Franklin LLS-7100 Language Master Colour Manuel utilisateur

LLS-7100

User’s Guide

™

1. Getting Started 4

1.1 Charging the Battery 4

1.2 Switching On and O 6

1.3 Setting the Message Language 6

1.4 Using the Main Menu 7

1.5 Key Guide 8

1.6 Browsing in the Device 10

1.7 Product Registration 11

2. Quick Guide to Product Features 12

2.1 Dictionaries and Searching 12

2.2 Basic Features 13

2.3 Other Useful Features 14

3. BOOKS Menu 15

3.1 Using Global Search 15

3.2 Using the Dictionaries 17

3.3 Searching Idioms, Usage Examples and Collocations 20

3.4 Misspelling Words 21

3.5 Uncertain Spellings 21

3.6 Inections/Conjugations 22

3.7 Confusable Words 23

3.8 Usage Examples 23

3.9 Highlighting Words 24

3.10 Adding Words to My Word List 25

3.11 Using Visual Dictionary 26

3.12 Hints on Inputting Words 29

3.13 Viewing Downloaded Dictionaries 30

4. LEARN Menu 31

4.1 Using Langenscheidt Praxiswörterbuch 31

4.2 Phrasebook 32

4.3 Grammar Guides 34

4.4 About EuroTalk 35

4.5 Studying with EuroTalk 36

4.6 My Word List 41

4.7 Personal Dictionary 45

4.8 Search History 47

5. EXERCISES Menu 48

5.1 Creating User Names 48

5.2 Audio Dictation 49

5.3 Phrase Builder 51

5.4 Picture Card Game 53

5.5 Pronunciation Trainer 55

5.6 Reading Comprehension 58

5.7 Exercise Review 60

6. ORGANIZER Menu 61

6.1 Using the Calendar 61

6.2 Using the Calculator 64

6.3 Using the Clock 65

6.4 Using the Alarm 66

6.5 Using the Phone Book 67

6.6 Using Memo 68

6.7 Using Voice Memo 69

6.8 Metric Converter 70

6.9 Currency Converter 71

6.10 Using Countdown Timer 72

6.11 Organizer Password 73

7. ENTERTAINMENT Menu 74

7.1 Music Player 74

7.2 Video Player 76

7.3 Photo Album 78

7.4 eBooks 81

8. SETTINGS Menu 83

8.1 Display Settings 83

8.2 Volume Control 83

8.3 Language Settings 83

8.4 Power Management 84

8.5 Disk Management 84

8.6 Host Information 85

8.7 Default Settings 85

9. General Controls 86

9.1 Headphone Jack 86

9.2 USB Port 86

9.3 Inserting microSD Card 86

9.4 Adjusting Sound Volume 87

9.5 Changing Size of Screen Type 87

9.6 Help is Always at Hand 87

9.7 Resetting Your Device 87

10. PC Connections 88

10.1 Connecting to a PC 88

10.2 Using WordBytes 2.0 89

10.3 Copying Files to Your Device 90

10.4 About Your Device Folders 91

10.5 Backing Up Your Data 91

10.6 Restoring Your Data 91

11. Additional Information 92

11.1 Specications 92

11.2 Product Care 93

11.3 Recycling and Disposal 94

11.4 FCC Notice (U.S. only) 95

11.5 License Agreement (U.S.) 96

12. Warranty Information 97

12.1 Disclaimer of Warranties 97

11.2 Limited Warranty (U.S. only) 97

12.3 Limited Warranty (EU and Switzerland) 98

12.4 Limited Warranty (outside U.S., EU and Switzerland) 98

1. Getting Started

1.1 Charging the Battery

Your device is powered by a built-in rechargeable lithium polymer

battery. To charge the battery:

1. Connect the small end of a USB cable to the Mini-USB port on the

device and the wide end to the USB port of your computer.

2. Once connected, you are asked if you want to connect the device

to your computer. To charge your device only, press / to

select“No” on the pop-up menu and then press eingabe .

• Alternatively,connectthewideendoftheUSBcabletothesupplied

AC power adapter and then connect the adapter to a power outlet.

• Thebatteryiconanimatesduringchargingandstayssolidwhenthe

battery is fully charged. It generally takes a few hours to completely

charge the battery.

1.1 Charging the Battery

Battery Precautions

• Ifthedeviceisnotusedforalongperiodoftime,thebatterymay

lose its charge. Please recharge the battery following the steps

described above in order to use your device.

• Rechargeablebatteriesareonlytobechargedunderadult

supervision.

• Useonlythesuppliedchargerstorechargethebattery.Improperly

charging a battery may damage it or the device.

• Donotuseanunauthorizedbattery.

• Never open the device by yourself. For replacement of battery

please contact our technical support (www.franklin.com/eu).

Opening the device by yourself will invalidate the warranty.

• Donotattempttoopentherechargeablebatteryorbatterypack.

There are no user serviceable parts inside.

• Keepbatteriesoutofreachofsmallchildren.Ifswallowed,consulta

physician immediately.

• Leavingthebatteryinhotorcoldplaces,suchasinaclosedcarin

summer or winter conditions, will reduce the capacity and lifetime of

the battery. Always try to keep the battery between 15°C and 25°C

(59°F and 77°F). A device with a hot or cold battery may not work

temporarily, even when the battery is fully charged.

• Donotdisposeofbatteriesinareastheymayexplode.Batteries

may also explode if damaged. Dispose of batteries according to local

regulations. Do not dispose as household waste.

1.2 Switching On and O

Press to switch on or o the device.

1.3 Setting the Message Language

The rst time you use this device (or following a product reset), you will

be promoted to set the message language used for on-screen prompts

and menu items.

1. Press / to select the language you want.

• Youmayalsopresstheletterkeyforthelanguageyouwant.

2. Press eingabe .

• YoucanchangethemessagelanguageatanytimeintheSettings

menu. See 8.3 Language Settings.

1.4 Using the Main Menu

Press menü to access the main menu at any screens to quickly take you

to dierent books and exercises in your device. The main menu contains

six tabs: Books, Learn, Exercises, Organizer, Entertainment and Settings.

Use / to select a tab and then press eingabe . In the selected tab,

press / / / to select the option you want and then press

eingabe . Or press / to skip to the previous or next tab.

Options in the

current tab

Available tabs (Current

tab is highlighted)

Time, date and

battery level

1.5 Key Guide

4567

12 13 14 15 16 17

1. Turns on or o.

2. Displays help instructions.

3. Reset button

4. Soft keys – Press F1 to F6 that corresponds to the functional label at

the bottom of the screen.

5. Microphone

6. Goes to the Books, Learn, Exercises or Organizer menu.

7. Cancels the current operation and reverts back to the last working

prompt, screen or menu. Turns o selection mode in an entry.

8. Input letters and numbers.

9. Shifts to type capital letters.

10. Performs additional functions in combination with other keys.

11. Shows the symbol menu for typing a symbol.

12. Goes to the main menu.

13. Selects accent for characters.

14. Changes the size of screen type.

15. Clears all entries.

1.5 Key Guide

16. Types a space.

17. Direction keys – Moves up ( ), down ( ), left ( ) or right ( ).

18. Scrolls up or down one screen at a time.

19. At a word entry screen, types a “?” to stand for an unknown letter in

a word.

20. Enters a word, selects an item, submits a response or begins

selection mode in an entry.

21. Erases a letter.

22. Speaks a word or phrase (if pronunciation is available).

Combination Keys

More functions are available by combining keys. Key 1 + Key 2 means

hold Key 1 while also pressing Key 2.

FN + Shows the search history.

+ / Jumps to the top or bottom of entries.

FN + / Adjusts the sound volume.

+ At a word entry screen, types an asterisk (*) to stand for any

series of unknown letters or characters in a word.

FN + Goes to Global Search or a specic dictionary indicated

above the button.

BÜCHER

-F5

1.6 Browsing in the Device

Browsing in a List

Browsing in an Entry

Press / to scroll up or down

one screen at a time.

In a screen, press /

to highlight an option and

press eingabe to select the

highlighted option.

Press / to scroll up or down

one line at a time

Press / to scroll up or down

one screen at a time
