Elcometer 119

Pipe Pit Gauge

User Guide

R

1 OVERVIEW

R

www.elcometer.com

The gauge shows the pit depth compared to the nominal pipe wall

thickness.

The Elcometer 119 Pipe Pit Gauge is a pocket sized gauge designed to

identify the condition of a pipe.

The gauge is placed horizontally on the surface of the pipe and the stylus

is positioned into the base of the corrosion pit.

2 TAKING A READING

1 Place the long edge of the Elcometer 119 Pipe Pit Gauge against the test surface.

2 Push the indicator arm until the stylus touches the bottom of the pit or crater.

3 Read the pit depth off the scale in line with the top edge of the indicator arm.

The instrument can be used to compare the pit depth with the pipe thickness. A scale showing pipe

diameters with corresponding wall thickness is marked on the gauge, adjacent to the pit depth scale.

When the indicator arm is in line with the pipe diameter this shows that the pit is approximately the same

depth as the wall thickness.

www.elcometer.com

R

3 TECHNICAL SPECIFICATION

Range*: 0 - 0.5"

Graduation*: 0.0625" and 0.01"

Dimensions: 68 x 133 x 4mm (21 x 5.25 x 0.18”)

Weight: 227g (8oz)

* Imperial units only.

Please ensure that all packaging is disposed of in an environmentally sensitive manner. Consult your local Environmental Authority for further guidance.

All other trademarks acknowledged.

© Elcometer Limited 2011 - 2019. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored (in a retrieval system or otherwise) or

translated into any language, in any form or by any means (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of

Elcometer Limited

is a registered trademark of Elcometer Limited, Edge Lane, Manchester, M43 6BU. United Kingdom

R

R

TMA-0502 Issue 02 - Text with cover 4278
