Dell S510 Manuel utilisateur

Dell™ Interactive Projector S510

User’s Guide

Downloaded From projector-manual.com DELL Manuals

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make

better use of your projector

CAUTION: A CAUTION indicates potential damage to hardware or

loss of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written

permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP

and DLP logo are trademarks of TEXAS INSTRUMENTS INCORPORATED; Microsoft and

Windows are either trademarks or registered trademarks of Microsoft Corporation in

the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either

the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model: Dell Interactive Projector S510

December 2014 Rev. A00

Downloaded From projector-manual.com DELL Manuals

Contents | 3

Contents

1 Your Dell Projector. . . . . . . . . . . . . . . . . . . . . . . 5

About Your Interactive Pen . . . . . . . . . . . . . . . . . . 7

2 Connecting Your Projector . . . . . . . . . . . . . . . . 9

Connecting to a Computer . . . . . . . . . . . . . . . . . 11

Connecting a DVD Player . . . . . . . . . . . . . . . . . . 19

Connecting to Local Area Network. . . . . . . . . . . . 23

3 Using Your Projector . . . . . . . . . . . . . . . . . . . . 25

Turning Your Projector On. . . . . . . . . . . . . . . . . . 25

Turning Your Projector Off . . . . . . . . . . . . . . . . . 25

Adjusting the Projector Focus . . . . . . . . . . . . . . . 26

Cleaning the Projector's Mirror . . . . . . . . . . . . . . 26

Adjusting Projection Image Size . . . . . . . . . . . . . . 27

Using the Remote Control. . . . . . . . . . . . . . . . . . 29

Installing the Remote Control Batteries . . . . . . . . . 32

Replacing the Interactive Pen Tips . . . . . . . . . . . . 33

Replacing the Interactive Pen Batteries . . . . . . . . . 34

Operating Range with Remote Control . . . . . . . . . 35

Using the On-Screen Display . . . . . . . . . . . . . . . . 36

Multimedia Introduction . . . . . . . . . . . . . . . . . . . 55

How to set-up File Type for Multimedia with USB . . 57

How to set-up File Type for Multimedia with

Internal Memory . . . . . . . . . . . . . . . . . . . . . . . . 59

Office Viewer for the USB and Internal Memory . . . 61

Multimedia SETUP for USB and Internal Memory. . . 62

Using Intel®Wireless Display (WiDi) . . . . . . . . . . . 63

Wireless Display or LAN Display Installation . . . . . . 71

For Windows Operating System Settings . . . . . . . . 72

For Mac Operating System Settings . . . . . . . . . . . 84

Audio Projection Installation . . . . . . . . . . . . . . . . 89

USB Display (DoUSB) Installation . . . . . . . . . . . . 101

IR Pen Interactivity Installation . . . . . . . . . . . . . . 104

Managing the Projector From Web Management . 109

Downloaded From projector-manual.com DELL Manuals

4| Contents

Make Application Token . . . . . . . . . . . . . . . . . . 132

4 Troubleshooting Your Projector . . . . . . . . . . 133

Guiding Signals . . . . . . . . . . . . . . . . . . . . . . . . 138

Changing the Lamp . . . . . . . . . . . . . . . . . . . . . 139

5 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 141

6 Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . 147

Contacting Crestron . . . . . . . . . . . . . . . . . . . . 148

7 Appendix: Glossary . . . . . . . . . . . . . . . . . . . . 149

Downloaded From projector-manual.com DELL Manuals

Your Dell Projector 5

Your projector comes with all the items shown below. Ensure that you have

all the items, and contact Dell if anything is missing.

1Your Dell Projector

Package Contents

Power cable VGA cable (VGA to VGA)

Remote control AAA Batteries (6)

CD User’s Guide and Documentation Mini USB cable (USB-A to Mini

USB-B)

IR Pen (2 pcs)/Pen tip cap (4 pcs) Wrist strap (2 pcs)

Freeze

Source Auto

Adjust

Blank

Screen

Blank

Screen

Video

Mode

VGA Video

PageDown

HDMI

PageUp

Aspect

Ratio

AAA

Dell

Projectors

oduct Information Guide

Informacion Importante

Dell™ Interactive Projector S510

Contents:

•User'sGuide

Documentation

P/N 8K5P4

Rev.A00

P/N 36.73901G001

December2014

MadeinChina

Dell

™

Projector S510

08K5P4A00

Downloaded From projector-manual.com DELL Manuals

6Your Dell Projector

About Your Projector

1 Power button

2TempLED

3 Lamp LED

4IRreceivers

5 Lamp cover

6 Camera

710Wspeaker

8 Lens

9Focusring

10 Mounting holes for wall mount: Screw hole M4 x 8 mm depth.

Recommended torque <10 kgf-cm

163.00

112.5038.80

151.30

10 7

936

821

Top View Bottom View

Downloaded From projector-manual.com DELL Manuals

Your Dell Projector 7

About Your Interactive Pen

You can navigate, select, and interact with your computer programs from the

projected screen using the interactive pens just as you would a mouse.

1 Power switch

2 Power indicator

As you turn on the pen, the power indicator flashes a few seconds

and goes off.

Green: Normal operation

Red: Battery is low

No light: Battery is empty

3 Wrist strap holder

4 Battery compartment access. Turn to open and replace batteries.

5 Pen tip

Downloaded From projector-manual.com DELL Manuals

8Your Dell Projector

CAUTION: Safety Instructions

Do not use the projector near appliances that generate a lot of heat.

Do not use the projector in areas where there is an excessive amount of

dust. The dust may cause the system to fail and the projector will

automatically shutdown.

Ensure that the projector is mounted in a well-ventilated area.

Do not block the ventilation slots and openings on the projector.

Ensure the projector operates between ambient temperatures (5 °C to

35 °C).

Do not try to touch the ventilation outlet as it can become very hot after

the projector has been turned on or immediately after it is turned off.

Do not look into the lens while the projector is on as it may cause injury to

your eyes.

Do not place any objects near or in front of the projector or cover its lens

while the projector is on as the heat may cause the object to melt or burn.

Do not use the wireless projector near cardiac pacemakers.

Do not use the wireless projector near medical equipment.

Do not use the wireless projector near microwave ovens.

NOTE:

•

Do not attempt to wall mount the projector by yourself. It should be

installed by a qualified technician.

•

Recommended Projector Wall Mount Kit (P/N: 7XY53). For more

information, see the Dell Support website at

dell.com/support

•

For more information, see the Safety Information that shipped with

your projector.

•

The S510 projector can only be used indoors.

Downloaded From projector-manual.com DELL Manuals

Connecting Your Projector 9

2Connecting Your Projector

1 Mini USB (Mini Type B)

connector for remote control,

interactive pen, and firmware

upgrade

10 Audio right-channel input

connector

2 HDMI-B connector 11 Audio left-channel input

connector

3 HDMI-A connector for support

MHL feature

12 Audio output connector

4 USB Type A connector for USB

Viewer

13 Power cord connector

5 USB Type B connector

(DoUSB) for USB Display

14 Microphone connector

6 VGA output (monitor loop

through) connector

15 Composite Video connector

7 RJ-45 connector 16 Audio-B input connector

8 VGA-A input (D-sub)

connector

17 VGA-B input (D-sub)

connector

9 Audio-A input connector 18 RS232 connector

1415161718

2 8 9 10 11 1243 5 6 7

Downloaded From projector-manual.com DELL Manuals

10 Connecting Your Projector

CAUTION: Before you begin any of the procedures in this section,

follow the Safety Instructions as described on page 8.
