Frigidaire FGEW3065PF Feuille d'instructions

frigidaire.com

Signature Features

30" Electric

Single Wall Ovens

FGEW3065P F/ W/ B

Power Broil

Added power means you can broil

food faster.

Quick Preheat

Preheat in less than six minutes.1

True Convection

Single convection fan circulates hot

air throughout the oven for faster and

more even multi-rack baking.

Eortless™ Convection

Takes the guesswork out of

convection cooking — our oven

automatically adjusts standard

baking temperatures to convection

temperatures for consistent results.

Product Dimensions

Height 29"

Width 30"

Depth 24-3/4"

More Easy-To-Use Features

Steam Cleaning

A light oven cleaning that’s chemical-free,

odor-free, and fast.

Eortless™ Temperature Probe

Take the guesswork out of cooking

with the Effortless Temperature Probe

that shows you the internal cooking

temperature of your food. You can set the

desired finished temperatire and the oven

alerts you when that temperature has been

reached.

Even Baking Technology

Our Even Baking Technology ensures even

baking every time.

One-Touch Keep Warm Setting

Just one touch of a button keeps food

warm until everything — and everyone —

is ready.

Smudge-Proof™ Stainless Steel2

Reduces fingerprints and smudges so it’s

easy to clean.

Built with American Pride

Appliances that are high-performing,

more accessible, and more innovative than

ever—designed, built, and engineered in

the U.S.A..

A.D.A. Compliant

When properly installed, this model

is A.D.A.-qualified based on the United

States Access Board’s A.D.A./A.B.A.

Accessibility Guidelines and the

Department of Justice’s 2010 A.D.A.

Standards for Accessible Design.

Sabbath Mode (Star-K® Certiﬁed)

Available in:

1Based on single rack cooking performance, not set

temperature, using Quick Preheat.

2Select model only.

Stainless

(F)

White

(W)

Black

(B)

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web

at frigidaire.com.

Spacer

Single Electric Wall Ovens

Frigidaire Baseline

Single Wall Ovens

FGEW3065P F / W / B 30" Electric

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Product Dimensions

A - Height

B - Width

C - Depth

D - Height (Wrapper)

E - Width (Wrapper)

Depth with Door Open 90˚

29"

30"

24-3/4"

27-3/16"

28-1/4"

45-3/4"

Cutout Dimensions

Height (Min.) / (Max.)

Width (Min.) / (Max.)

Depth (Min.)

27-1/4" / 28-5/8"

28-1/2" / 29"

23-1/2"

1When properly installed, this model is A.D.A.-qualiﬁed based on the

United States Access Board’s A.D.A./A.B.A. Accessibility Guidelines and

the Department of Justice’s 2010 A.D.A. Standards for Accessible Design.

2Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC

only electrical supply with ground required on separate circuit fused on

both sides of line.

Features

Oven Control / Timing System

Window

Exterior Door Finish

Handle Design

Oven Cleaning System

Oven Controls

Bake / Broil

Eortless™ Convection Conversion

Convection Bake / Broil / Roast

Oven Preheat

My Favorite

Slow Cook

Eortless™ Temperature Probe

Chicken Nugget Button

Pizza Button

Keep Warm

Add-a-Minute

Delay Start

Self-Clean / Clean Options

Steam Clean

Delay Clean

Kitchen Timer

Timed Cook Option

Control Lock

Auto Oven Shut-O

Oven Lock-Out

Oven Features

Capacity (Cu. Ft.)

Convection System

Oven Light

Hidden Bake Element

Rack Conﬁguration

Baking System

Broiling System

Bake / Broil Element (Watts)

Optional Accessories

3"-High Bottom Trim – Stainless

Steel (F) / White (W) /Black (B)

10'-Long Armored Power Cable

Certiﬁcations

A.D.A. Compliant1

Sabbath Mode (Star-K® Certiﬁed)

Speciﬁcations

Oven Interior ( H x W x D )

Power Supply Connection Location

Voltage Rating

Connected Load (kW Rating)

@ 240 / 208 Volts2

Amps @ 240 / 208 Volts

Minimum Circuit Required (Amps)

Approved for

Under-Counter Installation

Shipping Weight (Approx.)

Express-Select®

Extra-Large

Smudge-Proof™

Stainless Steel (F),

Color-Coordinated (W/B)

Stainless Steel (F),

Color-Coordinated (W/B)

Self-Clean w/ Steam Clean

Option

Yes / Variable (400 - 550 °F)

Yes

Yes / Yes / Yes

Quick

Yes

Yes / 2, 3, 4 Hours

Yes

4.6

True Convection

2 Halogen

Yes

2 Heavy Duty, 1 Oset Rack

Even Baking Technology

Power Broil

2,000 / 3,400

(F) PN # 318259707

(W) PN # 318259703

(B) PN # 318259704

PN # 903056-9010

Yes

17-1/2" x 24-1/8" x 18-3/4"

Left Bottom Rear

240V / 208V / 60Hz

3.7 /2.8

15.4 / 13.5

Yes

146 Lbs.

Accessories information available

on the web at frigidaire.com

30" Single Electric Wall Oven

Gallery

Single Wall Ovens

FGEW3065P F / W / B 30" Electric

Single Wall Oven Specifications

• Product Shipping Weight (approx.) – 146 Lbs.

• Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz

AC only electrical supply with ground required on separate circuit

fused on both sides of line.

• Connected Load (kW Rating) @ 240 / 208 Volts = 3.7 / 2.8 kW

• Amps @ 240 / 208 Volts = 15.4 / 13.5 Amps

• Recommended Circuit Breaker – 20 Amps

• Always consult local and national electric codes.

• Minimum 21" clearance for oven door depth when open.

• Suggested distance from floor is 31". Minimum required distance

is 4-1/2".

• Minimum 23-1/2" deep cutout dimension is critical for proper

installation, to ensure that oven’s faceplate will fit flush against

cabinet front.

• To adapt oven to fit cutout height greater than 28-1/8", add one

2"-wide wood shim of appropriate height to each side of opening

under oven side rails. Lifting oven will hide larger cutout opening

at top and oven’s 1"-high bottom trim will hide shims at bottom.

(Standard 1"-High Bottom Trim included.)

• To adapt oven to fit cutout height greater than 28-5/8", optional

3"-High Bottom Trim available.

• Full oven base of solid plywood or similar material required,

capable of supporting 200 Lbs.

• Base must be level and cabinet front must be square.

• Single Wall Ovens are NOT approved to be used in stackable or

side-by-side installation.

• Single Wall Ovens are approved to be used alone in under-counter

installation or beneath any approved Frigidaire® gas or electric

cooktop. (Refer to Gas or Electric Cooktop Installation Over 30" / 27"

Electric Single Wall Oven Specifications pages on web.)

• Single Wall Ovens are approved to be used in combination with any

Frigidaire® Warmer Drawer. (Refer to model-specific Warmer Drawer

product page for Combination Installation Specifications.)

• Single Wall Ovens are approved to be used in combination with

any Frigidaire® Built-In Microwave Oven.

Note: For planning purposes only. Refer to Product Installation Guide

on the web at frigidaire.com for detailed instructions.

Optional Accessories

• 3"-High Stainless Steel Bottom Trim – (PN # 318259707).

• 3"-High White Bottom Trim – (PN # 318259703).

• 3"-High Black Bottom Trim – (PN # 318259704).

• 10'-Long Armored Power Cable – (PN # 903056-9010).

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE •frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

General Installation Guidelines

with Side-by-Side Refrigerator

Top

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Specifications

subject to change.

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Top

General Installation Guidelines

with Top Mount Refrigerator

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Top

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

General Installation Guidelines

with French Door Refrigerator

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Top

General Installation Guidelines

with All Refrigerator or All Freezer

Autres manuels pour FGEW3065PF

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Frigidaire Four

Frigidaire

Frigidaire Gallery FGEW3065K Manuel utilisateur

Frigidaire

Frigidaire GLEB27T9FBC Manuel utilisateur

Frigidaire

Frigidaire FPEW2785KF - 27" Single Electric Wall Oven Instructions d'installation

Frigidaire

Frigidaire FCWM3027AD Manuel utilisateur

Frigidaire

Frigidaire PCWS3080AF Manuel du propriétaire

Frigidaire

Frigidaire FEB702CESH Guide de démarrage rapide

Frigidaire

Frigidaire CGLES389FB5 Manuel d'utilisation et d'entretien

Frigidaire

Frigidaire FEB27T7FC - 27" Electric Double Wall Oven Manuel utilisateur

Frigidaire

Frigidaire FEB386WE Manuel utilisateur

Frigidaire

Frigidaire FEB24S2AS - 24" Electric Wall Oven Guide de l'utilisateur

Frigidaire

Frigidaire FEB30T7DCB Guide de démarrage rapide

Frigidaire

Frigidaire FGB24L2EC - 24" Gas Wall Oven Manuel utilisateur

Frigidaire

Frigidaire 318200943 Manuel utilisateur

Frigidaire

Frigidaire PLEB30S8C Manuel utilisateur

Frigidaire

Frigidaire FEB398CESA Control Manuel d'utilisation et d'entretien

Frigidaire

Frigidaire GLEB30T8D Manuel utilisateur

Frigidaire

Frigidaire FEB500CEBI Mode d’emploi

Frigidaire

Frigidaire PLCS389ECE Manuel d'utilisation et d'entretien

Frigidaire

Frigidaire GLES388ASB Control Manuel d'utilisation et d'entretien

Frigidaire

Frigidaire FEB398WECD Control Mode d’emploi

Frigidaire

Frigidaire FFEW2725LBA Manuel du propriétaire

Frigidaire

Frigidaire PLEB30T8C Manuel utilisateur

Frigidaire

Frigidaire FGB500CG Manuel utilisateur

Frigidaire

Frigidaire FEB30T7D Manuel utilisateur

Manuels Four populaires d'autres marques

Bosch

Bosch HVA531NS0 Manuel utilisateur

Electrolux

Electrolux EOF6P46X Manuel utilisateur

NEFF

NEFF B44S32 5GB Series Manuel utilisateur

Combi

Combi BLODGETT BC142GDS Manuel utilisateur

AEG

AEG COMPETENCE 311704300 Manuel utilisateur

Falcon

Falcon DOMINATOR PLUS G3106 Series Guide de l'utilisateur

Rational

Rational SCC WE 61G Manuel utilisateur

Smeg

Smeg DOSPA38X Manuel d'installation et d'exploitation

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuel utilisateur

Miele

Miele HR 1954-2 Manuel utilisateur

KHIND

KHIND OT50 Manuel utilisateur

Henny Penny

Henny Penny Smoker Box Manuel utilisateur

Lang

Lang ECOD-AP Manuel utilisateur

AEG

AEG BEK455310M Manuel utilisateur

Hotpoint

Hotpoint FE9 S831 JSH IX Manuel utilisateur

GE Advantium SCB2000 Manuel utilisateur

AEG

AEG DE401301DM Manuel utilisateur

DeLonghi

DeLonghi XA660 Manuel
