ETC CE Source Four Manuel utilisateur

CE Source Four

User Manual

Gebrauchsanleitung

Manuel d'utilisation

Manual del usuario

DECLARATION OF CONFORMITY

We, Electronic Theatre Controls, Europe Limited

Unit 5, Victoria Industrial Estate, London W3 6UU United Kingdom

declare under sole responsibility that the product

Product name: CE Source Four

Product type/model: CE Source Four series (405, 410, 419, 426, 436, 450)

Lot: n/a

Batch / Serial number: n/a

Item numbers: one of each model

to which this declaration relates is in conformity with the following standards:

EN60598-1:1993 Luminaires, General requirements and tests

EN60598-2-17:1989 Specification for luminaires for stage lighting, television,

film, and photographic studios.

following the provisions of EU LV Directive(s) 73/23/EEC

London, United Kingdom Mr. Adam Bennette

(Place of issue) (Name of authorised person)

_________________________ ____________________________

(Date of issue) (signature of authorized person)

Electronic Theatre Controls Europe Ltd. Registered office:

Unit 5, Victoria Industrial Estate, Grant Thornton House

Victoria Road, London W3 6UU U.K. Melton St., London, NW1 2BW, England

Telephone (+44) 181 896 1000 Registered in England No.3057796

Fax (+44) 181 896 2000 VAT No. 662 9487 90

CE Source Four 3

CE Source Four

Contents • Inhaltsverzeichnis • Table des matières • Indice

Specifications/Technische Daten

Spécifications/Especificaciones .......................................... 4

CE Source Four ................................................................... 5

CE Source Four Instructions ............................................... 7

CE Source Four Bedienungsanleitung .............................. 15

Mode d'emploi CE Source Four ........................................ 23

Instrucciones para CE Source Four ................................... 31

4CE Source Four

692mm

759mm

254mm max.

175mm min.

262mm

314mm

432mm

911mm

978mm

254mm max.

175mm min.

262mm

365mm

495mm

Specifications • Technische Daten

Spécifications • Especificaciones

10º Weight: 6.8kg

10º Gewicht: 6,8kg

10º Poids: 6,8kg

10º Peso: 6,8kg

5°Weight: 8.6kg

5°Gewicht: 8,6kg

5°Poids: 8,6kg

5°Peso: 8,6kg

19º, 26º, 36º, 50º CE Source Four

5º CE Source Four

10º CE Source Four

19º to 50º Weight: 6.3kg

19º bis 50º Gewicht: 6,3kg

19º à 50º Poids: 6,3kg

19°a 50°Peso: 6,3kg

337mm

426mm

200mm

254mm max.

175mm min.

222mm

546mm

613mm

CE Source Four 5

Spacer

Abstandshalter

Pièce d'écartement

Pieza separadora

Yoke locking knob

Bügelfeststellschraube

Poignée de serrage de la lyre

Maneta para fijar la lira

Secondary suspension point

Befestigungsmöglichkeit für Sicherungsseil

Point de suspension secondaire

Punto secundario de suspensión

Gel frame holder extender (model #400GE)

Abstandhalter für Farbrahmen (Modell #400GE)

Rallonge du porte-filtre (modèle #400GE)

Extensión del marco portagelatinas (modelo 400GE)

Barrel rotation knob

Knopf für Rotation des Basisgehäuses

Bouton de rotation du corps

Maneta de rotación del tubo

Earth continuity cable

Erdungskabel

Cable de mise à la terre

Cable de tierra

Colour frame

Farbrahmen

Porte-filtre

Portafiltros

Colour frame holder

Farbrahmenhalter

Glissière porte-filtre

Marco portafiltros

Beam focus knob

Fokussierknopf

Bouton de réglage du faisceau

Maneta de enfoque del haz

Lens tube

Linsentubus

Tube de lentille

Tubo de lentes

Barrel

Basisgehäuse

Corps

Tubo

Drop-in iris slot

Einschubfach für Irisblende

Logement d'iris amovible

Ranura para el iris

Shutters

Blenden

Couteaux

Cuchillas

Pattern holder slot

Einschubfach für Gobohalter

Logement de porte-gobo

Ranura del portagobos

Safety screen

Schutzgitter

Grille de protection

Rejilla de seguridad

Retainer bolt 2

Sicherungsschraube Nr. 2

Vis de retenue 2

Tornillo de fijación 2

Safety cable

(model #400SC)

Sicherungsseil

(Modell #400SC)

Câble de sécurité

(modèle #400SC)

Cable de seguridad

(modelo #400SC)

Retainer bolt 1

Sicherungsschraube Nr.1

Vis de retenue 1

Tornillo de fijación 1

Reflector

Reflektor

Réflecteur

Reflector

Yoke

Bügel

Lyre

Lira

Retaining clip

Sicherungsbügel

Clip de mantien

Clip de seguridad

Lamp housing

Lampengehäuse

Compartiment lampe

Cubierta de la lámpara

Reflector housing

Reflektorgehäuse

Compartiment réflecteur

Cubierta del reflector

Primary suspension yoke mounting holes

Hauptaufhängelöcher für Hängebügel

Trous de montage de la lyre de la suspension principale

Hoyos para el montaje de la lira de la suspensión primaria

CE Source Four

6CE Source Four

CE Source Four 7

English

CE Source Four instructions

Safety warnings

The CE Source Four high performance ellipsoidal spotlight is intended for

professional use only. Read entire

User Manual

before using equipment.

Please note the following safety warnings before use:

Do not mount the CE Source Four on or near a flammable surface.

Use the luminaire in dry locations only, where humidity does not exceed 90

percent. Luminaire is not intended for outdoor use.

Mount and support the luminaire only by the primary suspension yoke holes.

Suspend the luminaire from a hook clamp or a stand mount, using a securely

tightened steel bolt (up to 12 mm Ø), washer and locking nut.

In addition to primary suspension, attach a safety cable (Model 400SC) or

chain to the secondary suspension point on the luminaire (see page 5).

Open all four shutters completely before turning the luminaire on.

Always hang the CE Source Four with the colour frame retaining clip in the

locked position.

Always replace the lamp if it becomes damaged or thermally deformed.

Keep the luminaire at least 0.7 meters away from anything it is shining on.

Lighted objects at this distance or greater will not exceed 90ºC temperature

from projected light.

Disconnect the unit from power before all cleaning and maintenance.

Maximum ambient temperature: T

=45

Maximum exterior surface temperature: T

max

=200ºC

A multilanguage label sheet is included with this manual. Affix the label of

the appropriate language over the existing warning label on the extension

yoke. Do not cover ETC trademark or CE mark.

Wiring and power information

A plug of at least 2.5 amp (220/240V) rating should be attached to the

luminaire's mains lead. The wires in the mains lead are 1.5mm 2 each and

coloured in accordance with the following code:

Green and Yellow: Earth

Blue: Neutral

Brown: Live

Warning: This luminaire must be earthed.

Current rating: 120V/5 amp maximum

240V/2.5 amp maximum

Operating frequency: 50/60Hz

t 180°c

0.7m

8CE Source Four

English

HPL lamps

HPL lamps are tungsten halogen lamps.

Important: Verify that the HPL lamp you use is suitable for the voltage at

your facility. 115-, 120-, 230-, and 240-volt HPL lamps are available.

Operating HPL lamps above their rated voltage reduces lamp life and can

cause premature lamp failure.

Warning: Do not use lamps other than the HPL in CE Source Four

luminaires. Use of lamps other than HPL will void CE safety conformity

and warranty.

Installing the HPL lamp

Important: The lamp must be installed before you use the luminaire.

Caution: Always replace the lamp if it becomes damaged or thermally

deformed.

1. Disconnect the unit from power before installing and replacing the lamp.

Warning: Let lamp cool before changing.

2. Loosen the knurled bolt on the back of the lamp housing and pull the

housing straight out.

3. Remove the HPL lamp from its box, holding it by the base.

Note: To avoid premature lamp failure, do not touch the lamp glass. If

you touch the lamp, clean it carefully with rubbing alcohol and a clean,

lint-free cloth before operation.

4. Line up the flat sides of the lamp base with the retention brackets on

either side of the socket. See figure 1.

5. Push down on the lamp base until the lamp seats firmly. (The top of the

lamp base will be even with the top edges of the retention brackets

when it is properly installed.)

Caution: Improperly installed lamps cause premature lamp failure and

socket problems.

6. Press lamp retainers down across lamp base and clip securely.

7. To reinstall the lamp housing, line up the side fins and the bolt hole, then

tighten the knurled bolt to secure the housing.

edocpmaLsttaWstloVpmetroloCefildetarevA

032/575LPH575032K˚002,3ruoh004

042/575LPH575042K˚002,3ruoh004

511/573LPH573511K

˚052,3ruoh003

X511/573LPH573511K˚050,3ruoh000,1

77/055LPH05577K˚052,3ruoh003

X77/055LPH05577K˚050,3ruoh000,2

511/575LP

H575511K˚052,3ruoh003

X511/575LPH575511K˚050,3ruoh000,2

021/575LPH575021K˚052,3ruoh003

Euro.

American

HPL lamp

Lamp

retention

brackets

Lamp housing

Knurled bolt

Figure 1

Lamp

retainers

CE Source Four 9

English

Aligning the lamp

Use the two concentric knobs on the rear of the lamp housing to align the

lamp. The outer knob centres the lamp within the reflector and locks it in

position; the inner knob fine tunes the field. See figure 1.

Important: Power must be on to align the lamp.

1. Unlock the outer knob by turning it anticlockwise one turn.

2. Gently push the outer knob from side to side and up and down until

the lamp is centred in the field.

3. Once the lamp is centred, tighten the outer knob to lock it in place.

4. Turn the inner knob right or left to adjust for optimum flat field.

Focusing the beam

1. Loosen the beam focus knob on the underside of the barrel. See

figure 2.

2. Slide the lens tube forward or backward to achieve the desired beam

edge. (For optimum gel life, set soft focus by moving the lens as shown

on table below.)

3. Once the luminaire is focused, tighten the beam focus knob.

Gel notes

For best results, always use a high quality, high temperature color medium.

ETC does not guarantee performance with low temperature, saturated color

gels.

ETC's Source Four gel frame holder extender may help increase your gel life.

Contact ETC or your dealer for ordering information.

Knurled

bolt

Lamp

housing

Peak and flat

adjustment

(inner knob)

Centre

adjustment

(outer knob)

Figure 1

Beam focus knob

Yoke

Bolt and spacer

Figure 2

Yoke locking knob

erutxiF

noisreV

sucoFtfoS

kcaBebuT

prahS

sucoF

sucoFtfoS

drawroFebuT

5°✔✔ ✔

01 °✔✔ ✔

91 °✘✔ ✔

62 °✘✔ ✔

63 °✔✔ ✘

05 °✘✔ ✔

✔= better gel life ✘ = worse gel life

10 CE Source Four

English

Shaping the beam

You may shape the beam with the shutters, a pattern, an optional drop-in

iris, and/or by rotating the barrel.

Pattern projection

The pattern holder slot is on the top side of the barrel, immediately in front

of the shutters. It accommodates A-size, B-size and glass pattern holders.

Use an optional donut (model #400DN) in the accessory holder to enhance

pattern projection. Donut diameter should be 64mm to 70mm for 19º

through 50º lenses.

Drop-in iris slot

The drop-in iris slot is on the top side of the front barrel, immediately in front

of the pattern holder slot. It accommodates either a drop-in iris or a

motorized pattern device. When it is not in use, a small sheet metal cover

secured with two crosshead screws prevents light leakage and retains the

iris assembly. To install an iris, follow these steps:

1. Use a crosshead screwdriver to loosen the screws on the drop-in iris

slot cover. Do not remove the screws.

2. Slide the cover completely forward, exposing the slot.

3. Insert the iris or motorized pattern device. If you install an iris, the flat

side must be toward the shutters and the iris handle should extend out

of slot.

4. Slide the slot cover back toward the shutters until it meets the iris

handle. Leave enough space to move the iris handle. Tighten the

screws.

Rotating the barrel assembly

1. Loosen the barrel rotation knob directly behind the shutters on the

underside of the reflector housing.

Caution: Do not remove the barrel rotation knob.

2. Rotate the barrel to the desired position (up to 25°in either direction

from centred position.)

3. Once the barrel is positioned, tighten the barrel rotation knob to lock it

into position.

Drop-in iris slot

Figure 2

Iris

Barrel rotation knob

Bolt 1 and spacer

Yoke

Beam focus knob

Figure 3

Bolt 2

A-size pattern holder

for 8cm diameter

patterns

B-size pattern holder

for 7cm and 6.3cm

diameter patterns

Figure 1

79mm

diameter

94 mm

70mm

diameter

94 mm

Autres manuels pour CE Source Four

Table des matières

Langues :

Autres manuels ETC Équipement d'éclairage

ETC

ETC Source Four Revolution Scroller Cartridge Manuel utilisateur

ETC

ETC Source Four LED Series Guide d'installation

ETC

ETC Selador Series Manuel utilisateur

ETC

ETC XDLT 26 Manuel utilisateur

ETC

ETC fos/4 Series Manuel utilisateur

ETC

ETC Source Four CE 405 Manuel utilisateur

ETC

ETC GDS CueSystem Manuel utilisateur

ETC

ETC Source Four LED 3 Series Manuel utilisateur

ETC

ETC ArcSystem Pro One-Cell Series Manuel utilisateur

ETC

ETC Acclaim 100 series Manuel utilisateur

ETC

ETC HIGH END SYSTEMS LONESTAR Manuel utilisateur

ETC

ETC fos/4 Series Manuel utilisateur

ETC

ETC XDLT Manuel utilisateur

ETC

ETC Cyberlight LED Manuel utilisateur

ETC

ETC Lustr+ Manuel utilisateur

ETC

ETC High End Systems SolaPix 19 Manuel utilisateur

ETC

ETC Source Four Revolution Scroller Cartridge Manuel utilisateur

ETC

ETC Irideon AR50 Manuel utilisateur

ETC

ETC Desire D22 Manuel utilisateur

ETC

ETC Sensor IQ Contact Input Control Option Card Manuel utilisateur

ETC

ETC Source Four LED Series Manuel utilisateur

ETC

ETC Source Four LED Series Manuel utilisateur

ETC

ETC Irideon WLZ Manuel utilisateur

ETC

ETC ColorSource Spot VXT Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
