EverFocus ED300 Series Manuel utilisateur

ED300 Series

User’s Manual

and

Operation Instructions

Version 1.0

Table of Contents

Notice ............................................................................................. 1

Safety Warning............................................................................... 2

Introduction.................................................................................... 3

Specification................................................................................... 4

Major Parts Names and Functions.......................................... 5

Installation Instructions............................................................ 7

Adjustments................................................................................ 8

Lens Adjustments ...................................................................... 9

Notice

This manual is presented to the users of ED300 by EverFocus Electronics Corp.

With years of engineering researches, EverFocus has spared all efforts to provide

the high quality products to the worldwide users. For the policy of continual

product improvement, EverFocus reserves the right to make changes to the

product specifications and documentation without notice. All the components

of the products, including accessories, components, and outlook, are based on

the agreements of each deals to satisfy all kinds of users. Please be advised that

every step of operation must follow the instruction of this manual to keep ED300

working under the best condition. Please notice that EverFocus will not be

charged any claims or renewing cases resulted from inappropriate operation.

1. Do not expose the camera to humidity and dust.

Moisture can damage the camera and cause the danger of electric

shock. If the camera is mounted outdoors, a camera housing is

required. Do not install the camera at where there is greasy

smoke or steam, where the humidity is too high, or where there is a

lot of dust to prevent damages to the camera.

2. Do not disassemble the camera.

Do not disassemble the camera body as it is dangerous and may

cause the damages to the camera. Refer all servicing to qualified

service personnel.

3. Handle the camera with care.

Be careful when handling the camera, do not drop it or subject it

too strong shock or vibration to prevent any damages to it.

4. Do not install the camera near electric or magnetic fields.

Installed the camera away from TV, radio transmitter, magnet,

electric motor, transformer, audio speakers because the magnetic

fields generate from above devices will distort the video image.

Safet

Warnin

5. Do not install the camera in the high temperature environment.

Installed the camera away from stoves, or other heat generating

devices, or where it could be subject to direct sunlight as the high

temperatures could cause deformation, discoloration or other

damages of the camera. Install the camera at where the

temperature range will stay between 0to 50(32to 122).

6. Cleaning

Use a soft cloth to remove the dirt from the unit. Use lens tissue

or a cotton tipped applicator and ethanol to clean the camera lens.

The ED300 Series Cameras are compact, full functioned CCD Color Cameras. Their

stylish appearance can be applied as per installer's ideal locations on the ceiling. The

dome camera designed with advanced digital processing curcuitry for high resolution

1/4" color interline transfer CCD sensor, it has DIP switch for AGC on/off, BLC on/off.

The dome camera uses a vari focal auto iris lens for discreet surveillance or close-up

viewing and it features with iris LEVEL volume control for the best viewing quality.

Main Features

Designed with advanced digital signal processing circuitry for high image quality.

The high sensitivity of 1.0 lux / F=1.2 is achieved by high-resolution 1/4” Interline

transfer CCD.

Built-in Vari Focal type, mechanical auto iris lens, f=2.8-5.8mm, F=1.4-1.8.

Able to adjust the viewing range with manual zoom lens. 

With manual PAN/TILT mechanism.

BLC and AGC function on/off switchable.

Compact size : 108mm O.D. x 80mm H.

System available for NTSC or PAL

Introduction

Pickup device: 1/4" Interline transfer CCD

Video format: NTSC/PAL

Scanning system: NTSC: 525 TV lines, 60 fields/sec; PAL: 625 TV lines, 50 fields/sec.

Picture elements: NTSC: 811(H) x 508 (V); PAL: 795 (H) x 596 (V)

Effective picture elements: NTSC: 768 (H) x 494 (V); PAL: 752 (H) x 582 (V)

Horizontal resolution: 480 TV lines

Sensitivity: 1.0 lux / F=1.2

S/N ratio: > 48 dB

Varifocal lens: f=2.8~5.8mm, F1.4~1.8 manual zoom and focus adjustment,

mechanical auto IRIS

IRIS level: Adjustable

Back light comp.: On / Off Switch

Auto Gain Control: On / Off Switch

Auto white balance: Yes

Gamma correction: 0.45

Monitor output pin: Yes, 1.0 Vp-p / 75 ohm, test point pin

Video output: 1.0Vp-p/75ohm

Sync. mode: Internal sync.

Audio Available for model ED300A

Power source 12VDC, 300mA

Dimension: 108 mm O.D. x 80 mm H

Operating temperature: 0oC to +50oC

Power consumption: 5W max.

ecification

ED300ED300A(with audio)

Major Parts Names and Functions

1111

1212

1313

)

1212

1111

)

))

)Camera Cover

This cover will protect the camera from dust

and damage.

$Lens

This Vari-Focal Lens allows users to adjust

the Zoom and Focus manually.

#Base

The camera unit is set in the dome base when

it is shipped from the factory.

%Focus Ring

To set the focus, loosen the Focus ring knob

first, then turn the ring toward <FAR> or

<NEAR> as necessary. When the focus is

obtained as desired, tighten the focus ring

knob.

&Zoom Ring

Loosen the zoom ring knob, then you can

adjust the viewing range. Turn the ring

towards <WIDE> or <TELE> as necessary.

When the setting is finished, tighten the

zoom ring knob.

'Auto Gain Control on/off switch.

The factory setting is AGC on.

(

((

(Back Light Compensation on/off

switch

The factory setting is BLC off.

*Level Volume Control

The iris level control for the lens.

+Ground Pin

For monitor use. Please see ,.

,Monitor Pin

When setting up the camera, connect a

monitor to this video output pin and to the

GROUND pin using alligator clip cables, then

using the image displayed on the monitor, set

the surveillance angle.

Power input DC-JACK

Use the connector to connect with

12VDC-power adaptor.

Video Output BNC Connector

Use the connector to connect with the video in

connector of a monitor.

Audio Output RCA Connector

Use the connector to connect with the audio in

connector of a monitor.

1212

1313

1111
