Edimax GS-5210PLG Manuel utilisateur

GS-5210PLG

User Manual

03-2022 / v1.0

Contents

I. Product Information.................................................1

I-1. Package Content ..................................................................2

I-2. Hardware Overview .............................................................2

I-3. LED Status.............................................................................3

II. Installation ..............................................................3

II-1. Physically Setup....................................................................3

II-2. Connection...........................................................................5

III.Web-based Configuration Utility ..............................6

IV. Web-based Switch Configuration .....................8

IV-1. System..................................................................................8

IV-2. Management........................................................................9

IV-3. Port.....................................................................................11

IV-4. Long Range Mode ..............................................................12

IV-5. VLAN...................................................................................12

IV-6. Trunking .............................................................................15

IV-7. Mirror.................................................................................16

IV-8. QoS.....................................................................................17

IV-8-1. Disable QoS: .......................................................17

IV-8-2. Port-Based QoS: .................................................18

IV-8-3. IEEE 802.1p QoS: ................................................19

IV-9. Broadcast Storm Control....................................................20

IV-10. Rate Limiting .................................................................21

IV-11. Loop Detect/Prevent.....................................................22

IV-12. IGMP Snooping .............................................................23

IV-13. PoE................................................................................24

IV-14. Password.......................................................................25

IV-15. Logout...........................................................................25

V. Safety Instructions .................................................26

I. Product Information

The Edimax Pro GS-5210PLG is a web-smart switch with 8 Gigabit PoE+, 1

Gigabit RJ45 uplink port and 1 Gigabit SFP uplink. Designed for medium to

small network environments, its standard 19-inch 1U rack-mount brackets

allow for integration with the most widely used mounting systems on the

market. The Edimax GS-5210PLG is a superb choice to boost your network

environment’s performance and efficiency.

You can find all supporting documents from the link below or via QR Code:

https://www.edimax.com/download

(Once you’ve visited the Edimax official website, please enter the model no.

“GS-5210PLG”into the search box to search for your product.)

I-1. Package Content

Before start using this product, please check if there is anything missing in the

package, and contact your dealer to claim the missing item(s):

I-2. Hardware Overview

GS-5408PLG V2

Power Cord

Rack-Mount Kit

GS-5210PLG

LED (PoE/Alert,

PWR)

LED

(Link/Act 1~8)

Reset

Gigabit PoE Port

(1~8)

PoE LED

(Link/Act 1~8)

Gigabit

RJ45 Port (9)

SFP Port (10)

Power Socket

Quick Installation

Guide

LED

(Link/Act 9-10)

I-3. LED Status

II. Installation

Read the following below procedures in the correct order. Incorrect

installation may cause damage to the product.

II-1. Physically Setup

There are two ways to physically set up the switch.

1. Desktop Placement: Place

the switch on a flat surface

and install the four rubber

feet (included) on the

bottom of the switch.

Function

Color

Status

Description

PWR

Green

Power on

Off

Power off

Blinking

Booting up

PoE Alert

Green

Total PoE power consumed is

OVER PoE power budget

Off

Total PoE power consumed is

under PoE power budget

Link/ACT

(Port 1-9)

Green

Link at 1000Mbps

Blinking

Sending or receiving data

Off

Port disconnected or link fail

Amber

Link at 10/100Mbps

Blinking

Sending or receiving data

Off

Port disconnected or link fail

SPF

(Port 10)

Green

Link at 1000Mbps

Blinking

Sending or receiving data

Off

Port disconnected or link fail

PoE

(Port 1-8)

Green

Feeding power to PoE devices

Off

PoE function is not active

2. Rack-mount the switch: You can mount the switch in any standard size,

19-inch (about 48 cm) wide rack with 1 Rack Unit (1U) of space, which is

1.75 inches (4.45 cm) high. A pair of extension brackets and screws are

needed to adapt the switch to the rack size.

Align the mounting brackets with the mounting holes on the switch’s side

panels and secure the brackets with the screws.

Secure the switch on the equipment rack with the screws provided.

II-2. Connection

1. Power on: Connect the power cord to the switch and the power outlet.

The switch is powered by the 100-240VAC 50/60Hz external high-

performance power supply. (Note: Make sure the PWR LED is green.)

2. Uplink: Plug the standard Cat5e(or above) Ethernet cable into the LAN

port no. 9 or plug the SFP cable into the SFP slot and connect it to the LAN

server or core switch. (Note: Make sure that the LED is green or amber.)

3. Connect devices: Plug the standard Cat5e(or above) Ethernet cable into

the LAN port and connect to any networking device with an Ethernet port.

(Note: Make sure that the "LAN" LED is green or amber.) The hardware

installation is complete!

4. Connect a computer: Connect your computer with the switch and get

ready for web-based configuration with following ＂Section III

Web-based Configuration Utility＂.

1. Power on

3. Connect devices

2. Uplink to the server

or core switch

4. Connect to

a computer

III.Web-based Configuration Utility

This section describes how to navigate the web-based switch configuration

utility through web browser. Be sure to disable any browser pop-up blocker.

Browser Restrictions

If you are using older versions of Internet Explorer, you cannot directly use

an IPv6 address to access the device. You can, however, use the DNS

(Domain Name System) server to create a domain name that contains the

IPv6 address, and then use that domain name in the address bar in place

of the IPv6 address.

If you have multiple IPv6 interfaces on your management station, use the

IPv6 global address instead of the IPv6 link local address to access the

device from your browser.

Launching the Configuration Utility

1. Connect your computer with the switch then open a web browser.

2. Enter the IP address of the switch you are configuring in the address bar

on the browser (factory default IP address is 192.168.2.1) and then press

Enter. Please make sure that your computer's IP address is in the same

subnet as this switch. The default IP address is an IP address in the range

of 192.168.2.X (X=2-254). You can modify the IP address of your computer

if you need.

Default IP

192.168.2.1

Default User Name

admin

Default Password

1234

3. The default username is “admin” and the default password is “1234”.

4. The first time that you log in with the default username and password,

you are required to change password.
