DTS Alchemy 7 Manuel utilisateur

RDM – DMX – Manual Ver. 1.01 1 di 47

ALCHEMY 7

Release 1.01

For more information

Language EN

Art-Net™ Designed by and Copyright Artistic Licence Holdings Ltd

All other trademarks, both marked and not marked, are the property of their respective owners.

RDM – DMX – Manual Ver. 1.01 2 di 47

ALCHEMY 7

ITA

Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è

assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può

essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S.

Illuminazione.

D.T.S. Illuminazione si riserva il diritto di apportare senza preavviso cambiamenti e modifiche estetiche funzionali

o di design a ciascun proprio prodotto. D.T.S. Illuminazione non assume alcuna responsabilità sull’uso o

sull’applicazione dei prodotti o dei circuiti descritti.

ENG

The information contained in this publication has been carefully prepared and checked. However, no

responsibility will be taken for any errors. All rights are reserved and this document cannot be copied,

photocopied or reproduced, in part or completely, without prior written consent from D.T.S. Illuminazione

D.T.S. Illuminazione reserves the right to make any aesthetic, functional or design modifications to any of its

products without prior notice. D.T.S. Illuminazione takes no responsibility for the use or application of the products

or circuits described herein.

FRA

Les informations contenues dans le présent manuel ont été rédigées et contrôlées avec le plus grand soin. Nous

ne peut être copié, photocopié ou reproduit, dans sa totalité ou partiellement, sans le consentement préalable

de D.T.S. Illuminazione.

D.T.S. Illuminazione. se réserve le droit d'apporter toutes modifications et améliorations esthétiques,

fonctionnelles ou de design, sans préavis, à chacun de ses produits. D.T.S. Illuminazione décline toute

responsabilité sur l'utilisation ou sur l'application des produits ou des circuits décrits.

ESP

Las informaciones contenidas en este documento han sido cuidadosamente redactadas y controladas. Con todo,

no se asume ninguna responsabilidad por eventuales inexactitudes. Todos los derechos han sido reservados y

este documento no puede ser copiado, fotocopiado o reproducido, total o parcialmente, sin previa autorización

escrita de D.T.S. Illuminazione.

D.T.S. Illuminazione se reserva el derecho a aportar sin previo aviso cambios y modificaciones de carácter

estético, funcional o de diseño a cada producto suyo. D.T.S. Illuminazione no se asume responsabilidad de

ningún tipo sobre la utilización o sobre la aplicación de los productos o de los circuitos descritos.

RDM – DMX – Manual Ver. 1.01 3 di 47

ALCHEMY 7

Table of Contents

1DMX Signal Connection ............................................................................................................................... 4

1.1 DMX Modes ......................................................................................................................................... 4

1.2 Setting Up the DMX Address ............................................................................................................... 5

2Art-Net / sACN Signal Connection ............................................................................................................... 5

2.1 Direct Ethernet Operation .................................................................................................................... 5

2.2 Ethernet to RDM/DMX Operation ........................................................................................................ 6

3RDM Functions............................................................................................................................................. 7

4Updating the Firmware............................................................................................................................... 10

5Rotating Framing System........................................................................................................................... 11

6Display Functions....................................................................................................................................... 12

7Error Messages.......................................................................................................................................... 19

8DMX Protocol ............................................................................................................................................. 21

8.1 DMX Personality 1 ............................................................................................................................. 21

8.2 DMX Personality 2............................................................................................................................ 26

8.3 DMX Personality 3............................................................................................................................ 31

8.4 DMX Personality 4............................................................................................................................ 36

8.5 DMX Personality 5............................................................................................................................ 41

8.6 All DMX Personality ......................................................................................................................... 46

NOTES ............................................................................................................................................................... 47

RDM – DMX – Manual Ver. 1.01 4 di 47

ALCHEMY 7

1 DMX Signal Connection

• The unit operates using the digital USITT DMX512 signal.

• Connection between the light controller and the projector, or between projectors, must be carried out using a

two-pair screened ø 0.5 mm cable, and a XLR 5 or 3 pins connector.

• Ensure that the conductors do not touch each other. Do not connect the ground cable to the XLR chassis.

The housing of the plug must be isolated.

• Connect the light controller to the DMX IN panel connector of the projector; to create a link to the next

projector, simply connect the DMX OUT plug of the former to the DMX IN plug of the new fixture in line.

Following this procedure, all the projectors will be cascade connected.

PS. If the display showing the DMX address flashes, then one of the following errors has occurred:

- DMX signal not present

- DMX reception problem

For installations where long distance DMX cable connections are needed, the use of a DMX terminator is

recommended.

The DMX terminator is a male XLR 3- or 5-pins connector with a 120 Ω resistor between pin 2 and pin 3.

The DMX terminator must be plugged in into the last unit’s DMX OUT panel connector of the DMX line.

Place a 120 Ω resistor between pin 2 and 3 of a male XRL

connector;

Plug the resistor into the DMX OUT panel connector of the last unit

connected to the DMX line.

1.1 DMX Modes

ALCHEMY 7 can be used in five different DMX modes:

•CCT (default mode);

•Advanced;

•Basic;

•Expo;

•CMY Emulation

e.g., when using the unit in “CCT” mode (20/25 DMX channels) (default), set the following addresses on the

light desk:

RDM – DMX – Manual Ver. 1.01 5 di 47

ALCHEMY 7

Projector 1 A001

Projector 2 A045 If you want to select the next projector, just add “44” to the former DMX address

Projector 3 A089

….. A….

projector 6 A221

1.2 Setting Up the DMX Address

1 Press the UP and DOWN key until you reach the desired DMX address. The numbers on the display will

start flashing (new DMX address hasn't yet been set).

2 Press ENTER to confirm your selection. The numbers on the display will stop flashing; the projector is now

set to the new DMX address.

TIP: if you keep pressed down the UP or DOWN keys, address scrolling will be quicker allowing thus for a

faster selection.

2 Art-Net / sACN Signal Connection

ALCHEMY 7 can be controlled through Art-Net / sACN signals.

Connection between the light controller and the projector must be carried out using a category 5 network cable

and a standard RJ45 connector.

2.1 Direct Ethernet Operation

For direct Ethernet operation, connect the light controller’s Art-Net / s-ACN output signal via Ethernet switch to

each unit’s etherCON RJ45 IN connector.

For each unit, scroll to “NETWORK” menu (refer to the paragraph “Display Function” for further details):

•Inside the “INPUT” menu, select “Art-Net” or “sACN” as input control signal.

•Inside the “IP ADDRESS MODE” menu, select “Default” or “Static” mode.

•Inside the “ETH TO DMX” menu, select ON.

•Set the IP address and Net Mask. IP address must be different for each unit on a network.

•Set the Art-Net or sACN Universe.

RDM – DMX – Manual Ver. 1.01 6 di 47

ALCHEMY 7

DMX address: 1 DMX address: 45 DMX address: 89

IP address: 002.214.192.007 IP address: 002.214.192.008 IP address: 002.214.192.009

Universe: 1 Universe: 1 Universe: 1

2.2 Ethernet to RDM/DMX Operation

For Ethernet to RDM/DMX operation, connect the light controller’s Art-Net / s-ACN output signal via Ethernet

switch to the etherCON RJ45 input connector of the first unit only.

In this configuration, the first unit works as an Ethernet-to-DMX converter and sends RDM/DMX signal to its

DMX output connector. All the other units must be connected as a DMX chain with standard DMX settings.

Only for the first unit, scroll until reaching “NETWORK” menu (refer to DISPLAY FUNCTIONS for details):

•Inside the “INPUT” menu, select “Art-Net” or “sACN” as input control signal.

•Inside the “IP ADDRESS MODE” menu, select “Default” or “Static” mode.

•Inside the “ETH TO DMX” menu, select ON.

•Set the IP address and Net Mask. IP address must be different for each unit on a network.

•Set the Art-Net or sACN Universe.

DMX address: 1 DMX address: 45 DMX address: 89

IP address: 002.214.192.007

Universe: 1

DMX address: 1 DMX address: 45 DMX address: 89

IP address: 002.214.192.008

Universe: 2

For installations where long-distance DMX cable connections are needed, the use of a DMX terminator is

recommended.

Please refer to page 4 for further information DMX terminators.

RDM – DMX – Manual Ver. 1.01 7 di 47

ALCHEMY 7

3 RDM Functions

By using a RDM controller, it is possible to read/set DMX addresses, DMX modes and other parameters.

ALCHEMY 7 accepts the following RDM commands:

RDM Device Model ID: - ALCHEMY 7: 0x001B

- ALCHEMY 7F: 0x001A

RDM PID DESCRIPTION RDM PID VALUE GET SET

Category – Network Management

DISC_UNIQUE_BRANCH 0x0001

DISC_MUTE 0x0002

DISC_UN_MUTE 0x0003

Category – Status Collection

STATUS_MESSAGES 0x0030 X

STATUS_ID_DESCRIPTION 0x0031 X

Category - RDM Information

SUPPORTED_PARAMETERS 0x0050 X

PARAMETERS_DESCRIPTION 0x0051 X

Category – Product Information

DEVICE_INFO 0x0060 X

DEVICE_MODEL_DESCRIPTION 0x0080 X

MANUFACTURER_LABEL 0x0081 X

DEVICE_LABEL 0x0082 X X

SOFTWARE_VERSION_LABEL 0x00C0 X

Category - DMX512 Setup

DMX_PERSONALITY 0x00E0 X X

DMX_PERSONALITY_DESCRIPTION 0x00E1 X

DMX_START_ADDRESS 0x00F0 X X

Category – Sensors

SENSOR_DEFINITION 0x0200 X

SENSOR_VALUE 0x0201 X X

Category – Power/Lamp Settings

DEVICE_HOURS 0x0400 X

LAMP_HOURS 0x0401 X

Category – Display Settings

DISPLAY_INVERT 0x0500 X X

Category – Configuration

PAN_INVERT 0x0600 X X

TILT_INVERT 0x0601 X X

Category – Control

IDENTIFY_DEVICE 0x1000 X X

Category – Dimmer Settings

CURVE 0x0343 X X

CURVE_DESCRIPTION 0x0344 X

OUTPUT_RESPONSE_TIME 0x0345 X X

RDM – DMX – Manual Ver. 1.01 8 di 47

ALCHEMY 7

RDM PID DESCRIPTION

RDM PID VALUE

GET

SET

OUTPUT_RESPONSE_TIME_DESCRIPTION 0x0346 X

MODULATION_FREQUENCY 0x0347 X X

MODULATION_FREQUENCY_DESCRIPTION 0x0348 X

Category – Custom PID

ETHERNET_TO_DMX 0x8000 X X

INPUT_PRIORITY 0x8001 X X

DISPLAY_STANDBY 0x8002 X X

FURTHER RDM MESSAGES:

CURVE

CURVE DESCRIPTION

LINEAR

QUADRATIC (default)

GAMMA 2.2

S-CURVE

OUTPUT RESPONSE TIME OUTPUT_RESPONSE_TIME_DESCRIPTION

SMOOTH OFF

SMOOTH 1 ( 25 ms)

SMOOTH 2 ( 50 ms)

SMOOTH 3 ( 75 ms)

SMOOTH 4 (100 ms) (default)

SMOOTH 5 (125 ms)

SMOOTH 6 (150 ms)

SMOOTH 7 (175 ms)

SMOOTH 8 (200 ms)

SMOOTH 9 (225 ms)

SMOOTH 10 (250 ms)

SMOOTH 11 (275 ms)

13 SMOOTH 12 (300 ms)

SMOOTH 13 (325 ms)

SMOOTH 14 (350 ms)

SMOOTH 15 (375 ms)

SMOOTH 16 (400 ms)

SMOOTH 17 (425 ms)

SMOOTH 18 (450 ms)

SMOOTH 19 (475 ms)

SMOOTH 20 (500 ms)
