Fein WSG 7-100 Guide de configuration

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

Repair instructions

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 1of 45

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

Contents

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 2of 45

1. Models described

2. Technical data

3. Notes and requirements

4. Tools required

5. Lubricants and auxiliary substances required

6. Removal

7. Fitting

8. Connection diagram

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

1. Models described

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 3of 45

These repair instructions describe how to repair the following models:

Model Order number

WSG 7-100 7 221 96 .. .. .

WSG 7-115 7 221 97 .. .. .

WSG 7-115 (A) 7 221 98 .. .. .

WSG 7 115 PT 7 222 31 .. .. .

WSG 7-125 7 222 65 .. .. .

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

2. Technical data

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 4of 45

Technical data

All the technical data can be found in the operating instructions for the model.

Tests

Up-to-date test data and test instructions after repair can be found on the FEIN Extranet (Customer Service → Repair Guides).

Lubricants / Auxiliary substances

The lubricants or auxiliary substances and their container sizes available from FEIN can be found on the FEIN Extranet

(Customer Service → Repair Guides).

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

3. Notes and requirements

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 5of 45

Please note

These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and

electrical training.

Only use original FEIN spare parts!

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in

serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when

commissioning.

The German Equipment and Product Safety Act [ProdSG] applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed!

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

4. Tools required

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 6of 45

Standard tools

Special tools

PH2 cross-tip screwdriver Drawing-off socket cap 6 41 04 150 00 8

Flat-nose pliers Chuck cone 19 mm 6 41 07 019 00 7

Slotted screwdriver Assembly aid 6 41 22 121 01 0

Plastic hammer Pressure piece 6 41 22 128 00 0

Hot air gun

Socket wrench

Socket wrench insert 10 mm

Punch Dia. 9 mm; dia. 17 mm

2x flat material 2 mm

Arbor press

Puller 6-10 mm

Sleeves

•55 mm inner diameter

65 mm outer diameter

•45 mm inner diameter

62 mm outer diameter

•32 mm inner diameter

40 mm outer diameter

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

4. Tools required

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 7of 45

Standard tools

Sleeves

•22 mm inner diameter

33 mm outer diameter

•17 mm inner diameter

33 mm outer diameter

•9 mm inner diameter

22 mm outer diameter

•12 mm inner diameter

22 mm outer diameter

•16 mm inner diameter

30 mm outer diameter

Bolt

Dia. 18 mm

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

5. Lubricants and auxiliary substances required

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 8of 45

Lubricants

Grease 0 40 12 901 00 0 10 g Gearbox housing

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

6. Removal

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 9of 45

Removing the cover

1. Unscrew the screw (1).

2. Pull off the cover.

Tools:

- PH2 cross-tip

screwdriver

WSG 7-100; WSG 7-115; WSG 7-115 (A); WSG 7-115 PT; WSG 7-125

6. Removal

C-SC_CSSM

Version 1.0

2019-07-05

FEIN retains all rights of disposal, such as copying and circulation.

Page 10 of 45

Removing the cover [applies to: WSG 7-115 PT]

1. Unscrew the two screws (1).

2. Remove the cover (2).

3. Remove the control rod (3).

4. Remove the cover (4).

Tools:

- PH2 cross-tip

screwdriver
