Fein WSG 11 R Guide de configuration

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

Repair instructions

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 1of 55

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

Contents

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 2of 55

1. Models described

2. Technical data

3. Notes and requirements

4. Tools required

5. Lubricants and auxiliary substances required

6. Removal

7. Fitting

8. Connection diagram

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

1. Models described

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 3of 55

These repair instructions describe how to repair the following models:

Model Order number

WSG 11-125R 7 221 86 .. .. .

WSG 11-125RT 7 221 87 .. .. .

WSG 11-150R 7 221 88 .. .. .

WSG 11-150RT 7 221 89 .. .. .

WSG 15-125PR 7 221 90 .. .. .

WSG 15-125PRT 7 221 91 .. .. .

WSG 15-150PR 7 221 92 .. .. .

WSG 15-150PRT 7 221 93 .. .. .

WSG 15-70InoxR 7 221 94 .. .. .

WSG 15-70InoxRT 7 221 95 .. .. .

WSG 17-125R 7 222 14 .. .. .

WSG 17-125RT 7 222 15 .. .. .

WSG 17-150R 7 222 16 .. .. .

WSG 17-150RT 7 222 17 .. .. .

WSG 17-125PR 7 222 18 .. .. .

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

1. Models described

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 4of 55

Model Order number

WSG 17-125PRT 7 222 19 .. .. .

WSG 17-150PR 7 222 20 .. .. .

WSG 17-150PRT 7 222 21 .. .. .

WSG 17-70InoxR 7 222 22 .. .. .

WSG 17-70InoxRT 7 222 30 .. .. .

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

2. Technical data

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 5of 55

Technical data

All the technical data can be found in the operating instructions for the model.

Test data

Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service →Repair Guides).

Lubricants

The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service →Repair Guides).

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

3. Notes and requirements

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 6of 55

Please note

These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and

electrical training.

Only use original FEIN spare parts.

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in

serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when

commissioning.

The German Equipment and Product Safety Act [ProdSG] applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed.

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

4. Tools required

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 7of 55

Standard tools

Special tools

Plastic hammer Drawing-off socket cap 6 41 04 150 00 8

Cross-tip screwdriver PH2 Chuck cone 19 mm 6 41 07 019 00 7

Torx screwdriver T15; T20 Chuck cone 26 mm 6 41 07 026 00 0

Punch Drawing-off plate 6 41 02 069 00 7

Arbor press Pipe 6 41 01 002 00 4

Ball bearing support 19 mm; 26 mm Assembly aid 6 41 22 121 01 0

Sleeves •35 mm inner diameter

•14 mm inner diameter

19 mm outer diameter

•30 mm inner diameter

42 mm outer diameter

•15 mm inner diameter

20 mm outer diameter

•15 mm inner diameter

27 mm outer diameter

•26 mm inner diameter

40 mm outer diameter

Pressure piece 6 41 22 003 00 0

4x round material Diameter 20 mm; length = 60 mm

Long-nosed pliers

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

5. Lubricants and auxiliary substances required

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 8of 55

Lubricants

WSG 11-125R; WSG11-125RT; WSG15-125PR; WSG15-125PRT;

Grease 0 40 101 01 00 4 21 g Gearbox

WSG11-150R; WSG11-150RT; WSG15-150PR; WSG15-150PRT; WSG15-70InoxR; WSG15-70InoxRT

Grease 0 40 101 01 00 4 29 g Gearbox

Auxiliary substances

Loctite 573 Washer

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

6. Removal

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 9of 55

Removing the handle

1. Unscrew the six screws (1) and remove the handle half shell (2). Tools:

- Torx T15

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT

6. Removal

C-SC_CSSM

Version 1.0

2015-07-20

FEIN retains all rights of disposal, such as copying and circulation.

Page 10 of 55

Removing the handle

1. Unscrew the screw (1).

2. Remove the cable clamping piece (2).

3. Remove the terminals (3).

4. Open the terminals (4) and remove the cables.

5. Remove the switch (5).

6. Loosen the screws (6) on the switch and remove the cables.

7. Remove the handle half shell (7).

Tools:

- Torx T15

- PH2 cross-tip

screwdriver
