Emerson PACSystems IC695ACC302 Manuel utilisateur

IMPORTANT PRODUCT INFORMATION

GFK-2592D

Jul 2023

PACSystemsTM

AUXILIARY SMART BATTERY MODULE

(IC695ACC302)

GFK-2592D Jul 2023

Warnings and Caution Notes as Used in this Publication

WARNING

Warning notices are used in this publication to emphasize that hazardous voltages, currents,

temperatures, or other conditions that could cause personal injury exist in this equipment or may be

associated with its use.

In situations where inattention could cause either personal injury or damage to equipment, a Warning

notice is used.

CAUTION

Caution notices are used where equipment might be damaged if care is not taken.

Note: Notes merely call attention to information that is especially significant to understanding and

operating the equipment.

These instructions do not purport to cover all details or variationsin equipment, nor to provide for

every possible contingency to be met during installation, operation, and maintenance. The

information is supplied for informational purposes only, and Emerson makes no warranty as to

the accuracy of the information included herein. Changes, modifications,and/or improvements to

equipment and specifications are made periodically and these changes may or may not be

reflected herein. It is understood that Emerson may make changes, modifications, or

improvements to the equipment referenced herein or to the document itself at any time. This

document is intended for trained personnel familiar with theEmerson products referenced herein.

Emerson may have patents or pending patent applications covering subject matter in this

document. The furnishing of this document does not provide any license whatsoever to any of

these patents.

Emerson providesthe following document andthe information included therein as-is and without

warranty of any kind, expressed or implied, including but not limited to any implied statutory

warranty of merchantability or fitness for particular purpose.

GFK-2592D Jul 2023

Introduction

The IC695ACC302 Auxiliary Smart Battery module is an enhanced version of the IC693ACC302 Auxiliary

Battery module. The IC695ACC302 Auxiliary Smart Battery module provides extended volatile memory

backup time compared to that of the standard coin cell batteries for PACSystems CPUs and includes reliable

low battery detection for compatible CPUs.

For details on the operation of specific CPU models, refer to the PACSystems CPU Reference Manual

(GFK-2222).

Foradditional details on battery installation, operation, safe handling and disposal, and agency certifications,

refer to the PACSystems Controllers Battery and Energy Pack Manual (GFK-2741).

Date Code

The date code is located on the product labelat the right bottom edge. Thedate codeconsists of fourdigits,

such as 1011. The first two digits represent the year of manufacture in the 21st century, such as 10 for the

year 2010. The last two digits represent the fiscal week of manufacture for the indicated year (for example

11 stands for fiscal week 11).

Installation Information

While installing thebattery to the CPU, first connect thefour-pin MaleJAEconnector on the enabling adapter

cable to the female four-pin JAE connector on the battery module as displayed in the following figure.

(Installing the four-pin connector enables the battery.)

Note: The battery will begin to drain immediately if attached to the CPU in Power OFF condition. To maximize

battery life, it is recommended that you install the fresh battery after power has been turned ON to the

attached CPU.

Once the enabling adapter cable is connected, the battery starts to drain, even if it is not attached to the

CPU. It is recommended to disconnect the enabling adapter cable from the battery module when the

battery is not in use. Even though the discharge currentwould be negligible with just the enabling adapter

cable connected, this can affect battery life if left in this condition for long durations.

WARNING

•The battery used in this device may present a risk of fire, explosion,orchemical burn if mistreated. Do

not short-circuit, crush, disassemble, or dispose of with fire.

•Use of a battery not specified by the manufacturer may present a risk of fire or explosion.

DANGER

EXPLOSION HAZARD

Do not install or replace the battery module unless the area is known to be non-hazardous.

Safe Handling and Disposal

For safe handling and disposal of dead battery modules, reference the manufacturer’s Material Safety Data

Sheet (MSDS) and the Battery Disposal Document included with this product.

GFK-2592D Jul 2023

Release History

Catalog

Numbers

Version

Date

Comments

IC695ACC302-CB

1.1

Jun 2023

•Change in component production location. No change to fit,

form, nor functionality.

•Product labels have been updated to show compliance with new

certifications. For updated certifications, please refer to

•https://emerson-

mas.force.com/communities/en_US/Article/Certifications-and-

Agency-Approvals-Landing-Page

•Removed ATEX markings from the product label.

•Removed EAC markings from product label.

IC695ACC302-BB

1.1

Sep 2019

Following Emerson’s acquisition of this product, changes have been

made to apply appropriate branding and registration of the product

with required certification agencies. No changes to material, process,

form, fit or functionality.

IC695ACC302-AB

1.1

Aug

2012

Resolves issue with indication of correct low battery period when

used with higher versions of RX7i CPUs

IC695ACC302-AA

1.0

Mar

2011

Initial release

Problems Resolved in this Version

None

Related Documents

PACSystems CPU Reference Manual (GFK-2222)

PACSystems RX7i Installation Manual (GFK-2223)

PACSystems RX3i System Manual (GFK-2314)

PACSystems Controllers Battery and Energy Pack Manual (GFK-2741)




General Contact Information
Home link: http://www.emerson.com/industrial-automation-controls
Knowledge Base: https://www.emerson.com/industrial-automation-controls/support

Technical Support
Americas
Phone: 1-888-565-4155
 1-434-214-8532 (If toll-free option is unavailable)

Customer Care (Quotes/Orders/Returns): customercare.mas@emerson.com
Technical Support: support.mas@emerson.com

Europe
Phone: +800-4444-8001
 +420-225-379-328 (If toll-free option is unavailable)
+39-0362-228-5555 (from Italy - if toll-free800 option is unavailable or dialing from a mobile
telephone)

Customer Care (Quotes/Orders/Returns): customercare.emea.mas@emerson.com
Technical Support: support.mas.emea@emerson.com

Asia
Phone: +86-400-842-8599
 +65-6955-9413 (All other Countries)

Customer Care (Quotes/Orders/Returns): customercare.cn.mas@emerson.com
Technical Support: support.mas.apac@emerson.com

Any escalation request should be sent to: mas.sfdcescalation@emerson.com
Note: If the product is purchased through an Authorized Channel Partner, please contact the seller
directly for any support.
Emerson reserves the right to modify or improvethe designs or specificationsof theproducts mentioned in
this manual at any time without notice. Emerson does not assume responsibility for the selection, use or
maintenance of any product. Responsibility for proper selection, use and maintenance of any Emerson
product remains solely with the purchaser.

© 2023 Emerson. All rights reserved.
Emerson Terms and Conditions of Sale are available upon request. The Emerson logo is a trademark and service mark
of Emerson Electric Co. All other marks are the property of their respective owners.
