275

Spezialnähmaschine

mit Direktantrieb

Betriebsanleitung

Instruction manual

Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld

Telefon +49 (0) 521/ 9 25 - 00 • Telefax +49 (0) 521/ 9 25 24 35 • www.duerkopp-adler.com

Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:

02/2002 Rev. index: 00.0 PrintedinGermany 0791 275740

Eigentum der Dürkopp Adler AG und urheberrechtlich geschützt. Jede, auch

auszugsweise Wiederverwendung dieser Inhalte ist ohne vorheriges schriftliches

Einverständnis der Dürkopp Adler AG verboten.

Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the

content in any manner, even in extracts, without prior written permission of

Dürkopp Adler AG, is prohibited.

Foreword

This instruction manual is intended to help the user to become

familiar with the machine and take advantage of its application

possibilities in accordance with the recommendations.

The instruction manual contains important information on how to

operate the machine securely, properly and economically.

Observation of the instructions eliminates danger, reduces costs

for repair and down-times, and increases the reliability and life of

the machine.

The instruction manual is intended to complement existing

national accident prevention and environment protection

regulations.

The instruction manual must always be available at the

machine/sewing unit.

The instruction manual must be read and applied by any person

that is authorized to work on the machine/sewing unit. This

means:

–Operation, including equipping, troubleshooting during the

work cycle, removing of fabric waste,

–Service (maintenance, inspection, repair and/or

–Transport.

The user also has to assure that only authorized personnel work

on the machine.

The user is obliged to check the machine at least once per shift

for apparent damages and to immediatly report any changes

(including the performance in service), which impair the safety.

The user company must ensure that the machine is only operated

in perfect working order.

Never remove or disable any safety devices.

If safety devices need to be removed for equipping, repairing or

maintaining, the safety devices must be

remounted directly after completion of the maintenance and

repair work.

Unauthorized modification of the machine rules out liability of the

manufacturer for damage resulting from this.

Observe all safety and danger recommendations on the

machine/unit! The yellow-and-black striped surfaces designate

permanend danger areas, eg danger of squashing, cutting,

shearing or collision.

Besides the recommendations in this instruction manual also

observe the general safety and accident prevention regulations!

General safety instructions

The non-observance of the following safety instructions can cause bodily in-

juries or damages to the machine.

1. The machine must only be commissioned in full knowledge of the instruction

book and operated by persons with appropriate training.

2. Before putting into service also read the safety rules and instructions of the

motor supplier.

3. The machine must be used only for the purpose intended. Use of the machine

without the safety devices is not permitted. Observe all the relevant safety

regulations.

4. When gauge parts are exchanged (e.g. needle, presser foot, needle plate, feed

dog and bobbin) when threading, when the workplace is left, and during

service work, the machine must be disconnected from the mains by switching

off the master switch or disconnecting the mains plug.

5. Daily servicing work must be carried out only by appropriately trained persons.

6. Repairs, conversion and special maintenance work must only be carried out by

technicians or persons with appropriate training.

7. For service or repair work on pneumatic systems, disconnect the machine from

the compressed air supply system (max. 7-10 bar).

Before disconnecting, reduce the pressure of the maintenance unit.

Exceptions to this are only adjustments and functions checks made by

appropriately trained technicians.

8. Work on the electrical equipment must be carried out only by electricians or

appropriately trained persons.

9. Work on parts and systems under electric current is not permitted,

except as specified in regulations DIN VDE 0105.

10. Conversion or changes to the machine must be authorized by us and made

only in adherence to all safety regulations.

11. For repairs, only replacement parts approved by us must be used.

12. Commissioning of the sewing head is prohibited until such time as the entire

sewing unit is found to comply with EC directives.

It is absolutely necessary to respect

the safety instructions marked by these signs.

Danger of bodily injuries !

Please note also the general safety instructions.

Contents page:

Foreword and general safety instructions

Part 1: Operating instructions Class 275 Direct Drive

1. Product description .............................. 5

2. Designated use................................. 5

3. Subclasses ................................... 6

4. Accessories ................................... 7

5. Technical data ................................. 9

6. Operation

6.1 Threading the needle thread ......................... 11

6.2 Setting the needle thread tension ...................... 11

6.3 Releasing the needle-thread tension..................... 11

6.4 Winding on the bobbin thread ......................... 12

6.5 Fitting the hook thread bobbin ........................ 13

6.6 Setting the hook thread tension........................ 14

6.7 Changing needles................................ 15

6.8 Setting the thread regulator .......................... 16

6.9 Settingthesewing-footpressure....................... 17

6.10 Setting the overfeed-foot contact pressure ................. 17

6.11 Setting the stitch length ............................ 18

6.12 Raisingthesewingfoot ............................ 19

6.13 Lockingthesewingfootintheupposition.................. 19

6.14 Settingthevalueoftheoverfeed(fullness)................. 20

6.15 Limit on overfeed length ............................ 20

6.16 Edge cutter (Cl. 275-740642) ......................... 21

6.16.1 Automatically switching on the edge cutter with the first stitch ..... 21

6.16.2 Switching on the edge cutter with an automatic delay........... 22

6.16.3 Switching on the edge cutter manually ................... 22

6.16.4 Switching off the edge cutter automatically, by stitch count ....... 22

6.17 Edge cutter (Cl. 275-742642) ......................... 23

6.17.1 Automatically switching on the edge cutter with the first stitch ..... 23

6.17.2 Switching on the edge cutter with an automatic delay........... 24

6.17.3 Switching on the edge cutter manually ................... 24

6.17.4 Switching off the edge cutter automatically, by stitch count ....... 24

6.18 Fullness control (Cl. 275-142342, 275-742642) .............. 25

6.18.1 General ..................................... 25

6.18.2 Operating terminal - description of the operating components ..... 25

6.18.3 Switchingthemachineon........................... 26

6.18.4 Sewing...................................... 26

6.18.4.1Smoothsewing................................. 26

6.18.4.2Sewingwithfullness.............................. 27

6.18.4.3Switchingbetweensmoothsewingandfullness.............. 27

6.18.4.4 Sewing with 8 programmed fullness sequences .............. 27

6.18.4.5 Alternately sewing right- and left-hand pieces with a

programmedfullness.............................. 28

6.18.5 Sequence advance by severing the thread ................. 28

6.18.6 Switching the edge cutter on and off (only Cl. 275-742642) ....... 28

6.18.7Displayingthecurrentprogram-switchingprograms........... 28

6.19 Keypadonthemachinearm.......................... 29

7. Sewing ...................................... 30

8. Maintenance

8.1 Cleaning and testing .............................. 32

8.2 Lubrication .................................... 33

1. Product description

The DÜRKOPP ADLER 275 is a special sewing machine with universal applications.

Basic type

Single-needle double-lockstitch machine with underfeed, differentiable-foot overfeed

and thread cutter for light to medium-heavy material with 4-mm stitch length and max.

8-mm overfeed length.

2. Designated use

The 275 is a special sewing machine designed to sew light material. Such material is

generally made of textile fibers, but it may also be leather. It is used in the clothing and

domestic-upholstery industries.

This sewing machine can also be used to produce so-called technical seams. In this

case, however, the operator must assess the possible dangers which may arise (with

which DÜRKOPP ADLER AG would be happy to assist), since such applications are on

the one hand relatively unusual and, on the other, they are so varied that no single set

of criteria can cover them all. The outcome of this assessment may require appropriate

safety measures to be taken.

Generally only dry material may be sewn with this machine. The material may be no

thicker than 6 mm when compressed by the lowered sewing feet. The material may not

contain any hard objects, since if it does the machine may not be operated without an

eye-protection device. No such device is currently available.

The seam is generally produced with textile-fibre sewing thread of gauge up to 30/2 Nm

(synthetic yarn) or 30/3 Nm (covering yarn). Before using any other thread the possible

dangers arising must be assessed and appropriate safety measures taken if necessary.

This special sewing machine may be set up and operated only in dry, well-maintained

premises. If the sewing machine is used in other premises which are not dry and

well-maintained it may be necessary to take further precautions (which should be

agreed in advance - see EN 60204-31: 1999).

As manufacturers of industrial sewing machines we proceed on the assumption that

personnel who work on our products will have received training at least sufficient to

acquaint them with all normal operations and with any hazards which these may involve.

3. Subclasses

Cl. 275-140332 Like the basic type, but with automatic electromagnetic

bar-tacking and automatic foot elevation, a smaller feeder

lifting cam and an adapted regulator to improve the

smooth-sewing results with small stitch lengths and light

materials, a drive motor with control device attached to the

machine. Fitted as standard with keys for bar-tacking within the

seam, for needle up/down and for activating and suppressing

bar tacks.

Cl. 275-140342 Like the basic type, but with automatic electropneumatic

bar-tacking and automatic foot elevation, a drive motor with

control device attached to the machine. Fitted as standard with

keys for bar-tacking within the seam, for needle up/down and

for activating and suppressing bar tacks.

Cl. 275-142342 Like the basic type, but with automatic electromagnetic

bar-tacking and automatic foot elevation, a drive motor with

control device attached to the machine. Also fitted with a

fullness control with 8 preselectable fullness values operating

via a step motor, plus smooth sewing, that can be selected with

keys or the knee-switch. Fitted as standard with keys for

bar-tacking within the seam, for needle up/down, for activating

and suppressing bar tacks and fullness on/off.

Cl. 275-740642 Like the basic type. but with automatic electromagnetic

bar-tacking and automatic foot elevation, an

electropneumatically connectable edge cutter driven by an

electric motor, a drive motor with control device attached to the

machine. Fitted as standard with keys for bar-tacking within the

seam, for activating and suppressing bar tacks and switching

the edge cutter on and off.

Cl. 275-742642 Like the basic type, but with automatic electromagnetic

bar-tacking and automatic foot elevation, an

electropneumatically connectable edge cutter driven by an

electric motor. Drive motor with control device attached to the

machine. Also fitted with a fullness control with 8 preselectable

fullness values operating via a step motor, plus smooth sewing,

that can be selected with keys or the knee-switch. Fitted as

standard with keys for bar-tacking within the seam, for

activating and suppressing bar tacks. Edge cutter on/off and

fullness activated or not activated.

4. Accessories

Subcl.

Material no. Equipment

0275 590034 Thread retractor X X X X X

0275 590014 Mechanical device to amplify

the overfeed during sewing (second pedal) XX X

0275 590044 Electropneumatic device to amplify the

overfeed via keys during sewing XX X

N900 020038 Swivel-down right edge stop

adjustment range 0-40 mm XXX

N900 040037 Swivel-down right edge stop with 2 mm, 5

mm or 10 mm stages XXX

N900 003601 Intermediate plate for particularly intensive

fullness XXXX

N005 225303 Edger, divided edger, pneumatic swivel-up

mechanism, for light material with 6-mm

seam width, containing N005 005302 edger

and N005 005301 attachment with Z100

001041 pneumatic switch unit

XXX

0271 002121 K conversion kit, 170% hook X X X X X

0271 590014 “Oil-free” hook conversion kit X X X X X

0271 000661 Knee lever add-on kit X X X X

0271 590024 Infrared reflex light barrier X X X X X

0271 590034 Photoelectric residual-thread monitor for

the looper thread XXXXX

9800 330009 Efka V810 operating panel X X X X X

9800 330010 Efka V820 operating panel X X X X X

9830 515031 Operating-panel attachment bracket X X X X X

9822 510001 Sewing lamp (Waldmann halogen) X X X X X

0APP 001041 Sewing-lamp installation kit X X X X X

0798 500088 Sewing-light transformer X X X X X

275-140332

275-140342

275-142342

275-740642

275-742642

Subcl.

9822 510000 Tripod sewing lamp X X X X X

9822 510011 Table clamp for tripod sewing lamp

9822 510000 XXXXX

9780 000108 WE8 maintenance unit X X X X X

0797 003031 Pneumatic- system connection pack X X X X X

MG53 400015 MG53-3, 1060x500 X X X X X

MG53 400016 MG53-3, 1060x600 X X X X X

MG53 400017 MG53-3, 1250x900/700 X X X X X

MG53 400018 MG53-3, 1060x600/table-plate opening

rotated by 10°X

275-140332

275-142042

275-140342

275-740642

275-742642

Autres manuels pour 275

Table des matières

Autres manuels Duerkopp Adler Machine à coudre

Duerkopp Adler

Duerkopp Adler 961-16-2 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 559 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 739-23 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 558 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 739-23 Caractéristiques techniques

Duerkopp Adler

Duerkopp Adler 744-122 Mode d'emploi

Duerkopp Adler

Duerkopp Adler 669 Premium Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 867-M PREMIUM Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 205-MO 2 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 528 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 1183i-7 Guide de dépannage

Duerkopp Adler

Duerkopp Adler 1230i-6 Guide de dépannage

Duerkopp Adler

Duerkopp Adler 973-S-204-4/. Mode d’emploi

Duerkopp Adler

Duerkopp Adler 550-16-23 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 205-370 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 272-160362 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 550-12-23 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 524-105 Mode d’emploi

Duerkopp Adler

Duerkopp Adler SP 460 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 269 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 2211/5 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 841-27 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 267 Manuel de la liste des pièces

Duerkopp Adler

Duerkopp Adler 4181i-3 Guide de dépannage

Manuels Machine à coudre populaires d'autres marques

Riccar

Riccar RL634DE Manuel utilisateur

Singer

Singer 2517 Manuel utilisateur

Pfaff

Pfaff 3307-1 SERIES Manuel utilisateur

Janome

Janome Quilt Maker Pro 18 VERSA Manuel utilisateur

Siruba

Siruba C007JP Manuel utilisateur

Husqvarna Viking

Husqvarna Viking Designer SE Manuel utilisateur

Singer

Singer 148-5 Manuel utilisateur

IKEA

IKEA SY Manuel utilisateur

Pfaff

Pfaff 571 Manuel utilisateur

Singer

Singer 15-91 Manuel utilisateur

Brother

Brother BB370 Manuel utilisateur

Pegasus

Pegasus WT100 Series Manuel utilisateur

Reliable

Reliable 7100DB Manuel utilisateur

Pfaff

Pfaff 937 Manuel utilisateur

Singer

Singer 6038 Manuel utilisateur

Singer

Singer 413K Manuel utilisateur

Pfaff

Pfaff 1471 E1 Manuel utilisateur

Kenmore

Kenmore 16677 - Serger Sewing Machine Manuel utilisateur
