Digi TX64 Manuel utilisateur

TX64

User Guide

Revision history—90002348

Revision Date Description

A November 2019 Initial release of DigiTX64 firmware version 19.11.

B February 2020 Release of DigiTX64 firmware version 20.2:

nDigi SureLinkTM support (formerly known as active

recovery).

lEnabled by default on preconfigured WANs and

WWANs.

nRole-based user access.

lAllow shell option added to authentication.

lRead-only access option added to user

configuration.

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United

States and other countries worldwide. All other trademarks mentioned in this document are the

property of their respective owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a

commitment on the part of Digi International. Digi provides this document “as is,” without warranty of

any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or

merchantability for a particular purpose. Digi may make improvements and/or changes in this manual

or in the product(s) and/or the program(s) described in this manual at any time.

Warranty

To view product warranty information, go to the following website:

www.digi.com/howtobuy/terms

Customer support

Gather support information: Before contacting Digi technical support for help, gather the following

information:

Product name and model

Product serial number (s)

Firmware version

Operating system/browser (if applicable)

Logs (from time of reported issue)

Trace (if possible)

TX64 User Guide 2

Description of issue

Steps to reproduce

Contact Digi technical support: Digi offers multiple technical support plans and service packages.

Feedback

To provide feedback on this document, email your comments to

techcomm@digi.com

Include the document title and part number (TX64 User Guide, 90002348 B) in the subject line of your

email.

TX64 User Guide 3
