Evertz 2400PSUA-8 Manuel utilisateur

2400PSUA-8

8 Channel Power Supply for 240xLT/LR Series

Instruction Manual

EVERTZ MICROSYSTEMS LTD.

5292 John Lucas Drive,

Burlington, Ontario, Canada

L7L 5Z9

Phone: +1 905-335-3700 Internet: Sales: [email protected]

Sales Fax: +1 905-335-3573 Tech Support: [email protected]

Tech Support Phone: +1 905-335-7570 Web Page: http://www.evertz.com

Tech Support Fax: +1 905-335-7571

Revision 1.2, January 2017

The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely

for the use of purchasers of the 2400 series products. Evertz Microsystems expressly prohibits the use of this manual for any

purpose other than the operation of the Routers.

Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz Microsystems.

This page left intentionally blank

IMPORTANT SAFETY INSTRUCTIONS

Model 2400PSUA-8

The lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of un-

insulated “Dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user

to the presence of important operating and maintenance (Servicing) instructions

in the literature accompanying the product.

•Read these instructions

•Keep these instructions.

•Heed all warnings.

•Follow all instructions.

•Do not use this apparatus near water

•Clean only with dry cloth.

•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than other. A grounding-type plug has two blades and a third

grounding prong. The wide blade or the third prong is provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

•Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles and the point where they exit from the apparatus.

•Only use attachments/accessories specified by the manufacturer

•Unplug this apparatus during lightning storms or when unused for long periods of time.

•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has

been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC –

SHOCK, DO NOT EXPOSE THIS APPARATUS

TO RAIN OR MOISTURE

WARNING

DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO

OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT

WARNING

TO COMPLETELY DIS

CONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE

POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE

WARNING

THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

IMPORTANT SAFETY INSTRUCTIONS

Model 2400PSUA-8-WP

The lightning flas

h with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of un-insulated “Dangerous voltage”
