Extech Instruments 380320 Manuel utilisateur

User's Guide

Analog High Voltage Megohmmeter

Model 380320

380320-en-GB_V1.5 9/15

Introduction

Congratulations on your purchase of the Extech 380320 Analog High Voltage Megohmmeter. The

380320 features three Insulation test ranges with a live circuit indicator, as well as low resistance

and AC voltage measurements. The Power Lock On feature allows hands-free operation. This

professional meter is shipped fully tested and calibrated and, with proper use, will provide years of

reliable service.

Safety

International Safety Symbols

This symbol, adjacent to another symbol or terminal, indicates the user must refer to the

manual for further information.

This symbol, adjacent to a terminal, indicates that, under normal use, hazardous voltages

may be present

Double insulation

Safety Notes

Do not exceed the maximum allowable input range of any function.

Set the function switch OFF when the meter is not in use.

Remove the battery if meter is to be stored for longer than 60 days.

Circuits under test must be de-energized and isolated before connections are made (except for

voltage measurements).

Circuit connections must not be touched during a test. Use extreme caution when working near

bare conductors and bus bars. Accidental contact with conductor could result in electrical

shock.

After insulation tests, capacitors must be discharged.

Warnings

Set function switch to the appropriate position before measuring.

When changing ranges always disconnect the test leads from the circuit under test.

Cautions

Improper use of this meter can cause damage, shock, injury or death. Read and understand

this user manual before operating the meter.

Always remove the test leads before replacing the battery.

Inspect the condition of the test leads and the meter itself for any damage before operating the

meter. Repair or replace any damage before use.

Use great care when making measurements if the voltages are greater than 25VAC rms or

35VDC. These voltages are considered a shock hazard.

Voltage checks on electrical outlets can be difficult and misleading because of the uncertainty

of connection to the recessed electrical contacts. Other means should be used to ensure that

the terminals are not "live".

If the equipment is used in a manner not specified by the manufacturer, the protection provided

by the equipment may be impaired.

380320-en-GB_V1.5 9/15

Meter Description

1. Analog display – See Display Description below

2. Batt Check key – Checks battery level (with TEST key)

3. 0 ADJ key – Adjusts Zero point for Analog

display

4. Backlight key – Turns on Backlight

5. TEST/LOCK key – Enables Battery Check,

Resistance, and Megohmmeter functions

(can be locked by rotating clockwise)

6. Function Selector knob – Selects desired

range and function

Top View

1. VTest Lead Input

2. COM Test Lead Input

Display Description

1. Red: Megohmmeter Scale: Multiply reading by 0.5 (for 250V range), 1 (500V), 2 (1000V)

2. Green: Low Resistance Scale (0 to 3)

3. Green: Resistance Scale (0 to 500

4. Blue: AC Voltage Measurement Scale (0 to

600V)

5. BATT GOOD indicator

6. LIVE CIRCUIT Indicator LED

380320-en-GB_V1.5 9/15

Operation

CAUTIONS

Observe all safety precautions when the FUNCTION switch is set to the 250V, 500V or 1000V

positions.

Connect the meter test leads to the circuit under test before operating the TEST key.

Do not touch the clip ends of the test leads when the TEST key is pressed.

Some electrical equipment, especially cables, may retain an electrical charge when

disconnected from the line. It is good practice to discharge such equipment with grounding

straps, or other suitable devices, before touching or making connections. The meter

automatically discharges the test circuits when the spring loaded TEST key is released.

IMPORTANT NOTE

Remove all power to the circuit under test when making resistance measurements. If any

voltage is present in the test circuit the red on the meter scale plate will light. Immediately

disconnect test leads and turn off power to test circuit.

Live Circuit Indicator LED

If the Live Indicator status LED is lit, voltage is present on the device under test. DO NOT proceed

to test with voltage present. Shock to the user and damage to the meter or device under test can

result if testing is done with voltage present. Proceed with testing only when the voltage is removed

from the device under test.

Connecting Test Leads

For all measurements, connect the red test lead to the Vinput terminal and the black test lead to

the COM input terminal.

Battery Check

1. Set the range selector switch to the BATT.CHECK position

2. Press and hold the TEST key.

3. Press the Batt Check key.

4. Observe the meter pointer. If the pointer falls in the BATT GOOD range of the bottom scale,

batteries are good. If the pointer falls outside of (to the left of) the BATT GOOD area, replace

the batteries.

Test Lead Check

1. Set the FUNCTION switch to the 3range.

2. Touch the test lead tips together and press the TEST key.

3. Resistance should read less than 0.5.

4. With the leads not touching, the display should read infinity.

5. Readings displayed other than the readings described above are indicative of a test lead

problem. The test leads must be replaced before using the meter. Failure to do so could result

in damage to equipment and electrical shock.

380320-en-GB_V1.5 9/15

Megohm Measurements

1. Disconnect all power from the circuit to be tested.

2. Connect the red test lead to the Vinput terminal and the black test lead to the COM input

terminal.

3. Set the FUNCTION switch to the desired test range

4. Connect the test leads to the circuit to be tested

CAUTION: If the LIVE CIRCUIT indicator lights up at this point, DO NOT operate the TEST

key. Remove the test leads and disconnect all power from the circuit.

5. Press and hold the TEST key to make the measurement. Turn the key clockwise to lock the

test on.

6. Read the value on the MΩscale and apply the range multiplier to determine the Megohm

resistance reading.

7. Release or unlock the TEST key and allow the device to discharge before removing the test

leads.

Range Reading Multiplier

250V 0.5

500V 1

1000V 2

Resistance Measurements

WARNING: Do not run this test unless the voltage on the device under test is zero. If the Live

Circuit status LED lights when a test is initiated, immediately abort the test and check that the circuit

under test is not powered.

1. Set the Function select switch to the appropriate Resistance (3or 500Ω) position.

2. Connect the red test lead to the Vinput and the black lead to the COM input.

3. Perform a zero adjustment using the 0 ADJ screw on the unit as described below.

4. Connect the test lead tips to the circuit under test.

5. Press the TEST key. Lock by rotating clockwise if desired.

6. Read the resistance on the appropriate green display scale (3or 500.

7. Release or unlock the Test key.

Zero Adjust

1. Set the range selector switch to the 3Ωor 500Ωrange.

2. Short the test leads together.

3. Press the Test key. Lock by rotating clockwise if desired.

4. Use the 0 ADJ control to align the display pointer with the 0 point on the 3Ωor 500Ωscale.

5. Release or unlock the Test key.

AC Voltage Measurements

1. Set the Rotary switch to the OFF/VAC position.

2. Connect the red test lead to the Vinput and the black lead to the COM input.

3. Connect the other end of the test leads to the circuit under test.

4. Read the voltage value on the meter.

380320-en-GB_V1.5 9/15

Battery Replacement

1. If the Battery Check indicates low battery power, the 6 AA batteries must be replaced.

2. Remove the test leads and turn the meter over.

3. Unsnap the tilt stand from the rear of the meter.

4. Remove the 4 Phillips head screws that secure the battery cover.

5. Remove the battery compartment cover

6. Replace the batteries, observing correct polarity.

7. Replace the battery compartment cover and secure the 4 screws.

8. Re-attach the tilt stand.

You, as the end user, are legally bound (Battery ordinance) to return all used batteries and

accumulators; disposal in the household garbage is prohibited!

You can hand over your used batteries / accumulators at collection points in your community

or wherever batteries / accumulators are sold!

Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the

end of its lifecycle

380320-en-GB_V1.5 9/15

Specifications

General Specifications

Display Multiband analog display with zero adjust

Live Circuit Indicator LED lights when live circuit is sensed

Power supply 6 x 1.5V AA batteries

Power consumption 32mA

Fuse Protection 500mA 600V

Operating Temperature 0 to 40oC (32 to 104oF)

Operating Humidity Below 80% RH

Altitude Up to 2000 meters

Storage Temperature -10 to 60oC (14 to 140oF)

Storage Humidity Below 70% RH

Dimensions 200 x 92 x 50mm (7.9 x 3.6 x 2")

Weight Approx. 700g. (24.7 oz) with batteries

CAT rating CATIII 1000V & CATIV 600V

Resistance Specifications

Range Resolution Accuracy MIN. Open Circuit Voltage MIN Circuit Current

3Ω0.05Ω+3% 4.1V 200mA

500Ω1Ω4.1V

AC Voltage

Range Res. Accuracy Input impedance Overload Protect

600VAC 20V ±5% 1.2M1000Vrms

Megohmmeter Specifications

Range Accuracy Terminal voltage

100M250VDC 0.2M M ±5% 250V + 10% ~ -0%

5M to 100 M±10%

200M500VDC 0.5MM ±5% 500V + 10% ~ -0%

10MM±10%

400M1000VDC 1 M M±5% 1000V + 10% ~ -0%

20 M M±10%

Range Test Current / Load Short circuit Current

100M250VDC

1mA

250K

Approx. 1.3mA

200M500VDC 500K

400M1000VDC 1M

Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform

ISO‐9001Certified

www.extech.com
