DUKANE CORP AV SERVICE DEPT
2900 Dukane Drive
St Charles, IL 60174
800-676-2487 / 630-762-4032
Fax 630-584-5156
www.dukane.com/av
Information in this Guide may change due to product improvements. To obtain the latest
manuals, literature, and software please visit the Dukane web site at; www.dukane.com/av
and look at the specic model SUPPORT or DOWNLOADS section.
LCD Data Video Projector
Concise User’s Manual
MODELS
8958A, 8959A, 8957WA
403-8958A/8959A/8957WA-C-02Concise
1
ENGLISH
WARNING ►Before using this product, be sure to read all manuals for this
product. After reading them, store them in a safe place for future reference.
►Heed all the warnings and cautions in the manuals or on the product.
►Follow all the instructions in the manuals or on the product.
First of all ............................................ 2
Entries and graphical symbols explanation ......2
Important safety instruction ..............................2
Regulatory notices .............................. 3
About Electro-Magnetic Interference ................3
About Waste Electrical and Electronic Equipment
...4
Contents of package........................... 4
Preparing for the remote control ......... 5
Arrangement ....................................... 6
Connecting with your devices ............. 7
Fastening the adapter cover ............... 8
Connecting power supply ................... 8
Turning on the power .......................... 9
Adjusting the projector's elevator ..... 10
Displaying the picture ....................... 11
Turning off the power ........................ 12
Replacing the lamp ........................... 13
Cleaning and replacing the air lter
.. 15
Using the CD manual ....................... 17
Specications ................................... 18
Troubleshooting
- Warranty and after-service ........... 19
Contents
NOTE • In this manual, unless any comments are accompanied, “the
manuals” means all the documents provided with this product, and “the product”
means this projector and all the accessories came with the projector.
• The information in this manual is subject to change without notice.
• The illustrations in this manual are for illustrative purposes. They may differ
slightly from your projector.
• The manufacturer assumes no responsibility for any errors that may appear in
this manual.
• The reproduction, transfer or copy of all or any part of this document is not
permitted without express written consent.
Projector
8958A/8959A/8957WA
C
User's Manual (concise)
Thank you for purchasing this projector.
Please read through this manual before using this product, in order to use safely
and utilize well the product.
2
First of all
Entries and graphical symbols explanation
The following entries and graphical symbols are used for the manuals and the
product as follows, for safety purpose. Please know their meanings beforehand,
and heed them.
Important safety instruction
The followings are important instructions for safely using the product. Be sure to
follow them always when handling the product. The manufacturer assumes no
responsibility for any damage caused by mishandling that is beyond normal usage
dened in these manuals of this projector.
WARNING
This entry warns of a risk of serious personal injury or even death.
CAUTION This entry warns of a risk of personal injury or physical damage.
NOTICE This entry notices of fear of causing trouble.
WARNING ►Never use the product in or after an abnormality (ex. giving
off smoke, smelling strange, took a liquid or an object inside, broken, etc.) If an
abnormality should occur, unplug the projector urgently.
►Situate the product away from children and pets.
►Keep small parts away from children and pets. If swallowed, consult a
physician immediately for emergency treatment.
►Do not use the product when there is fear of a thunderbolt.
►Unplug the projector from the power outlet if the projector is not used for the
time being.
►Do not open or remove any portion of the product, unless the manuals direct
it. For internal maintenance, leave it to your dealer or their service personnel.
►Use only the accessories specied or recommended by the manufacturer.
►Do not modify the projector or accessories.
►Do not let any things or any liquids enter to the inside of the product.
►Do not wet the product.
►Do not place the projector where any oils, such as cooking or machine oil,
are used. Oil may harm the product, resulting in malfunction, or falling from the
mounted position.
►Do not apply a shock or pressure to this product.
- Do not place the product on an unstable place such as the uneven surface or
the leaned table.
- Do not place the product unstably. Place the projector so that it does not
protrude from the surface where the projector is placed on.
- Remove all the attachments including the power cord and cables, from the
projector when carrying the projector.
►
Do not look into the lens and the openings on the projector, while the lamp is on.
►
Do not approach the lamp cover and the exhaust vents, while the projection lamp
is on. Also after the lamp goes out, do not approach them for a while, since too hot.
3
ENGLISH
Regulatory notices
About Electro-Magnetic Interference
In CANADA
This Class B digital apparatus complies with Canadian ICES-003.
In the US, and other places where the FCC regulations are applicable
Declaration of Conformity
Trade name HITACHI/DUKANE
Model Number CP-X4022WN/8958A, CP-X5022WN/8959A, CP-WX4022WN/8957WA
Responsible Party Hitachi America, Ltd.
Address 900 Hitachi way, Chula Vista, CA 91914-3556 U.S.A.
Telephone Number +1 -800-448-2244
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.This equipment has
been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
INSTRUCTIONS TO USERS: This equipment complies with the requirements of
FCC (Federal Communication Commission) equipment provided that the following
conditions are met. Some cables have to be used with the core set. Use the
accessory cable or a designated-type cable for the connection. For cables that
have a core only at one end, connect the core to the projector.
CAUTION: Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
4
NOTE • Keep the original packing materials for future reshipment. Be sure
to use the original packing materials when moving the projector. Use special
caution for the lens.
• The projector may make a rattling sound when tilted, moved or shaken, since
a ap to control the air ow inside of the projector has moved. Be aware that
this is not a failure or malfunction.
About Waste Electrical and Electronic Equipment
The mark is in compliance with the Waste Electrical and Electronic
Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment
including any spent or discarded batteries or accumulators as unsorted
municipal waste, but use the return and collection systems available.
If the batteries or accumulators included with this equipment, display
the chemical symbol Hg, Cd, or Pb, then it means that the battery has a
heavy metal content of more than 0.0005% Mercury or more than, 0.002%
Cadmium, or more than 0.004% Lead.
Regulatory notices (continued)
WARNING ►Keep small parts away from children and pets. Take care
not to put in the mouth. If swallowed, consult a physician immediately for
emergency treatment.
Contents of package
Your projector should come with the items
shown below. Check that all the items are
included. Require of your dealer immediately if
any items are missing.
(1) Remote control with two AA batteries
(2) Power cord
(3) Computer cable
(4) Adapter cover
(5) Lens cover
(6) User’s manuals (Book x1, CD x1)
(7) Security label
(8) Application CD
(9) Hexagon wrench
(6)
(7)
(2)
(3)
(5)
(1)
VIDEO
DOC.CAMERA
KEYSTONE
ASPECT SEARCH BLANK
MUTE
MY BUTTON
POSITION
ESC
MENU
RESET
COMPUTER MY SOURCE/
AUTO
MAGNIFY
PAGE
DOWN
ON
OFF
FREEZE
UP
ー
＋
VOLUME
12
ENTER
(8)
(9)
(4)
5
ENGLISH
Preparing for the remote control
Please insert the batteries into the remote control before using it. If the remote
control starts to malfunction, try to replace the batteries. If you will not use the
remote control for long period, remove the batteries from the remote control and
store them in a safe place.
1. Holding the hook part of the battery
cover, remove it.
2. Align and insert the two AA batteries
(HITACHI MAXELL ENERGY, Part
No.LR6 or R6P) according to their plus
and minus terminals as indicated in the
remote control.
3. Replace the battery cover in the direction of the arrow and snap it back into
place.
WARNING ►Always handle the batteries with care and use them only as
directed. Improper use may result in battery explosion, cracking or leakage,
which could result in re, injury and/or pollution of the surrounding environment.
• When replacing the batteries, replace both of the batteries with new batteries
of the same type. Do not use a new battery with a used battery.
• Be sure to use only the batteries speci ed. Do not use batteries of different
types at the same time. Do not mix a new battery with used one.
•
Make sure the plus and minus terminals are correctly aligned when loading a battery.
• Keep a battery away from children and pets.
• Do not recharge, short circuit, solder or disassemble a battery.
•
Do not place a battery in a re or water. Keep batteries in a dark, cool and dry place.
•
If you observe battery leakage, wipe out the leakage and then replace a battery.
If the leakage adheres to your body or clothes, rinse well with water immediately.
•
Obey the local laws on disposing the battery.
21 3
6
WARNING ►Install the projector where you can access the power outlet
easily.
►Install the projector in a stable horizontal position.
• Do not use any mounting accessories except the accessories speci ed by the
manufacturer. Read and keep the manuals of the accessories used.
•
For special installation such as ceiling mounting, be sure to consult your dealer
beforehand. Speci c mounting accessories and services may be required.
• Do not put the projector on its side, front or rear position.
• Do not attach nor place anything on the projector unless otherwise speci ed
in the manual.
►Do not install the projector near thermally conductive or ammable things.
►Do not place the projector where any oils, such as cooking or machine oil, are
used.
►Do not place the projector in a place where it may get wet.
CAUTION ►Place the projector in a cool place with suf cient ventilation.
• Keep a space of 30 cm or more between a side of the projector and other
objects such as walls.
• Do not stop up, block nor cover the projector’s vent holes.
• Do not place the projector at places that are exposed to magnetic elds, doing
so can cause the cooling fans inside the projector to malfunction.
►Avoid placing the projector in smoky, humid or dusty place.
• Do not place the projector near humidi ers.
NOTICE ►Position the projector to prevent light from directly hitting the
projector’s remote sensor.
►Do not place the product in a place where radio interference may be caused.
►Check and correct the setting for ALTITUDE of SERVICE in the OPTION
menu according to the usage environment. For details, see User’s Manual -
Operating Guide.
Arrangement
Refer to the tables T-1 and T-2 at the back of this manual as well as the following
to determine the screen size and projection distance. The values shown in the
table are calculated for a full size screen.
• If the projector is used at an altitude of about 1200 m (3937 feet) or higher, set ALTITUDE
of the SERVICE item in the OPTION menu to HIGH. Otherwise, set it to NORMAL.
If the projector is used with a wrong setting, it may cause damage to the projector itself or
the parts inside.
Ⓗ× Ⓥ: Screen size
ⓐ: Projection distance
(from the projector’s end)
ⓑ, ⓒ: Screen height, when
the vertical lens shift
is set full upward.
Projector top
Projector bottom
7
ENGLISH
Connecting with your devices
Before connecting the projector to a device, consult the manual of the device to
conrm that the device is suitable for connecting with this projector and prepare
the required accessories, such as a cable in accord with the signal of the device.
Consult your dealer when the required accessory did not come with the product or
the accessory is damaged.
After making sure that the projector and the devices are turned off, perform the
connection, according to the following instructions. Refer to gures F-1 to F-4 at the
end of this manual.
For details, see User’s Manual - Operating Guide. Before connecting the projector
to a network system, be sure to read User’s Manual - Network Guide too.
WARNING ►Use only the appropriate accessories. Otherwise it could
cause a re or damage the projector and devices.
• Use only the accessories specied or recommended by the projector’s
manufacturer. It may be regulated under some standard.
• Neither disassemble nor modify the projector and the accessories.
• Do not use the damaged accessory. Be careful not to damage the accesso-
ries. Route a cable so that it is neither stepped on nor pinched out.
CAUTION ►For a cable with a core at only one end, connect the end with
the core to the projector. That may be required by EMI regulations.
►Before connecting the projector to a network system be sure to obtain the
consent of the administrator of the network.
►Do not connect the LAN port to any network that might have the excessive
voltage.
►The designated USB wireless adapter that is sold as an option is required to
use the wireless network function of this projector.
►Before removing the USB storage device from the port of the projector, be
sure to use the REMOVE USB function on the thumbnail screen to secure your
data. Before you insert or pull out the USB wireless adapter from the projector,
turn off the power of the projector and pull out the power cord’s plug from the
outlet. Do not touch the USB wireless adapter while the projector is receiving
AC power.
NOTE • Do not turn on or off the projector while connected to a device in
operation, unless that is directed in the manual of the device.
• Some input ports are selectable in the use. For details, see User’s Manual -
Operating Guide.
• Be careful not to mistakenly connect a connector to a wrong port.
• If an oversized USB storage device blocks the LAN port, use a USB extension
cable to connect the USB storage device.
• If a loud feedback noise is produced from the speaker, move the microphone
away from the speaker.
• This projector doesn't support plug-in power for the microphone.
8
Connecting power supply
1. Put the connector of the power cord into the
AC IN (AC inlet) of the projector.
2. Firmly plug the power cord’s plug into the
outlet. In a couple of seconds after the power
supply connection, the POWER indicator will
light up in steady orange.
Please remember that when the DIRECT POWER
ON function activated, the connection of the power
supply make the projector turn on.
WARNING ►Please use extra caution when connecting the power cord, as
incorrect or faulty connections may result in re and/or electrical shock.
• Do not touch the power cord with a wet hand.
• Only use the power cord that came with the projector. If it is damaged, consult
your dealer to get a new one. Never modify the power cord.
• Only plug the power cord into an outlet whose voltage is matched to the power
cord. The power outlet should be close to the projector and easily accessible.
Remove the power cord for complete separation.
• Do not distribute the power supply to multiple devices. Doing so may overload
the outlet and connectors, loosen the connection, or result in re, electric
shock or other accidents.
• Connect the ground terminal for the AC inlet of this unit to the ground terminal
of the building using an appropriate power cord (bundled).
NOTICE ►This product is also designed for IT power systems with a phase-
to-phase voltage of 220 to 240 V.
Fastening the adapter cover
Use the supplied adapter cover to prevent the
USB wireless adapter (optional) from coming
off easily and prevention from burn injury.
Refer to the following gures to fasten the
adapter cover.
WARNING ►
Keep small parts away from children and pets. Take care not to
put in the mouth. Heat may build up in the USB wireless adapter, to avoid possible
burns disconnect the projector power cord for more than 5min. before touching it.
AC IN
Power
cord
1
2
3
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Dukane Projecteur
Dukane
Dukane 8926H-RJ Manuel utilisateur
Dukane
Dukane 8115 Manuel utilisateur
Dukane
Dukane ImagePro 8807 Manuel utilisateur
Dukane
Dukane ImagePro 8780 Manuel utilisateur
Dukane
Dukane 8105B Manuel utilisateur
Dukane
Dukane ImagePro 8038A Manuel utilisateur
Dukane
Dukane ImagePro 8064 Manuel utilisateur
Dukane
Dukane 8933B Manuel utilisateur
Dukane
Dukane 8964WUSS Manuel utilisateur
Dukane
Dukane 6528 Manuel utilisateur
Dukane
Dukane ImagePro 8053 Manuel utilisateur
Dukane
Dukane ImagePro 8943 Manuel utilisateur
Dukane
Dukane ImagePro 8925H-RJ Manuel utilisateur
Dukane
Dukane 68100-4KSS Manuel utilisateur
Dukane
Dukane ImagePro 8779 Manuel utilisateur
Dukane
Dukane 9007WU Manuel utilisateur
Dukane
Dukane ImagePro 8077A Manuel utilisateur
Dukane
Dukane MPS Manuel utilisateur
Dukane
Dukane ImagePro 8776 Manuel du propriétaire
Dukane
Dukane ImagePro 8913-W Manuel utilisateur
Manuels Projecteur populaires d'autres marques
Panasonic
Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur
NEC
NEC NP600S EDU Manuel utilisateur
BenQ
BenQ SH753P Manuel utilisateur
Eiki
Eiki EK-623U series Manuel utilisateur
Epson
Epson PowerLite Pro Cinema 6020UB Manuel utilisateur
Epson
Epson PowerLite Home Cinema 705HD Manuel utilisateur
