Fujitsu Siemens Computers 461V FA Manuel utilisateur

461V FA

461V FA461V FA

461V FA

LCD-Bildschirm / Moniteur / Monitor / Skärm / Beeldscherm

BETRIEBSANLEITUNG

BETRIEBSANLEITUNGBETRIEBSANLEITUNG

BETRIEBSANLEITUNG

OPERATING MANUAL

OPERATING MANUALOPERATING MANUAL

OPERATING MANUAL

Sie haben ...

... technische Fragen oder Probleme?

Wenden Sie sich bitte an

unseren Help Desk (siehe Garantiekarte).

Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:

http://www.fujitsu-siemens.com

Are there ...

... any technical problems or other

questions you need clarified?

Please contact

our Help Desk (see Guarantee Card).

The latest information on our products, tips, updates, etc., can be found on the Internet under:

http://www.fujitsu-siemens.com

Dieses Handbuch wurde auf Recycling-Papier gedruckt.

This manual has been printed on recycled paper.

Ce manuel est imprimé sur du papier recyclé.

Este manual ha sido impreso sobre papel reciclado.

Questo manuale è stato stampato su carta da riciclaggio.

Denna handbok är tryckt på recyclingpapper.

Dit handboek werd op recycling-papier gedrukt.

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Bestell-Nr./Order No.: A26361-K708-Z100-1-5E19

A26361-K708-Z100-1-5E19A26361-K708-Z100-1-5E19

A26361-K708-Z100-1-5E19

Printed in Taiwan

AG 1200 12/00

A26361-K708-Z100-1-5E19

461V FA BETRIEBSANLEITUNG

OPERATING MANUAL

461V FA

LCD-Bildschirm

LCD monitor

Moniteur LCD

Monitor LCD

LCD-skärm

LCD-beeldscherm

Betriebsanleitung

Operating Manual

Deutsch

lish

Fran

ais

Español

Italiano

Svenska

Nederlands

TCO'99

Ausgabe Dezember 2000

December 2000 edition

VESA, DDC und DPMS sind eingetragene Warenzeichen der Video Electronics Standards

Association.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

Dieses Handbuch wurde erstellt von

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

VESA, DDC and DPMS are registered trademarks of Video Electronics Standards

Association.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved.

Delivery subject to availability. Right of technical modification reserved.

This manual was produced by

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

A26361-K708-Z100-2-5E19 English

Contents

Introduction........................................................................................................................................1

Notational conventions ..............................................................................................................2

Important notes .................................................................................................................................2

Safety........................................................................................................................................2

Cleaning....................................................................................................................................3

Transport...................................................................................................................................3

FCC Class B Compliance Statement.........................................................................................4

Important note on power cable ..................................................................................................4

Declaration of Conformity..........................................................................................................6

Energy Star Guidelines..............................................................................................................6

CE certificate.............................................................................................................................6

Disposal and recycling...............................................................................................................7

Checking the contents of the consignment ........................................................................................7

Installing an ergonomic video workstation .........................................................................................8

Connecting the monitor......................................................................................................................8

Connecting cables to the monitor ..............................................................................................9

Connecting cables to the computer..........................................................................................10

Operation of the monitor..................................................................................................................10

Adjusting rake and rotation......................................................................................................10

Switching the monitor on/off ....................................................................................................11

Notes on power management..................................................................................................12

Changing the monitor settings.................................................................................................12

Notes on ergonomic colour adjustment............................................................................................17

Removing the monitor base.............................................................................................................18

Technical data.................................................................................................................................18

VESA-DDC-compatible VGA interface.....................................................................................19

Preset operating modes...........................................................................................................20

Pin assignment D-SUB............................................................................................................20

Monitor port DVI-D...................................................................................................................21

Error handling..................................................................................................................................21

A26361-K708-Z100-2-5E19 English - 1

Introduction

Your new LCD (Liquid Crystal Display) monitor 461V FA offers numerous features and functions, for

example:

• TFT display (Thin Film Transistor; active matrix)

• minimal space requirements thanks to slim housing

• optimum ergonomic characteristics (totally distortion-free, excellent picture definition and colour

purity right into the corners)

• high degree of brightness and good contrast

• high resolution (1280x1024) for displaying the information content of a conventional 21-inch

screen with CRT (Cathode Ray Tube)

• presentation of up to 16.7 million colours (in conjunction with an appropriate graphics card)

• automatic scanning of horizontal frequencies from 31 to 82 kHz and refresh rates (vertical

frequencies) from 56 to 85 Hz (absolutely flicker-free)

• digital screen controller with microprocessor for storing 28 different display modes

• freely adjustable colour alignment for matching the screen colours to the colours of various

input and output devices

• convenient operation via integrated OSD (On-Screen-Display) menu

• VESA-DDC compatibility

• VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) - mechanical

interface to swivel arm and wall bracket)

• plug&play capability

• power management for reducing power consumption when the computer system is not in use

• compliance with the recommendations in accordance with TCO ’99

In normal screen mode (dark characters against a light background) the monitor satisfies the

ergonomic requirements for the GS symbol.

This Operating Manual contains important information you require to start up and run your LCD

monitor.

A graphics card (screen controller) with VGA interface or a digital graphics card with DVI interface is

required to control the 461V FA LCD monitor. The monitor processes the data supplied to it by the

screen controller. The screen controller/the associated driver software is responsible for setting the

modes (resolution and refresh rate).

When putting the monitor into operation for the first time, the screen display should be optimally

adapted to the screen controller used and adjusted in accordance with your needs (see section

"Changing the monitor settings" in chapter "Operation of the monitor").

Target group

You don't need to be an "expert" to perform the operations described here. Do, however, read the

chapter "Important notes" in the Operating Manual of the computer and in this Operating Manual.

In the event of any problems occurring, please contact your sales outlet or our Help Desk.

Further information

Details of how you set the resolution and refresh rate are provided in the documentation on your

screen controller/the associated driver software.

Color monitor 461V FA

2 - English A26361-K708-Z100-2-5E19

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to texts marked with this symbol. Failure to observe this warning

endangers your life, destroys the system, or may lead to loss of data.

Supplementary information, remarks and tips follow this symbol.

Texts which follow this symbol describe activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters and terms that are being emphasised.

Texts in italics indicate filenames and menu items.

Important notes

!In this chapter you will find information regarding safety which is essential to take note of

with your monitor.

Safety

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales outlet or our Help Desk.

• The display surface of the LCD monitor is sensitive to pressure and scratches. You should

therefore be careful with the display surface so as to avoid lasting damage (Newton rings,

scratches).

• If the device is brought into the installation site from a cold environment, condensation can

form. Before operating the device, wait until it is absolutely dry and has reached approximately

the same temperature as the installation site.

• During installation and before operating the device, please observe the instructions on

environmental conditions in the chapter entitled "Technical data" as well as the instructions in

the chapter "Installing an ergonomic video workstation".

• To ensure sufficient ventilation, the intake and exhaust air openings of the monitor must never

be blocked.

• The device automatically sets itself to the correct voltage within the range from 100 V to 240 V.

Ensure that the local mains voltage lies within these limits.

• Ensure that the power socket on the device or the grounded wall outlet is freely accessible.

• The ON/OFF switch does not disconnect the device from the line voltage. To disconnect the

line voltage completely, remove the power plug from the socket.

• Lay all cables so that nobody can stand on them or trip over them. When attaching the device,

observe the relevant notes in the chapter "Connecting the monitor".
