Fluke 9040 Manuel utilisateur

PN 2438546

April 2005, Rev. 3, 11/21

All product names are trademarks of their respective companies.

9040

Phase Rotation Indicator

Users Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This Fluke product will be free from defects in material and workmanship for one year

from the date of purchase. This warranty does not cover fuses, disposable batteries,

or damage from accident, neglect, misuse, alteration, contamination, or abnormal

conditions of operation or handling. Resellers are not authorized to extend any other

warranty on Fluke’s behalf. To obtain service during the warranty period, contact your

nearest Fluke authorized service center to obtain return authorization information,

then send the product to that Service Center with a description of the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH

AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED.

FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSE-

QUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY.

Since some states or countries do not allow the exclusion or limitation of an implied

warranty or of incidental or consequential damages, this limitation of liability may not

apply to you.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

11/99

Table of Contents

Title Page

Introduction..........................................................................................................1

How to Contact Fluke..........................................................................................1

Unpacking the 9040 ............................................................................................2

Safety Information ...............................................................................................3

Symbols...............................................................................................................5

Elements of the 9040 ..........................................................................................7

Determine the Rotary Field Direction..................................................................8

Maintaining the 9040...........................................................................................9

Replacing the Fuse (9040UK only) .....................................................................10

Specifications ......................................................................................................11

Introduction

The Fluke 9040 Phase Rotation Indicator (the 9040 or the Product) is a handheld

instrument designed to detect the rotary field of three-phase systems.

How to Contact Fluke

Fluke Corporation operates worldwide. For local contact information, go to our website:

www.fluke.com

To register your product, view, print, or download the latest manual or manual supplement,

go to our website.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

+1-425-446-5500

[email protected]

9040

Users Manual

Unpacking the 9040

The 9040 is available in three configurations. Depending on your purchase, the 9040 ships

with these items:

•9040

o3 self-retaining test probes, 1000 V CAT II

o3 alligator clips, 1000 V CAT III/600 V CAT IV

oUsers Manual

•9040UK

o3 fused test probes, 1000 V CAT III

o3 alligator clips, 1000 V CAT III/600 V CAT IV

oUsers Manual

•9040EUR

o3 Slim-Reach™ test probes (black) 1000 V CAT III/600 V CAT IV

o3 self-retaining test probes, 1000 V CAT II

o3 alligator clips, 1000 V CAT III/600 V CAT IV

oUsers Manual XW Warning

To prevent possible electrical shock, fire, or personal injury, do not exceed

the Measurement Category (CAT) rating of the lowest rated individual

component of a product, probe, or accessory.

If an item is damaged or missing, contact the place of purchase immediately.

Phase Rotation Indicator

Safety Information

Caution identifies conditions and actions that may damage the 9040.

Warning identifies conditions and actions that pose hazard(s) to the user.

XW Warning

To prevent possible electrical shock, fire, or personal injury:

•Read all safety information before you use the Product.

•Carefully read all instructions.

•Use this Product indoors only.

•Use only current probes, test leads, and adapters supplied with the

Product.

•Do not use the Product above its rated frequency.

•Do not apply more than the rated voltage, between the terminals or

between each terminal and earth ground.

•Do not keep the Product in operation and unattended at high

temperatures.

9040

Users Manual

•Comply with local and national safety codes. Use personal protective

equipment (approved rubber gloves, face protection, and flame-

resistant clothes) to prevent shock and arc blast injury where

hazardous live conductors are exposed.

•Use the product only as specified, or the protection supplied by the

product can be compromised.

•Do not work alone.

•Do not use test leads if they are damaged. Examine the test leads for

damaged insulation or exposed metal. Check test lead continuity.

•Do not touch voltages >30 V ac rms, 42 V ac peak, or 60 V dc.

•Keep fingers behind the finger guards on the probes.

•Measurements can be adversely affected by impedances of additional

operating circuits connected in parallel or by transient currents.

•Verify operation prior to measuring hazardous voltages (voltages above

30 V ac rms, 42 V ac peak and 60 V dc).

•Do not use the 9040 with any of the parts removed.

•Do not use the product around explosive gas, vapor, or in damp or wet

environments.

Phase Rotation Indicator

Symbols

The following symbols appear on the 9040 or in this manual.

Table 1. Symbols

WWARNING. RISK OF DANGER. JEarth ground.

XHazardous voltage. Risk of

electric shock. TDouble Insulated.

»Consult user documentation. PConforms to requirements of

European Union.

Measurement Category II is

applicable to test and measuring

circuits connected directly to

utilization points (socket outlets

and similar points) of the low-

voltage MAINS installation.

Measurement Category III is

applicable to test and measuring

circuits connected to the distribution

part of the building’s low-voltage

MAINS installation.

9040

Users Manual

Table 1. Symbols (cont.)

Measurement Category IV is

applicable to test and measuring

circuits connected at the source

of the building’s low-voltage

MAINS installation.

This product complies with the

WEEE Directive marking

requirements. The affixed label

indicates that you must not discard

this electrical/electronic product in

domestic household waste. Product

Category: With reference to the

equipment types in the WEEE

Directive Annex I, this product is

classed as category 9 "Monitoring

and Control Instrumentation"

product. Do not dispose of this

product as unsorted municipal

waste.
