................................19

Power supply plug ...................................................................................................................19

Pin assignment D-SUB............................................................................................................20

Trouble shooting..............................................................................................................................20

S26361-K841-V150-1-5E19 English - 1

Introduction

Your new LCD (Liquid Crystal Display) monitor 4312 FA offers numerous features and functions, for

example:

• TFT display (Thin Film Transistor; active matrix)

• minimal space requirements thanks to slim housing

• height adjustment and ability to turn (portrait mode)

• optimum ergonomic characteristics (totally distortion-free, excellent picture definition and colour

purity right into the corners)

• high degree of brightness and good contrast

• high resolution (1280x1024) for displaying the information content of a conventional 19-inch

screen with CRT (Cathode Ray Tube)

• presentation of up to 16.7 million colours (in conjunction with an appropriate screen controller)

• automatic scanning of all horizontal frequencies from 31 to 80 kHz and all refresh rates (vertical

frequencies) from 55 to 75 Hz (all absolutely flicker-free)

• digital screen controller with microprocessor for storing 20 different display modes

• freely adjustable colour alignment for matching the screen colours to the colours of various

input and output devices

• convenient operation via integrated OSD (On-Screen-Display) menu

• VESA-DDC compatibility

• VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface, mechanical

interface to swivel arm and wall bracket)

• plug&play capability

• power management for reducing power consumption when the PC system is not in use

• compliance with the recommendations in accordance with TCO ’99

This Operating Manual contains important information you require to start up and run your LCD

monitor.

A screen controller with VGA interface is required to control the 4312 FA LCD monitor. The monitor

processes the data supplied to it by the screen controller. The screen controller/the associated

driver software is responsible for setting the modes (resolution and refresh rate).

When putting the monitor into operation for the first time, the screen display should be optimally

adapted to the screen controller used and adjusted in accordance with your needs (see section

"Changing the monitor settings" in chapter "Operation of the monitor").

Target group

You don't need to be an "expert" to perform the operations described here. Do, however, read the

chapter with the "Important notes" in the Operating Manual of the system unit and in this Operating

Manual.

In the event of any problems occurring, please contact your sales outlet or our customer service

centre.

Further information

Details of how you set the resolution and refresh rate are provided in the documentation on your

screen controller/the associated driver software.

Colour monitor 4312 FA

2 - English S26361-K841-V150-1-5E19

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to text marked with this symbol. Failure to observe this warning

endangers your life, destroys the device, or may lead to loss of data.

Supplementary information, remarks, and tips follow this symbol.

Ê Text which follows this symbol describes activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters or terms.

Important notes

!In this chapter you will find information regarding safety which is essential to take note of

with your monitor.

Safety

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales outlet or our customer service centre.

• The display surface of the LCD monitor is sensitive to pressure and scratches. You should

therefore be careful with the display surface so as to avoid lasting damage (Newton rings,

scratches).

• If the device is brought into the installation site from a cold environment, condensation can

form. Before operating the device, wait until it is absolutely dry and has reached approximately

the same temperature as the installation site.

• During installation and before operating the device, please observe the instructions on

environmental conditions in the chapter entitled "Technical data" as well as the instructions in

the chapter "Installing an ergonomic video workstation".

• To ensure adequate ventilation the monitor may only be operated with the monitor foot

installed.

• Only the power adapter supplied may be used for the LCD monitor's power supply.

• Do not cover the power adapter when it is operational. Do not place the power adapter on heat-

sensitive material.

• The power adapter automatically sets itself to a mains voltage in the range of 100 V to 240 V.

Ensure that the local mains voltage lies within these limits.

• Ensure that the power socket on the power adapter or the grounded mains outlet is freely

accessible.

• The ON/OFF switch does not disconnect the device from the mains voltage. To completely

disconnect the mains voltage, remove the power plug from the socket.

Colour monitor 4312 FA

S26361-K841-V150-1-5E19 English - 3

• Lay all cables so that nobody can stand on them or trip over them. When attaching the device,

observe the relevant notes in the chapter "Connecting the monitor".

• No data transmission cable should be connected or disconnected during a thunderstorm.

• Please ensure that no objects (e.g. necklaces, paperclips etc.) or liquids can get into the

interior of the device (this may cause an electrical shock or short circuit).

• In emergencies (e.g. damaged casing, elements or cables, penetration of liquids or foreign

matter), switch off the unit, disconnect the power plug and contact your sales outlet or our

customer service centre.

• The screen background lighting contains mercury. You must observe the applicable handling

and disposal safety regulations for fluorescent tubes.

• If the LCD monitor is damaged (for example the glass is broken), avoid letting any liquids that

may escape coming into contact with any part of your body (skin, mouth, nose) or foodstuffs.

Clean parts of the body and clothing that have already come into contact with such liquids with

plenty of soap and water.

Do not breathe in any of the escaping vapours. You should contact your doctor if you have

breathed in fumes or come into contact with the liquid.

• Only qualified technicians should repair the device. Unauthorised opening and incorrect repair

may greatly endanger the user (electric shock, fire risk).

• The power adapter may only be opened by authorised specialist personnel.

• You may set only those resolutions and refresh rates specified in the "Technical data" chapter.

Otherwise you may damage your monitor. If you are in any doubt, contact your sales outlet or

customer service centre.

• Keep this operating manual together with your device. If you pass on the device to third parties,

you should include this manual.

Cleaning notes

• Always pull out the power plug before you clean the monitor.

• Do not clean any interior parts yourself, leave this job to a service technician.

• Do not use any cleaning agents that contain abrasives or may corrode plastic.

• Ensure that no liquid will run into the system.

• Ensure that the ventilation areas of the monitor are free.

• The display surface of the LCD monitor is sensitive to pressure and scratches. Clean it only

using a soft, slightly moistened cloth.

Wipe the monitor housing with a dry cloth. If the monitor is particularly dirty, use a cloth which has

been moistened in mild domestic detergent and then carefully wrung out.

Transport notes

• Transport the monitor with care and only in its original packaging or another corresponding

packaging fit to protect it against knocks and jolts.

• Never drop the LCD monitor (danger of glass breakage).

Colour monitor 4312 FA

4 - English S26361-K841-V150-1-5E19

Manufacturer’s notes

Energy Star

The Fujitsu Siemens LCD colour monitor 4312 FA is designed to conserve

electricity by dropping to less than 5 W when it goes into standby,

suspend and OFF mode. With this new power management the 4312 FA

qualifies for the U.S. Environmental Protection Agency's (EPA) Energy

Star Computers award.

The EPA estimates that computer equipment uses 5% percent of all business electricity and that

this is growing rapidly. If all desktop PCs and peripherals enter a low-power mode when not in use,

the overall savings in electricity could amount to $ 2 milliard annually. These savings could also

prevent the emission of 20 million tons of carbon dioxide into the atmosphere - the equivalent of 5

million automobiles.

As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product

meets the Energy Star guidelines for energy efficiency.

CE marking

The shipped version of this device complies with the requirements of the EEC

directives 89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage

directive".

FCC Class B Compliance Statement

The following statement applies to the products covered in this manual, unless otherwise specified

herein. The statement for other products will appear in the accompanying documentation.

NOTE:

This equipment has been tested and found to comply with the limits for a "Class B" digital device,

pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian Interference-

Causing Equipment Regulations. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in strict accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

The manufacturer is not responsible for any radio or television interference caused by unauthorised

modifications of this equipment or the substitution or attachment of connecting cables and

equipment other than those specified by the manufacturer. The correction of interference caused by

such unauthorised modification, substitution or attachment will be the responsibility of the user.

The use of shielded I/O cables is required when connecting this equipment to any and all optional

peripheral or host devices. Failure to do so may violate FCC rules.

Colour monitor 4312 FA

S26361-K841-V150-1-5E19 English - 5

Important note on power cable

To guarantee safe operation, use the cable supplied. Use the following guidelines if it is necessary

to replace the original cable set.

• The female/male receptacles of the cord set must meet CEE-22 requirements.

• The cable has to be HAR-certified or VDE-certified. The mark HAR or VDE will appear on the

outer sheath or on the insulation of one of the inner conductors.

• For devices which are mounted on a desk or table, type SVT or SJT cable sets may be used.

For devices which sit on the floor, only SJT type cable sets may be used.

• The cable set must be selected according to the rated current for your device.

Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Product Name: Color LCD Monitor

Trade Name: Fujitsu Siemens Computers

Model Number(s): 4312 FA

Name of Responsible Party: Siemens Information and Communication

Products LLC

3860 N. First Street

San Jose, CA 95134-1702

U.S.A.

Contact Person: Mike Fitzner

Phone No.: (408) 428-8918

Fax No.: (408) 428-7290

We, Siemens Information and Communication Products LLC, hereby declare that the equipment

bearing the trade name and model number specified above was tested confirming to the applicable

FCC Rules under the most accurate measurement standards possible, and that all the necessary

steps have been taken and are in force to assure that production units of the same equipment will

continue to comply with the Commissions requirements.

Colour monitor 4312 FA

6 - English S26361-K841-V150-1-5E19

Disposal and recycling

This device has been manufactured to the highest possible degree from materials which can be

recycled or disposed of in a manner that is not environmentally damaging.

The device may be taken back after use to be recycled, provided that it is returned in a condition

that is the result of normal use. Any components not reclaimed will be disposed of in an

environmentally acceptable manner.

If you have any questions about disposal of the batteries or system, please contact your local sales

outlet or:

Fujitsu Siemens Computers GmbH

Recyclingcenter

D-33106 Paderborn

Tel.: ++ 49 5251 - 818 010/ Fax: ++ 49 5251 - 818 015

Checking the contents of the consignment

Ê Unpack all the individual parts.

Ê Check the delivery for damage incurred during transportation.

Ê Check whether the delivery agrees with the details in the delivery note.

The complete LCD monitor package includes:

− one monitor

− one data cable (D-SUB)

− one power cable

− a power adapter with power adapter cable

− one floppy disk

− this Operating Manual

Should you discover that the delivery does not correspond to the delivery note, notify your local

sales outlet immediately.

It is recommended not to throw away the original packing material. Keep it for future

transportation.

Colour monitor 4312 FA

S26361-K841-V150-1-5E19 English - 7

Installing an ergonomic video workstation

Before you set up your equipment, you should select a suitable position for working at the monitor.

Please observe the following advises when installing a video workstation.

Window

edge of desk

permissible

reaching sector

600 mm

permissible

reaching sector

600 mm

Avoid direct and reflected glare. Avoid glare from electric

lighting. Position the keyboard where it

is easiest to reach.

30°

65°

0°

60°

0°

permissible viewing sector

preferable viewing sector

permissible

viewing sector approx. 90°

and more

approx. 90°

Position the monitor for

optimum viewing. The viewing

distance to the monitor should

be approximately 50 cm.

Keep ventilated areas clear. Remember to maintain correct

posture.

Table des matières

Autres manuels Fujitsu Siemens Computers Moniteur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 23" Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW P20W-3 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 21P4 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW L17-2 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW Q22W-1 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 21P3 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers Fujitsu Siemens SCENICVIEW P17-2 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 22" LCD Monitor Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers MCM 153V Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW A17-2 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW A17-3A Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers Fujitsu Siemens SCENICVIEW P17-2 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 461V FA Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers MCM 171E Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers FSC B17-1 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 5110 FA Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO SL 3260W Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW L17-6 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers C551 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers FSC B15-1A Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers C384FA-M Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW B17-5 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers L19-2SD Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers x178 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
