Intelliguard 850

OOwwnneerr’’ssGGuuiiddee

limited lifetime consumer warranty

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace

with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding

without limitation the siren, the remote transmitters, the associated sensors and accessories,

which proves to be defective in workmanship or material under reasonable use during the life-

time of the vehicle provided the following conditions are met: the unit was professionally

installed and serviced by an authorized Directed dealer; the unit will be professionally rein-

stalled in the vehicle in which it was originally installed by an authorized Directed dealer; and

the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other

dated proof of purchase bearing the following information: consumer's name, telephone num-

ber and address; the authorized dealers name, telephone number and address; complete prod-

uct description, including accessories; the year, make and model of the vehicle; vehicle license

number and vehicle identification number. All components other than the unit, including with-

out limitation the siren, the remote transmitters and the associated sensors and accessories,

carry a one-year warranty from the date of purchase of the same. This warranty is non-trans-

ferable and is automatically void if: the original purchaser has not completed the warranty card

and mailed it within ten (10) days of the date of purchase to the address listed on the card; the

unit's date code or serial number is defaced, missing or altered; the unit has been modified or

used in a manner contrary to its intended purpose; the unit has been damaged by accident,

unreasonable use, neglect, improper service, installation or other causes not arising out of

defects in materials or construction. The warranty does not cover damage to the unit caused

by installation or removal of the unit. Directed, in its sole discretion, will determine what con-

stitutes excessive damage and may refuse the return of any unit with excessive damage. TO

THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING BUT NOT LIMITED

TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS

FOR PARTICULAR PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL

PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES

ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CON-

NECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY

FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR

INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS

AGAINST POSSIBLE THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE

AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;

AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITHOUT LIM-

ITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRANTY DOES NOT

COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR

ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE

INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUN-

TY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS

SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM

AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER'S

PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES

WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCI-

DENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE,

THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-

TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an

implied warranty will last or the exclusion or limitation of incidental or consequential damages.

This warranty gives you specific legal rights and you may also have other rights that vary from

State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your authorized

Directed dealer for details of the plan or call Directed Customer Service at 1-800-876-0800.

Directed security systems, including this unit, are deterrents against possible theft. Directed is

not offering a guarantee or insurance against vandalism, damage or theft of the automobile,

its parts or contents; and hereby expressly disclaims any liability whatsoever, including without

limitation, liability for theft, damage and/or vandalism. Directed does not and has not autho-

rized any person or entity to create for it any other obligation, promise, duty or obligation in

connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

zDate of purchase

zYour full name and address

zAuthorized dealer's company name and address

zType of alarm installed

zYear, make, model and color of the automobile

zAutomobile license number

zVehicle identification number

zAll security options installed on automobile

zInstallation receipts

trademarks and copyrights

Bitwriter™, Clifford®, Code-Hopping™, Directed®, Doubleguard®, ESP™, FailSafe®, Ghost Switch™,

Learn Routine™, Nite-Lite®, Nuisance Prevention Circuitry®, NPC®, Revenger®, Silent Mode™, Soft

Chirp®, Stealth Coding™, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away®are

all Trademarks or Registered Trademarks of Directed Electronics, Inc.

iimmppoorrttaanntt!!Please note that this manual was intended for US consumers

and therefore includes American phrases or words.

limited lifetime consumer

warranty . . . . . . . . . . . . . . . . . . . . .i

trademarks and copyrights . . . . .ii

what is included . . . . . . . . . . . . .2

important information . . . . . . . . .2

system maintenance . . . . . . . .3

your warranty . . . . . . . . . . . . .3

fcc/id notice . . . . . . . . . . . . . . .3

transmitter configurations . . . . . .4

transmitter functions . . . . . . . . . .4

standard configuration . . . . . . .5

using your system . . . . . . . . . . . . .6

arming . . . . . . . . . . . . . . . . . . .6

disarming . . . . . . . . . . . . . . . . .8

disarming without a transmitter .8

remote siren silencing . . . . . . .8

transmitter chirp muting . . . . .9

transmitter sensor disable . . . .9

intellistart and smartwindows

sensor bypass . . . . . . . . . . . . . . .10

auxiliary channel bypass . . . . .10

panic mode with smart door

locking . . . . . . . . . . . . . . . . . .10

disarm/valet mode . . . . . . . . .11

transmitter valet mode . . . . . .12

one-time auto-arming bypass .12

low battery warning . . . . . . .12

multiple event total recall . . . .13

false alarm control

technology (FACT II) . . . . . . . .13

select siren sounds . . . . . . . . . . .14

diagnostics . . . . . . . . . . . . . . . . . .14

arming diagnostics . . . . . . . . .15

disarming diagnostics . . . . . . .15

arm/disarm diagnostic chart . .16

table of zones . . . . . . . . . . . .16

anti-code grabbing (ACG) . . . . .17

high frequency . . . . . . . . . . . . . .18

smart power up II . . . . . . . . . . . .18

power saver mode . . . . . . . . . . .18

programming options . . . . . . . .19

cliffnet wizard installation soft-

ware programming . . . . . . . . . .21

manual programming

instructions . . . . . . . . . . . . . .21

user selectable features . . . . .23

user selectable features

descriptions - column one . . .24

user selectable features

descriptions - column two . . .26

user selectable features

descriptions - column three . .28

pin programming . . . . . . . . . . . .30

auto-immobilization feature . . .31

auto-immobilization sequence 31

one-time valet feature . . . . . .32

blackjax feature . . . . . . . . . . .32

blackjax activation sequence .33

blackjax deactivation sequence34

bypass blackjax temporarily . . . .34

blackjax off warning indicator 35

adjusting the proximity sensor 35

adjusting the omnisensor . . . .37

glossary of terms . . . . . . . . . . . . .40

security & convenience

expansions . . . . . . . . . . . . . . . . . .42

health check . . . . . . . . . . . . . . . .43

contents

what is included

zIntelliguard control module and harness

zTwo five-button transmitters

zPresentation envelope and quick reference card

zTwo window decals

zXHF antenna/receiver with harness

zPre-wired blue status LED

zPlainView 2 Valet switch

z518C neo-siren

zDigital dual-zone proximity sensor

zDigital dual-zone omnisensor

important information

Congratulations on the purchase of your state-of-the-art vehicle

security system. It has been designed to provide years of trouble-free

operation. This system must be installed by an authorized dealer.

Installation of this product by anyone other than an authorized dealer

voids the warranty. As verification of authorization, all authorized deal-

ers are provided with preprinted dealer certificates.

In order to maximize the use of this system, please review this owner's

guide carefully prior to using your system. You can print additional or

replacement copies of this owner’s guide by accessing the Clifford web-

site at www.clifford.com.

system maintenance

The system requires no specific maintenance. Your transmitter is pow-

ered by a miniature 3V lithium battery that will last approximately one

year under normal use. When the battery weakens, operating range will

be reduced and the system will provide a low battery warning chirp indi-

cation when disarming.

your warranty

Your warranty registration must be completely filled out and returned

within 10 days of purchase. Your product warranty will not be validat-

ed if your warranty registration is not returned. Make sure you receive

the warranty registration from your dealer. It is also necessary to keep

your proof of purchase, which reflects that the product was installed by

an authorized dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) This device must accept any interference received,

including interference that may cause undesirable operation.

Changes or modifications not expressly approved by the party responsi-

ble for compliance could void the user's authority to operate this device.

Tested to Comply

with FCC Standards

Directed Electronics, Inc. EZSRADAR2

transmitter configurations

transmitter functions

This system uses computer-based code learning to learn the transmit-

ter buttons. This makes it possible to assign any transmitter button to

any system function. The transmitter initially comes programmed with

standard configuration, but may also be customized using the CliffNet

Wizard PC program. The buttons in all of the instructions in this man-

ual correspond to a standard configuration transmitter.

nnoottee::This manual describes the features and accessories that are

included with your system along with information about compatible

Clifford accessories that are not included. For a list of included acces-

sories, please refer to the

What Is Included

section of this manual.

Arm/Disarm and

Panic Button

Trunk Release or

Optional Accessory

Channel Button

Remote Start or

Accessory Output Button

Silent Arm/Disarm or

Accessory Output Button

Shift Button

standard configuration

Button

The arming, disarming, and panic function are controlled by this button.

Button

The trunk release or accessory output A is controlled by this button.

Button

Silent arm and disarm is controlled by this button.

Button

Remote start is controlled by this button.

Button, then Button

Accessory B output is controlled by these buttons.

Button, then Button

These buttons activate SmartWindows.

Button, then Button

Accessory C output is controlled by these buttons.

Button twice, then Button

These buttons activate remote valet.

Button twice, then Button

These buttons disable the sensors.

Button twice, then Button

These buttons enter safe start mode for manual transmission vehicles

and activate Autostart mode.

Button three times, then Button

These buttons adjust the dual-zone omnisensor.

Button three times, then Button

These buttons adjust the dual-zone radar sensor.

using your system

The buttons used in the instructions in this manual correspond to the

standard transmitter configuration. If your transmitter has been custom

configured, the icons on your transmitter buttons may not correspond

to the indicated functions.

arming

You can activate, or arm, the system by pressing on your trans-

mitter for one second. When the system arms, you will hear two short

siren sounds, or chirps, and see the parking lights flash twice. The LED

will begin to flash steadily. If the vehicle’s power door locks have been

connected to the system, the doors will lock.

While the system is armed, the LED status indicator will flash approxi-

mately once per second showing that the system is actively protecting

your vehicle. If you hear more than two chirps when arming, refer to

the Diagnostics section of this guide. These extra chirps confirm a mal-

function autobypass.

The security system also can be programmed to arm itself

automatically (called passive arming). If the system is programmed for

passive arming, it will automatically arm 30 seconds after the ignition is

turned off and the system sees you leave the vehicle by opening and

closing a door. Whenever the system is in its 30-second passive-arming

countdown. The siren will chirp twice and the lights will flash twice five

seconds after the last door has been closed. The system is not actually

armed at that point. The system arms and the doors lock (if connected

and programmed for passive locking) at 30 seconds, but the siren will

not chirp. The early chirps provide you with a 25-second warning prior

to arming.

When armed, your vehicle is protected as follows:

zThe LED will flash as a visible theft deterrent.

zLight impacts will trigger the Warning Zone signal. When

triggered, the siren will sound for a few seconds.

zHeavy impacts will trigger the system. The triggered

sequence is 30, 60, or 90 seconds of constant siren sounding

and flashing parking lights.

zIf a protected entry (door, hood, or trunk) is opened, the system

will immediately trigger the siren and flash the parking lights.

nnoottee::If any protected entry point (a door or a switch-protected trunk or

hood) is open, the system will not passively arm. Additionally, each

time a protected entry is triggered during the arming countdown, the

30-second countdown starts over.

Table des matières

Autres manuels Directed Electronics Alarme de voiture

Directed Electronics

Directed Electronics Python 323 Manuel utilisateur

Directed Electronics

Directed Electronics 4103 Series Manuel utilisateur

Directed Electronics

Directed Electronics Hornet 563T Manuel utilisateur

Directed Electronics

Directed Electronics VIPER 3203 Manuel utilisateur

Directed Electronics

Directed Electronics Clifford 2.2 Manuel utilisateur

Directed Electronics

Directed Electronics Python 571XP Manuel utilisateur

Directed Electronics

Directed Electronics Viper 140 HF Manuel utilisateur

Directed Electronics

Directed Electronics WASP 718W Manuel utilisateur

Directed Electronics

Directed Electronics Python 990 Manuel utilisateur

Directed Electronics

Directed Electronics Vehicle Security System 3901V Manuel utilisateur

Directed Electronics

Directed Electronics 10 Manuel utilisateur

Directed Electronics

Directed Electronics Viper 4704 Manuel utilisateur

Directed Electronics

Directed Electronics Viper 571XV Manuel utilisateur

Directed Electronics

Directed Electronics Cyber 76XV Manuel utilisateur

Directed Electronics

Directed Electronics VIPER 5701 Manuel utilisateur

Directed Electronics

Directed Electronics Viper 211HV Manuel utilisateur

Directed Electronics

Directed Electronics 554R Manuel utilisateur

Directed Electronics

Directed Electronics Avital 2300 Manuel utilisateur

Directed Electronics

Directed Electronics Python 881XP Manuel utilisateur

Directed Electronics

Directed Electronics K10 Manuel utilisateur

Directed Electronics

Directed Electronics 4400 Manuel utilisateur

Directed Electronics

Directed Electronics 410S Manuel utilisateur

Directed Electronics

Directed Electronics Viper 220MAX Manuel utilisateur

Directed Electronics

Directed Electronics Viper 5601 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
