User's Guide

Pinless Moisture/Humidity Meter with

Memory + IR Thermometer

Model MO295

STORE

MEM

RH%

MO295

GPP

mBAR

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

MO295-EU-EN-1.5 4/13

Introduction

Congratulations on your purchase of the Extech MO295 Pinless Moisture Meter with Patented Built-in

IR Thermometer and 20 Point Memory. Monitor moisture in wood and other building materials with no

surface damage with the Pinless Moisture sensor (Pin-type Moisture Probe included). Measure

Humidity and Air Temperature with built-in probe plus non-contact InfraRed Temperature with patented

IR design. Advanced functions provide Grains per Pound, Dew Point and Vapor Pressure calculations.

This meter is shipped fully tested and calibrated and, with proper use, will provide years of reliable

service.

Meter Description

1. IR temperature sensor

2. Laser pointer

3. Humidity sensor

4. Temperature sensor

5. LCD display

6. Relative Humidity button

7. Mode/Zero Button

8. IR thermometer button

9. Alarm set button

10. Alarm adjust down button

11. ON/OFF power button

12. Remote pin probe input jack (bottom)

13. Battery compartment (rear)

14. Alarm adjust up button

15. Moisture/Relative button

16. Protective cap

LCD Display

1. MIN MAX – Minimum and maximum value

2. HIGH LOW – Alarm limits

3. INT EXT – Internal/External probe

4. mBar – Vapor pressure

5. kPa – Vapor pressure

6. GPP – Grains per Pound

7. g/kg – Grains per kilogram

8. MOIST – Moisture mode

9. RH% - Relative Humidity mode

10. COND – Condensation mode

11. APO – Auto power off

12. DEW – Dew Point temperature

13. C/F – Temperature units

14. - Low battery

15. MEM - Memory location indicator

16. - Laser pointer On

REL

123

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

MO295-EU-EN-1.5 4/13

Safety

Use extreme caution when the laser pointer beam is on

Do not point the beam toward anyone's eye or allow the beam to

strike the eye from a reflective surface

Do not use the laser near explosive gases or in other potentially

explosive areas

Features

Quickly indicates the moisture content of materials with Pinless technology without damaging

the surface;

Optional remote Pin-type probe (MO290-P) allows for moisture readings at different

penetration levels (3ft/0.9m cable length);

Easy to read, large dual display with backlit feature;

Simultaneously displays % moisture of wood or material being tested and Air Temperature, IR

Temperature, or Humidity

Designed with patented IR design to measure non-contact surface temperature; 8:1 distance to

spot ratio with 0.95 fixed emissivity

Built-in Humidity/Temperature probe measures Relative Humidity,

Air Temperature plus Grains Per Pound (GPP) and Dew Point (DP)

Ambient and Surface Vapor Pressure

Automatic calculation of differential Temperature (IR - DP)

Min/Max and Data Hold

20 point internal memory

Auto power off and low battery indication

Battery Replacement

1. Turn off the meter.

2. Remove one Philips head screw and lift off the rear battery cover.

3. Replace the 9V battery.

4. Secure the rear battery cover.

You, as the end user, are legally bound (EU Battery ordinance) to return all used

batteries, disposal in the household garbage is prohibited! You can hand over your

used batteries / accumulators at collection points in your community or wherever batteries

/ accumulators are sold!

Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the

end of its lifecycle

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

MO295-EU-EN-1.5 4/13

Operation

Powering the meter

1. Remove the RH sensor protective cap before use.

2. Press the power button to turn the meter on.

3. If the symbol appears or the meter does not turn on, replace the battery.

Humidity (Dew point, GPP, g/kg) Measurements

1. Press the power button to turn the meter on.

2. Press the RH button

3. Relative Humidity will be displayed in the primary display and the temperature will be displayed

in the secondary display.

4. Press the up or down arrow button to change the temperature units.

5. Press the MODE button to display the DEW point.

6. Press the MODE button to display GPP (°F) or g/kg (°C). Press the ▲or ▼button to

toggle between GPP or g/kg.

Pinless Moisture Measurements

1. Press the power button to turn the meter on.

2. Press the MOIST button to select Moisture measurement.” MOIST”, and “INT” (internal pinless

sensor) will appear in the display.

3. Hold the meter so that the rear sensor is away from any surface or your hand. The reading

should be near 0.0. If not, press and hold the ZERO button for more than 2 second and the

ZERO icon appears.

4. Place the rear sensor on the surface of the material to be tested and read the relative moisture

content.

Pin Type Moisture Measurements

1. Connect the external pin probe to the jack on the bottom of the meter.

2. Press the power button to turn the meter on.

3. Press the MOIST button twice to select Moisture measurement.” MOIST”, and “EXT” (external

pin probe) will appear in the display.

4. Press the probe pins into the material and read the % moisture content in the display.

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

MO295-EU-EN-1.5 4/13

Infrared Temperature Measurements

1. Press the power button to turn the meter on.

2. Press the IRT button to enable the IR thermometer and the laser pointer. The laser pointer icon

will flash while the mode is active.

3. Press the ▲or ▼button to change the temperature units

4. Aim the laser pointer at the surface to be measured and read the surface temperature in the

secondary display.

5. Release the IRT button. The last temperature measured and the laser icon will remain on the

display for approximately 10 seconds before returning to ambient temperature measurement.

IRT MAX MIN display:

The meter can be set to display only the maximum or minimum temperature measured during an IR

scan.

1. With the meter in the IR hold mode, press the MODE button. “MIN” will appear in the

display.

2. Press the IRT button to enable the IR thermometer. The meter will display the minimum

temperature measured and will update only when a lower temperature is measured.

3. Press the MODE button twice to enable the MAX mode and proceed as stated above for the

maximum temperature.

4. The MAX or MIN temperature is not stored when the function is exited. The unit

automatically exits MAX/MIN mode after approximately 10 seconds.

IR Field of View

Ensure that the desired target is larger than the spot size. As the distance from an object increases,

the spot size of the area measured by the meter becomes larger. The meter’s field of view ratio is

8:1, meaning that if the meter is 8 inches (cm) from the target, the diameter (spot) of the object

under test must be at least 1 inch (cm). Refer below to the field of view diagram.

WARNING: Do not directly view or direct the laser pointer at an eye. Low power visible lasers

do not normally present a hazard, but may present some potential for hazard if viewed directly for

extended periods of time.

1” @ 8”

2” @ 16”

20mm @ 160mm

40mm @ 320mm

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

MO295-EU-EN-1.5 4/13

Condensation Mode

The Condensation feature alerts the user when the surface temperature as measured by the IR

thermometer is close to or has reached the Dew Point temperature.

1. Press the power button to turn the meter on.

2. Simultaneously press the MOIST and RH buttons. The “COND” icon will appear.

3. Point the meter at a surface, press the IRT button to measure the surface temperature. The

small display will indicate the IR surface temperature and the large display will indicate the

difference between the IR temperature and the Dew Point temperature.

4. The meter will then report the potential for condensation on that surface in the following

manner

If the temperature of the IRT is more than 14°C (25°F) above the Dew Point, the

temperature difference shall be displayed, with no other warning.

If the temperature of the IRT is 3-14°C (5-25°F) above the Dew Point, the temperature

difference shall be displayed, along with a standard Condensation Indicator icon. The meter

shall beep once to confirm that the reading is in the risk area.

If the temperature of the IRT is less than 3°C (5°F) above the Dew Point, the temperature

difference shall be displayed, along with a flashing Condensation Indicator icon. The meter

shall beep twice to confirm that the reading is in the high-risk area.

5. Press the RH button to exit the mode.

Vapor Pressure Mode

Ambient Vapor Pressure

1. With the Condensation mode active, press the MODE button to display the Vapor Pressure in

mBAR (°F) or kPa (°C). Press the ▲or ▼button to toggle between mBAR or kPa.

2. Press the MODE button to exit the Vapor Pressure mode.

Surface Vapor Pressure

1. Enter the Vapor Pressure mode as described above.

2. Press the IRT button and aim the laser pointer at the surface to be measured to display the

Surface Vapor Pressure in mBAR (°F) or kPa (°C).

Alarm High and Low Limit Setting

High and Low alarm points can be set for Humidity and Moisture measurements.

Humidity Alarm Set Procedure:

1. With RH% displayed, simultaneously press the RH and MODE buttons.

2. The “HIGH” icon will appear on the display.

3. Press the ▲or ▼button to set the high limit desired.

4. Press the STORE/ALARM SET button to save the value and proceed to the LOW set value.

5. With the “LOW” icon in the display, Press the ▲or ▼button to set the low limit desired.

6. Press the STORE/ALARM SET button to save the value and to return to the normal mode.

7. If the humidity measurement is lower than the low alarm setting or higher than the high alarm

setting, the meter will beep once every second.

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

MO295-EU-EN-1.5 4/13

Moisture Alarm Set Procedure:

1. With MOIST displayed, simultaneously press the MOIST and MODE buttons.

2. The “HIGH” icon will appear on the display.

3. Press the ▲or ▼button to set the high limit desired.

4. Press the STORE/ALARM SET button to save the value and proceed to the LOW set value.

5. With the “LOW” icon in the display, Press the ▲or ▼button to set the low limit desired.

6. Press the STORE/ALARM SET button to save the value and to return to the normal mode.

7. If the moisture measurement is higher than the LOW alarm setting, the meter will beep once

every second

8. If the moisture measurement is higher than the HIGH alarm setting, the meter will beep

continuously.

Memory Mode

Saving Readings:

1. With the meter in the desired measurement mode, press the STORE button for 2 seconds until

the unit beeps to save a reading into the internal memory. The numeric display above the MEM

icon will indicate the memory location the reading is stored to.

2. When the 20 memory locations are full, the unit will overwrite old saved readings starting with

memory location 01.

Recalling Stored Readings:

1. Press the ▲and ▼buttons simultaneously to display stored readings. The numeric display

above the MEM icon will flash.

2. Use the ▲or ▼button to scroll through the memory locations.

3. To return to normal operating mode, press the STORE button.

Clearing Stored Data:

1. To clear stored data, press and hold the ▲and STORE buttons simultaneously until CLR

appears on the display.

Auto Power Off

The meter will enter a sleep mode after 30 minutes of inactivity. The meter will emit a warning beep 15

seconds before shutting down.

To disable the APO feature, press the MODE button when turning the meter ON. The “APO” icon will

not appear, indicating it is disabled.

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

MO295-EU-EN-1.5 4/13

Specifications

Function Range Accuracy

Pinless Moisture 0 to 99.9 Relative only

External - Moisture in

wood 6-99 % ± 5%

External - Moisture in

building materials 13-99 % ± 5%

Pinless Depth Up to 0.75” (19mm)

0 to 10% ± 3%RH

11 to 90% ± 2.5%RH

RH Measurement

91 to 100% ± 3%RH

Air Temperature -20 to 170°F (-29 to 77°C) 3.6F (2.0C)

IR Temp -4 to 31F 9F

32°F ± 2°F

33 to 392F Greater of 3.5% or 9F

-20 to-1C 4.5C

0C 1C

1 to 200C Greater of ±3.5% or ± 4.5°C

Display 3-digit primary display, 4-digit secondary display

Vapor Pressure 0 to 20.0kPA, calculated from temperature and RH measurements

Dew Point -30 to 100°C (-22 to 199°F)

Mixing Ratio 0 to 160g/kg (0-999GPP)

Sample Rate 2 per second

Backlight White LED

Memory 20 point memory

Operating Temperature 4 to 43°C (40 to 110°F)

Storage Temperature -30 to 60°C (-14 to 140°F)

Operating Humidity 90%, 0-30°C (32-86°F), 75%, 30-40°C (86-104°F),

45%, 40-50°C (104-122°F)

Storage Humidity 90%

Power Supply 9V battery

Battery Life 6-8 weeks (4 hrs/day use), using alkaline batteries

Auto Power Off (APO) After 30 minutes (nominal) inactivity. The APO function can be disabled

by the user.

APO Quiescent Current 50µA maximum

Dimensions 165x70x38mm (6.5x2.8x1.5’)

Weight 210g (7.4oz)

Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform

ISO‐9001Certified

www.extech.com

Shop for Extech products at: 1.877.766.5412

ShopExtech.com

Table des matières

Autres manuels Extech Instruments Thermomètre

Extech Instruments

Extech Instruments EA25 Manuel utilisateur

Extech Instruments

Extech Instruments EzSmart RHT3 Manuel utilisateur

Extech Instruments

Extech Instruments 42529 Manuel utilisateur

Extech Instruments

Extech Instruments 42509 Manuel utilisateur

Extech Instruments

Extech Instruments RHT510 Manuel utilisateur

Extech Instruments

Extech Instruments RH200W-T Manuel utilisateur

Extech Instruments

Extech Instruments 42500 Manuel utilisateur

Extech Instruments

Extech Instruments TM200 Manuel utilisateur

Extech Instruments

Extech Instruments EzSmart RHT3 Manuel utilisateur

Extech Instruments

Extech Instruments 421508 Manuel utilisateur

Extech Instruments

Extech Instruments AN500 Manuel utilisateur

Extech Instruments

Extech Instruments EA15 Manuel utilisateur

Extech Instruments

Extech Instruments SDL200-NIST Manuel utilisateur

Extech Instruments

Extech Instruments 421504 Manuel utilisateur

Extech Instruments

Extech Instruments IR100 Manuel utilisateur

Extech Instruments

Extech Instruments VIR50-NISTL Manuel utilisateur

Extech Instruments

Extech Instruments EasyView EA20 Manuel utilisateur

Extech Instruments

Extech Instruments 42545-NIST Manuel utilisateur

Extech Instruments

Extech Instruments EasyView Dual K EA10 Manuel utilisateur

Extech Instruments

Extech Instruments TM100 Manuel utilisateur

Extech Instruments

Extech Instruments TM300 Manuel utilisateur

Extech Instruments

Extech Instruments 39240 Manuel utilisateur

Extech Instruments

Extech Instruments SD500 Manuel utilisateur

Extech Instruments

Extech Instruments 421504 Manuel utilisateur

Manuels Thermomètre populaires d'autres marques

Delton

Delton 981A Manuel utilisateur

Baker

Baker MM2P Manuel utilisateur

Tarmo

Tarmo 320281 Manuel utilisateur

Citizen

Citizen CTD 504 Manuel utilisateur

TFA

TFA 14.1500 Manuel utilisateur

Vive

Vive DMD1010 Manuel utilisateur

Gotemp

Gotemp THB4002 Manuel utilisateur

GREISINGER

GREISINGER G 1202 Manuel utilisateur

Amprobe

Amprobe TMD-53W Manuel utilisateur

Trotec

Trotec BP10 Manuel utilisateur

Radiance instruments

Radiance instruments RT616 Series Manuel utilisateur

Eurolec

Eurolec IR151 Manuel utilisateur

Scaneo

Scaneo TS42B Manuel utilisateur

Sper scientific

Sper scientific 800043 Manuel utilisateur

Microlife

Microlife NC 200 Mode d’emploi

Motorola

Motorola MBP69SN Guide de configuration

The MeatStick

The MeatStick The MeatStick Manuel utilisateur

Hama

Hama TH35-A Manuel utilisateur
