E+E Elektronik EE150 Manuel utilisateur

SCOPE OF SUPPLY

• Foraccuratemeasurementitisessentialthatthetemperatureoftheprobeandmainlyofthesensingheadissameasthe

temperatureoftheairtomeasure.

• AvoidmountingtheEE150transmitterinawaywhichcreatestemperaturegradientsalongtheprobe.Ifpossible,EE150shall

beinstalledwiththeentireprobeinsidetheduct.Forinstallationwithmountingflange,incaseofdifferenttemperatureinside

andoutsidetheduct,theprobepartoutsidetheductshallbethermallyisolated.

• Thedeviceandmainlythesensingheadshallnotbeexposedtoextrememechanicalstress.

• Donotattempttoremovethefilercap,whichisfixed.Avoidtouchingthesensingheadatalltimes.

• ThestainlesssteelprobeisESDsensitiveandshallbehandledassuch.Donotconnectittothegroundpotential.

CAUtiOn

USER‘S GUIDE

COnnECtiOn diAgrAm

EE150 - Humidity and Temperature Transmitter for HVAC applications

(class III)

T-passive connection

for HT3xxx/HT6xxx

EE150-HT3xxx

EE150-HT6xxx

dimEnSiOnS / mOUnting

CABLE GLAND M16x1.5

80.8 (3.18)

56 (2.2)

63 (2.48)

55.3 (2.18)

39.5 (1.56)

ø 5 (ø 0.2)

ø 4 (ø 0.16)

ø 6

(ø 0.24)

ø 7

(ø 0.28)

42 (1.65)

28.55

(1.12)

200

(7.87)

drilled hole for

mounting: ø>9 (ø>0.35)

Dimensions: mm (inch)

setupandadjustmentinterface(withEE-PCA)

• EE150transmitter,typenumberaccordingtoorder(fororderingguideseedatasheetatwww.epluse.com/EE150)

• CableglandM16x1.5

• Mountingflange,PC,Ø6.0mm

• TestreportaccordingtoDINEN10204–2.2

tECHniCAL dAtA

(Modification rights reserved)

INFORMATION +43 7235 605 0 / inf[email protected]

Langwiesen7•A-4209Engerwitzdorf

Tel:+437235605-0•Fax:+437235605-8

[email protected]•www.epluse.com

LGLinzFn165761t•UID-Nr.ATU44043101

PlaceofJurisdiction:A-4020Linz•DVR0962759

BA_EE150_e//v1.0//TechnischeÄnderungenvorbehalten

TheEE150isreadytouseanddoesnotrequireanycongurationbytheuser.ThefactorysetupofEE150correspondstothetypenum-

berordered.Fororderingguidepleaseseedatasheetatwww.epluse.com/EE150.

Ifneeded,theusercanchangethefactorysetupbyusingtheoptional E+E Product ConfigurationAdapter (EE-PCA) and the E+E

ProductConfigurationSoftware(EE-PCS).Withthese one can set the output scaling, and perform one or twopointadjustmentfor

humidityandtemperature.

ForproductdatasheetEE-PCApleaseseewww.epluse.com.

TheE+EProductConfigurationSoftware(EE-PCS)isfreeandcanbedownloadedfromwww.epluse.com/configurator.

SEtUP And AdJUStmEnt

USA

FCC notice:

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsare

designedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiatera-

diofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstallationmanual,maycauseharmfulinterferencetoradiocommunications.

However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneor

moreofthefollowingmeasures:

- Reorientorrelocatethereceivingantenna.

- Increasetheseparationbetweentheequipmentandreceiver.

- Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.

- Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

CANADIAN

ICES-003 Issue 5:

CANICES-3B/NMB-3B

Measured values

Relative Humidity

 Workingrange 10...90%RH

 Accuracyat20°C ±3%RH(30...70%RH),otherwise±5%RH

 Temperaturedependency typ.±0.05%RH/°C

Temperature

 Workingrange -5...55°C(23...131°F)

 T-Accuracyat20°C ±0.3°C

Outputs

Analog output 0-10V RL≥10kOhm

 (0...100%RH;T:seeorderingguide) 4-20mA(2-wire) RL≤500Ohm

Passive T-sensor

 2-wire seeorderingguide

 Wiresresistance(terminal-sensor) typ.0.5Ohm

General

Powersupply(ClassIII)

 for0-10V 15-35VDCor24VAC±20%

 for4-20mA 10V+RLx20mA<UV<35VDC

 Currentconsumption withDCpowersupply typ.5mA

  withACpowersupply typ.13mAeff

 Connection Screwterminals,max.1.5mm2

 Housingmaterial Polycarbonate,UL94V-0approved

 Protectionclass IP65/NEMA4

 Cablegland M16x1.5

 Sensorprotection PTFEfilter,non-removable

 Electromagneticcompatibility EN61326-1EN61326-2-3Industrialenvironment

   FCCPart15ClassBICES-003Issue5ClassB

 Workingconditions -5...55°C (23...131°F) 0...95%RH(non-condensing)

 Storageconditions -25...60°C(-13...140°F) 20...80%RH
