EverFocus EZ230 Manuel utilisateur

-R

User’s Manual

and

Operation Instructions

Notice

This manual is presented to the users of EZ230/235 by EverFocus

Electronics Corp. With years of engineering researches, EverFocus

has spared no effort to provide the high quality products to the

worldwide users. For the policy of continual product improvement,

EverFocus reserves the right to make changes to the product

specifications and documentation without notice. All the components

of the products, including accessories, components, and outlook, are

based on the agreements of each deals to satisfy all kinds of users.

Meanwhile, please be advised that every step of operation must follow

the instruction of this manual to keep EZ230/235 working under the

best condition. Please notice that EverFocus will not be charged any

claims or renewing cases resulted from inappropriate operation.

Table of Contents

Safety Warning …………………………………………1

Introduction……………………………………………..3

Specification…………………………………………….4

Safet

Warnin

Be careful when handling the camera, do not drop it or

subject it to strong shock or vibration to prevent any

damages to it. Do not disassemble it or place it on an

unstable base.

Installed the camera away from TV, radio transmitter,

magnet, electric motor, transformer, audio speakers

because the magnetic fields generate from above devices

will distort the video image.

Installed the camera away from stoves, or other heat

generating devices as the high temperature could cause

deformation, discoloration or other damages of the

camera. Install the camera at where the temperature

range will stay between -46℃to 50℃(-50℉to 122℉).

Never aim the camera at the sun or other extremely bright

objects whether it is in use or not.

Do not touch the surface of CCD sensor by hand directly.

Use a soft cloth to remove the dirt from the camera body.

Use lens tissue or a cotton tipped applicator and ethanol

to clean the CCD sensor and the camera lens. When

the camera is not in use, put the cover cap on the lens

mount.

Do not touch the surface of CCD sensor by hand directly.

Use a soft cloth to remove the dirt from the camera body.

Use lens tissue or a cotton tipped applicator and ethanol

to clean the CCD sensor and the camera lens. When

the camera is not in use, put the cover cap on the lens

mount.

All warnings on the products and in the operating instructions

should be adhered to.

Do not use attachments not recommended by the appliance

manufacturer as they may cause hazards

Do not allow anything to rest on the power cord. Do not locate

this appliance where the cord will be abused by persons

walking on it.Do not overload wall outlets and extension cords

as this

can result in fire or electric shock.

 Never push objects of any kind into his appliance through

cabinet slots as they may touch dangerous voltage points or

short out parts that could result in fire or electric shock.

 Refer all work related to the installation of this product to

qualified service personnel or system installers.

Introduction

The new EZ230/235 series offers great performance in 1/3”image

format color CCD camera. The EZ230/235 is ideal for outdoor

applications such as parking lots, gas stations or shopping malls.

The sophisticated circuit design provides a heater that turns on at 10

℃for cold weather. The EZ230/235 will provide protection against

the elements and provide an excellent quality picture.

Main Features :

Middle-Resolution: 380 TV Lines(NTSC) & 340 TV Lines (PAL).

Two types of built-in vari-focal lens for versatile applications.

Designed with sturdy aluminum shell specifically for outdoor

surveillance.

Removable sun shield.

The heater allows the camera to be used in extremely low

temperature to -46°C.

ecification

Pickup Device: 1/3”Interline transfer CCD

Picture Element: 510 x 492 (NTSC)/500 x 582 (PAL)

Horizontal Resolution: 380 TVL (NTSC)/340 TVL (PAL)

Sensitivity: 3.5 Lux/F=2.0, 0.95 Lux/F=1.2(AGC ON)

0 Lux (IR ON) turn to B/W mode

S/N ratio: Over 48 dB

Back light compensation: ON

Auto Gain control: ON

Auto White Balance: YES

Gamma Correction: > 0.45

Electronic shutter: Up to 1/100,000 sec

Video output: 1.0vp-p, 75ohm

Power rate: 12V DC ±10%, 300mA

Sync. Mode: Internal Sync.

Lens Mount: M12 x P0.5 Yes

Dimension: 106 mm D x 85 mm H

Operating Temperature: -20℃to+50℃

Power Consumption: 4W

Lens: 4.3 mm/6 mm/8 mm optional

IR Wavelength: 850nm

IR distance: 30M for EZ230; 50M for EZ235

IR status: Under 25 Lux by CDS auto control

Led life: More than 20,000 hours

EverFocus Electronics Corp.

P/N : MW01G00400

Head Office:

12F, No.79 Sec. 1 Shin-Tai Wu Road,

Hsi-Chih, Taipei, Taiwan

TEL: +886-2-26982334

FAX: +886-2-26982380

www.everfocus.com.tw

USA Office:

1801 Highland Ave. Unit A

Duarte, CA 91010, U.S.A.

TEL: +1-626-844-8888

FAX: +1-626-844-8838

www.everfocus.com

European Office:

Albert-Einstein-Strasse 1

D-46446 Emmerich, Germany

TEL: 49-2822-9394-0

FAX: 49-2822939495

www.everfocus.de

China Office:

Room 609, Technology Trade Building,

Shandgdi Information Industry Base,

Haidian District, Beijing,China

TEL: +86-10-62971096

FAX: +86-10-62971432

www.everfocus.com.cn

Japan Office:

1809 WBG MARIBU East 18F,

2-6 Nakase.Mihama-ku.

Chiba city 261-7118, Japan

TEL : +81-43-212-8188

FAX : +81-43-297-0081

www.everfocus.com
