Edimax BR-6216Mg Manuel utilisateur

MIMO Wireless LAN Router

BR-6216Mg

MIMO Wireless LAN AP Router

IEEE 802.11g/b with MIMO Solution

Introduction :

The MIMO (Multiple-Input Multiple-Output) technology enables you to

connect to wireless networks from further distances than before, the MIMO

solution has two antennas for signal reception and one antenna for high

power signal transmission. Not only the reach is enhanced, but also the

“dead spots” in the network are reduced.

The features Packet-OVERDRIVE™(Turbo Mode)technology that

combines Packet Burst and Frame Aggregation for up to 35 Mbps

throughput, without resorting to channel bonding that decreases available

channels and increases interference.

In addition, the MIMO solution remains backwards compatible, and works

perfectly with existing 802.11g/b products and doesn’t make previous Wi-Fi

investments redundant.

Features :

lP Sharing

The NAT/NAPT function lets you share the ADSL line with all the Intranet

users (supports up to 253 users). It also provides virtual server and virtual

DMZ functions to let your internal servers be accessed from the Internet.

Wireless MIMO Access Point

The wireless MIMO access point function offers your IEEE 802.11g/b

wireless client devices access to the Intranet through this router and

provides improved throughput and a broader reach than existing 802.11g/b.

Supports Special Applications

The router can let you setup trigger ports of special applications, and let

you utilize Internet services smoothly.

Virtual Server and DMZ

The virtual server and DMZ function lets you setup your servers in the

Intranet and still provides services to the Internet users.

MIMO XR™

12V DC, 1A Linear Power AdaptorPower

10/100 UTP X 1WAN Port

Realtek RTL8305SC (5 Port Switch)Switch

10/100 UTP X 4LAN Ports

18dBm ±2dBmTransmit Power

54/48/36/24/18/12/11/9/6/5.5/2/1Mbps auto

fallback

Data Rate

64/128-bit WEP Data Encryption, WPA (TKIP with

IEEE 802.1x) and WPA2 (AES with IEEE 802.1x)

Security

RP-SMA Detachable Antenna

Antenna

FCC, CE, C-TickCertification

Max. 90% (Non-Condensing)Humidity

32~131°F (0 ~55°C)Temperature

30(H) x 187(W) x 100(D) mmDimension

2 MB NOR Flash / 16 MB SDRAM

Flash / RAM

Ralink RT2661

RDC 3211CPU

EW-6216Mg

Model NO.

Functions :

•Supports IEEE 802.11e WMM and Quality of Service (QoS)

•NAT/NAPT IP Sharing

•Anti-DoS Firewall and Virtual Server / DMZ

•Supports 64/128 Bit Key Length WEP Encryption

•Supports WPA-PSK, WPA-Radius, WPA2 Security

•Supports Special Applications (Port Triggers)

•Supports DDNS (DynDNS, TZO)

•VPN Pass Through (IPSec/PPTP)

•Obtains WAN IP by PPPoE/Static IP/PPTP/DHCP

•Provide DHCP Server

•Web User Interface (Remote Configuration)

•System Status / Security Log

•Firmware Upgrade

Specifications :

Taiwan / Headquarters

Edimax Technology Co., LTD.

TEL:886-2-7739-6888

FAX:886-2-7739-6887

[email protected]

China

Beijing Edimax Science &

Technology Co., LTD.

TEL:8610-6213-9288

FAX:8610-6213-9231

[email protected]

Europe

Edimax Technology Europe B.V.

TEL:31-499-377344

FAX:31-499-372647

[email protected]

Latin America

TEL:1-786-845-8099

FAX:1-786-331-8490

[email protected]

Poland

Edimax Technology Europe

B.V. SP. Z O.O.

Tel: +48(22)-6060-255

Fax: +48(22)-6060-254

[email protected]

U.S.A.

Edimax Computer Company

TEL:1-408-496-1105

FAX:1-408-980-1530

[email protected]

U.K.

Edimax Technology (UK) Ltd.

TEL:44-870-7740226

FAX:44-870-7740227

[email protected]
