Digitus DN-651126 Manuel utilisateur

INDUSTRIAL GIGABIT SWITCH

DN-651126 (5-port) DN-651127 (8-port)

User Manual

Package content

Check the following contents of your package:

Ethernet Switch x 1

User Guide x 1

Terminal block x 1

DIN Rail mount x 1

If any part is lost and damaged, please contact your local agent

immediately.

Introduction

The Industrial Gigabit Switch is designed for harsh environments where

it is exposed to moisture, temperature fluctuations and vibration. With

a temperature range of -40°C to 85°C, the Industrial Gigabit Ethernet

Switch can be used under the most adverse conditions. It ensures a

constant availability in highly sensitive areas such as transport,

production, traffic and safety monitoring. The simple plug and play

system allows the Industrial Gigabit Switch to be quickly integrated into

the respective environment. With its Gigabit connectivity, the Industrial

Gigabit Switch is a flexible, cost-effective solution for the industrial

environment.

Hardware Description

Upper Panel

The upper panel has a standard 3-Pin industrial power input terminal

for DC power input. Also Ethernet Ports and LED indicators are located

on the panel.

DN-651126

DN-651127

LED indicator

LED

Color

Function

Power

Red

Off: No Power supply

Light: Indicates the switch has power

Act

Green

Off: No device is connected to the corresponding port

Light: Indicates the link through that port is

successfully established at 10/100/1000Mbps

Blink: Indicates that the Switch is actively sending or

receiving data over that port

Power input

This unit provides a 3-pin terminal block. It can be operated using 12-48 V

DC power source. Always make sure your input voltage is within this

supported voltage range.

To connect power:

This unit supports two power inputs. Follow the printed polarity for

+Power-, - and ground. Connect positive wires to V+, connect negative

wires to V-, and connect a neutral wire to the ground mark.

Figure:

WARNING:

Always SHUT OFF power source to connect power wire.

Any exceeded input voltage will not make this unit function and may

damage this unit.

Grounding Column

The switch already comes with lightning protection mechanism. You can also

ground the switch through the PE (Protecting Earth) with Ground Cable.

Installation of the Switch

This part describes how to install your Ethernet Switch and make

connections to it. Please follow the following instructions to avoid

incorrect installation causing device damage and security threat.

Before cleaning the switch, unplug the power plug of the switch first.

Do not clean the switch with wet cloth or liquid;

Do not place the switch near water or any damp area. Prevent water

or moisture from entering the switch chassis;

Do not place the switch on an unstable case or desk. The switch

might be damaged severely in case of a fall;

Ensure proper ventilation of the equipment room and keep the

ventilation vents of the switch free of obstruction;

Make sure that the operating voltage is the same one labeled

on the switch;

Do not open the chassis while the switch is operating or when

electrical hazards are present to avoid electrical shocks.

DIN-Rail Mounting

The DIN-Rail is already screwed on the Industrial Equipment. Please refer

to following figures and know how to hang the Industrial Equipment:

Step 1: Lightly press the button of DIN-Rail into the track. Install

Industrial Equipment in DIN-Rail mount.

Step 2: Check the DIN-Rail is tightly on the track.

Remove DIN-Rail Mounting

Step 1: Please refer to following procedures to remove the Industrial.

Equipment from the track. Remove Industrial Equipment in

DIN-Rail mount.

Step 2: Lightly press the button of DIN-Rail for remove it from the track.

Model

DS-651126

DS-651127

Description

Industrial 5-Port

Gigabit Switch

Industrial 8-port

Gigabit Switch

Standard

IEEE802.3, IEEE802.3u, IEEE802.3ab,

IEEE802.3x, IEEE 802.3z

Network Media(Cable)

10BASE-T: UTP category 3,4,5 cable (≤100m)

100BASE-TX: UTP category 5 cable (≤100m)

1000BASE-T: UTP category 5e, 5 cable

(≤100m)

MAC Address Table

4K, Auto-learning, Auto-aging

Transfer mode

Store-and-Forward

Switching Capacity

10Gbps

16Gbps

Input power supply

DC: 12-48V

Dimensions (L*W*H)

120*110*30mm

Fan

Fanless

Temperature

Operating Temperature: -40°C ~ 85 °C

Storage Temperature: -40 °C ~ 85°C

Humidity

Operating Humidity:

5% ~ 95% non-condensing

Storage Humidity: 5% ~ 95% non-condensing

Surge Protection

Differential mode ±4KV

Common mode ±6KV

MTBF

300,000 hours

Electrostatic standard

Contact 8KV,air 15KV

This is a Class A product. In home environment, this product may cause

radio interference. In this case, the user may be required to take

appropriate measures.

Hereby Assmann Electronic GmbH declares that the Declaration of

Conformity is part of the shipping content. If the Declaration of

Conformity is missing, you can request it by post under the below

mentioned manufacturer address.

www.assmann.com

Assmann Electronic GmbH

Auf dem Schüffel 3

58513 Lüdenscheid

Germany
