Front Runner RRAC210 Manuel utilisateur

front runner

RRAC210

ENG

Thank you for purchasing a Front Runner Rack Mounted Bottle Opener.

Before you start, take a moment to familiarize yourself with the Fitting Instructions and the included components.

Refer to Page 2 for a list of all the components, quantities and tools required.

READ ME !

IMPORTANT WARNING!

IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD

RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT

RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND

DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO

INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY

FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.

Please call us if you have any questions about the installation of this product.

Rack Mounted Bottle Opener

TOOLS NEEDED

FIGURE 1.1

GET ORGANIZED

IN THE BOX

4mm

5mm

1 1 X Bottle Opener

2 1 X M8 x 12 Button Head Bolt

3 1 X M8 Thin Nut

4 1 X M8 Schnorr Washer

CHECK ONLINE FOR LATEST FITMENT GUIDE WWW.FRONTRUNNEROUTFITTERS.COM

FIT AND SECURE2

2.1

2.2

INSTALL OTHER VEHICLE AND RACK ACCESSORIES

Now's the time to visit your favorite Front Runner dealer in person or online.

Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam

Share your adventures on:

FINISH

Congratulations! You did it. Take a step back and admire your work!

FIT AND SECURE TO SLIMSPORT RACK

Preassemble the M8 x 12 Button Head

Bolt, M8 Schnorr Washer and M8 Thin Nut

(Items 2, 3 & 4) to the Bottle Opener (Item 1)

as shown.

Slide the assembly into the open end of the

slat before fully tightening the M8 Thin Nut

(Item 3).

FIT AND SECURE TO SLIMLINE II RACK

Loosen and remove the corner from the rack.

Preassemble the M8 x 12 Button Head Bolt,

M8 Schnorr Washer and M8 Thin Nut (Items

2, 3 & 4) to the Bottle Opener (Item 1) as

shown.

Slide the assembly into the open end of the

side proﬁle before fully tightening the M8

Thin Nut (Item 3).

Reﬁt the corner to the rack.

4mm

5mm

4mm

5mm
