Fein GSZ8-280P Guide de configuration

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

Repair instructions

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 1of 53

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

Contents

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 2of 53

1. Models described

2. Technical data

3. Notes and requirements

4. Tools required

5. Lubricants and auxiliary substances required

6. Removal

7. Fitting

8. Connection diagram

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

1. Models described

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 3of 53

These repair instructions describe how to repair the following models:

Model Order number

GSZ 8-280P 7 223 16 .. .. .

GSZ 8-280PE 7 223 17 .. .. .

GSZ 8-280PL 7 223 18 .. .. .

GSZ 8-280PEL 7 223 19 .. .. .

GSZ 8-90PEL 7 223 20 .. .. .

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

2. Technical data

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 4of 53

Technical data

All the technical data can be found in the operating instructions for the model.

Tests

Up-to-date test data and test instructions after repair can be found on the FEIN Extranet (Customer Service → Repair Guides).

Lubricants / Auxiliary substances

The lubricants or auxiliary substances and their container sizes available from FEIN can be found on the FEIN Extranet

(Customer Service → Repair Guides).

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

3. Notes and requirements

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 5of 53

Please note

These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and

electrical training.

Only use original FEIN spare parts.

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in

serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when

commissioning.

The German Equipment and Product Safety Act [ProdSG] applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed.

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

4. Tools required

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 6of 53

Standard tools

Special tools

Plastic hammer Drawing-off socket cap 6 41 04 150 00 8

Slotted screwdriver Chuck cone 19 mm 6 41 07 019 00 7

Slotted screwdriver (small) Assembly aid 6 41 22 121 01 0

Torx T15 Pressure piece 6 41 22 003 00 0

Punch 5 mm

Arbor press

Long-nosed pliers

4x round material Diameter 20 mm; length =

60 mm

Vice

Open-ended spanner 13 mm; 17 mm; 30 mm

Circlip pliers

Socket head wrenches 3 mm

Inner puller

Slide hammer

Flat material 45 mm x 20 mm x 5 mm

Arbor 13 mm diameter

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

4. Tools required

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 7of 53

Standard tools

Sleeve 20 mm inner diameter

32 mm outer diameter

21 mm inner diameter

26 mm outer diameter

16 mm inner diameter

31 mm outer diameter

11 mm inner diameter

16 mm outer diameter

10 mm inner diameter

25 mm outer diameter

8 mm inner diameter

19 mm outer diameter

8 mm inner diameter

12 mm outer diameter

80 mm inner diameter

90 mm outer diameter

20 mm inner diameter

26 mm outer diameter

9 mm inner diameter

21 mm outer diameter

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

5. Lubricants and auxiliary substances required

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 8of 53

Lubricants

GSZ 8-280PL, GSZ 8-280PEL

Oil (acid-free) Felt ring

GSZ 8-280P, GSZ 8-280PE, GSZ 8-280PL, GSZ 8-280PEL

These machines do not require any grease.

GSZ 8-90PEL

Grease 0 40 101 01 00 4 13 g Gearbox

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

6. Removal

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 9of 53

Removing the cover

1. Unscrew the two screws (1).

2. Remove the lower part of the cover (2). Tools:

- Torx T15

GSZ 8-280P; GSZ 8-280PE; GSZ 8-280PL; GSZ 8-280PEL; GSZ 8-90PEL

6. Removal

C-SC_CSSM

Version 1.0

2015-12-09

FEIN retains all rights of disposal, such as copying and circulation.

Page 10 of 53

Replacing the mains cable

1. Unscrew the screw (1).

2. Remove the cable clamp (2).

3. Pull off the cover (3).

4. Slide the assembly aid into the opening (4).

5. Turn the assembly aid and take out the cable (5).

6. Take out the cable (6).

7. Remove the cable with plug (7).

Tools:

- Torx T15

- Assembly aid
