D55171

Oil Free Portable Air Compressor

Compresseur d’air portatif sans huile

Compresor de aire sin aceite portátil

INSTRUCTION MANUAL

GUIDE D'UTILISATION

MANUAL DE INSTRUCCIONES

INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIOY PÓLIZA

DE GARANTÍA.ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES

DE USAR EL PRODUCTO.

If you have questions or comments, contact us.

Pour toute question ou tout commentaire, nous contacter.

Si tiene dudas o comentarios, contáctenos.

1-800-4-De



A. Sliding Handles

B. Drain Valve

C. Storage Support

D. Regulated Pressure Gauge

E. Quick Connects

F. Regulator

G. Safety Valve



Voltage: Single 120V

Minimum branch circuit requirement: 15 A

Fuse Type: Time delay



MODEL D55171

WEIGHT 126 lbs. (57.2 kg)

HEIGHT 18.0" (457.2 mm)

WIDTH 24.0" (609.6 mm)

LENGTH 33.0" (838.2 mm)

AIR TANK CAPACITY (GALLONS) 7.5 Gallon (28.4 liters)

APPROX CUT-IN PRESSURE

145 PSI

APPROX. CUT-OUT PRESSURE

175 PSI

SCFM @ 100 PSI *4.6

NOISE LEVEL +74 dBA

*Tested per ISO 1217

+Tested per ISO 3744



H. Pressure Switch

I. Cord Wrap

J. Air Filter

K. Tank Pressure Gauge

L. On/Auto/Off Switch





Noise Emission Values

Sound Pressure Level: LpA = 74.0 dBA re 20μPA

Uncertainty in the Sound Pressure Level: KpA = 3.0 dBA re 20μPA

Sound Power Level: LwA = 87.0 dBA re 1 pw

Uncertainty in the Sound Power Level: KwA = 3.0 dBA re 1 pw

The sum of the emission value and the uncertainty is the limit

below which there is a 95% confidence the value of a single tool

will lie below when the tool is new.

FIG. 1





The definitions below describe the level of severity

for each signal word. Please read the manual and pay

attention to these symbols.

DANGER: Indicates an imminently hazardous situa-

tion which, if not avoided, will result in death or seri-

ous injury.

WARNING: Indicates a potentially hazardous

situation which, if not avoided, could result in death or

serious injury.

CAUTION: Indicates a potentially hazardous

situation which, if not avoided, may result in minor or

moderate injury.

CAUTION: Used without the safety alert symbol

indicates a potentially hazardous situation which, if not

avoided, may result in property damage.

IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT

THIS OR ANY D

WALT TOOL, CALL US TOLL FREE AT:

1-800-4-D

WALT (1-800-433-9258)



WARNING: Do not operate this unit until you read and understand

this instruction manual for safety, operation and maintenance

instructions.

WARNING: This product contains chemicals known to the

State of California to cause cancer, and birth defects or other

reproductive harm. Wash hands after handling.

WARNING: Some dust contains chemicals known to the State of

California to cause cancer, birth defects or other reproductive harm

such as asbestos and lead in lead based paint.



DANGER: RISK OF EXPLOSION OR FIRE

WHAT CAN HAPPEN HOW TO PREVENT IT

 • Itisnormalforelectrical

contacts within the motor

and pressure switch to

spark.

 • Alwaysoperatethecompres-

sor in a well ventilated area

free of combustible materials,

gasoline, or solvent vapors.

 • Ifelectricalsparksfrom

compressor come into con-

tact with flammable vapors,

they may ignite, causing fire

or explosion.

 • Ifsprayingflammablemate-

rials, locate compressor

at least 20' (6.1 m) away

from spray area. An addi-

tional length of hose may be

required.

 • Storeflammablematerialsin

a secure location away from

compressor.



 • Restrictinganyofthecom-

pressor ventilation openings

will cause serious overheat-

ing and could cause fire.

 • Neverplaceobjectsagainst

or on top of compressor

pump.

 • Operatecompressorin

an open area at least 12"

(30.5 cm) away from any

wall or obstruction that would

restrict the flow of fresh air to

the ventilation openings.

 • Operatecompressorina

clean, dry well ventilated area.

Do not operate unit indoors or

in any confined area.

 • Unattendedoperationof

this product could result in

personalinjuryorproperty

damage. To reduce the

risk of fire, do not allow

the compressor to operate

unattended.

 • Alwaysremaininattendance

with the product when it is

operating.

 • Always turn off and unplug

unit when not in use.

DANGER: RISK TO BREATHING (ASPHYXIATION)

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairdirectly

from your compressor is not

safe for breathing.The air

stream may contain carbon

monoxide, toxic vapors,

or solid particles from the

air tank.Breathing these

contaminants can cause

seriousinjuryordeath.

• Airobtaineddirectlyfromthe

compressor should never

be used to supply air for

human consumption. In order

to use air produced by this

compressor for breathing,

suitable filters and in-line

safety equipment must be

properly installed. In-line

filters and safety equipment

usedinconjunctionwiththe

compressor must be capable

of treating air to all applicable

local and federal codes prior to

human consumption.

• Sprayedmaterialssuchas

paint, paint solvents, paint

remover, insecticides, weed

killers, may contain harmful

vapors and poisons.

• Workinanareawithgood

cross ventilation.Read and

follow the safety instructions

provided on the label or safety

data sheets for the materials

you are spraying. Always use

certified safety equipment:

OSHA/MSHA/NIOSH

respiratory protection designed

for use with your specific

application.



• Somedustcreatedby

power tools may contain

harmful chemicals.

• Toreduceyourexposure

to these chemicals: work in

a well ventilated area and

always wear OSHA/MSHA/

NIOSH approved, properly

fitting face mask or respirator

when using such tools.

WARNING: RISK OF BURSTING

Air Tank: The air tank on your Air Compressor is designed and

may be UM coded [for units with air tanks greater than 6" (152 mm)

diameter] according to ASME Section VIII, Div. 1 rules. All pressure

vessels should be inspected once every two years. To find your state

pressure vessels inspector, look under the Division of Labor and

Industries in the government section of a phone book or call 1-800-

4-DeWALT for assistance.

The following conditions could lead to a weakening of the air tank,

and result in a violent air tank explosion:

WHAT CAN HAPPEN HOW TO PREVENT IT

• Failuretoproperlydrain

condensed water from

air tank, causing rust and

thinning of the steel air tank.

• Drainairtankdailyorafter

each use. If air tank develops

a leak, replace it immediately

with a new air tank or replace

the entire compressor.

• Modificationsorattempted

repairs to the air tank. • Neverdrillinto,weld,ormake

any modifications to the air

tank or its attachments. Never

attempt to repair a damaged or

leaking air tank. Replace with a

new air tank.

• Unauthorizedmodifications

to the safety valve or any

other components which

control air tank pressure.

• Theairtankisdesigned

to withstand specific

operating pressures. Never

makeadjustmentsorparts

substitutions to alter the factory

set operating pressures.

Attachments & accessories:

• Exceedingthepressure

rating of air tools, spray guns,

air operated accessories,

tires, and other inflatables

can cause them to explode

or fly apart, and could result

inseriousinjury.

• Followtheequipmentmanu-

facturers recommendation

and never exceed the maxi-

mum allowable pressure rat-

ing of attachments. Never

use compressor to inflate

smalllowpressureobjects

such as children’s toys, foot-

balls, basketballs, etc.



Tires:

• Over inflation of tires could

resultinseriousinjuryand

property damage.

 • Useatirepressuregaugeto

check the tires pressure before

each use and while inflating

tires; see the tire sidewall for

the correct tire pressure.

NOTE: Air tanks, compressors and

similar equipment used to inflate

tires can fill small tires similar to

theseveryrapidly.Adjustpressure

regulator on air supply to no more

than the rating of the tire pressure.

Add air in small increments and

frequently use the tire gauge to

prevent over inflation.

WARNING: RISK OF ELECTRICAL SHOCK

WHAT CAN HAPPEN HOW TO PREVENT IT

• Your air compressor is

Like any other electrically

powered device, If it is not

used properly it may cause

electric shock.

 • Never operate the

compressor outdoors when it

is raining or in wet conditions.

 • Never operate compressor

with protective covers

removed or damaged.

 • Repairs attempted by

unqualified personnel can

resultinseriousinjuryor

death by electrocution.

 • Any electrical wiring or

repairs required on this

product should be performed

by a DeWALT factory

service center or a DeWALT

authorizedservicecenterin

accordance with national and

local electrical codes.

 • Electrical Grounding:

Failure to provide adequate

grounding to this product

couldresultinseriousinjury

or death from electrocution.

See Grounding

Instructions under

Installation.

 • Make certain that the

electrical circuit to which the

compressor is connected

provides proper electrical

grounding, correct voltage

and adequate fuse protection.

WARNING: RISK FROM FLYING OBJECTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairstream

can cause soft tissue

damage to exposed skin and

can propel dirt, chips, loose

particles,andsmallobjects

at high speed, resulting in

property damage or personal

injury.

• Always wear certified safety

equipment: ANSI Z87.1 eye

protection (CAN/CSA Z94.3)

with side shields when using

the compressor.

• Neverpointanynozzleor

sprayer toward any part of

the body or at other people or

animals.



• Alwaysturnthecompressoroff

and bleed pressure from the

air hose and air tank before

attempting maintenance,

attaching tools or accessories.

WARNING: RISK OF HOT SURFACES

WHAT CAN HAPPEN HOW TO PREVENT IT

• Touchingexposedmetal

such as the compressor

head, engine head, engine

exhaust or outlet tubes, can

result in serious burns.

 • Nevertouchanyexposed

metal parts on compressor

during or immediately after

operation. Compressor will

remain hot for several minutes

after operation.

 • Donotreacharound

protective shrouds or attempt

maintenance until unit has

been allowed to cool.

WARNING: RISK FROM MOVING PARTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Movingpartssuchasthe

pulley, flywheel, and belt can

causeseriousinjuryifthey

come into contact with you or

your clothing.

• Neveroperatethecompressor

with guards or covers which

are damaged or removed.

• Keepyourhair,clothing,and

gloves away from moving

parts.Looseclothes,jewelry,

or long hair can be caught in

moving parts.

• Airventsmaycovermoving

parts and should be avoided

as well.

• Attemptingtooperate

compressor with damaged or

missing parts or attempting

to repair compressor with

protective shrouds removed

can expose you to moving

parts and can result in

seriousinjury.

• Anyrepairsrequiredonthis

product should be performed

by a DeWALT factory

service center or a DeWALT

authorizedservicecenter.



WARNING: RISK OF FALLING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Aportablecompressor

can fall from a table,

workbench, or roof causing

damage to the compressor

and could result in serious

injuryordeathtothe

operator.

• Alwaysoperatecompressor

in a stable secure position to

prevent accidental movement

of the unit. Never operate

compressor on a roof or

other elevated position. Use

additional air hose to reach

high locations.

WARNING: RISK OF

INJURY FROM LIFTING

WHAT CAN HAPPEN HOW TO PREVENT IT

 • Seriousinjurycanresult

from attempting to lift too

heavyanobject.

•The compressor is too heavy

to be lifted by one person.

Obtain assistance from

others before lifting.

CAUTION: RISK FROM NOISE

WHAT CAN HAPPEN HOW TO PREVENT IT

 • Under some conditions and

duration of use, noise from

this product may contribute

to hearing loss.

 • Alwayswearcertifiedsafety

equipment: ANSI S12.6

(S3.19) hearing protection.

WARNING: RISK OF UNSAFE OPERATION

WHAT CAN HAPPEN HOW TO PREVENT IT

• Unsafeoperationofyourair

compressor could lead to seri-

ousinjuryordeathtoyouor

others.

• Reviewandunderstandall

instructions and warnings in

this manual.

• Becomefamiliarwiththe

operation and controls of the

air compressor.

• Keepoperatingareaclear

of all persons, pets, and

obstacles.

• Keepchildrenawayfromthe

air compressor at all times.

• Donotoperatetheproduct

when fatigued or under the

influence of alcohol or drugs.

Stay alert at all times.

• Neverdefeatthesafetyfea

tures of this product.

• Equipareaofoperationwith

a fire extinguisher.

• Donotoperatemachinewith

missing, broken, or unautho-

rizedparts.

• Neverstandonthe

compressor.







)

ON/AUTO/OFF SWITCH

Place this switch (L) in the ON/AUTO H

position to provide automatic power to the

pressure switch and OFF to remove power

at the end of each use. NOTE: ALWAYS

ensure the switch (L) is in the OFF

position before removing or replacing

pressure switch cover.

PRESSURE SWITCH

The pressure switch (H) automatically starts the motor when the

air tank pressure drops below the factory set cut-in pressure. It

stops the motor when the air tank pressure reaches the factory set

cut-out pressure.

SAFETY VALVE

If the pressure switch does not shut off the air

compressor at its cut-out pressure setting, the

safety valve (G) will protect against high pressure

by popping out at its factory set pressure (slightly

higher than the pressure switch cut-out setting).

CHECK VALVE

When the air compressor is operating, the check valve is open,

allowing compressed air to enter the air tank. When the air

compressor reaches cut-out pressure, the check valve closes,

allowing air pressure to remain inside the air tank.

TANK PRESSURE GAUGE

The tank pressure gauge (K) indi- E

cates the reserve air pressure in

the tank.

REGULATED PRESSURE

GAUGE

The regulated pressure gauge (D)

indicates the air pressure available

at the outlet side of the regulator. This pressure is controlled by the

regulator and is always less than or equal to the tank pressure.

REGULATOR

The regulator (F) controls the air pressure shown on the regulated

pressure gauge. Pull the knob out and turn clockwise to increase

pressure and counterclockwise to decrease pressure. When the

desired pressure is reached push knob in to lock in place.

UNIVERSAL QUICK CONNECT BODIES

The universal quick connect body (E) accepts the three most popular

styles of quick connect plugs: Industrial, automotive, and ARO. One

hand push-to-connect operation makes connections simple and

easy. The two quick connect bodies allow the use of two tools at the

same time.

DRAIN VALVE

The drain valve (B) is located at the base of

the air tank and is used to drain

condensation at the end of each use.

See

Draining Air Tank under Maintenance.

COOLING SYSTEM

This compressor contains an advanced design cooling system.

It is normal for this fan to blow air through the vent holes in large

amounts. The cooling system is working when air is expelled.



AIR COMPRESSOR PUMP

The pump compresses air into the air tank. Working air is not

available until the compressor has raised the air tank pressure

above that required at the air outlet.

AIR INTAKE FILTER

The filter (J) is designed to clean air entering the

pump. To ensure the pump continually receives a

clean, cool, and dry air supply the filter must always

be clean and the filter intake must be free from

obstructions.

MOTOR OVERLOAD PROTECTOR

The motor has an automatic reset thermal overload protector. If the

motor overheats for any reason, the overload protector will shut off

the motor.The motor must be allowed to cool down before restarting.

The compressor will automatically restart after the motor cools.





INSTALLING HOSES

WARNING: Risk of unsafe operation. Firmly grasp hose in hand

when installing or disconnecting to prevent hose whip.

1. Ensure regulated pressure gauge reads 0 PSI.

2. Grasp the hose at the quick connect plug and push the plug

into the quick connect body (E). Coupler will snap into place.

3. Grasp the hose and pull to ensure coupler is seated.

DISCONNECTING HOSES

WARNING: Risk of unsafe operation. Firmly grasp hose in hand

when installing or disconnecting to prevent hose whip.

1. Ensure regulated pressure gauge reads 0 PSI (0 kPa).

2. Push coupler on quick connect body back to release quick

connect plug on hose.



WARNING: Risk of electrical shock. In the event of a short

circuit, grounding reduces the risk of shock by providing an escape

wire for the electric current. This air compressor must be properly

grounded.

The portable air compressor is equipped with a cord having a

grounding wire with an appropriate grounding plug.

1. The cord set and plug (M) with this unit

contains a grounding pin (N).This plug

MUST be used with a grounded

outlet (O).

IMPORTANT: The outlet being used must

be installed and grounded in accordance

with all local codes and ordinances.

2. Ensure the outlet being used has the same configuration as the

grounded plug. DO NOT USE AN ADAPTER.

3. Inspect the plug and cord before each use. Do not use if there

are signs of damage.

4. If these grounding instructions are not completely understood, or

if in doubt as to whether the compressor is properly grounded,

have the installation checked by a qualified electrician.

DANGER: Risk of electrical shock. IMPROPER GROUNDING

CAN RESULT IN ELECTRICAL SHOCK.

•Do not modify the plug provided. If it does not fit the available

outlet, a correct outlet should be installed by a qualified

electrician.

•Repairs to the cord set or plug MUST be made by a qualified

electrician.

Table des matières

Langues :

Autres manuels DeWalt Compresseur d'air

DeWalt

DeWalt D55146 Manuel utilisateur

DeWalt

DeWalt D55146-CA Manuel utilisateur

DeWalt

DeWalt DXCMH1393075 Manuel utilisateur

DeWalt

DeWalt DXCMH1608WB Manuel utilisateur

DeWalt

DeWalt Emglo D55155 Manuel utilisateur

DeWalt

DeWalt DCC2560 Manuel utilisateur

DeWalt

DeWalt D55270 Manuel utilisateur

DeWalt

DeWalt DXCM803 Manuel utilisateur

DeWalt

DeWalt XR DCC1018 Manuel utilisateur

DeWalt

DeWalt D55180T Manuel utilisateur

DeWalt

DeWalt XR FLEX VOLT DCC1054 Manuel utilisateur

DeWalt

DeWalt D55167 Manuel utilisateur

DeWalt

DeWalt DPC6MRC-QS Manuel utilisateur

DeWalt

DeWalt Emglo D55150 Manuel utilisateur

DeWalt

DeWalt D55141-CA Manuel utilisateur

DeWalt

DeWalt Emglo D55151 Manuel utilisateur

DeWalt

DeWalt D55167-CA Manuel utilisateur

DeWalt

DeWalt DXCM271 Manuel utilisateur

DeWalt

DeWalt D55684 Manuel utilisateur

DeWalt

DeWalt DXCMH1608WB Manuel utilisateur

DeWalt

DeWalt Contractor's Electric Wheeled Portable Air Compressor... Manuel utilisateur

DeWalt

DeWalt 919.175260 Manuel utilisateur

DeWalt

DeWalt D55154 Manuel utilisateur

DeWalt

DeWalt Contractor's Electric Wheeled Portable Air Compressor... Manuel utilisateur

Manuels Compresseur d'air populaires d'autres marques

Sparmax

Sparmax DC-25XR Manuel utilisateur

KAESER

KAESER M122 Manuel utilisateur

GMC

GMC GAC1500 Manuel utilisateur

Briggs & Stratton

Briggs & Stratton Air Compressor Manuel utilisateur

Fini

Fini F3GST2TK Manuel utilisateur

Industrial Air

Industrial Air CP1580325 Manuel de programmation

Campbell Hausfeld

Campbell Hausfeld RP3300 Guide de démarrage rapide

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Manuel utilisateur

Hitachi

Hitachi EC99S Manuel de l'opérateur

Parkside

Parkside PKO 270 A1 Manuel utilisateur

Sullair

Sullair 185 Manuel utilisateur

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Manuel utilisateur

Ferm

Ferm CRM1046 Manuel utilisateur

BE AC153 Manuel utilisateur

RIDGID

RIDGID OF25150A Manuel utilisateur

Johnson Controls

Johnson Controls QUANTUM LX Manuel

Sears

Sears Craftsman 919.167463 Manuel utilisateur

Ring Automotive

Ring Automotive RAC700 Manuel utilisateur
