Eaton Power Xpert PXGMS Manuel de programmation

p/n: 164000208

Revision 4

Package Contents

lPower Xpert Gateway Minislot (PXGMS) UPS Card

lUSB Cable

lQuick Start Instructions

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100

Quick Start Instructions

Eaton®® Power Xpert®® Gateway Minislot (PXGMS) UPS Card

Eaton reserves the right to change specifications without prior notice. Eaton , Power Xpert , and PredictPulseTM are registered

trademarks of Eaton or its subsidiaries and affiliates. Google Chrome is a trademark of Google Inc. Linux is a registered trademark of

Linus Torvalds. Microsoft, Internet Explorer, and Windows are registered trademarks of Microsoft Corporation in the United States and in

other countries. Mozilla and Firefox are registered trademarks of the Mozilla Foundation. All other trademarks are property of their

respective companies.

express written approval of Eaton.

Help Desk Numbers

United States 1-800-356-5737 or 1-800-843-9433

Canada 1-800-461-9166 ext 260

All Other Countries Call your local service representative

Web Site www.eaton.com/pxgms

NOTE On the Web site opening page, click Support and select the Customer Service

link for more information.

Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4 iii

TTaabbllee ooff CCoonntteennttss

11 IInnssttaallllaattiioonn CChheecckklliisstt ..........................................................................................................................................................................................................................................................................11

22 IInnssttaallll tthhee CCaarrdd............................................................................................................................................................................................................................................................................................33

33 CCoonnnneecctt tthhee CCaarrdd ttoo tthhee CCoommppuutteerr ....................................................................................................................................................................................................................................55

44 IInnssttaallll tthhee UUSSBB DDrrii eerr SSooffttwwaarree ............................................................................................................................................................................................................................................77

55 OObbttaaiinn aa DDHHCCPP--AAssssiiggnneedd IIPP AAddddrreessss.......................................................................................................................................................................................................................... 1111

66 AAssssiiggnn aann IIPP AAddddrreessss MMaannuuaallllyy ........................................................................................................................................................................................................................................ 1155

77 EEnnaabbllee BBrroowwsseerr CCoommppaattiibbiilliittyy MMooddee............................................................................................................................................................................................................................ 1199

88 RReeggiisstteerr aa PPrreeddiiccttPPuullssee SSuubbssccrriippttiioonn ........................................................................................................................................................................................................................ 2211

iv Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4

Table of Contents

Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4 1

CChhaapptteerr 11 IInnssttaallllaattiioonn CChheecckklliisstt

1. Verify that the following items are available:

oower Xpert Gateway Minislot ( XGMS) U S Card package contents (card, cable, Quick Start

Instructions)

ohillips®screwdriver

oAvailable USB port on a computer running Microsoft®Windows®

oWeb browser (Microsoft Internet Explorer®version 11.0 and higher, Mozilla®Firefox®, or

Google Chrome™ are recommended)

2. If you are going to use Dynamic Host Configuration rotocol (DHC ), provide your local network

administrator with the card's MAC address. The MAC address is located on either the shipping box label or

the label on this card.

oMAC Address _______________________________________________

3. If you are not going to use DHC to provide any of the settings listed below, contact your local network

administrator for the settings.

In the table below, check the DHCP check box or enter the values for manual configuration. This data is

referenced later in the procedure.

Item D CP* Manual Configuration

IPv4 oCard IP Address: _______________________________

Netmask: _____________________________________

Gateway: _____________________________________

DNS – Name Servers oName Server #1:________________________________

Name Server #2:________________________________

Name Server #3:________________________________

DNS – Domain oDomain:_________________________________________

* The network administrator normally sets up the DHCP server to provide a static IP address each time the card makes a

DHCP request.

4. If you need e-mail functionality, obtain the SMT mail server's I address or host name. If using the SMT

host name, verify that you also have the Name Server I address (see Step 3).

oSMT (mail server) I Address

or Host Name

__________________________________________________________________________________

2 Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4

Installation Checklist

Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4 3

CChhaapptteerr 22 IInnssttaallll tthhee CCaarrdd

NOTE The hot-swappable XGMS card can be installed without turning off the U S or

disconnecting the load.

NOTE If your U S is a 93 M, there may be a metal strip that prevents you from installing the

XGMS card. If so, locate the metal strip bolted to the top of the U S. Remove the

three bolts that attach the metal strip. Then, follow the procedure to install the XGMS

card.

To install the XGMS card:

1. On the XGMS card, verify that all six DI switches are in the OFF position (see Figure 1).

Figure 1. Verify DIP Switches are OFF

Ident

Power

Act

100

PXGMS UPS

Restart

Setup

CMN

Status

DHCP

EMP

Ethernet 10/100

13456

OFF

2. If not already done, record the MAC address from either the shipping box label or the label on this card for

future reference (see the Chapter 1 Installation Checklist).

3. Remove the mini-slot cover from the U S. Retain the screws.

NOTE If another card is already installed with an attached communication cable, disconnect the

cable and then remove the card.

4. To prevent electrostatic discharge (ESD), place one hand on a metal surface, such as the U S rear panel.

5. Slide the card into the open slot and secure it with the screws removed in Step 3(see Figure 2).

4 Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4

Figure . Secure the PXGMS Card

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100 +

6. From your laptop, go to www.eaton.com/pxgms.

7. On the Resources tab, click the Software,Firmware, and Applications link to download the Power

Xpert Gateway USB Signed Windows Device Driver.

8. Save the driver configuration file ((eaton-pxgms-firmware.zip) to the C: drive using the default location or a

folder you select. Note the path of the downloaded file on your computer. (Never download the file to your

desktop).

Install the Card

Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4 5

CChhaapptteerr 33 CCoonnnneecctt tthhee CCaarrdd ttoo tthhee CCoommppuutteerr

To connect the card to the computer:

1. lug the small connector at the end of the supplied USB configuration cable into the setup port on the card

(see Figure 3).

Figure 3. Install the USB Cable

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100 +

2. lug the other end of the USB cable into the USB port on the computer. The Windows operating system

detects new hardware.

NOTE If a message indicates that the device driver software was not successfully installed,

click Ignore.

NOTE You may see a pop-up message window that shows “Found new hardware.” This

indicates that the hardware installed successfully.

3. Connect an active Ethernet cable (not supplied) to the Ethernet 10/100 connector on the XGMS card (see

Figure 4).

6 Eaton PXGMS Card Quick Start Instructions 164000208—Rev 4

Figure 4. Install the Ethernet Cable

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100 +

4. Wait for the power light and status light on the installed card to illuminate. This takes about two minutes.

5. Open a Web browser and type the default I address (https://169. 54.0.101 for firmware 2.6.0 or later,

http://19 .168. 00.101 for earlier firmware versions).

6. Did the ower Xpert Gateway software open to the XGMS page?

• If yes, the driver has already been installed automatically. Either verify the I address assigned

through DHC or manually enter a static (fixed) I address for the card’s network connection:

a. To verify the DHC -assigned I address, go to section

Chapter 5 Obtain a DHCP-Assigned IP Address step 12.

b. To manually enter a fixed I address, go to Chapter 6 Assign an IP Address Manually.

• If no, the driver has not been installed. Go to the next section

Chapter 4 Install the USB Driver Soft are, in order to confirm that you have the most current USB

Driver software. If not, you need to install or update the USB Driver software.

Connect the Card to the Computer
