443366SSeerriieess

➤

OOwwnneerr’’ssGGuuiiddee

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or

replace with a comparable reconditioned model any Directed unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated sensors and

accessories, which proves to be defective in workmanship or material under reasonable use

during the lifetime of the vehicle provided the following conditions are met: the unit was

professionally installed and serviced by an authorized Directed dealer; the unit will be pro-

fessionally reinstalled in the vehicle in which it was originally installed by an authorized

Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy

of the bill of sale or other dated proof of purchase bearing the following information: con-

sumer's name, telephone number and address; the authorized dealers name, telephone

number and address; complete product description, including accessories; the year, make

and model of the vehicle; vehicle license number and vehicle identification number. All

components other than the unit, including without limitation the siren, the remote trans-

mitters and the associated sensors and accessories, carry a one-year warranty from the date

of purchase of the same. This warranty is non-transferable and is automatically void if: the

original purchaser has not completed the warranty card and mailed it within ten (10) days

of the date of purchase to the address listed on the card; the unit's date code or serial num-

ber is defaced, missing or altered; the unit has been modified or used in a manner con-

trary to its intended purpose; the unit has been damaged by accident, unreasonable use,

neglect, improper service, installation or other causes not arising out of defects in materi-

als or construction. The warranty does not cover damage to the unit caused by installa-

tion or removal of the unit. Directed, in its sole discretion, will determine what consti-

tutes excessive damage and may refuse the return of any unit with excessive damage. TO

THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-

ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,

WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE

AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,

ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR

AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,

OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.

DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY

AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-

ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS

UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT

OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-

AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND

HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-

ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR

VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR

MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM

OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER

VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.

CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY

AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY

CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE

AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.

DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-

ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,

INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF

EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY

AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER

DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-

TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or con-

sequential damages. This warranty gives you specific legal rights and you may also have

other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-

rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-

876-0800. Directed security systems, including this unit, are deterrents against possible

theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft

of the automobile, its parts or contents; and hereby expressly disclaims any liability what-

soever, including without limitation, liability for theft, damage and/or vandalism.

Directed does not and has not authorized any person or entity to create for it any other

obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of alarm installed

➤Year, make, model and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

ttaabblleeooffccoonntteennttss

LLiimmiitteeddLLiiffeettiimmeeCCoonnssuummeerrWWaarrrraannttyy......................................................................ii

SSttaannddaarrddTTrraannssmmiitttteerrCCoonnffiigguurraattiioonn........................................................................22

WWhhaattiissIInncclluuddeedd................................................................................................33

IImmppoorrttaannttIInnffoorrmmaattiioonn............................................................................................33

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Your Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FCC/ID Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

TTrraannssmmiitttteerrFFuunnccttiioonnss............................................................................................55

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

UUssiinnggYYoouurrSSyysstteemm..............................................................................................66

Active Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Passive Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Multi-Level Security Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Arming While Driving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Disarming Without a Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Silent Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Panic Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Nuisance Prevention® Circuitry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

DDiiaaggnnoossttiiccss............................................................................................................1155

Arming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Disarming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

System Status Chirps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Table of Zones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Interpreting Zone Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

CCooddeeHHooppppiinngg......................................................................................................1188

HHiigghhFFrreeqquueennccyy....................................................................................................1199

OOwwnneerrRReeccooggnniittiioonn................................................................................................1199

RRaappiiddRReessuummeeLLooggiicc..............................................................................................2200

PPoowweerrSSaavveerrMMooddee................................................................................................2200

PPrrooggrraammmmiinnggOOppttiioonnss........................................................................................2211

IInnssttaallllaattiioonnOOppttiioonnss............................................................................................2244

VVeehhiicclleeRReeccoovveerryySSyysstteemm((VVRRSS®®))..........................................................................2255

Arming the VRS®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

VRS® Triggered Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Disarming the VRS® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

GGlloossssaarryyooffTTeerrmmss..................................................................................................2288

SSeeccuurriittyy&&CCoonnvveenniieenncceeEExxppaannssiioonnss......................................................................3300

QQuuiicckkRReeffeerreenncceeGGuuiiddee((RReemmoovvaabbllee))......................................................................3333

ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn

controls the AArrmmfunction.

controls the DDiissaarrmmfunction.

controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt.

controls the PPaanniiccfunction.

and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt.

wwhhaattiissiinncclluuddeedd

➤One control module

➤A pair of four-button transmitters

➤A Stinger® Doubleguard® dual-stage shock sensor

➤The Revenger® Soft Chirp® six-tone programmable siren

➤The red status LED indicator light

➤A push-button Valet button

➤Your warranty registration

➤Failsafe® Starter Kill ready circuitry

(may require additional labor)

➤XHF external receiver/antenna

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your state-of-the-art vehicle

security system. This system has been designed to provide years

of trouble-free operation. Due to the complexity of this system,

it must be installed by an authorized dealer only. Installation of

this product by anyone other than an authorized dealer voids the

warranty. All dealers are provided with preprinted dealer certifi-

cates to verify that they are authorized.

This owner’s guide should help you to get the most out of your

system. Please take the time to read it prior to using the system.

system maintenance

The system requires no specific maintenance. Your remote

control is powered by a small, lightweight 3 volt lithium battery

that will last approximately one year under normal use. When

the battery weakens, operating range will be reduced and the

LED on the remote will dim.

your warranty

Your warranty registration must be returned and the bar code

serial number must not be removed. If the warranty registration

is not returned, you do not have a warranty. It is also necessary

to keep your proof of purchase, which reflects that the product

was installed by an authorized dealer. Make sure that you receive

the warranty registration from your dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

➜

ttrraannssmmiitttteerrffuunnccttiioonnss

This system uses a computer-based learn routine to learn the

transmitter buttons. This makes it possible to assign any trans-

mitter button to any system function. The transmitter initially

comes programmed with Standard Configuration, but may also

be customized by an authorized dealer. The buttons in all of the

instructions in this manual correspond to a Standard

Configuration transmitter.

standard configuration

Button

The arming function is controlled by pressing this button for one

second.

Button

The disarming function is controlled by pressing this button for

one second.

Button

Silent Mode™ and an optional auxiliary function are controlled

by pressing this button. (Silent Mode works by pressing this

button for less than one second before arming or disarming. An

optional auxiliary function, such as trunk release, can be

controlled by pressing this button for 1.5 seconds.)

The auxiliary output controls __________________________.

Button

The panic feature is controlled by pressing this button for two

seconds.

➜

and Buttons

An optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing these

buttons simultaneously.

The auxiliary output controls_________________________.

uussiinnggyyoouurrssyysstteemm

The buttons used in the instructions in this manual correspond

to the standard configuration. Remember, this is not the only

way your transmitter may be set up. It can be custom configured

to meet your needs.

active arming

You can activate, or arm, the system by pressing on your

transmitter for one second. When the system arms, you will hear

a short siren sound, or chirp, and the parking lights will flash

once. If the vehicle’s power door locks have been connected to

the system, the doors will lock.

While the system is armed, the status LED will flash approxi-

mately once per second, indicating that the system is actively

protecting your vehicle. If you hear a second chirp after arming,

and see the status LED flashing in groups, refer to the Diagnostics

section of this guide. This extra chirp is called Bypass Notification.

➜

passive arming

The system also can be programmed to arm itself automatically

(called passive arming). If the system is programmed for passive

arming, it will automatically arm 30 seconds after the ignition is

turned off and the system "sees" you leave the vehicle by opening

and closing a door. Whenever the system is in its 30-second

passive-arming countdown, the status LED will flash twice as fast

as it does when the system is armed. The siren will chirp once 20

seconds after the last door has been closed. The system is not

actually armed at that point. The system arms and the doors lock

(if connected and programmed for passive locking) at the 30

second mark, but the siren will not chirp. The early chirp

provides you with a 10-second warning prior to arming.

When armed, your vehicle is protected as follows:

➤Light impacts will trigger the Warn Away®signal. When trig-

gered, the siren will chirp and the parking lights will flash for

a few seconds.

➤Heavy impacts will trigger the system. The triggered

sequence is between 1-180 seconds of constant siren and

flashing parking lights.

➤If a door is opened, the system will immediately start

note: If any protected entry point (such as a door or a

switch-protected trunk or hood) is open, the system will

not passively arm (unless forced passive arming is pro-

grammed on). See Programming Options section of this

guide. Additionally, each time a protected entry is trig-

gered during the arming countdown, the 30-second

countdown starts over.

➜

Table des matières

Autres manuels Directed Electronics Alarme de voiture

Directed Electronics

Directed Electronics Python 881XP Manuel utilisateur

Directed Electronics

Directed Electronics PYTHON 333 Manuel utilisateur

Directed Electronics

Directed Electronics Viper 5601 Manuel utilisateur

Directed Electronics

Directed Electronics PS-7870TWE-FM Manuel utilisateur

Directed Electronics

Directed Electronics 555X Manuel utilisateur

Directed Electronics

Directed Electronics 411R Series Manuel utilisateur

Directed Electronics

Directed Electronics Viper 571XV Manuel utilisateur

Directed Electronics

Directed Electronics MERLIN 2000 Manuel utilisateur

Directed Electronics

Directed Electronics PYTHON 210P Manuel utilisateur

Directed Electronics

Directed Electronics Viper 106V Manuel utilisateur

Directed Electronics

Directed Electronics Arrow 5 Manuel utilisateur

Directed Electronics

Directed Electronics CLIFFORD 320.3X Manuel utilisateur

Directed Electronics

Directed Electronics Viper 350HV Manuel utilisateur

Directed Electronics

Directed Electronics Hurricane 3 Manuel utilisateur

Directed Electronics

Directed Electronics 736T Manuel utilisateur

Directed Electronics

Directed Electronics Vehicle Security System 3901V Manuel utilisateur

Directed Electronics

Directed Electronics 100 ESP Manuel utilisateur

Directed Electronics

Directed Electronics 381 Series Manuel utilisateur

Directed Electronics

Directed Electronics Car Alarm Manuel utilisateur

Directed Electronics

Directed Electronics Clifford 120XV Manuel utilisateur

Directed Electronics

Directed Electronics Avital Manuel utilisateur

Directed Electronics

Directed Electronics Intelliguard 750 Manuel utilisateur

Directed Electronics

Directed Electronics Python 450 ESP Manuel utilisateur

Directed Electronics

Directed Electronics AM1 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
