FLIR TA72 Manuel utilisateur

USERMANUAL



FLIRMODELTA72andTA74



UNIVERSALFLEXCURRENTPROBEACCESSORIES







FLIRTA72_TA74USERMANUALDocumentIdentifier:TA72_TA74en‐US_AC

TableofContents

1.DISCLAIMERS3

1.1Copyright3

1.2QualityAssurance3

1.3Documentation3

1.4DisposalofElectronicWaste3

2.SAFETY4

3.INTRODUCTION6

3.1KeyFeatures6

4.DESCRIPTIONS7

4.1MeterDescription7

4.2ControlbuttonsandIndicators8

5.OPERATION9

5.1PoweringtheMeter9

5.2WorkLights9

5.3ACCurrentMeasurements10

6.MAINTENANCE13

6.1CleaningandStorage13

6.2BatteryReplacement13

7.SPECIFICATIONS14

7.1Generalspecifications14

7.2ACCurrentElectricalspecifications15

8.TECHNICALSUPPORT16

9.WARRANTY16



1. Disclaimers

1.1Copyright

©2015‐2016,FLIRSystems,Inc.Allrightsreservedworldwide.Nopartsofthesoftwareincluding

sourcecodemaybereproduced,transmitted,transcribedortranslatedintoanylanguageor

computerlanguageinanyformorbyanymeans,electronic,magnetic,optical,manualor

otherwise,withoutthepriorwrittenpermissionofFLIRSystems.

Thedocumentationmustnot,inwholeorpart,becopied,photocopied,reproduced,translatedor

transmittedtoanyelectronicmediumormachinereadableformwithoutpriorconsent,inwriting,

fromFLIRSystems.

Namesandmarksappearingontheproductshereinareeitherregisteredtrademarksor

trademarksofFLIRSystemsand/oritssubsidiaries.Allothertrademarks,tradenamesorcompany

namesreferencedhereinareusedforidentificationonlyandarethepropertyoftheirrespective

owners.

1.2QualityAssurance

TheQualityManagementSystemunderwhichtheseproductsaredevelopedandmanufactured

hasbeencertifiedinaccordancewiththeISO9001standard.

FLIRSystemsiscommittedtoapolicyofcontinuousdevelopment;thereforewereservetheright

tomakechangesandimprovementsonanyoftheproductswithoutpriornotice.

1.3Documentation

Toaccesstheusermanuals,extendedwarrantyregistrationandnotificationsgototheDownload

tabat:http://support.flir.com.Inthedownloadareayouwillalsofindthelatestreleasesof

manualsforourotherproducts,aswellasmanualsforourhistoricalandobsoleteproducts.The

extendedwarrantypagecanalsobefoundatwww.Flir.com/testwarranty.

1.4DisposalofElectronicWaste

Aswithmostelectronicproducts,thisequipmentmustbedisposedofinan

environmentallyfriendlyway,andinaccordancewithexistingregulationsfor

electronicwaste.

PleasecontactyourFLIRSystemsrepresentativeformoredetails.



2. Safety



SafetyNotes



Beforeoperatingthedevice,youmustread,understand,andfollowallinstructions,dangers,

warnings,cautions,andnotes.

FLIRSystemsreservestherighttodiscontinuemodels,partsoraccessories,andotheritems,

ortochangespecificationsatanytimewithoutpriornotice.

Removethebatteriesifthedeviceisnotusedforanextendedperiodoftime.

WarningStatements



Toensurethesafeoperationandserviceofthemeter,followtheseinstructionsclosely.Failureto

observewarningscanresultinsevereinjury.

WARNINGSidentifyhazardousconditionsandactionsthatcouldcauseBODILYHARMorDEATH.

IndividualprotectiveequipmentshouldbeusedifHAZARDOUSLIVEpartsintheinstallation

wheremeasurementsaretobecarriedoutcouldbeaccessible.

Iftheequipmentisusedinamannernotspecifiedbythemanufacturer,theprotection

providedbytheequipmentmaybeimpaired.

Alwaysuseproperterminals,switchposition,andrangeformeasurements.

Toreducetheriskoffireorelectricshock,donotexposethisproducttorainormoisture.

Verifythemeteroperationbymeasuringaknowncurrent.Ifindoubt,havethemeter

serviced.

Donotapplymorethantheratedvoltage/currentasmarkedonthemeter.

Toavoidfalsereadingsthatcanleadtoelectricshockandinjury,replacebatteryassoonas

thelowbatteryindicatorappears.

Donotusethemeterinoraroundexplosivegasorvapor.

Donotuseaflexiblecurrentsensoriftheinnercopperwireoftheflexiblecordisvisible.

De‐energizetheinstallationundertestorwearsuitableprotectiveclothingwhenplacingor

removingtheflexiblecurrentprobefromatestsetup.

Donotapply/removetheflexiblecurrentprobeto/fromUNINSULATEDHAZARDOUSLIVE

conductorswhichmaycauseelectricshock,electricburn,orarcflash.

AgencyApprovals:

 MSIP-REI-FS5-TA74

ULlistingisnotanindicationoraverificationoftheaccuracyofthemeter

CAUTIONS



CAUTIONSidentifyconditionsandactionsthatcouldcauseDAMAGEtothemeterorequipment

undertest.Donotexposethemetertoextremesintemperatureorhighhumidity.



SafetySymbolsthataretypicallymarkedonmetersandinstructions

Thissymbol,adjacenttoanothersymbol,indicatestheusermustrefertothe

manualforfurtherinformation.

DonotapplyorremoveclampfromHAZARDOUSLIVEconductors

Equipmentprotectedbydoubleorreinforcedinsulation

Batterysymbol

ConformstoEUdirectives

Donotdiscardthisproductinhouseholdtrash.

ACmeasurement

Earthground



PERIEC1010OVERVOLTAGEINSTALLATIONCATEGORY

OVERVOLTAGECATEGORYI

EquipmentofOVERVOLTAGECATEGORYIisequipmentforconnectiontocircuitsinwhichmeasuresaretakentolimitthe

transientover‐voltagestoanappropriatelowlevel.

Note–Examplesincludeprotectedelectroniccircuits.

OVERVOLTAGECATEGORYII

EquipmentofOVERVOLTAGECATEGORYIIisenergy‐consumingequipmenttobesuppliedfromthefixedinstallation.

Note–Examplesincludehousehold,office,andlaboratoryappliances.

OVERVOLTAGECATEGORYIII

EquipmentofOVERVOLTAGECATEGORYIIIisequipmentinfixedinstallations.

Note–Examplesincludeswitchesinthefixedinstallationandsomeequipmentforindustrialusewithpermanent

connectiontothefixedinstallation.

OVERVOLTAGECATEGORYIV

EquipmentofOVERVOLTAGECATEGORYIVisforuseattheoriginoftheinstallation.

Note–Examplesincludeelectricitymetersandprimaryover‐currentprotectionequipment



3. Introduction

ThankyouforchoosingtheFLIRTA72orTA74UNIVERSALFLEXCURRENTPROBEACCESSORYthat

canmeasureupto3000AAC.AstandardDigitalMultiMeter(DMM)inVACmodecanbeusedto

displaythecurrentmeasurementwhenthecurrentprobeisconnectedtotheDMM.

TheTA74isthe18”(45.7cm)clampversionandtheTA72isthe10”(25.4cm)clampversion,

otherwisebothmetersarethesame.ThesedevicesareprofessionalCATIV600VCATIII1000V

instrumentswithhighpowerWorkLights.Thismeterisshippedfullytestedandcalibratedand,

withproperuse,willprovideyearsofreliableservice.



3.1KeyFeatures

3000AACCurrentMeasurementsdisplayedonconnectedDMM

ConvenientFlexibleClampwithlockingmechanism

0.3”(7.5mm)coildiameterformeasuringintightspaces

Suppliedbananaplugcables

Powerbutton

BatterystatusLEDindicator

CurrentACRangeselectswitch30A,300A,3000A

Batterypowered

Highpowerworklights



www.Flir.com/testwarranty



Fig.4‐1Description

4. Descriptions



4.1MeterDescription

1. FlexibleCurrentClampCoil

2. WorkLights

3. Coiltip(insertsintolockmechanism)

4. Clamplockmechanism

5. Rangeindicators

6. RANGEselectbutton

7. PowerandWorkLightsbutton

8. Testleadcableconnection

9. TestleadsconnecttoDMM

Notethatbatterycompartmentislocatedonthebackofthemeter



4.2ControlbuttonsandIndicators

Momentarypressesstepthroughtherangesmanually

Whenpowered,presstoactivate/deactivateworklights

PressandholdtoswitchpowerON/OFF

Illuminateswhenthe30Arangesisselected

Illuminateswhenthe300Arangesisselected

Illuminateswhenthe3000Arangesisselected



5. Operation

Note:Beforeoperatingthedevice,pleasereadandunderstandallWarningandCaution

statementsandfollowallinstructionsandnotes.

Note:ModelsTA72andTA74arenotdesignedforusewithVFD(VariableFrequencyDrive)

equipment,aserroneousreadingsmayresult.UsingwithVFDequipmentdoesnotposeasafety

hazardtopersonnelandwillnotdamageequipment.PleasecontactFLIRforadditional

information.



5.1PoweringtheMeter

Themeterispoweredbytwo(2)AAA1.5Vbatteries(locatedinthecompartmentonthebackof

themeter).PressandholdthePowerbuttonfor>2secondstoswitchthedeviceONorOFF.

ThemeterwillbeepasitswitchesONandoneoftheRangeindicatorlampswillbelit.Usethe

Rangebuttontoselectarangemanually.

IfthemeterdoesnotswitchONpleasecheckthebatterieslocatedintherearbattery

compartment.RefertothebatteryreplacementsectionofthisUserGuide.

5.1.1AutoPowerOFF(APO)

ThemeterswitchesOFFautomaticallyafteranapproximately10‐minuteperiodofinactivity.

SeveralsecondsbeforethemeterautomaticallyswitchesOFFthemeterbeepsseveraltimesto

alerttheuser.

TodisabletheAPOfeature,pressboththeRANGEandPOWERbuttonssimultaneously(with

themeterOFF).ThethreerangeindicatorLEDswillflashthreetimes.Tore‐enableAPO,turn

themeterOFFthenON.

Themeterre‐enablesAPOeachtimethemeterispoweredOFF.

5.2WorkLights

Withtheunitpoweredup,presstheWorkLightbutton toswitchthehighpowerWorkLights

ONorOFF.NotethatexcessiveuseoftheWorkLightswillshortenbatterylife.



V AC

Fig.5‐1ConnecttoDMM

Fig.5‐2ClampJawLock

5.3ACCurrentMeasurements

WARNING:EnsurethatpowertothedeviceundertestisOFFbeforestartingthis

procedure.SwitchpowertothedeviceundertestONonlyaftertheclamphasbeensafely

attachedtothedeviceundertest.

CAUTION:Donotmovefingersabovetherangelampsatanytimeduringatest.

Note:ModelsTA72andTA74arenotdesignedforusewithVFD(VariableFrequencyDrive)

equipment,aserroneousreadingsmayresult.UsingwithVFDequipmentdoesnotposeasafety

hazardtopersonnelandwillnotdamageequipment.PleasecontactFLIRforadditional

information.

1. SwitchOFFtheClampAdaptor,theDMM,and

thedeviceundertest.

2. ConnecttheClampAdaptortotheDMMinput

jacksusingthesuppliedbananaplugs(Fig.5‐1).

3. SwitchONtheDMMandsettheDMMtotheAC

Vmode.

4. UsetheRANGEbuttontosetthemeasurement

rangeoftheClampAdaptortotheexpected

currentrangemeasurement.

5. Turntheclamplock(1)counter‐clockwisetoreleasethe

clamp(2).SeeFig.5‐2.

6. Fullyenclosetheconductorundertestwiththeflexible

clampprobe(seeFig.5‐3).Donotmeasurecurrenthigher

thanthespecifiedcurrentlimit.
