3-Axis Stabilized Handheld Gimbal
for
Smartphone
Catalogue
1. SPG 2 Overview 1
2. Quick Start Guide 3
3. Charging 5
4. Function operation 6
Modes 6
Introduction of Display 6
Joystick - operation 7
5. Advanced Operation 11
6. Parameters 14
Manual Lock 11
Auto-rotation Mode 11
Firmware Upgrade 12
Mobile phone audio connection 12
Setting Button - operation
7
Function Button - operation
7
Bluetooth shutter operation
8
Swith Smartphone Modes
Volume adjustment 8
8
Trigger Button - operation
8
Setting Button - operation
8
Multifunction Knob - Zooming control / Follow focus / Control 3 Axis
9
App - Download and Connecting 10
Gimbal Initialization 12
Vertical Shooting 13
Audio recording with Bluetooth connection 13
www.feiyu-tech.com
26650 Li-ion Battery
X1
Micro USB cable
X1
Knob Ring
Cross Arm
Pan Axis
Vertical Arm
Smartphone Holder
Hand Grip
1/4-20 Thread Mount
Multifunction
Knob
Smartphone Holder
Roll Axis
Tilt Axis
Trigger Button
Horizontal
Adjustment
Button
1. SPG 2 Overview
01
www.feiyu-tech.com
Micro USB Port
Micro USB Port Audio Jack
Used to connect the phone to the audio input
or output of the phone.
Setting Button
ON / OFF
Accessories
Introduction of Interface and screws
3
6
8
1
3
3
4
4
2
1
1/4-20 Thread Mount
3
2
Audio Jack
Function Button
Joystick
Shutter Button
Display 1
2
3
4
1
Micro USB
Port
1
5
Vertical Arm
5
1
Pan Axis
4
1/4-20 Thread Mount
3
2
2
2
1
7
(1) Used for charging the gimbal (input 5V / 2A ), the gimbal
can be used while being charged, but it is not available for
external power supply.
(2) Used for firmware upgrade (computer), please refer to
the firmware upgrade operation steps for details.
Please stuff up this port by the dustproof plug when it is not in use.
Used for expanding other accessories, such as
the tripod which built-in 1/4 inch screw,extension
rod and so on.
Tripod
X1
Display
Introduction of Display and Buttons
Introduction of Axis and Knob
1
Joystick
2
Tilt Axis
Take the Smartphone lens as the base point, and control the
smartphone lens to move upward or downward by tilt axis.
1
4
Roll axis
Take the smartphone lens as the base point, and control
the smartphone lens to tilt to the left or tilt to the right by
roll axis.
2
3
Pan axis
Pan Axis
Take the smartphone lens as the base point, and control
the smartphone lens to turn left or turn right by pan axis.
Used for fixing the cross arm.
Knob Ring
Introduction of Other Components
Cross arm
Used for adjusting the up and down centre-of-gravity
position of smartphone.
Used for fixing the Smartphone.
1
Smartphone holder
2
Vertical arm
Used for connecting the rolling axis and the panning
axis.
Used for holding the gimbal by one hand.
3
Hand grip
4
Function Button
3Shutter Button
4
Setting Button
5Horizontal Adjustment Button
6
Multifunction Knob
8
Up
Left Right
Down
Double tap Follow Mode
Quadruple tap Auto-rotation Mode
Five tap Initialization
Refer to Page 7
Refer to Page 8
(Connect to the mobile phone APP
for use) Refer to Page8
Refer to Page 7
Refer to Page 9
Triple tap All Follow Mode
Panning Mode / Lock Mode Single tap
After the gimbal is connected to the mobile phone
through Feiyu ON App, single tap the shutter button
to control the phone to take photos, and double
tap it to switch between the front and the rear lens
of the camera, press and hold to control the video
recording.
Please refer to the chapter "App - Download and
Connecting" in page 10
Please refer to the chapter "App - Download and
Connecting" in page 10
Single tap Click on the main interface to switch to
the phone shooting mode
You can control the horizon angle via the horizontal
adjustment button.
Switch the volume interface/Click to exit
Long press
(1) Achieve the control to the focal length of
Smartphone, such as follow focus, zoom.
(2) Control the axial angle of the gimbal
Trigger Button
7Refer to Page 9
Double tap Reset
Fast follow modePress and hold
02
www.feiyu-tech.com
Main interface of
the display screen
Shooting
mode
Audio connection
App connection
Bluetooth Modes
Battery Level
Power on / Power offLong press
2. Quick Start Guide
Remove the bottom cap, insert a 26650
battery and then tighten the cap.
Type 26650
5000mAhBattery Capacity
Install Battery
1
Balance the Gimbal
3
Put the Smartphone on
2
03
www.feiyu-tech.com
Place smartphone in holder so that the phone
is snug against the back of the holder.
It’s recommended to remove your smartphone protective case.
If the phone tilts to left side
(1) loose the knob ring and slide the
cross arm to opposite side
(2) After sliding right to find perfect
balance status
(3) Tighten the knob ring
If the phone tilts to right side
(1) loose the knob ring and slide the
cross arm to opposite side
(2) After sliding left to find perfect
balance status
(3) Tighten the knob ring
Best balance
Cross Arm
knob ring
knob ring
Cross Arm
Set the horizontal shooting/ vertical shooting of mobile phone
4
Power on / off
5
04
www.feiyu-tech.com
Pull the mobile phone fixture to switch between horizontal and vertical shooting, as shown in
below picture:
90°
90°
90°
90°
(1) Please mount the smartphone before powering on the gimbal.
(2) When the battery is low, please charge the gimbal.
(3) When not in use, turn off the gimbal and then remove the battery.
NOTE
Power on / off:Long press the function button, the display will show and release it when
you hear the beep tone.
Support clockwise / counterclockwise rotation
05
www.feiyu-tech.com
3. Charging
*Please fully charge the battery before power on the gimbal for the first time.
Micro USB Port
Micro Port USB Port
Micro USB
Cable
Charging with Micro USB cable as shown below.
(Equipped by user)
Output: 5V / 2A
Charging the Gimbal
Use the mobile phone transfer charging cable (self-provided) to charge the mobile phone, and
select the corresponding charging adapter cable according to the charging port of the mobile
phone.
Charging connection diagram
of the mobile phone
Charging connection diagram
of the mobile phone
Charging the Smartphone
Corresponding
charging interface of
the mobile phone
Transfer charging cable
of the mobile phone
(self-provided)
Micro USB
charging interface
Transfer charging cable
of the mobile phone
(self-provided)
Micro USB Port
Tilt Axis
Cross Arm
06
www.feiyu-tech.com
4. Operation
The roll and tilt direction are fixed, and the smartphone moves according to the left-right movements of the
user's hand.
The smartphone moves according to the user's hand.
The roll direction is fixed, and the smartphone moves according to the left-right movements, up-down
movements of the user's hand.
Panning Mode（Default mode）
Follow Mode
Return to panning mode, three axises return to default position.
Reset
The orientation of the camera is fixed.
Lock Mode
All Follow Mode
Modes
Display icon Display iconMode / Status Mode / Status
HF
TF
AF
Panning Mode
All follow mode
Follow Mode
Lock Mode
LK
Bluetooth1 is connected
Bluetooth2 is connected
Bluetooth1 is connected
Bluetooth2 is not connected
Bluetooth1 is not connected
Bluetooth2 is connected
Introduction of Display
Bluetooth1 is not connected
Bluetooth2 is not connected
① Bluetooth 1 is used for connecting the mobile phone with the gimbal via audio; please refer to the “Mobile Phone Audio Connection”
section on page 12.
② Bluetooth 2 is used for connecting the mobile phone with the gimbal via APP; please refer to the “App Downloading and Connection”
section on page 10.
Battery Level
Charging
Video mode
Panorama mode
Fast motion mode
Slow motion mode
①
②
①
②
①
②
①
②
Panning Mode Default Follow Mode All Follow Mode Lock Mode
07
www.feiyu-tech.com
Joystick
- operation
Joystick
Please refer to the chapter "Gimbal Initialization" in page 12
五连击 初始化
Function Button - operation
Note：Functions in practice may differ from what is described in the manual in hand due to firmware upgrade. Please refer to the
latest version of manual which could be found on official website.
Please refer to the chapter "Auto-rotation Mode" in page 11
Enter auto-rotation mode
Enter all follow mode
Enter initialization
Panning Mode / Lock Mode/
Check the battery level
Double tap Follow mode
Triple tap All Follow Mode
Quadruple tap Auto-rotation Mode
Initialization
Single tap to switch between panning mode
and lock mode
Single tap to check the battery level during charging
Under the follow mode, single tap to switch to
panning mode
Function
Button
Five tap
Shutter Button-operation
Please refer to the chapter "App - Download and Connecting" in page 10
Shooting
Shutter
Button
Switch between the front and
the rear lens of the camera
Start shooting / Stop shooting
Up
Left Right
Down
Upward
（1）Lens upward
（2）Increase the volume
Downward
Move to right
（1）Lens move to right
Move to left
（1）Lens move to left
（1）Lens downward
（2）Decrease the volume
Single tap
When SPG 2 is connected to the mobile phone via Feiyu ON App, single tap
the shutter button to control the phone to take photos, double tap it to
switch between the front and the rear lens of the camera, press and hold
it to control the video recording.
Single tap
Long press
Double tap
08
www.feiyu-tech.com
Setting
Button
Setting Button - operation
When SPG 2 is connected to the mobile phone via Feiyu ON App, the setting button can switch
the phone shooting mode, and the phone volume can be adjusted after connecting to the phone
audio Bluetooth.
Please refer to the chapter "App - Download and Connecting" in page 10
Single tap the setting button to switch the phone shooting mode
Swith Camera Modes
Video mode
Panorama mode
Fast motion
Slow motion
Shooting mode
Main interface of
the display screen
Single tap
Setting
Horizontal Adjustment Button - operation
You can control the horizon angle via the horizontal adjustment button.
Press and hold the setting button to switch between the main interface and the volume interface.
You can adjust the volume by moving the four-directional joystick up/down (this operation
requires connecting to the mobile phone audio Bluetooth)
Adjust volume
Volume interface
Volume
“+”
Volume “-”
Main interface of
the display screen
Long press
Setting Button
Push to the right
Horizontal
Adjustment
Button
Horizontal
Adjustment
Button
Push to the left
Table des matières
Autres manuels FeiYu Tech Accessoires pour appareils photo
FeiYu Tech
FeiYu Tech AK4500 Guide d'installation
FeiYu Tech
FeiYu Tech Vimble 2A Guide d'installation
FeiYu Tech
FeiYu Tech G6 Max Manuel utilisateur
FeiYu Tech
FeiYu Tech SCORP 2 Manuel utilisateur
FeiYu Tech
FeiYu Tech Double-hand foldable set Manuel utilisateur
FeiYu Tech
FeiYu Tech Vimble 2A Manuel utilisateur
FeiYu Tech
FeiYu Tech VIMBLE 3 Manuel utilisateur
FeiYu Tech
FeiYu Tech WG2 Manuel utilisateur
FeiYu Tech
FeiYu Tech VLOG Pocket Manuel utilisateur
FeiYu Tech
FeiYu Tech G6 Manuel utilisateur
FeiYu Tech
FeiYu Tech VIMBLE3 Manuel utilisateur
FeiYu Tech
FeiYu Tech vimble 2 Manuel utilisateur
FeiYu Tech
FeiYu Tech G4 Manuel utilisateur
FeiYu Tech
FeiYu Tech QING Manuel utilisateur
FeiYu Tech
FeiYu Tech Feiyu-WCP2 Manuel utilisateur
FeiYu Tech
FeiYu Tech G6 Plus Manuel utilisateur
FeiYu Tech
FeiYu Tech G3Ultra Manuel utilisateur
FeiYu Tech
FeiYu Tech G3 Steadycam Manuel utilisateur
FeiYu Tech
FeiYu Tech AK4500 Guide d'installation
FeiYu Tech
FeiYu Tech FY-G3 Ultra Manuel utilisateur
