Evikon E2638-H2S Manuel utilisateur

PluraSens®

Hydrogen Sulﬁde Detector-Transmitter

E2638-H2S

User Manual

E2638-H2S Rev 21.06.2021
Table of contents
Hydrogen Sulﬁde 3
Speciﬁcations 4
Product description 6
Safety requirements 6
Operating conditions 7
Installation guidelines 7
Mounting dimensions 8
Sensor probe handling 9
Gas sensor replacement procedures 9
Electrical connections 10
Correct and incorrect cabling for 24 VAC 12
Operation 13
Maintenance 13
Calibration 13
Delivery set 14
Order code for E2638-H2S options 14
Conﬁguring 15
Return to default settings 15
Modbus RTU Communication 16
RS485 communication interface 16
Communication parameters 16
Modbus holding registers 16
Warranty 21
Manufacturer contacts 21
2

E2638-H2S Rev 21.06.2021

Hydrogen Sulﬁde

Colorless toxic, corrosive and ﬂammable gas with a smell of rotten eggs. Occurs in natural

gas, volcanic gases, petroleum, and some sources of well water. It results from the

anaerobic decay of sulfur-containing proteins, e.g. in sewers.

Synonyms: Hydrosulfuric acid, Sewer gas, Sulfuretted hydrogen.

Chemical formula

H2S

Molar weight

Conversion

1 ppm = 1.40 mg/m3

Relative gas density (to air)

1.17

Boiling point

−60 °C

Low explosive limit (LEL), % vol. in air

4.0

Upper explosive limit (UEL), % vol. in air

44.0

Odor

The characteristic smell of rotten eggs. Above 30 ppm,

the odor is described as sweet or sickeningly sweet.

Odor threshold

0.01-1.5 ppm

Note: Sense of smell becomes rapidly fatigued and can

NOT be relied upon to warn of the continuous presence of

H2S.

Hazards

Highly ﬂammable, explosive gas.

Broad-spectrum poison, mostly affecting the nervous

system. At low concentrations causes eye irritation, a sore

throat and cough, nausea, shortness of breath, and

pulmonary edema. Long-term, low-level exposure results

in fatigue, loss of appetite, headache, poor memory,

irritability, and dizziness. Exposure to high levels can

induce immediate collapse, with loss of breathing and a

high probability of death.

Exposure limits

(Commission

Directive

2009/161/EU)

TWA

7 mg/mm3/ 5 ppm

STEL

14 mg/mm3/ 10 ppm

IDLH (NIOSH)

140 mg/mm3/ 100 ppm

Conversion of ppm to mg/m3is calculated for 25°C and 1 atm.

E2638-H2S Rev 21.06.2021

Speciﬁcations

Sensor type

Electrochemical cell

Sampling method

Diffusion

Typical detection range

0...100 ppm

0...2000 ppm

Maximum overload

500 ppm

4000 ppm

Resolution / digital unit

0.1 ppm

1 ppm

Response time T90

< 30 s

< 25 s

Operating temperature

-30...+50 °C

-40...+50 °C

Sensor lifetime

> 2 years

Calibration interval

6 months

Signal update

Every 1 second

Power supply

11...30 VDC,

24 VAC or 90...265 VAC as options

Power consumption

< 2 VA

Analog outputs

2 × 4-20 mA / 0-10 V, user settable

Load resistance

RL< (Us - 2 V) / 22 mA for 4-20 mA

RL> 250 kOhm for 0-10 V mode

Digital interface

RS485, Modbus RTU protocol; No galvanic isolation

Enclosure

Grey ABS, wall mount, protection class IP65

Dimensions

H90 × W145 × D55 mm

(overall dimensions H140 × W145 × D55 mm)

Outputs assignment

OUT1 gas; OUT2 gas

NOTE! for the LCD version only output 1 is available

Output scale width

> 10 × resolution

Recommended: 20-100% of the detection range

CE marking

According to 2014/30/EU and 2014/35/EU, EN 50491-4-1:2012

EN 61000-6-3:2020, EN 61326-1:2013(EMC, emissions)

EN 61000-6-1:2019, EN 61000-6-2:2019(EMC, Immunity)

EN 60079-29-1:2016, EN 60079-29-2:2015 and EN 60079-29-3:2014

Operating conditions

(operating temperature is speciﬁed above)

15...90% RH Non-condensing, 0,9...1,1 atm

Explosion-safe areas,

Non-aggressive atmosphere

E2638-H2S Rev 21.06.2021

Relay option

Output relays

2 × SPST relays (closing contact),

250 VAC / 30 VDC, 5 A max

Default alarm setpoints

(set/release)

LOW: 10 ppm/ 8 ppm

HIGH: 20ppm/16 ppm

Determined by user

within 5-95% of the range

Signaling options

Visual

Red and green LEDs

Acoustic alarm

Buzzer 85 dB

LCD indicator option

Operating temperature

0...+50 °C

Display dimensions

72 × 36 mm

Number of digits

3.5 7-segment

Character height

14 mm

Other features

backlight

Other options

Remote probe

Protection IP65, default cable length 3.0 m;

max height 80 mm, max diameter 65 mm

E2638-H2S Rev 21.06.2021

Product description

E2638 series detectors-transmitters belong to the PluraSens® family of multifunctional

measurement instruments. The instruments utilize gas sensors of various types with

excellent repeatability, stability, and long lifetime.

E2638 series provides two independent analog outputs OUT1 and OUT2, user-selectable to

4-20 mA or 0-10 V, proportional to gas concentrations. RS485 Modbus RTU digital

communication interface allows easy instrument conﬁguration and integration into various

automation systems.

The following features are available as an option:

●Two relays RE1 and RE2 with closing contacts. Relay outputs can be used to

switch alarm sirens, ventilation fans, shut-off valves, or other actuators,

●Acoustic (85 dB buzzer) and visual (red and green LED) signaling,

●24 VAC or 230 VAC as options for power supply module,

●LCD indicator,

●Remote probe.

The version of your device is marked on the package. If the symbol

⚠

is marked on the

equipment, consult the documentation for further information.

Safety requirements

Misuse will impair the protection of the product. Always adhere to the safety provisions

applicable in the country of use.

Do not perform any maintenance operation with the power on. Do not let water or foreign

objects inside the device.

Removal of the PCB from the enclosure voids the warranty. Do not touch the electronic

components directly, as they are sensitive to static electricity.

Connection diagrams can be found in the electrical connections section. The device might

not perform correctly or be damaged if the wrong power supply is connected.

External circuits connected to the equipment should have suﬃcient insulation rating

according to the environmental conditions and equipment power.

A disconnecting device that is marked as such and easily accessible should be included in

the installation of this product.

E2638-H2S Rev 21.06.2021

Operating conditions

The device should be used both in a non-hazardous area and in a basic electromagnetic

environment, where the latter is deﬁned in EN 61326-1. Avoid strong mechanical shock and

vibrations. Avoid corrosive atmosphere and areas highly contaminated with dust, oil mist,

etc. Keep the instrument away from direct sunlight. A sudden temperature or humidity

change might affect the sensitivity of the sensor.

Installation guidelines

Before proceeding with the installation it is mandatory to read the Safety requirements

section and make sure to comply with all listed instructions. Installation standards EN

60079-29-2 and EN 45544-4 are also recommended for further instructions and related

information about the installation. During the installation of the detector-transmitter the

following points must be considered:

●Application (air quality control or leakage detection)

●Properties of the space under investigation (room geometry, direction, and

velocity of airﬂows, etc.),

●Hydrogen sulﬁde is slightly heavier than air and spreads evenly in the room. The

recommended location is close to the potential leakage source.

●The device should be accessible for maintenance and repair.

The aforementioned conditions above will affect the coverage area of the device. however,

the coverage area for a transmitter is usually between 2.5 to 5 meters radius.

For early leakage detection install the sensor as close as possible to the potential leakage

sources (ﬂanges, valves, pressure reducers, pumps, etc.), taking into consideration other

points listed above.

For general area monitoring without deﬁnite leakage sources, the detectors should be

distributed evenly in the room.

For personal safety control, the detectors are installed in the breathing zone (at the height

of the head of people or animals). The recommended sensor position is vertical, pointing

downwards.

For installing the device, attach the device to the wall using provided screws through the

side mounting holes or key slots (see mountains dimensions).

E2638-H2S Rev 21.06.2021

Mounting dimensions

Front view

Bottom view

E2638-H2S Rev 21.06.2021

Sensor probe handling

The E2638 series devices are available with a remote probe. The remote probe is

connected to the main unit with a shielded cable. The default remote probe cable length is

3 m.

A) Wall mount remote probe with ﬁxing clamp (default version),

B) Remote probe with rubber ﬂange and three self-tapping screws (on request)

The sensor probes of all types are equipped with a hydrophobic microporous PTFE ﬁlter to

protect the sensor from dust, dirt, and water drops. The ﬁlter should be replaced if it gets

strongly contaminated. To replace the PTFE ﬁlter, unscrew the sensor head cap and

remove the old ﬁlter. Place a new ﬁlter into the cap and tighten it again.

NOTE! Never stab or press the ﬁlter near its center where the sensor is located since this

may damage the sensor. Do not remove the ﬁlter as it may cause the device to show

incorrect values and/or break the sensor.

The recommended orientation of the sensor probe is vertical with the sensor tip pointing

downwards. This prevents the possible accumulation of condensed water on the sensor

protection ﬁlter.

Gas sensor replacement procedures

1. Remove the sensor head cap from the device (or the remote probe),

2. Remove the PTFE ﬁlter (if it is not removed within the cap),

3. Remove the O-ring rubber,

4. Detach the electrochemical sensor from the device,

5. Insert the new electrochemical sensor inside,

6. Put back the O-ring rubber, PTFE ﬁlter, and the head cap, respectively.

E2638-H2S Rev 21.06.2021

Electrical connections

Unscrew four lid screws and detach the lid from the device. Use two M16 cable glands to

let in the cables of the power supply and of the external devices. Without turning on the

power, plug the power cable, and connect the analog/relay outputs and/or digital interface

terminals to the necessary devices according to the relevant connection diagram.

Version with PSU and relays Version with PSU and without relays

Version without PSU and with relays Version without PSU and relays

Table des matières

Autres manuels Evikon Émetteur

Evikon

Evikon PluraSens E2611-HFC Manuel utilisateur

Evikon

Evikon PluraSens E2618-Cl2 Manuel utilisateur

Evikon

Evikon PluraSens E2618-O3 Manuel utilisateur

Evikon

Evikon PluraSens E2218 Manuel utilisateur

Evikon

Evikon PluraSens E2648-ETO Manuel utilisateur

Evikon

Evikon PluraSens E2418DP Manuel utilisateur

Evikon

Evikon PluraSens E2648-H2S Manuel utilisateur

Evikon

Evikon PluraSens E2658-NH3-E Manuel utilisateur

Evikon

Evikon E2615-NO2 Manuel utilisateur

Evikon

Evikon PluraSens E2648-NO2 Manuel utilisateur

Evikon

Evikon E2618-C2H2 Manuel utilisateur

Evikon

Evikon PluraSens E2227 Manuel utilisateur

Evikon

Evikon PluraSens E2638-SO2 Manuel utilisateur

Evikon

Evikon PluraSens E2608-NO Manuel utilisateur

Evikon

Evikon PluraSens E2608-H2S Manuel utilisateur

Evikon

Evikon PluraSens E2638-VOC Manuel utilisateur

Evikon

Evikon E2615-H2S Manuel utilisateur

Evikon

Evikon PluraSens E2618-NO Manuel utilisateur

Evikon

Evikon E2618-H2 Manuel utilisateur

Evikon

Evikon E2618-CO Manuel utilisateur

Evikon

Evikon PluraSens E2670-Cl2 Manuel utilisateur

Evikon

Evikon PluraSens E2648-CO2 Manuel utilisateur

Evikon

Evikon PluraSens E2618 Series Manuel utilisateur

Evikon

Evikon E2660-CO-CO2 Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
