ETC Source 4WRD II Manuel utilisateur

Source 4WRD II

HPL to LED Retrofit (CE)

Installation and User Manual

Version 1.9.0

Part Number: 7067M1210-1.9.0 Rev A

Released: 2020-10

To view a list of ETCtrademarks and patents, go to

etcconnect.com/ip. All other trademarks, both marked and not

marked, are the property of their respective owners.

ETC intends this document, whether printed or electronic, to be

provided in its entirety.

Table of Contents

Source 4WRD II Installation and User Manual i

Introduction 1

Help from ETC Technical Services 2

Safety 3

Retrofit the Fixture 6

Wire the Power Connector 6

Remove Incandescent Lamp Housing 7

Install the Source 4WRD II Retrofit 8

Install the Fixture 10

Attach Hanging Clamp and Safety Cable 10

Connect Cables 11

Configure the Fixture 14

RDMValues 14

Focus the Fixture 15

Set the Z-adjustment 15

Adjust the Yoke Position 16

Shape the Beam 17

Troubleshoot the Source 4WRD II 18

Clean and Maintain the Fixture 19

Clean the Fixture 19

Store the Retrofit 19

Clean the Lenses 20

Clean the Reflector 21

Clean 5° and 10° Polymer Lenses 22

ii Source 4WRD II Installation and User Manual

Source 4WRD II Installation and User Manual 1

Introduction

The Source 4WRDII LED is a replacement for a standard Source Four

burner assembly. It converts the HPL source to a white-light LED and

provides a significant reduction in power consumption.

The Source 4WRDII LED retrofit kit is available in 80 CRI, 90 CRI (Gallery),

and 90 CRI Daylight (Gallery) variants.

Retrofit kit,

shown installed

on a Source Four

fixture body

Note:

The Source 4WRDII LED retrofit kit is not compatible with

Source Four LED, Fresnel, PAR, PARNel, or jr fixtures.

2 Source 4WRD II Installation and User Manual

Help from ETC Technical Services

If you are having difficulties and your problem is not addressed by this

document, try the ETC support website at support.etcconnect.com or the

main ETC website at etcconnect.com. If none of these resources are

sufficient, contact ETC Technical Services directly at one of the offices

identified below. Emergency service is available from all ETC offices

outside of normal business hours.

When calling for help, take these steps first:

•

Prepare a detailed description of the problem

•

Go near the equipment for troubleshooting

•

Find your notification number if you have called in previously

Americas United Kingdom

ETC, Inc. ETC Ltd

Technical Services Department Technical Services Department

3031 Pleasant View Road 26-28 Victoria Industrial Estate

Middleton, WI 53562 Victoria Road,

800-775-4382 (USA, toll-free) London W3 6UU England

+1-608 831-4116 +44 (0)20 8896 1000

service@etcconnect.com techservltd@etcconnect.com

Asia Germany

ETCAsia ETC GmbH

Technical Services Department Technical Services Department

Room 1801, 18/F Ohmstrasse 3

Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany

9 Sheung Yuet Road +49 (80 24) 47 00-0

Kowloon Bay, Kowloon, Hong Kong techserv-germany@etcconnect.com

+852 2799 1220

techserv-asia@etcconnect.com

France

ETC France

Zone Urbaparc -

Bâtiment E

6 Boulevard de la Libération

Saint-Denis, 93200

+33 1 4243 3535

techservltd@etcconnect.com

Source 4WRD II Installation and User Manual 3

Safety

The Source 4WRD II fixture is intended for professional use only. Read the

entire manual before using this equipment.

WARNING: This fixture must be installed by a qualified

electrician in accordance with all national and local electrical

and construction codes and regulations.

WARNING: Note the following safety warnings before use:

•

Do not mount the fixture on or near a flammable

surface.

•

Do not use this fixture with a damaged power lead. If

the power lead (cord set) is damaged, it must be

replaced.

•

Mount and support the fixture only by the primary

suspension holes in the yoke.

•

Suspend the fixture from a suitable structure using only

hardware rated for the weight of the fixture.

•

In addition to primary suspension, attach a safety cable

to the fixture housing. An appropriate attachment point

(hole) is provided in the protruding tab on the fixture

housing.

•

Disconnect the unit from power and DMX and allow the

fixture to cool before removing or installing accessories,

and before all cleaning and maintenance.

•

Do not cover the fixture with material that is used for

thermal insulation.

4 Source 4WRD II Installation and User Manual

WARNING: Note the following safety warnings before use:

•

The Source 4WRD II LED is not user serviceable. Field

modification of the Source 4WRD II LED will void your

ETC warranty.

•

Do not use the fixture below 5°C (41°F).

•

Minimum storage temperature is 5°C (41°F). When the

fixture has been stored or transported in cold

temperatures, allow it to warm to room temperature

for a minimum of 1hour before applying power.

Applying power to a cold fixture will cause damage to

the fixture and void the ETCwarranty.

•

Do not use this fixture if a glass lens is deeply scratched

or cracked. Damaged lenses must be replaced.

•

To prevent wiring damage, or abrasion, do not expose

wiring to edges of sheet metal or other sharp objects.

•

Use the fixture in dry locations only, where humidity

does not exceed 90 percent (non-condensing). These

fixtures are not intended for outdoor use.

Source 4WRD II Installation and User Manual 5

Specifications

For full product specifications, see the Source 4WRDII LED datasheet at

etcconnect.com.

Electrical

•

209–252 VAC 47–53 Hz power input

•

175 W draw at full

•

Recommended 2 fixtures per dimmed circuit (ED15 module)

•

Maximum of 6 fixtures per non-dimmed circuit (ER15AFR module)

•

If using in DMX mode: Connect fixture to relay, constant power, or

dimmer with regulation off and parked at full

•

Inrush: 12 A (first half-cycle)

Typical Power Consumption

Mode Power Current

Idle:DMXMode 3.7W .05A

Idle: ACMode 0W 0 A

Full Intensity 175W .75A

Environment

•

Ambient operating temperature: 5°C–50°C (41°F–122°F)

•

Minimum storage temperature: 5°C (41°F)

•

Maximum recommended ambient operating temperature:Ta=50°C

(122°F)

•

Maximum anticipated external surface temperature: Tmax=63°C

(145°F) at Ta=50°C (122°F)

•

External Temperature (steady state achieved) at 25°C (77°F)

ambient: 38°C (100°F)

Weight

•

Source 4WRDII LED retrofit kit only: 1.69kg (3.73lb)

•

Source 4WRDII LED installed on 26° fixture with yoke: 5.48kg

(12.1lb)

Optical

Compatible with all ETCSource Four lens tubes.

6 Source 4WRD II Installation and User Manual

Retrofit the Fixture

WARNING: RISK OF FIRE OR ELECTRIC SHOCK! Installing the

Source 4WRDII LED retrofit kit requires knowledge of

luminaire electrical systems. If you are not qualified, do not

attempt installation. Contact a qualified electrician.

Note:

THE RETROFIT KIT IS ACCEPTABLE AS A COMPONENT OF A

LUMINAIRE WHERE THE SUITABILITY OF THE COMBINATION SHALL

BE DETERMINED BY AUTHORITIES HAVING JURISDICTION.

Retrofit kit

LEDs

RJ45 data in

and data thru

User interface and

navigation buttons

Wire the Power Connector

If you ordered a Source 4WRD II retrofit without a power connector, wire

the connector in accordance with all national and local electrical codes:

•

Brown = Live

•

Blue = Neutral

•

Green/Yellow = Protective earth
