USER MANUAL

Insulation Tester + DMM

Model MG320

2 MG320-en-GB_v1.1 1/17

TableofContents

1.INTRODUCTION3

2.SAFETY3

3.METERDESCRIPTION5

4.CONTROLBUTTONS6

5.SYMBOLSANDANNUNCIATORS6

6.OPERATINGINSTRUCTIONS7

6.1DisplayBacklight7

6.2DataHold7

6.3LowBatteryIndication7

6.4DCVOLTAGEMEASUREMENTS7

6.5ACVOLTAGEMEASUREMENTS8

6.6LOWRESISTANCE/CONTINUITYMEASUREMENTS9

6.7INSULATIONRESISTANCEMEASUREMENTS10

6.7.1DisableInsulationTestLockMode10

6.7.2InsulationResistanceTestTimeSetup11

6.7.3DielectricAbsorptionRatio[DAR]InsulationTesting11

6.7.4PolarizationIndex[PI]InsulationTesting11

6.7.5ComparatorUtility12

7.DATARECORDING12

8.MAINTENANCE13

8.1BATTERYINSTALLATION13

8.2REPLACINGTHEFUSE13

9.SPECIFICATIONS14

3 MG320-en-GB_v1.1 1/17

1. Introduction

Congratulations on your purchase of the MG320 True RMS Insulation Resistance CAT IV 600V DMM.

The MG320 features a rugged design for heavy duty use. The MG320 measures Insulation

Resistance, AC/DC Voltage, and Resistance.

Insulation Resistance tests are automatic ranging with 5 test voltages from 50V to 1000V. The

MG320 can store and recall up to 99 measurements.

The MG320 is suitable for measuring the insulation resistance on elecrical equipment such as

transformers, motors, cables, switches, and appliances.

Proper use and care of this meter will provide years of reliable service.

Features

True RMS AC/DC Voltage Measurments to 600V

Insulation Resistance Measurements up to 20G

Low Resistance/Continuity Measurements to 20k

Auto Ranging measurements

Polarization Index (PI) and Dielectric Aborption Ratio (DAR) tests

Five (5) Insulation Resistance test voltages (50, 100, 250, 500, and 1000V)

Insulation Resistance tests in10% voltage steps (from 50% to 120% of range)

Front panel LED test voltage alert lamp

Eight (8) Insulation Resistance measurement ranges (automatic ranging)

Pass/Fail Comparator function

Auto-discharge at end of test

High voltage display symbols

Hand’s free test lock feature

Manually store and recall up to 99 readings

Overload indication

Optional remote test probe for controlling the TEST button remotely

Test leads, alligator clips, batteries, user manual, and case included

2. Safety

Warning and Caution safety label

Double Insulation

DC Direct Current

AC Alternating Current

Low Battery

Fuse symbol

High Voltage Alert

Audible beeper

Earth ground

Complies with EC standard

4 MG320-en-GB_v1.1 1/17

PER IEC1010 OVERVOLTAGE INSTALLATION CATEGORY

OVERVOLTAGE CATEGORY I

Equipment of OVERVOLTAGE CATEGORY I is equipment for connection to circuits in which measures are taken

to limit the transient over-voltages to an appropriate low level.

Note – Examples include protected electronic circuits.

OVERVOLTAGE CATEGORY II

Equipment of OVERVOLTAGE CATEGORY II is energy-consuming equipment to be supplied from the fixed

installation.

Note – Examples include household, office, and laboratory appliances.

OVERVOLTAGE CATEGORY III

Equipment of OVERVOLTAGE CATEGORY III is equipment in fixed installations.

Note – Examples include switches in the fixed installation and some equipment for industrial use with permanent

connection to the fixed installation.

OVERVOLTAGE CATEGORY IV

Equipment of OVERVOLTAGE CATEGORY IV is for use at the origin of the installation.

Note – Examples include electricity meters and primary over-current protection equipment

SAFETY INSTRUCTIONS

This meter has been designed for safe use, but must be operated with caution. The rules listed below

must be carefully followed for safe operation.

1. NEVER apply voltage to the meter that exceeds the specified maximum:

Input Protection Limits

Function Maximum Input

V DC or V AC 600VDC/AC rms

Resistance/Continuity 500mA/600V fuse protected input

Insulation Resistance 250VDC/AC rms

Surge Protection: 8kV peak per IEC 61010

2. USE EXTREME CAUTION when working with high voltages.

3. DO NOT measure voltage if the voltage on the "COM" input jack exceeds 600V above earth

ground.

4. NEVER connect the meter leads across a voltage source while the function switch is in the

resistance mode. Doing so can damage the meter.

5. ALWAYS discharge filter capacitors in power supplies and disconnect the power when making

resistance tests.

6. ALWAYS turn off the power and disconnect the test leads before opening the covers to replace

the fuse or batteries.

7. NEVER operate the meter unless the battery/fuse cover is in place and fastened securely.

8. If the equipment is used in a manner not specified by the manufacturer, the protection provided by

the equipment may be impaired.

5 MG320-en-GB_v1.1 1/17

SAFETY STANDARDS

This instrument is designed and produced strictly in accordance with the safety requirements for GB4793 electronic

measuring instruments and IEC61010-1 safety standards. This instrument meets the double insulation over-voltage

standard CAT IV 600V and pollution degree II. Failure to use the instrument as described in this user manual can

weaken or negate the protections provided.

Check the instrument, test leads, and test pen before use. Check for any abnormal conditions such as

exposed test lead wire, damaged meter housing, no display or random display errors.

Do not use this instrument with an open battery compartment.

Damaged test leads must be replaced with those of the same type or specifications.

Do not touch bare wires or conductors, unused input terminals, or the circuit being measured when the

instrument is in operation.

Use caution when measuring voltages greater than 42V DC or 30V AC. Keep fingers behind the finger guard

on the test leads to avoid electrical shocks when measuring.

Do not apply signals greater than those specified between any two terminals or any terminal and ground.

Set the function switch to the correct position before beginning a test. Never move the function switch during a

test. Please stop testing and remove connections to the circuit under test before moving the function switch to

a new position.

Do not store or use the instrument in an explosive or flammable environment or an environment characterized

by high temperature, high humidity, or strong electromagnetic fields.

There are no user-serviceable parts in this instrument. Please refer all service and repairs to Extech

Instruments.

Replace the batteries as soon as the low battery icon appears in order to ensure the highest measurement

accuracy.

3. MeterDescription

1. 5999 count backlit LCD display with bargraph

2. Control buttons; detailed in next section

3. Rotary function switch

4. Low Resistance/Continuity (+) positive input jack

5. Low Resistance/Continuity (-) COM input jack

6. Insulation and Voltage (-) COM input jack

7. Insulation and Voltage (+) positive input jack

8. Test Voltage alert LED indicator

Note: Tilt stand and battery compartment on back

6 MG320-en-GB_v1.1 1/17

4. Controlbuttons

1. Data Hold on/off (short press) for AC/DC Voltage and Resistance modes only. Also for display

Backlight on/off (long press)

2. Short press to Recall stored readings. Another short press to exit this mode.

3. Save reading (short press) and Clear all stored readings (long press)

4. Comparator (short press) and Zero (long press)

5. PI and DAR test mode selection (short

presses)

6. Insulation Test Lock button (long press to

activate/deactivate lock mode)

7. Up arrow for adjusting test voltage output and

scrolling through recalled readings

8. Down arrow for adjusting test voltage output

and scrolling through recalled readings

9. Press to start Insulation or Low Resistance

tests. Insulation tests output high voltages and measure insulation resistance. Low Resistance

tests can be made up to 20kΩ.

5. SymbolsandAnnunciators

1. Test Voltage alert

2. Insulation Test Lock icon

3. Audible beeper symbol

4. PI/DAR test modes

5. True RMS voltage measurement

6. ZERO function icon

7. Battery status

8. Test voltage value

9. Measurement type and units

10. PI/DAR timer information

11. Bargraph measurement representation

12. Comparator area: Test pass [PASS], test fail [NG], units [K, M, G], and reference value.

13. Main measurement display digits

14. Display Hold Icon (freeze/unfreeze display)

15. Save/Recall readings (01-99)

1234 567

7 MG320-en-GB_v1.1 1/17

6. OperatingInstructions

WARNING: Risk of electrocution. High-voltage circuits, both AC and DC, are very dangerous and should be

measured with great care.

1. ALWAYS turn the function switch to the OFF position when the meter is not in use.

2. If “>” appears in the display during a measurement, the value exceeds the maximum range of

the meter.

6.1 Display Backlight

Press and hold the button to switch the backlight on or off. Excessive use of the backlight will

cause the batteries to drain quicker.

6.2 Data Hold

The Data Hold function freezes the reading in the display. To freeze or unfreeze the reading, press

H (Data Hold) key. The Hicon is shown when data hold is active. This mode is available for Voltage

and Resistance modes only.

6.3 Low Battery Indication

When the icon appears in the display, the battery must be replaced. See the Maintenance

section for details on battery and fuse replacement.

6.4 DC VOLTAGE MEASUREMENTS

CAUTION:

When the measured voltage is > 42VDC or 600VAC the meter flashes the warning icon on the upper left.

Do not measure DC voltages if a motor on the circuit is being switched ON or OFF. Large voltage surges may

occur that can damage the meter.

1. Set the function switch to the position.

2. Insert the black test lead banana plug into the negative COM jack (6).

Insert the red test lead banana plug into the positive Vjack (7).

3. Touch the black test probe tip to the negative side of the circuit.

Touch the red test probe tip to the positive side of the circuit.

4. Read the voltage in the main display and in the lower bargraph.

5. Press the button to store the reading.

6. Short press the H (Hold) button to freeze (Hicon displayed) or

unfreeze (no Hicon displayed) the displayed reading.

7. Note that the Auto Power OFF function activates after 3 minutes of

inactivity. The meter will audibly beep just prior to shutting off.

100 200 300 400 500 600 700

8 MG320-en-GB_v1.1 1/17

6.5 AC VOLTAGE MEASUREMENTS

WARNING: Risk of Electrocution. The probe tips may not be long enough to contact the live parts inside

some 240V outlets for appliances because the contacts are recessed deep in the outlets. As a result, the reading

may show 0 volts when the outlet actually has voltage on it. Make sure the probe tips are touching the metal

contacts inside the outlet before assuming that no voltage is present.

CAUTION

Do not measure AC voltages if a motor on the circuit is being switched ON or OFF. Large voltage surges may

occur that can damage the meter.

Do not measure voltages higher than 600V

When the measured voltage is > 60VDC or 600VAC the meter flashes the warning icon on the upper left.

Do not measure AC voltages if a motor on the circuit is being switched ON or OFF. Large voltage surges may

occur that can damage the meter.

1. Set the function switch to the position.

2. Insert the black test lead banana plug into the negative COM jack

(6).

Insert red test lead banana plug into the positive Vjack (7).

3. Touch the black test probe tip to the neutral side of the circuit.

Touch the red test probe tip to the “hot” side of the circuit.

4. Read the voltage in the main display and in the lower bargraph.

5. Short press the H (Hold) button to freeze (Hicon displayed) or

unfreeze (no Hicon displayed) the displayed reading.

6. Press to store the reading

7. Note that the Auto Power OFF function activates after 3 minutes

of inactivity. The meter will audibly beep just prior to shutting off.

8. Note that the Auto Power OFF function activates after 3 minutes

of inactivity. The meter will audibly beep just prior to shutting off.

100 200 300 400 500 600 700

9 MG320-en-GB_v1.1 1/17

6.6 LOW RESISTANCE/CONTINUITY MEASUREMENTS

WARNING: To avoid electric shock, disconnect power to the unit under test and discharge all capacitors

before taking any resistance measurements. Remove the batteries and unplug the line cords.

WARNING: To avoid electric shock, never measure resistance on circuits or wires that have a voltage.

1. Set the function switch to the Ωposition.

2. Insert the black test lead banana plug into the negative COM

jack (5).

Insert the red test lead banana plug into the positive

CONTINUITYjack (4).

3. Press the TEST button on the meter (or on the optional

remote test leads) to put the meter in test mode. The display

will show TEST and the front panel alert LED will light.

4. Reset the display to zero before testing: Short the test probes

and note the value. Short the test probes again and press and

hold ZERO until ZERO is displayed (0.00Ωreading when

successful). Press and hold ZERO again to exit.

5. Before testing, it is best to disconnect one side of the part

under test so that other circuits do not interfere with the

resistance reading.

6. Touch the test probe tips across the circuit or part under test.

7. Read the resistance in the main display.

8. If the circuit is open, the display will indicate “>”. If 2V or more

are sensed on the device under test, the meter will stop the

test.

9. Short press the H (Hold) button to freeze (Hicon displayed) or unfreeze (no Hicon displayed)

the displayed reading.

10. Press to store the reading

11. Note that the Auto Power OFF function activates after 3 minutes of inactivity. The meter will

audibly beep just prior to shutting off.

TEST

10 MG320-en-GB_v1.1 1/17

6.7 INSULATION RESISTANCE MEASUREMENTS

Note: Disconnect the unit under test from all power sources and isolate it from any stray

resistance.

1. Connect the red test lead to the meter’s INSULATION (+) jack (7) and the black test lead to the

EARTH (-) jack (6). Connect the probe end of the test leads to the circuit under test.

2. Set the rotary function switch to one of the Insulation Resistance test positions (50V, 100V,

250V, 500V, or 1000V); the selected test voltage is indicated on the top right of the display.

3. Press the TEST button on the meter (or on the optional remote test lead) to start testing (TEST

will display).

4. The primary display and the analog bargraph will show

the insulation resistance in Ω.

5. The test voltage (VDC) value will be indicated in the top

right display, the symbol will flash and the front panel

red LED will light.

6. The meter defaults to test lock mode (lock icon

displayed) so the test will run without having to hold the

TEST button.

7. Press the TEST button to stop the test.

8. At the end of each test the high voltage switches off

(alert symbol and LED light switch off), the measured

resistance value is held in the primary display, and the

meter internally discharges the balance of the test

voltage.

9. Short press the H(Hold) button to freeze (Hicon) or

unfreeze (no Hicon) the displayed reading.

10. Press to store the reading

Note: If the circuit under test is live and has a voltage potential (AC/DC) over 25V, the meter will not

test (the display will show “EXT” and the symbol will flash). If the circuit under test is not live or if

its voltage is less than 25V, the meter will begin applying voltage to the circuit under test.

Note: Do not turn the function switch to another test position during a test. Please wait until a test is

completed and test leads are removed from the device under test before moving the function switch.

6.7.1 Disable Insulation Test Lock Mode

To disable test lock mode, press and hold the button until the lock icon switches off and

then press and hold the TEST button for the duration of the test (TEST will be displayed).

Release the button to stop the test.

Table des matières

Autres manuels Extech Instruments Équipement de test

Extech Instruments

Extech Instruments prc20 Manuel utilisateur

Extech Instruments

Extech Instruments 382356 Manuel utilisateur

Extech Instruments

Extech Instruments 382252 Manuel utilisateur

Extech Instruments

Extech Instruments FT10 Manuel utilisateur

Extech Instruments

Extech Instruments 7470 Manuel utilisateur

Extech Instruments

Extech Instruments IRC350 Manuel utilisateur

Extech Instruments

Extech Instruments ET15 Manuel utilisateur

Extech Instruments

Extech Instruments VT10 Manuel utilisateur

Extech Instruments

Extech Instruments 407744 Manuel utilisateur

Extech Instruments

Extech Instruments MG500 Manuel utilisateur

Extech Instruments

Extech Instruments 422123 Manuel utilisateur

Extech Instruments

Extech Instruments 380260-NIST Manuel utilisateur

Extech Instruments

Extech Instruments 381285 Manuel utilisateur

Extech Instruments

Extech Instruments VT30 Manuel utilisateur

Extech Instruments

Extech Instruments 380320 Manuel utilisateur

Extech Instruments

Extech Instruments 380260 Manuel utilisateur

Extech Instruments

Extech Instruments 380260 Manuel utilisateur

Extech Instruments

Extech Instruments 380353 Manuel utilisateur

Extech Instruments

Extech Instruments ExStik CL200 Manuel utilisateur

Extech Instruments

Extech Instruments 380395 Manuel utilisateur

Extech Instruments

Extech Instruments ET60 Manuel utilisateur

Extech Instruments

Extech Instruments CT70 Manuel utilisateur

Extech Instruments

Extech Instruments PRC30 Manuel utilisateur

Extech Instruments

Extech Instruments PRC10 Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
