Directed Electronics PYTHON 480XP Manuel utilisateur

448800XXPP

➤

OOwwnneerr’’ssGGuuiiddee

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or

replace with a comparable reconditioned model any Directed unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated sensors and

accessories, which proves to be defective in workmanship or material under reasonable use

during the lifetime of the vehicle provided the following conditions are met: the unit was

professionally installed and serviced by an authorized Directed dealer; the unit will be pro-

fessionally reinstalled in the vehicle in which it was originally installed by an authorized

Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy

of the bill of sale or other dated proof of purchase bearing the following information: con-

sumer's name, telephone number and address; the authorized dealers name, telephone

number and address; complete product description, including accessories; the year, make

and model of the vehicle; vehicle license number and vehicle identification number. All

components other than the unit, including without limitation the siren, the remote trans-

mitters and the associated sensors and accessories, carry a one-year warranty from the date

of purchase of the same. This warranty is non-transferable and is automatically void if: the

original purchaser has not completed the warranty card and mailed it within ten (10) days

of the date of purchase to the address listed on the card; the unit's date code or serial num-

ber is defaced, missing or altered; the unit has been modified or used in a manner con-

trary to its intended purpose; the unit has been damaged by accident, unreasonable use,

neglect, improper service, installation or other causes not arising out of defects in materi-

als or construction. The warranty does not cover damage to the unit caused by installa-

tion or removal of the unit. Directed, in its sole discretion, will determine what consti-

tutes excessive damage and may refuse the return of any unit with excessive damage. TO

THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-

ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,

WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE

AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,

ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR

AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,

OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.

DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY

AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-

ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS

UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT

OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-

AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND

HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-

ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR

VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR

MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM

OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER

VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.

CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY

AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY

CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE

AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.

DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-

ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,

INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF

EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY

AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER

DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-

TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or con-

sequential damages. This warranty gives you specific legal rights and you may also have

other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-

rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-

876-0800. Directed security systems, including this unit, are deterrents against possible

theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft

of the automobile, its parts or contents; and hereby expressly disclaims any liability what-

soever, including without limitation, liability for theft, damage and/or vandalism.

Directed does not and has not authorized any person or entity to create for it any other

obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of alarm installed

➤Year, make, model and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

ttaabblleeooffccoonntteennttss

ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn..........................................................................22

wwhhaattiissiinncclluuddeedd......................................................................................................33

iimmppoorrttaannttiinnffoorrmmaattiioonn............................................................................................33

system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

ttrraannssmmiitttteerrffuunnccttiioonnss..............................................................................................55

standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

uussiinnggyyoouurrssyysstteemm..................................................................................................66

warning! safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

locking/arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

unlocking/disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

disabling the system without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

valet mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

remote start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

valet take-over . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

timer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

ssaaffeettyyffeeaattuurreess......................................................................................................1166

starter anti-grind circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

disabling the remote start system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

over and under rev protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

shut down inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

ccooddeehhooppppiinngg........................................................................................................1188

oowwnneerrrreeccooggnniittiioonn..................................................................................................1188

rraappiiddrreessuummeellooggiicc..................................................................................................1199

pprrooggrraammmmiinnggooppttiioonnss............................................................................................2200

gglloossssaarryyoofftteerrmmss..................................................................................................2211

ccoonnvveenniieenncceeeexxppaannssiioonnss........................................................................................2222

qquuiicckkrreeffeerreenncceegguuiiddee............................................................................................2244

ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn

controls the AArrmmfunction.

controls the DDiissaarrmmfunction.

controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt.

controls the PPaanniiccfunction.

and pressed together control the RReemmootteeSSttaarrtt..

wwhhaattiissiinncclluuddeedd

➤The control module

➤An XHF receiver/antenna

➤A pair of four-button transmitters

➤The red status LED indicator light

➤A push-button Valet®switch

➤Your warranty registration

➤Failsafe®Starter Kill Relay

➤A shut-down toggle switch

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your remote start keyless

entry system. Due to the complexity of this system, it must be

installed by an authorized dealer only. Installation of this product

by anyone other than an authorized dealer voids the warranty. All

dealers are provided with a preprinted dealer certificate to verify

that they are authorized.

By carefully reading this Owner's Guide prior to using your

system, you will maximize the use of this system and its features.

You can print additional or replacement copies of this manual by

accessing the Directed web site at www.directed.com.

system maintenance

The system requires no specific maintenance. Your remote is

last approximately one year under normal use. When the battery

begins to weaken, operating range will be reduced and the LED

on the remote will dim.

your warranty

Your warranty registration must be completely filled out and

returned within 10 days of purchase. Your product warranty

will not be validated if your warranty registration is not returned.

Make sure you receive the warranty registration from your dealer.

It is also necessary to keep your proof of purchase, which reflects

that the product was installed by an authorized dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

➜

caution

This product is designed for fuel injected, automatic transmis-

sion vehicles only. Use of this product in a standard transmission

vehicle is dangerous and contrary to the product's intended use.

ttrraannssmmiitttteerrffuunnccttiioonnss

The receiver uses a computer-based learn routine to learn the

transmitter buttons. This makes it possible to assign any specific

transmitter button, or combination of buttons, to any receiver

function. The transmitter initially comes programmed with the

Standard Configuration, but may also be customized by an

authorized dealer. The transmitter buttons indicated in all of the

instructions in this manual correspond to a Standard

Configuration transmitter.

standard configuration

Button

The locking/arming function is controlled by pressing this

button for one second.

Button

The unlocking/disarming function is controlled by pressing this

button for one second.

Button

Silent Mode™ and an optional auxiliary function are controlled

by this button. (Silent Mode works by pressing this button for

➜

less than one second before arming or disarming. An optional

auxiliary function, such as trunk release, can be controlled by

pressing this button for 1.5 seconds.)

The auxiliary output controls __________________________.

Button

The panic feature is controlled by pressing this button for one

second.*

and Buttons

The remote start function of your system is controlled by

pressing these buttons simultaneously.

*This is an optional feature that may require additional parts and labor.

uussiinnggyyoouurrssyysstteemm

warning! safety first

The following safety warnings must be observed at all times:

➤Due to the complexity of this system, installation of this

product must only be performed by an authorized Directed

dealer.

➤When properly installed, this system can start the vehicle via

a command signal from the remote control transmitter.

Therefore, never operate the system in an enclosed area or

partially enclosed area without ventilation (such as a garage).

➜

Autres manuels pour PYTHON 480XP

Table des matières

Autres manuels Directed Electronics Alarme de voiture

Directed Electronics

Directed Electronics AM1 Manuel utilisateur

Directed Electronics

Directed Electronics Viper 140 HF Manuel utilisateur

Directed Electronics

Directed Electronics Hornet 563T Manuel utilisateur

Directed Electronics

Directed Electronics Vehicle Security System 3901V Manuel utilisateur

Directed Electronics

Directed Electronics Car Alarm Manuel utilisateur

Directed Electronics

Directed Electronics Concept 550 Manuel utilisateur

Directed Electronics

Directed Electronics 410S Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 20095 Manuel utilisateur

Directed Electronics

Directed Electronics 446 Series Manuel utilisateur

Directed Electronics

Directed Electronics Concept 650 Manuel utilisateur

Directed Electronics

Directed Electronics Security System and Convenience 125xv Manuel utilisateur

Directed Electronics

Directed Electronics Clifford 120XV Manuel utilisateur

Directed Electronics

Directed Electronics 435 Manuel utilisateur

Directed Electronics

Directed Electronics G436S 5220XS Manuel utilisateur

Directed Electronics

Directed Electronics Python 533 Manuel utilisateur

Directed Electronics

Directed Electronics 4100 Manuel utilisateur

Directed Electronics

Directed Electronics AVITAL 3001L Manuel utilisateur

Directed Electronics

Directed Electronics AM2 Manuel utilisateur

Directed Electronics

Directed Electronics 436 Series Manuel utilisateur

Directed Electronics

Directed Electronics Clifford RS2.1 Manuel utilisateur

Directed Electronics

Directed Electronics Python 500 Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics Avital Manuel utilisateur

Directed Electronics

Directed Electronics 871XP Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
