Directed Electronics Model 3000 ESP Manuel utilisateur

Model 3000 ESP

Owner's Guide

Limited Lifetime

Consumer Warranty

Directed Electronics, Inc. ("DEI®") promises to the original purchaser to repair or

replace with a comparable reconditioned model any DEI unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated

sensors and accessories, which proves to be defective in workmanship or material

under reasonable use during the lifetime of the vehicle provided the following condi-

tions are met: the unit was professionally installed and serviced by an authorized DEI

dealer; the unit will be professionally reinstalled in the vehicle in which it was orig-

inally installed by an authorized DEI dealer; and the unit is returned to DEI, shipping

prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing

the following information: consumer's name, telephone number and address; the

authorized dealers name, telephone number and address; complete product descrip-

tion, including accessories; the year, make and model of the vehicle; vehicle license

number and vehicle identification number. All components other than the unit,

including without limitation the siren, the remote transmitters and the associated

sensors and accessories, carry a one-year warranty from the date of purchase of the

same. This warranty is non-transferable and is automatically void if: the original

purchaser has not completed the warranty card and mailed it within ten (10) days of

the date of purchase to the address listed on the card; the unit's date code or serial

number is defaced, missing or altered; the unit has been modified or used in a

manner contrary to its intended purpose; the unit has been damaged by accident,

unreasonable use, neglect, improper service, installation or other causes not arising

out of defects in materials or construction. The warranty does not cover damage to

the unit caused by installation or removal of the unit. DEI, in its sole discretion, will

determine what constitutes excessive damage and may refuse the return of any unit

with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL

WARRANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED

WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE

AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE

EXPRESSLY EXCLUDED; AND DEI NEITHER ASSUMES NOR AUTHORIZES ANY PERSON

OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNEC-

TION WITH ITS PRODUCTS. DEI DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY

FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS

OR INSTALLERS. DEI SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS

AGAINST POSSIBLE THEFT. DEI IS NOT OFFERING A GUARANTEE OR INSURANCE

AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR

CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER,

INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR

VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE,

REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF

ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DEI OR ITS

SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF

CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL

APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM

AGAINST DEI SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DEI DEALER'S

PURCHASE PRICE OF THE UNIT. DEI SHALL NOT BE RESPONSIBLE FOR ANY

DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL

DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF

EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE.

NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED

WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.

Some states do not allow limitations on how long an implied warranty will last or the

exclusion or limitation of incidental or consequential damages. This warranty gives

you specific legal rights and you may also have other rights that vary from State to

State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your

authorized DEI dealer for details of the plan or call DEI Customer Service at 1-800-

876-0800. DEI security systems, including this unit, are deterrents against possible

theft. DEI is not offering a guarantee or insurance against vandalism, damage or theft

of the automobile, its parts or contents; and hereby expressly disclaims any liability

whatsoever, including without limitation, liability for theft, damage and/or vandalism.

DEI does not and has not authorized any person or entity to create for it any other

obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of alarm installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

Table of Contents

Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Expanded Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using Your System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Arming While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Multi-Level Security Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Disarming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Disarming Without A Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Ghost Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Silent Mode™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Valet® Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Remote Valet® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Nuisance Prevention Circuitry™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Arming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Disarming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Code Hopping™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

High Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Owner Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Rapid Resume Logic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Vehicle Recovery System (VRS®) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Arming the VRS® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

VRS® Triggered Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Disarming the VRS® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Glossary Of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Quick Reference Guide (Removable). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Standard Configuration

controls the Arm, Disarm and Panic functions.

is used for Silent Mode, Remote Valet and optional Trunk

Release.

controls an optional Auxiliary Output.

controls another optional Auxiliary Output.

and pressed simultaneously control another optional

Auxiliary Output.

and pressed simultaneously control another optional

Auxiliary Output.

What is Included

■7-Channel Receiver

■A pair of four-button transmitters

■A Stinger®DoubleGuard®dual-output shock sensor

■The Revenger®Soft Chirp®six-tone programmable siren

■The red status LED indicator light

■A push-button Valet®switch

■Your warranty card

■FailSafe®Starter Kill ready circuitry (may require additional labor)

Important Information

Congratulations on the purchase of your state-of-the-art vehicle

security system. This system has been designed to provide years of

trouble-free operation. Due to the complexity of this system, it

must only be installed by an authorized dealer. Installation of this

product by anyone other than an authorized dealer voids the

warranty. All dealers are provided with preprinted dealer certifi-

cates as proof of authorization.

This owner’s guide should help you to get the most out of your

system. Please take the time to read it thoroughly prior to using

this system. Additional or replacement copies of this manual may

be downloaded from the DEI®website at www.directed.com.

This system requires no specific maintenance. Your remote control

is powered either by a miniature 12V battery, type GP23A, or a

lightweight 3-volt lithium battery, both of which will last approx-

imately one year under normal use. Contact your dealer if you have

any questions. When the battery weakens, operating range will be

reduced and the LED on the remote will dim.

Your warranty card must be returned and the bar code serial

number must not be removed. If the warranty card is not returned

you do not have a warranty. Make sure you receive the warranty

card from your dealer. It is also necessary to keep your proof of

purchase, which indicates that the product was installed by an au-

thorized dealer.

This device complies with Part 15 of FCC rules. Operation is subject

to the following two conditions: (1) This device may not cause

harmful interference, and (2) This device must accept any interfer-

ence received, including interference that may cause undesired

operation.

Caution: Changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to

operate this device.

FCC/ID Notice

Your Warranty

System Maintenance

Transmitter Functions

The receiver uses a computer-based Learn Routine to learn the

transmitter buttons. This makes it possible to assign any button on

the remote transmitter to any receiver function. Two possible

transmitter configurations are described in this section. Remember

that there are many alternate custom configurations that can be

programmed by your dealer.

The standard configuration is how the transmitters come programmed

initially. If you would like a custom configuration, contact an

authorized dealer.

Button I

The arm, disarm, and panic functions are usually controlled by

pressing .

Button II

Silent Mode™, Remote Valet®, and optional trunk release (if

equipped) functions are usually controlled by . (Silent Mode

and Remote Valet work by pressing for less than one second.

Trunk release requires you to press and hold for 1.5 seconds.)

Button III

An optional auxiliary convenience or expansion function that you

may have added to your system can be activated by pressing .

This auxiliary output controls _____________________________.

Standard Configuration

Button IV

Another optional auxiliary convenience or expansion function that you

may have added to your system can be activated by pressing .

This auxiliary output controls _____________________________.

Buttons I and II

Another optional auxiliary convenience or expansion function that

you may have added to your system can be activated by pressing

and simultaneously.

This auxiliary output controls _____________________________.

Buttons III and IV

Another optional auxiliary convenience or expansion function that

you may have added to your system can be activated by pressing

and simultaneously.

This auxiliary output controls _____________________________.

A remote that uses the expanded configuration operates similarly

to many factory keyless entry remotes. An expanded configuration

transmitter allows you to arm, disarm, and activate Panic Mode

with separate transmitter buttons. The expanded configuration

also allows you to utilize Multi-Level Security Arming, an addi-

tional feature that cannot be utilized when using a standard

configuration transmitter. (See Multi-Level Security Arming Section

of this guide for details about this feature.) The transmitter

buttons are used for the following functions in the expanded

configuration:

Expanded Configuration

Button I

The arming and Multi-Level Security functions are usually

controlled by . Pressing for one second will arm the

system. Pressing again within five seconds of arming

activates Multi-Level Security.

Button II

Pressing for one second will disarm the system. If configured

for optional progressive unlocking, pressing when disarming

will only unlock the driver’s door. A second press of will then

unlock the passenger doors.

Button III

Silent Mode™, Remote Valet®, and optional trunk release are all

controlled by pressing . Silent Mode™and Remote Valet work

by pressing for less than one second. Pressing for 1.5

seconds will activate the trunk release function.

Button IV

Pressing at any time will activate Panic Mode.

Button Combinations

Four unique combinations of buttons can be assigned to control

convenience or expansion options that you may have added to

your system. Consult your authorized dealer for details.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Directed Electronics Alarme de voiture

Directed Electronics

Directed Electronics 411R Series Manuel utilisateur

Directed Electronics

Directed Electronics Matrix 1 Manuel utilisateur

Directed Electronics

Directed Electronics Viper 140 HF Manuel utilisateur

Directed Electronics

Directed Electronics Intelliguard 750 Manuel utilisateur

Directed Electronics

Directed Electronics Intelliguard 850 Manuel utilisateur

Directed Electronics

Directed Electronics Hurricane 3 Manuel utilisateur

Directed Electronics

Directed Electronics 871XP Manuel utilisateur

Directed Electronics

Directed Electronics 3100 Manuel utilisateur

Directed Electronics

Directed Electronics Arrow 5 Manuel utilisateur

Directed Electronics

Directed Electronics Python 500 Manuel utilisateur

Directed Electronics

Directed Electronics Valet 561T Manuel utilisateur

Directed Electronics

Directed Electronics Python 460HP Manuel utilisateur

Directed Electronics

Directed Electronics VIPER 1000 Manuel utilisateur

Directed Electronics

Directed Electronics 625 Manuel utilisateur

Directed Electronics

Directed Electronics WASP 718W Manuel utilisateur

Directed Electronics

Directed Electronics Vehicle Security System 3901V Manuel utilisateur

Directed Electronics

Directed Electronics 410S Manuel utilisateur

Directed Electronics

Directed Electronics Security System and Convenience 125xv Manuel utilisateur

Directed Electronics

Directed Electronics Viper 220MAX Manuel utilisateur

Directed Electronics

Directed Electronics 6000 Manuel utilisateur

Directed Electronics

Directed Electronics 4103 Series Manuel utilisateur

Directed Electronics

Directed Electronics Hornet 719T Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics 460MAX Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
