Foxconn 400M01 Series Manuel utilisateur

Chapter

Thank you for your buying Foxconn’s 400M01 series

motherboard. This series of motherboard is one of our new

products and offers superior performance, reliability and

quality, at a reasonable price. This motherboard adopts the

advanced VIA KM400/KM400A + VT8235/VT8237 chipset, pro-

viding users a computer platform with a high integration-com-

patibility-performance price ratio.

This chapter includes the following information:

Main Features

Motherboard Layout

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:511

Chapter 1 Product Introduction

2400M01 Series User Manual

Main Features

Size

mATX form factor of 9.6”x 8.5”

Microprocessor

Supports AMD socket 462 K7, DuronTM, AthlonTM, AthlonTM XP processors

Supports FSB at 200MHz/266MHz/333MHz/400MHz (400MHz only for KM400A)

Chipset

VIA chipset: KM400/KM400A (North Bridge)+VT8235/VT8237 (South Bridge)

System Memory

Two 184-pin DIMM slots

Supports PC1600/PC2100/PC2700/PC3200 memory (PC3200 only for

KM400A )

Supports 128/256/512 Mb technology up to 2GB

Onboard IDE

Supports up to 4 independent drives

Supports Ultra DMA 133/100/66/33

Two fast IDE interfaces supporting four IDE devices, including IDE hard disk

and CD-ROM/DVD-ROM drives

Onboard Serial ATA (only for VT8237)

150MB/s transfer rate

supports two S-ATA devices

Supports Raid0, Raid1 and JBOD

USB 2.0 Ports

Supports hot plug

Six USB 2.0 ports (four rear panel ports, one onboard USB header provid-

ing two extra ports)

Supports wake-up from S1 and S3 mode

Supports USB 2.0 protocol up to 480 Mbps transmission rate

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:512

Chapter 1 Product Introduction

400M01 Series User Manual

Onboard 1394 (optional)

Supports hot plug

With rate of transmission up to 400Mbps

Self-configured addressing

Can connect with 2 independent 1394 units synchronously at most, such

as HDD, CD-ROM

Onboard LAN

VIA VT6103L 10/100Mbps Ethernet PHY

LAN interface built-in on board

Onboard Graphics

Integrated VIA UniChromeTM Graphics

Onboard Audio

AC’ 97 2.1 Specification Compliant

Supports 48KHz of S/PDIF output

Onboard Line-in jack, Microphone jack, Line-out jack

Supports 5.1 channels audio (setting via software)

AGP 8X support

AGP 8X (AGP 3.0) is the VGA interface specification that enabled enhanced

graphics performance with high handwidth speeds up to 2.12 GB/s

Expansion Slots

Three PCI slots

One AGP slot

One CNR slot (optional)

BIOS

Licensed advanced AWARD (Phoenix) BIOS, supports flash ROM, plug-

and-play ready

Supports HDD, CD-ROM, SCSI HDD, LAN or USB device boot up

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:513

Chapter 1 Product Introduction

4400M01 Series User Manual

Green Function

Supports ACPI (Advanced Configuration and Power Interface)

Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4

(suspend to disk – depends on OS) and S5 (soft-off)

Advanced Features

PCI 2.2 Specification Compliant

Supports Windows 98/2000/ME/XP soft-off

Supports Wake-on-LAN, Wake-on-Modem

Supports PC Health function (capable of monitoring system voltage, CPU

temperature, system temperature and fan speed)

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:514

Chapter 1 Product Introduction

400M01 Series User Manual

Motherboard Layout

Note:

The above motherboard layout is provided for reference only;

please refer to the physical motherboard.

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:515

Chapter 1 Product Introduction

6400M01 Series User Manual

Flash Rom

This 4Mb firmware contains the programmable BIOS program.

ATX power connector

This 20-pin connector connects to an ATX power supply. The power supply

must have at least 1A on the +5V standby lead (+5VSB).

AGP slot

This Accelerated Graphics Port (AGP) slot supports 1.5V AGP 8X/4X mode

graphics cards for 3D graphical applications.

CPU socket

Socket 462 (socket A) Zero Insertion Force (ZIF) for the AMD processor,

with 200/266/333/400MHz (400MHz only for KM400A) system bus.

North Bridge controller

The VIA KM400/KM400A controller integrates a high performance host

interface for the AMD processor, a DDR memory controller, and support AGP

8X/4X technology. It also loaded with the VIA UniChromeTM 2D/3D graphics

core for efficient multimedia applications including DVD and video playback

support.

DDR DIMM sockets

These two 184-pin DIMM sockets support up to 2GB system memory

using unbuffered non-ECC PC1600/PC2100/PC2700/PC3200 (only for

KM400A) DDR DIMMs.

IDE connectors

These dual-channel bus master IDE connectors support Ultra DMA 133/

100/66/33 devices. Both the primary (blue) and secondary (white) connectors

are slotted to prevent incorrect insertion of the IDE ribbon cable.

Serial ATA connectors (only for VT8237)

These connectors support Serial ATA HDDs and allow for up to 150MB/s

data transfer rate, faster than the standard Parallel ATA with 133MB/s.

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:516

Chapter 1 Product Introduction

400M01 Series User Manual

South Bridge controller

The VIA VT8235/VT8237 integrated peripheral South Bridge controller

communicates with the North Bridge at the rates of up to 533MB/s using the

VIA 8X VLink technology. This controller supports standard UltraATA 133/

100/66/33 and provides separate data paths for each IDE channel for up to

two IDE devices. This controller also integrates SATA RAID controller (only

for VT8237), Ethernet MAC, Universal Serial Bus Host controller.

1394 controller (optional)

VT6307 is the controller for IEEE1394a on motherboard. The VT6307 is a

complete small package single chip PCI solution at 400Mbps, low power

seamless plug and play connections to the latest IEEE 1394 enabled

devices.

Floppy disk connector

This connector accommodates the provided ribbon cable for the floppy disk

drive. One side of the connector is slotted to prevent incorrect insertion of

the floppy disk cable.

PCI slots

These three 32-bit PCI 2.2 expansion slots support bus master PCI cards

like SCSI or LAN cards with 133MB/s maximum throughput.

CNR Slot (optional)

This slot is specifically designed for the Communication and Networking

Riser (CNR) card. The CNR supports V.90 analog modem only.

Super I/O controller

The VIA VT1211 I/O controller offers support for a variety of I/O function.

Provides a high-performance floppy disk controller for a 360K/720K/1.44M/

2.88M floppy disk drive, a multi-mode parallel port, one serial port and a

Flash ROM interface.

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:517

Chapter 1 Product Introduction

8400M01 Series User Manual

Audio CODEC

The VIA VT1616 provides 6-channel outputs fully supporting surround sound

applications, along with 4 stereo and 2 mono inputs. Supporting the AC’97

2.1 specification, the VIA VT1616 enables 20-bit resolution, and a variable

sampling rate with 1Hz resolution.

10/100M LAN PHY

The VT6103L is a single-port PHY transceiver with an MII (Media Independent

Interface) and supports 10/100 Mbps data transfer rate.

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:518

Chapter 2 Installation Instructions

400M01 Series User Manual

This chapter introduces the hardware installation process,

including the installation of the CPU and memory. It also

addresses the connection of your power supply, use of the

rear panel connectors, connection of hard drive and floppy

drive data cables, and setting up various other feature of the

motherboard. Caution should be exercised during the in-

stallation process. Please refer to the motherboard lay-

out prior to any installation and read the contents in this

chapter carefully.

This chapter includes the following information:

CPU

Memory

Power Supply

Rear Panel Connectors

Other Connectors

Expansion Slots

Jumpers

Chapter2

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:519

Chapter 2 Installation Instructions

10 400M01 Series User Manual

Notes:

Take note of the following precautions before you install compo-

nents or change settings.

1. Use a grounded wrist strap or touch a safely grounded object,

such as an attached power supply, before handling compo-

nents to avoid damaging them due to static electricity.

2. Unplug the power cord before opening your chassis or touching

any component.

3. Hold components by their edges to avoid touching any exposed

integrated circuits (ICs).

4. Whenever you uninstall a component, place it on a grounded

anti-static pad or into anti-static bag that it came in.

400M01-FOXCONN-V1.0-HW-en-030304.p65 2004-3-18, 13:5110
