Extech Instruments EC170 Manuel utilisateur

USERGUIDE



SalinityMeter

PenStyleWaterQualityMeter



ModelEC170



www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

2 EC170-EU-EN V1.1 7/13

Introduction

CongratulationsonyourpurchaseoftheExtechPenStyleWaterQualityinstrument;theModel

EC170measuresSalinityandtemperature.TheinstrumentishousedinanIP65Water‐proof

enclosureforsafety.Thismeterisshippedfullytestedandcalibratedand,withproperuse,will

provideyearsofreliableservice.Pleasevisitourwebsite(www.extech.com)tocheckforthe

latestversionofthisUserGuide,ProductUpdates,andCustomerSupport.



Features

IP65Waterproofhousing

AutomaticRangingandManualRangingcapability

DualDisplaywithATC(automatictemperaturecompensation)

Dataholdforfreezingdisplayedreadings

Lowbatteryindicator

Automaticpower‐offformaximumbatteryefficiency

Switchabletemperatureunitsofmeasure(oC/oF)

Multi‐pointandone‐touchcalibrationfeatures

Pocketsized,poweredbyfour(4)LR44batteries



SuppliedMaterials

EC170meter

Four(4)LR44buttonbatteries

Operationmanual(hardcopy,mini‐disk,andon‐lineavailabilityatwww.extech.com)



www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

3 EC170-EU-EN V1.1 7/13

BatteryInstallation

Themeterisshippedwiththefour(4)LR44button

batteriesremoved.Theusermustinstallthebatteries

beforethemetercanbeused.Refertoaccompanying

diagram.

1. Unscrewthebatterycompartmentcover(topof

meter)inacounter‐clockwisedirection.Please

donotdiscardtheblackwasher.

2. Installthefour(4)LR44buttonbatteries,

carefullyorientingthebatteriesandobserving

polarity.

3. Replacethebatterycompartmentcover.

4. Pleaseremovethebatterieswhilethemeterisnotinuseforlongperiods.

Neverdisposeofusedbatteriesorrechargeablebatteriesinhouseholdwaste.

Asconsumers,usersarelegallyrequiredtotakeusedbatteriestoappropriate

collectionsites,theretailstorewherethebatterieswerepurchased,orwherever

batteriesaresold.

Disposal:Donotdisposeofthisinstrumentinhouseholdwaste.Theuseris

obligatedtotakeend‐of‐lifedevicestoadesignatedcollectionpointforthedisposal

ofelectricalandelectronicequipment.



OtherBatterySafetyReminders

a. Neverdisposeofbatteriesinafire.Batteriesmayexplodeorleak.

b. Nevermixbatterytypes.Alwaysinstallnewbatteriesofthesametype.



www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

4 EC170-EU-EN V1.1 7/13

MeterDescription

1. BatteryCompartment

2. Display

3. Keypad

4. Electrode

5. Electrodeprotectivecap





DisplayDescription

1. DataHoldicon

2. Micro‐andmilli‐Siemensunits(unusedinthismeter)

3. Primarymeasurementreading

4. Partsperthousandsalinityunits(ppmpartspermillion

arenotusedinthismeter)

5. Temperaturereading

6. Temperatureunitsofmeasure

7. Batterystrengthindicator

8. Calibrationicon



KeypadDescription

1. PowerON‐OFFandSETbutton

2. DownArrow,DataHold,andCalibrationbutton

3. Uparrowbutton



www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

5 EC170-EU-EN V1.1 7/13

Operation

GettingStarted

1. Removetheprobe’sprotectivecap(bottomofmeter)bypullingthe

capfirmlydownward,awayfrommeter,untilitsnapsoff(seediagram).

2. Pressthepowerbutton topowerONthemeter.Themeterdisplay

willcyclethroughseveralicons(representingthecurrentconfiguration

ofthemeter)beforesettlingonthemaindisplayasshowninthe

displaydescriptionabove.

3. PressthepowerbuttonmomentarilytopowerOFFthemeter.

4. Thismeterispoweredbyfour(4)LR44buttonsbatteries.IfthemeterwillnotswitchON

pleasecheckthatfreshbatteriesareinstalled.

AutomaticandManualRanging

TherearetworangesavailableRange1(0.00to10.00ppt)andRange2(10.1to70.0ppt).The

meterdefaultstotheAUTORangemodewhereoneofthesetworangesisselected

automaticallytoprovidethebestresolutionandaccuracyforeachgivenmeasurement.

However,MANUALRangemodecanalsobeusedwhererange1andrange2canbeselected

manually.



5. PressandholdtheUParrowbutton,thenumber1(range1)willappearonthelower

rightoftheLCDand‘ran’(range)willappearatthecenteroftheLCD.

6. Releasethebuttonandthemeterwillbeforcedintorange1.

7. PressandholdtheUParrowbuttonagain,thenumber2(range2)willappearonthelower

rightoftheLCDand‘ran’(range)willappearatthecenteroftheLCD.

8. Releasethebuttonandthemeterwillbeforcedintorange2.

9. PressandholdtheUParrowbuttonagain,‘ATo’willappearonthelowerLCDareaindicating

thatthemeterisonceagainintheAUTORangemode.

10. Releasethebuttontoendtherangesettingsessionorreturntostep1torepeatthis

process.



www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

6 EC170-EU-EN V1.1 7/13

MeasurementPreparations,Notes,andConsiderations

Accuracyisgivenas%full‐scale;thereforeusingthelowestrangewillyieldthebest

accuracy.

Themeter’sdisplaywillindicateE02orE03ifthemeasuredvalueisbelow(E02)orabove

(E03)specifiedlimitsofthemeter.Ifthisoccurs,pleaseselectanotherrangeasdescribedin

theManualRangediscussioninpreviousparagraph.

Thetemperaturecoefficientisfixedandcannotbeadjusted.

Thenormalization(reference)temperatureisfixed(25oC);thenominalvalueiscorrectfor

mostapplications.

Rinsetheprobewithdeionizedordistilledwaterbeforeusetoremoveimpuritiesthatmay

adheretotheelectrode.Whenthemeterhasbeenidleforalongperiod,soaktheelectrode

foratleast30minutesbeforeuse.

Whendippingtheprobeintoasamplesolution,besuretoeliminateairbubblestrappedin

theprobe’sslot.Toremoveairbubbles,givetheprobeagentlestirwhilesubmergedinthe

solution.

Whentakingameasurement,stirtheprobegentlyinthesampletocreateahomogenous

sample.Allowafewsecondstoelapsefortheprobeandthesampletoreachtemperature

equilibrium.Ideally,wait15minutestoachievemaximumaccuracyandbesttemperature

compensation.

Theunitofmeasureiconwillflashonthemeter’sdisplaywhilestabilizationistakingplacein

measurementmode.Whenstabilizationisachieved,themeter’siconwillstopflashing.

PresstheHOLDbuttontofreezeadisplayedreading.Pressagaintoreleasethedisplay.

SalinityMeasurement

1. ReadtheMeasurementPreparationsectionabovebeforecontinuing.

2. Inserttheelectrodeintothesampleensuringthattheelectrodesarecompletelysubmersed.

3. Slowlystirthesolutionwiththeelectrodetoremoveairbubbles.

4. ThemeterusestheAuto‐rangeutilitytofindtheproperrangeandthendisplaysthesalinity

readingatthecenteroftheLCDwiththetemperaturereadingshownonthelowerLCDarea

insmallerdigits.

FinishingaMeasurementSession

Afterameasurementsession:

Rinsetheelectrodeindeionizedordistilledwaterandstoredry.

Affixtheprotectivecapovertheelectrodewhenstoring.

Iftheunitistobeleftun‐unusedforlongperiods,removeandstorethebatteriesseparately.

AutomaticPowerOFF(Sleepmode)

ThemeterwillautomaticallyswitchOFFafter20minutesofinactivity.TodisabletheSleep

Mode:Withtheinstrumentswitchedoff,pressandholdtheSETandHLD/CALbuttons

simultaneouslyuntilthe‘n’iconappearsonthedisplay.Releasethebuttonsandthemeterwill

powerup.ThemeterwillnowstayswitchedONuntiltheusermanuallyswitchesitOFF.The

meterrevertstothe‘SleepModeactive’stateeachtimeitispowereddown.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

7 EC170-EU-EN V1.1 7/13

SetupMode

ParameterP1:TemperatureUnits

1. Fromthenormaloperatingmode,pressandholdtheSETbuttonforatleast2secondsuntil

the‘Px’iconappearsonthebottomoftheLCDdisplay(x=setupparameternumber).

2. UsethearrowbuttonstoscrolltotheP1.0iconifnecessary.

3. PresstheSETbuttonmomentarily,the‘C’or‘F’iconshouldnowbeflashingandthe‘t.ut’

icon(abbreviationfortemperatureunits)willbevisibleabovetheflashingunit.

4. Usethearrowkeystoselectthedesiredunitofmeasure.

5. PresstheSETbuttonmomentarilytoconfirmtheselection.

6. ThedisplayreturnstotheP1.0screen.

7. PresstheuparrowbuttontoscrolltothenextparameterP3.0with‘rSt’displayed(factory

defaultresetmode)andfollowthestepsinthenextsection.

ParameterP3:FactoryDefaultReset

Thisparametercanbeusedtorestoreallsettingstotheirfactorydefaultstate.

1. IfcontinuingfromParameterP1skipdirectlytostep2below.Ifstartingfromthenormal

operatingmode,pressandholdtheSETbuttonforatleast2secondsuntilthe‘Px’icon

appearsonthemeterdisplay(x=setupparameternumber)andthenusethearrowbuttons

toscrolltotheP3icon.The‘rSt’displayiconwillbevisibleabovetheP3icon.

2. AttheP3.0‘rSt’screenpresstheSETbuttonmomentarily;a‘y’oran‘n’willbeflashing.

3. Usethearrowbuttonstoselect‘y’forYESRESETor‘n’forNORESET.

4. PresstheSETbuttonmomentarilytoconfirmthesetting.

5. PressandholdtheSETbuttonforatleast2secondstoreturntothenormaloperationmode

orpresstheuparrowbuttonmomentarilytomovetoParameterP4(seebelow).

ParameterP4:CalibrationReviewforRange1andRange2Concentrations

1. IfcontinuingfromParameterP3skipdirectlytostep2below.Ifstartingfromthenormal

operatingmode,pressandholdtheSETbuttonforatleast2secondsuntilthe‘Px’icon

appearsonthemeterdisplay(x=setupparameternumber)andthencontinuestep2below.

2. UsethearrowbuttonstoscrolltotheP4.0iconifnecessary.The‘CAL’displayiconwillbe

visibleabovetheP4.0icon.

3. PresstheSETbuttonmomentarilytoviewthecurrentRange1CalibrationConcentration.

TheP4.0iconwillchangetoP4.1.Ifdashes(‐‐‐)appearonthedisplaythisindicatesthatthe

meterhasnotbeencalibratedthusfar.

4. PresstheuparrowbuttontomovetotheP4.2display.Thedisplayedvaluenowrepresents

theRange2CalibrationConcentration.Again,ifdashedlinesappear,thenthemeterhasnot

beencalibrateduptothispoint.

5. PressandholdtheSETbuttonforatleast2secondstoreturntotheP4.0‘CAL’screen.

6. UsethearrowkeystoselectanotherparameterorpressandholdtheSETbuttonforatleast

2secondstoreturntothenormaloperationmode.



www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

8 EC170-EU-EN V1.1 7/13

Calibration

CalibrationPreparationandConsiderations

Theusermustfirstdetermine:

1.Thebestcalibrationschedulefortheapplicationathand.

2.Whatcalibrationstandardtouse.



CalibrationSchedule

Calibrationisnecessaryandshouldbeperformedregularly.

Ifmeasuringinthemid‐rangescalibratethemeteratleastoncepermonthandsoakthe

probedeionizedorfor15minutesbeforeeachuse.

Ifmeasuringinextremetemperatureenvironments,oratthelowendofthemeasurement

range,calibratethemeteratleastonceperweek.



SelectingaCalibrationStandard

Forbestresultsselectacalibrationstandardclosesttotheexpectedsamplevalue.

Alternatively,useacalibrationsolutionvaluethatisapproximately2/3oftheexpectedfull

scalemeasurementrange.Remembernottore‐usecalibrationsolutions;contaminantsinthe

solutionwillaffectthecalibrationandtheaccuracy.



SalinityCalibrationProcedure

1. Inserttheprobeintodeionizedordistilledwaterforapproximately30minutestorinsethe

probe.

2. SelecttheSodiumChloridestandardthatisclosesttotheexpectedmeasurementrange.

3. Filltwoseparateandcleansamplecupswiththestandardizingsolutiontoadepthofat

least3cm(1.2”)each.

4. SwitchthemeterON.

5. Rinsetheprobeinoneofthesamplecupsolutions,gentlystirringtheprobe.Rinsingcould

removecontaminantsthatcouldaffectcalibrationandcausemeasurementerrors.

6. Diptherinsedprobeintotheothersamplecupsolution.Tapormovetheelectrodeinthe

sampletodislodgeairbubbles.Lettheprobestabilizetothesolutiontemperature.

7. PressandholdtheHOLD/CALbutton(approximately2seconds)untilthesalinityvalueand

the‘CAL’iconbeginflashingontheLCD.

8. Usethearrowbuttonstoadjustthedisplayedvaluetomatchthevalueofthestandard

solution.TheSalinityreadingcanbeadjusted±30%fromthedetectedvalue.Values

differingmorethan±30%fromthedetectedvalueindicatesthattheelectrodeneedstobe

cleaned.

9. WhentheCALiconstopsflashing,presstheSETbuttonmomentarilytoconfirmthevalue.

Themeterwillthenreturntothenormalmeasurementmode.

10. NotethatincaseswheretheSalinityreadingisoutsidethe±30%window,themeterdisplay

mayfreezeandnotallowtheusertoreturntothenormaloperatingmode.Inthiscase,

removeoneofthebatteriestoswitchthemeterOFFanddonotusethemeteragainuntil

theelectrodehasbeencleanedorreplaced.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

9 EC170-EU-EN V1.1 7/13

Maintenance

Keepthemeter’smeasurementelectrodeclean.Betweenmeasurements,rinsetheelectrode

withdeionizedordistilledwater.Iftheelectrodehasbeenexposedtoasolventimmisciblein

water,cleanitwithasolventmiscibleinwater,e.g.Ethanol,andthenrinsecarefullywith

water.

Storetheelectrodecarefully.Beforestoring,rinsecarefullyindeionizedordistilledwaterand

storedry.

Troubleshooting

PowerONisattemptedbutthereisnodisplay

BesuretopresstheON‐OFFbuttonforatleast100mStoswitchthemeterON.

Checkthatbatteriesarepositionedcorrectly,makinggoodcontact,andcorrectpolarity.

Replacethebatteriesifnecessary.

Removeandreplacetheexistingbatteries.

DisplayswitchesOFF

ThisisnormalwhenAutoPowerOFFisactivated.

Replacethebatteriesifnecessary.

AirBubblesadheredtoElectrode

Stirtheelectrodecompletelyandbesuretodiptheelectrodeintoasolutionatanoblique

angle.Verticaldippingcancausemanyairbubblestoadhere.

Gentlytapthebottomofthesolutioncontainerwhilestirringtheelectrodeinthesolution.

Aircanbeblownacrosstheelectrodebeforedippingitintothesolution.

ErrorCodes

RefertotheTablebelowfordetailsonErrorCodesdisplayedbythemeter.

CodeDescriptionSuggestions

SALINITYERRORS

‐‐‐‐‐ Measurementoutsideof

range

InManualRangemode,pressandholdtheup

arrowfor2secondstochangerangeorusethe

AutoRangemode

E03Salinityisover‐rangeCheckagainstastandardbuffersolution.If

problempersists,repairmeter

E04TemperatureerrorRepairmeter

TEMPERATUREERRORS

E01Temperaturecircuit

damaged

Repairmeter

E02Temperaturevalueisbelow

allowablerangeor

Temperaturecircuitdamage

Checkagainatroomtemperature.Iferror

persists,repairmeter

E03Temperaturevalueisabove

allowablerangeor

Temperaturecircuitdamage

Checkagainatroomtemperature.Iferror

persists,repairmeter

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

10 EC170-EU-EN V1.1 7/13

FactoryDefaultSettings

TypeParameterDefaultNotes

P1.0Select°C/°F°CTemperatureunits

P3.0ReverttoFactoryDefaultsettingsNOSelectYEStoreverttodefault

settings

P4.1‐‐‐‐‐ CalibrationDataforRange1

P4.2

ReviewpreviousCalibrationdata

‐‐‐‐‐ CalibrationDataforRange2



Specifications



MeasurementrangesRange1: 0.00to10.00pptSalinity

  Range2: 10.1to70.0pptSalinity



ppt=partsperthousand

1ppt=1g/L



SalinityAccuracyRange1: 1%FullScale±1digitor2%FullScale

Range2: ±1digit

SalinityResolutionRange1: 0.01ppt

Range2: 0.1ppt



TemperatureAccuracy±0.5

C(0.9

F)

TemperatureResolution0.1

F



TDSFactorBuilt‐inNaClconductivitytoTDSconversionfactor

CalibrationOnepointcalibrationperrange

AutoPowerOFFAfter20minutesofinactivity

DataHoldFreezesdisplayedreading

AutomaticTemperatureCompensation(ATC):0to50

C(32to122

F)

WaterproofIP65rated

TemperatureCoefficientBuilt‐inNaCltemperaturecoefficient

OperatingConditionsTemperature:0to50

C(32to122

F);<80%RH

StorageConditionsTemperature:0to60

C(32to140

F);<90%RH

NormalizationTemperatureFixedat25

C(77

F)

BasicstatusindicatorsOut‐of‐range(‐‐‐‐)andlowbattery

PowerSupplyFour(4)LR44‘button’batteries

DimensionsMeter:165x35x32mm(6.5x1.4x1.3”)

LCD:30x18mm(1.2x0.7”)

Weight115g(4oz.)



Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform

www.extech.com

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Table des matières

Autres manuels Extech Instruments Instrument de mesure

Extech Instruments

Extech Instruments PQ3350 Manuel utilisateur

Extech Instruments

Extech Instruments 407703A Manuel utilisateur

Extech Instruments

Extech Instruments PQ34-12 Manuel utilisateur

Extech Instruments

Extech Instruments 461825 Manuel utilisateur

Extech Instruments

Extech Instruments Oyster 341350A-P Manuel utilisateur

Extech Instruments

Extech Instruments EasyView EA33 Manuel utilisateur

Extech Instruments

Extech Instruments 380942 Manuel utilisateur

Extech Instruments

Extech Instruments 380193 Manuel utilisateur

Extech Instruments

Extech Instruments VB450 Manuel utilisateur

Extech Instruments

Extech Instruments MO50 Manuel utilisateur

Extech Instruments

Extech Instruments 380580 Manuel utilisateur

Extech Instruments

Extech Instruments 380580 Manuel utilisateur

Extech Instruments

Extech Instruments UV505 Manuel utilisateur

Extech Instruments

Extech Instruments EX650 Manuel utilisateur

Extech Instruments

Extech Instruments MO257 Manuel utilisateur

Extech Instruments

Extech Instruments 461700 Manuel utilisateur

Extech Instruments

Extech Instruments 407355 Manuel utilisateur

Extech Instruments

Extech Instruments ExStik DO600 Manuel utilisateur

Extech Instruments

Extech Instruments MultiScope 381270 Manuel utilisateur

Extech Instruments

Extech Instruments CO200 Manuel utilisateur

Extech Instruments

Extech Instruments 850 OWL Manuel utilisateur

Extech Instruments

Extech Instruments ExStik II EC400 Manuel utilisateur

Extech Instruments

Extech Instruments 407730 Manuel utilisateur

Extech Instruments

Extech Instruments SP505 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
