RM5800 User Manual

Revision B.1 1

RM5800 User Manual

Emerson™Automation Solutions, Rosemount® Inc

Revision B.1

18 March 2022

RM5800 User Manual




Revision B.1 2
1CONTENTS
Purpose .................................................................................................................................................3
General Information .............................................................................................................................3
1 Product Description ......................................................................................................................3
Product Specifications...........................................................................................................................3
1 Operational Description................................................................................................................3
2 Normal Operating Conditions.......................................................................................................3
3 Radio Specifications ......................................................................................................................4
4 Antenna Specifications..................................................................................................................4
Integration Instructions ........................................................................................................................5
1 Design description.........................................................................................................................5
1.1 Device Photo .........................................................................................................................5
2 Installation Guidelines ..................................................................................................................5
Regulatory and Standards compliance .................................................................................................5
1 FCC Compliance Testing................................................................................................................5
1.1 FCC Antenna Selection..........................................................................................................6
1.2 FCC Allowed Antenna Types .................................................................................................6
1.3 FCC Labeling Requirements ..................................................................................................6
1.4 FCC Documentation Requirements.......................................................................................7
2 ISED Compliance Testing...............................................................................................................7
2.1 ISED Antenna Requirements.................................................................................................7
2.2 ISED Labeling Requirements .................................................................................................7
2.3 ISED Documentation Requirements .....................................................................................7
3 EU Compliance..............................................................................................................................8




RM5800 User Manual

Revision B.1 3

1PURPOSE

This document serves as a user manual for the Emerson Rosemount RM5800 radio module.

2GENERAL INFORMATION

2.1 PRODUCT DESCRIPTION

Rosemount Inc.’s RM5800 WirelessHART 2.4GHz Radio Module has been specifically designed to

interface with industrial and process control equipment designed and marketed by the Emerson family

of companies. The RM5800 is designed to be fully compliant with the WirelessHART specification. The

RM5800 utilizes the global license-free 2.4GHz band at output power levels that are compatible with

government regulations throughout the world.

The RM5800’s very low power consumption characteristics make it perfect for battery-powered

equipment. The multi-functional interface of the RM5800 is flexible enough for it to be integrated into

many types of sensors. From pressure, temperature, and flow monitoring to machinery health and valve

position control, the RM5800 is the best choice for WirelessHART compatible communications.

3PRODUCT SPECIFICATIONS

3.1 OPERATIONAL DESCRIPTION

The RM5800 radio module is an 802.15.4 standard radio with the following features:

•+8 dBm (6.3 mW) conducted RF output power specification

•–95 dBm receiver sensitivity

•AES FIPS PUB 197 (128 bit) encryption

3.2 NORMAL OPERATING CONDITIONS

Parameter

Min

Typ

Max

Units

Comments

Operational supply voltage range

(between VDD and VSS)

2.1

3.76

Including noise and load

regulation

Voltage on analog input pins

1.8

Voltage supply noise

250

mVp-p

50 Hz to 2 MHz

Operating temperature range

–40

+85

°C

Maximum allowed temperature

ramp during operation

°C/min

–40 °C to +85 °C

Unless otherwise noted, assume VDD is 3.0 V and temperature is 25 °C.

RM5800 User Manual

Revision B.1 4

3.3 RADIO SPECIFICATIONS

Parameter

Min

Typ

Max

Units

Comments

Operating frequency

2.4000

2.4835

GHz

Channel center: 2.440Ghz

Number of channels

Channel separation

MHz

Occupied channel bandwidth

2.5

MHz

At –20 dBc

Modulation

IEEE 802.15.4

Raw data rate

250

kbps

Receiver operating maximum

input level

dBm

Receiver sensitivity

–95

dBm

At 50% PER, VDD = 3 V,

25 °C

–93

dBm

At 1% PER, VDD = 3 V,

25 °C, (inferred from 50%

PER measurement)

Output power, conducted

+8.5

dBm

VDD = 3 V, 25 °C,

manufacturing tolerance

variation +0.5dBm

3.4 ANTENNA SPECIFICATIONS

The antenna used with this module must meet specifications below.

Parameter

Value

Frequency range

2.4–2.4835 GHz

Antenna connector

MMCX

Minimum cable length

100mm (3.937in)

Trace antenna specifications

N/A

When the RM5800 is placed inside an enclosure, the antenna should be mounted such that the radiating

portion of the antenna protrudes from the enclosure and connected using a coaxial cable. For optimum

performance, allow the antenna to be positioned vertically when installed.

Note, local government regulations must be consulted with regards to approved antenna type and

allowed antenna gain for use with this module.

RM5800 User Manual

Revision B.1 5

4INTEGRATION INSTRUCTIONS

4.1 DESIGN DESCRIPTION

The RM5800 connects to a host feature board via 22 pin connectors. Antennas or antenna adapter

cables are connected to the radio module via MMCX cable connector.

4.1.1 Device Photo

4.2 INSTALLATION GUIDELINES

The RM5800 radio module is only available for use in the Emerson family of products. The RM5800 is

not readily available to consumers; it is not sold by retail to the public. The RM5800 radio module has a

limited modular approval, which requires that it be installed by approved host integrators under

advisement of the module manufacturer. Host products are used in industrial and commercial

environments.

5REGULATORY AND STANDARDS COMPLIANCE

The RM5800 allows a limited modular host product implementation in the United States, Canada, and

European Union. The following guidance must be reviewed to ensure final compliance to regulatory

standards.

5.1 FCC COMPLIANCE TESTING

The RM5800 radio module has demonstrated compliance to FCC 15.247:2021.

To fulfill FCC certification requirements, products incorporating the RM5800 must comply with the

following:

RM5800 User Manual

Revision B.1 6

1. An external label must be provided on the outside of the final product enclosure specifying the

FCC identifier as described in 5.1.3 below.

2. The antenna must be electrically identical to the FCC-approved antenna specifications for the

RM5800 as described in 5.1.2 with the exception that the gain may be lower than specified in

Section 5.1.2.

3. The device integrating the RM5800 may not cause harmful interference, and must accept any

interference received, including interference that may cause undesired operation.

4. An unintentional radiator scan must be performed on each final device integrating the RM5800,

per FCC rules and regulations, CFR Title 47, Part 15, Subpart B. If the final device system (host

product and modular transmitter) exceeds the spurious emissions or output power limit, the

product must not be marketed in the United States.

5. Professional installation as per section 4.3 of the modular integration manual, available upon

request.

Reference KDB 996369 D04 Module Integration Guide v02 for detailed integration and testing guidance.

5.1.1 FCC Antenna Selection

The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20

cm from all persons and must not be collocated or operating in conjunction with any other antenna or

transmitter within a host device, except in accordance with FCC multi-transmitter product procedures.

Compliance to FCC rule 15.203 must be ensured in the final design of the product. Reference KDB

353028 for direct guidance on meeting this requirement. This can be done by either ensuring the

professional installation of the final product or designing it in such a way as to make the antenna

integral to the final product. Further, the RM5800 is only utilized by Emerson internal companies, and is

not available to the general public. The RM5800 is an industrial network communication module and

only works on Wireless Hart protocols and as such is part of an industrial process control system

professionally installed and maintained per Section 4.3 of the modular integration manual, available

upon request.

5.1.2 FCC Allowed Antenna Types

Allowed antenna types include:

1. Maximum 8.0dBi dipole antenna (tested kinds include Taoglas 2.5/3.0dBi PCB strip, Emerson

4.5dBi per drawing 00753-2035, and PCTEL 8.0dBi omnidirectional antenna BOA24008NF)

2. Maximum 14.5dBi yagi-uda (tested L-COM 14.5dBi model HG2415Y-HF)

3. Maximum 18dBi reflective array (tested L-COM 18dBi flat panel antenna model HG2418P)

5.1.3 FCC Labeling Requirements

The exterior of the host product must have a label with the following (or similar) text specifying the FCC

identifier in 4 points or larger.

Contains transmitter module FCC ID: LW2-RM5801

Or Contains FCC ID: LW2-RM5801

RM5800 User Manual

Revision B.1 7

5.1.4 FCC Documentation Requirements

User documentation must contain the following statements:

•This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

•This device must be installed to ensure a minimum antenna separation distance of 20 cm from all

persons.

•Changes or modification to the equipment not expressly approved by Rosemount, Inc. could void

the user's authority to operate the equipment.

5.2 ISED COMPLIANCE TESTING

The RM5800 radio module has demonstrated compliance to ISED RSS 247. Host products are required to

meet all applicable requirements in RSS-Gen, including the radio frequency exposure compliance

requirements in RSS-102.

5.2.1 ISED Antenna Requirements

This radio module HVIN 5801 IC: 2731A-RM50801 has been approved by Innovation, Science and

Economic Development Canada to operate with the antenna types listed below, with the maximum

permissible gain indicated. Antenna types not included in this list that have a gain greater than the

maximum gain indicated for any type listed are strictly prohibited for use with this device.

Antenna types:

1. Maximum 8.0dBi dipole antenna (tested kinds include Taoglas 2.5/3.0dBi PCB strip, Emerson

4.5dBi per drawing 00753-2035 and PCTEL 8.0dBi omnidirectional antenna BOA24008NF),

nominal impedance 50 ohms

2. Maximum 14.5dBi yagi-uda (tested L-COM 14.5dBi model HG2415Y-HF), impedance 50 ohms

3. Maximum 18dBi reflective array (tested L-COM 18dBi flat panel antenna model HG2418P),

impedance 50ohms

5.2.2 ISED Labeling Requirements

The exterior of the host product must have a label with the following (or similar) text specifying the IC

identifier in 4 points or larger.

Contains IC: 2731A-RM5801

5.2.3 ISED Documentation Requirements

User documentation of host products must contain the following statements:

•This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,

Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the

following two conditions: This device may not cause interference. This device must accept any

interference, including interference that may cause undesired operation of the device.

•Cet appareil est conforme à la norme RSS-247 Industrie Canada exempt de licence. Son

fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne doit pas provoquer

RM5800 User Manual

Revision B.1 8

d'interférences et (2) cet appareil doit accepter toute interférence, y compris les interférences

pouvant causer un mauvais fonctionnement du dispositif.

5.3 EU COMPLIANCE

The RM5800 has been demonstrated compliance to EN 300 328.

Host products are required to demonstrate compliance to EU Radio Equipment Directive (RED)

2014/53/EU and follow all documentation and labeling requirements.

Antennas may have a maximum gain of 12dBi.

RM5800 User Manual

Revision B.1 9

The Emerson logo is a trademark and service mark of Emerson Electric Co.

Rosemount is a mark of one of the Emerson family of companies.

All other marks are the property of their respective owners.

Table des matières

Autres manuels Emerson Unité de contrôle

Emerson

Emerson FieldQ QC4124 V DC Manuel utilisateur

Emerson

Emerson Fisher V270 Manuel utilisateur

Emerson

Emerson unidrive m Manuel utilisateur

Emerson

Emerson MVME7616E Guide de démarrage rapide

Emerson

Emerson Anderson Greenwood 9300 Series Manuel utilisateur

Emerson

Emerson KEYSTONE OPTISEAL F16 Manuel utilisateur

Emerson

Emerson CSI 6500 Manuel utilisateur

Emerson

Emerson Neotecha Sapro Guide de configuration

Emerson

Emerson Keystone PED Guide rapide

Emerson

Emerson KEYSTONE FIGURE PCS17 Manuel d'exploitation et d'entretien

Emerson

Emerson PACSystems RX3i IC695ECM850 Manuel utilisateur

Emerson

Emerson FISHER CV500 Manuel utilisateur

Emerson

Emerson Tartarini PRX Series Manuel utilisateur

Emerson

Emerson AVENTICS AV Manuel utilisateur

Emerson

Emerson SI-I/O Manuel utilisateur

Emerson

Emerson IEC 62591 Manuel utilisateur

Emerson

Emerson Anderson Greenwood 727 Series Manuel utilisateur

Emerson

Emerson Keystone Figure 952 Manuel utilisateur

Emerson

Emerson Keystone 990 Document technique

Emerson

Emerson Fisher V250 Manuel utilisateur

Emerson

Emerson Keystone Figure 637 Manuel d'installation et d'exploitation

Emerson

Emerson Baumann 24000 Little Scotty Manuel utilisateur

Emerson

Emerson Fisher 92C Manuel utilisateur

Emerson

Emerson Fisher Vee-Ball V150 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
