Denver CRL-330 Manuel utilisateur

Instruction Manual

Clock Radio

CRL-330

www.denver-electronics.com

Before operating this product, please read this instruction manual carefully and completely.

Product Information

Correctly set the stand in specially design for it slot.

-Use USB cable to connect alarm clock to computer

-Use the adaptor to an electricity network

Use batteries as a backup power source (if the electricity is down, no access

to the network or computer; using the alarm clock in different locations, the

batteries save all your setting)

Use batteries as a backup power source (if the electricity is down, no access

to the network or computer; using the alarm clock in different locations, the

batteries save all your setting)

To install the batteries:

Use 2 batteries type AAA (not included).

-Open the battery compartment, following the arrow on the battery cover

to remove the cover.

-Open the battery compartment, following the arrow on the battery cover

to remove the cover.

-lnsert 2 AAA batteries, observe the polarity, which can be viewed inside

the compartment.

-lnsert 2 AAA batteries, observe the polarity, which can be viewed inside

the compartment.

-Close the battery cover.

When the product is running on batteries, they are Function abilities limited:

-Time display will be switched off after 5 seconds. Press any key to switch

on time display.

-Time display will be switched off after 5 seconds. Press any key to switch

on time display.

-Alarm function is available.

-Radio is available.

-All light functions are unavailable in battery mode

Setting current time

When the power is connected, the hours indication starts to blink

Hours Setting:

Use to adjust hour

To confirm press To confirm press

Minute Setting:

Use to adjust minute

To confirm press To confirm press

If the indication is stopped touch again. If the indication is stopped touch again.

12H-24H-format

Press key to switch the time format between 12H and 24H Press key to switch the time format between 12H and 24H

12H AM or PM will appear on time display.

Changing current time

Touch button Touch button

The hours indication starts to blink.

Hours Setting:

Use to adjust hour

To confirm press

Minute Setting:

Use to adjust minute.

To confirm press

If the indication is stopped touch again.

Intensity of time display

Press key to select the display intensity

LOW

HIGH

OFF

Sunrise light simulation

When the alarm time is set, the wake up light will switch on 30 minuts before the alarm time in low brightness and gradually increase the brightness. At the

alarm time the brightness will be full. The natural sound or radio will be played for 2 minuts at the alarm time.

During wake up alarm play

-Touch button to snooze the alarm for 5 minuts. After 5 minuts the alarm will play again for 2 minuts. Press or touch any buttons except to stop

sound.

-- Press and hold to switch off wake up light.

FM Radio

Touch button to turn on/off. Press and hold button for 3 seconds to auto

scan.

Touch button to turn on/off. Press and hold button for 3 seconds to auto

scan.

All available FM channels will be scanned and saved automatically.

Touch to select an FM station.

Press key to choose volume level 1-15.

Note: time display isn’t indicated when Radio is turned on.

Setting the alarm wake-up time

Touch button to switch on/off alarm mode.

symbol appears/disappears on clock display.

Press and hold button to set alarm. Press and hold button to set alarm.

The hours indication starts to blink.

Hours Setting:

Use to adjust hour.

To confirm press

Minute Setting:

Use to adjust minute.

To confirm press

If the indication is stopped touch again.

Nature sounds

Press key to select the alarm sound Press key to select the alarm sound

Use to select 1-7 sounds. Press to confirm selection.

Each sound (1-6) will play 5 sec before you choose.

When 7 is selected the last played radio station will be played as wake up

sound

When 7 is selected the last played radio station will be played as wake up

sound

Press Key to select volume level 00-15 Press Key to select volume level 00-15

Setting the Sunset time

Touch to switch on/off sunset mode symbol appears/disapears

on time display.

Press and hold to set

The hours indication starts to set.

Hours Setting:

Use to adjust hours.To confirm press

minute setting:

Use to adjust minute. To confirm press

Light

Touch to switch on the light

Use to adjust the level (1-10) of the brightness

Second touch of will switch on automatic color changing mode

Use to select color: Green, Red, Blue, Purple, Orange, lndigo

Third touch to switch off the light

Sunset light simulation

30 min before sunset time, the light is turned on with 100% brightness and then the brightness is reduced gradually

and will turn off at sunset time.

During sunset light is turned on you may: Press and hold to turn off the light.

Description

*Led time display in 12H-24 format

*Sunrise wake up light simulation

*Sunset light simulation

*6 Nature sounds to wake up

*Bedside lamp

*White light flux: 73LM

*10 levels of the brightness

*6 coloured light+white light

*Automatic changing of color light

*FM radio with antenna

*15 volume levels

*Touch mode

*Power supply: DC 5V; 2xAAA batteries; USB cable.

Note: When the battery is low the product may not

function properly.

Replace the battery with fresh battery.

Light display

Time display

Snooze

Current time

Alarm

Down i

Light

Sunset

Nature sounds

Volume

Battery compartment

Stand

12H-24H format

Intensity of time display
