Elcometer 3000 Series Manuel utilisateur

English

Elcometer 3000

Clemen Unit

Operating Instructions

3000_TMA_0326_00_02.fm Page -1 Monday, January 19, 2009 2:35 PM

English

The Elcometer 3000/3 Motorised Clemen Unit has been tested in

accordance with EU regulations governing Electro-magnetic

compliance and it meets the required directives.

is a registered trademark of Elcometer Limited.

All other trademarks acknowledged.

transcribed, stored (in a retrieval system or otherwise) or translated into any

language, in any form or by any means (electronic, mechanical, magnetic,

optical, manual or otherwise) without the prior written permission of

Elcometer Limited.

Doc.No. TMA-0326 Issue 02

Text with Cover No: 19438

3000_TMA_0326_00_02.fm Page 0 Monday, January 19, 2009 2:35 PM

CONTENTS

Section Page

1 About your tester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.2 The parts of your tester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.3 Power input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.4 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.5 Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3 Testing a sample - Manual Clemen Unit . . . . . . . . . . . . . . . . . . . . . . 6

3.1 Adjusting the tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.2 Test procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4 Testing a sample - Motorised Clemen Unit . . . . . . . . . . . . . . . . . . . . 8

4.1 Adjusting the tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.2 Test procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5 Testing thick samples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

6 Tool accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6.1 Cutting tool - for scratch testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6.2 Rubber tool - for drying time assessment . . . . . . . . . . . . . . . . . . . . . . 12

7 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

8 Technical specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

8.1 Manual model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

8.2 Motorised model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

8.3 Sample size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

8.4 Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

9 Spares . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

10 Related equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3000_TMA_0326_00_02.fm Page 1 Monday, January 19, 2009 2:35 PM

hank you for your purchase of this Elcometer 3000 Clemen Unit. Welcome

to Elcometer.

Elcometer are world leaders in the design, manufacture and supply of

inspection equipment for coatings and concrete. Our products cover all aspects

of coating inspection, from development through application to post application

inspection.

The Elcometer 3000 Clemen Unit is a world beating product. With the purchase

of this product you now have access to the worldwide service and support

network of Elcometer. For more information visit our website at

www.elcometer.com

1 ABOUT YOUR TESTER

The Elcometer 3000 Clemen Unit is a robust and simple-to-use instrument for

evaluation of the resistance to scratching of a coated surface. The sample can

be metal, wood, glass, plastic or other hard materials.

A tool fitted with a hemispherical ball is lowered gradually onto the surface of

the sample and moved in a straight line a distance of 60 mm (2.4"). The

downward force exerted by the tool onto the surface is adjustable by means of

a sliding weight.

Depending on the purpose of the test and the force applied, varying degrees of

penetration of the tool into the coating are observed, from a superficial trace to

total destruction.

The Elcometer 3000 is available in two versions; the original Manual Clemen

Unit and the Motorised Clemen Unit.

•Elcometer 3000/1 Manual Clemen Unit. The sample is clamped to a sliding

platform which is moved manually.

•Elcometer 3000/3 Motorised Clemen Unit. The sample is clamped to a fixed

platform. At the press of a button, the tool is moved across the sample and

stops automatically at the end of its travel. Contact between the tool and a

metallic sample is indicated by a lamp and voltmeter.

1.1 Standards

The Elcometer 3000 Clemen Unit can be used in accordance with the following

National and International Standards:

AS/NZS 1580.403.1 EN13523-12 supersedes ECCA T12

ISO 1518 supersedes DIN 53799, BS 3900-E2

3000_TMA_0326_00_02.fm Page 2 Monday, January 19, 2009 2:35 PM

1.2 These instructions

These instructions describe the operation of the following Elcometer Clemen

Units:

• Elcometer 3000/1 Manual Clemen Unit

• Elcometer 3000/3 Motorised Clemen Unit

1.3 What the box contains

• Elcometer 3000/1 Clemen Unit or

Elcometer 3000/3 Motorised Clemen Unit

• 1000 g weight x 4 (Elcometer 3000/3 models only)

• 1 mm (0.04") Ball Tool

• Operating Instructions

To maximise the benefits of your new Elcometer 3000 Clemen Unit please

take some time to read these Operating Instructions. Do not hesitate to

contact Elcometer or your Elcometer supplier if you have any questions.

3000_TMA_0326_00_02.fm Page 3 Monday, January 19, 2009 2:35 PM

2 GETTING STARTED

This section of the instructions is intended for first-time users of the

Elcometer 3000 Clemen Unit. It describes the steps you must take before you

can start using the unit and offers advice on safe operation.

2.1 Installation

Place the Elcometer 3000 Clemen Unit onto a rigid table. The motorised model

includes adjustable feet which can be used to level the unit.

2.2 The parts of your tester

Figure 1. The parts of your tester (manual model shown)

1. Weight

2. Clamp

3. Load beam

4. Tool

5. Sample platform

2.3 Power input

(These instructions apply to motorised models only)

The power input panel is protected by two fuses - see “Technical specification”

on page 14 for fuse rating.

3000_TMA_0326_00_02.fm Page 4 Monday, January 19, 2009 2:35 PM

2.4 Control panel

(These instructions apply to motorised models only)

Figure 2. Control panel

•To switch on the Clemen Unit, press the Power On/Off button. The button

will illuminate when the Clemen Unit is switched on. Press again to switch

the tester off.

•To start the tool movement, press the Start button. The tool will stop

automatically at the end of its stroke. To stop the movement at any time,

press the Power On/Off button. The light in the Start button will flash when

coating has been removed completely from a metallic sample - see page 9.

2.5 Caution

The Elcometer 3000 Clemen Unit has been manufactured with your safety in

mind. However, improper use can result in damage to the tester.

Please observe the precautions discussed in these operating instructions.

To reduce the risk of electric shock, do not open the housing of the

Elcometer 3000/3 Motorised Clemen Unit. There are no user-

serviceable parts inside.

To reduce the risk of fire or electric shock, do not expose the Elcometer 3000/

3 Motorised Clemen Unit to rain or excess moisture.

The mains plug on your Elcometer 3000/3 Motorised Clemen Unit may be fitted

with a fuse. When replacing this fuse, ensure a fuse of the correct rating is used.

OFF

Power

on/off

StartVoltmeter

3000_TMA_0326_00_02.fm Page 5 Monday, January 19, 2009 2:35 PM

3 TESTING A SAMPLE - MANUAL CLEMEN UNIT

Before the sample can be tested, adjust the height of the tool:

3.1 Adjusting the tool

1. Place the sample onto the sample platform and fix in position by rotating the

clamp handle.

2. Lift and hold the load beam in its raised position and slide the sample

platform until the centre of the sample is underneath the tool (Figure 3).

3. Insert the metal shim between the nylon wheel (1) and the load beam and

then lower the load beam.

Figure 3. Adjusting the scratching tool

4. Adjust the height of the tool (2) until it is touching the surface of the sample

and then tighten the knurled wheel (3) to lock the tool in position.

5. Raise the load beam, remove the metal shim and slide the sample platform

back to its starting position.

6. Slide the weight along the load beam to the required load and lock in place

by tightening the knurled wheel. The load can be set from 0 g to 2000 g

(0 lb to 4.4 lb).

3000_TMA_0326_00_02.fm Page 6 Monday, January 19, 2009 2:35 PM

The instrument and sample are now ready for the test to be carried out

(Figure 4).

Figure 4. Manual Clemen Unit ready for test

3.2 Test procedure

1. Pull the sample platform towards you in a single smooth action (Figure 4);

the standard speed of movement is approximately 30 mm/s (1.2"/s).

The tool will lower down onto the sample at the start of the test and raise up

at the end of the test.

2. Inspect the sample for damage in accordance with the requirements of the

test standard. Repeat the test as necessary, increasing the loading

between tests.

3000_TMA_0326_00_02.fm Page 7 Monday, January 19, 2009 2:35 PM

4 TESTING A SAMPLE - MOTORISED CLEMEN UNIT

Before the sample can be tested, adjust the height of the tool:

4.1 Adjusting the tool

1. Connect the unit to the mains supply and press the Power On/Off button.

2. Place the sample onto the sample platform and fix in position by rotating the

clamp handle.

3. Lift and hold the load beam in its raised position.

4. Press the Start button (Figure 2). Wait until the tool is halfway through its

travel and then press the Power On/Off button to stop the tool in this

position.

5. Insert the metal shim between the nylon wheel (1) and the load beam and

then lower the load beam.

Figure 5. Adjusting the scratching tool

6. Adjust the height of the tool (2) until it is touching the surface of the sample

and then tighten the knurled wheel (3) to lock the tool in position.

7. Raise the load beam, remove the metal shim and while supporting the

beam, press the Power On/Off button and then the Start button to return the

tool to the starting position.

Supporting the load beam while the tool is moving to its starting position

prevents damage to the sample surface, the tool or the sample platform.
