Dell™3300MPProjectorUser'sGuide

Safety Instructions (Read before connecting the projector)

About Your Projector

Installation

Using Your Projector

Troubleshooting

Specifications

Regulatory Notices

Contacting Dell

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your projector.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP and Texas Instruments are trademarks of Texas Instruments

Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation; Macintosh is a registered trademark of Apple Computer, Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc.

disclaims any proprietary interest in trademarks and trade names other than its own.

Restrictions and Disclaimers

The information contained in this document, including all instructions, cautions, and regulatory approvals and certifications, is based upon statements

provided to Dell by the manufacturer and has not been independently verified or tested by Dell. Dell disclaims all liability in connection with any deficiencies

in such information.

All statements or claims regarding the properties, capabilities, speeds, or qualifications of the part referenced in this document are made by the

manufacturer and not by Dell. Dell specifically disclaims any knowledge of the accuracy, completeness, or substantiation for any such statements.

February2004Rev.A00

Back to Contents Page

AboutYourProjector:Dell™3300MPProjector

Features

Equipment

Main Unit

Control Panel

Connection Ports

Remote Control



Features



Singlechip0.7"TexasInstrumentsDLP™technology

High contrast, double data rate (DDR) digital micro mirror device

True XGA (1024 x 768) native resolution

3.99 lbs (1.81 kg) lightweight compact design

1600 ANSI lumens brightness (Max)

1700:1 full on / full off contrast ratio

1.2x manual zoom lens

Built in 2W speaker

Auto image re-sizing (Auto-Sync) to 1024x 768 full screen with scaling compression compatibility for SXGA+, SXGA, XGA, SVGA,

VGA, MAC

Great connectivity -- Multiple PC and High Definition inputs (via M1-DA and RGB), S-Video, Composite Video (RCA), Component Video

Preset and user defined video modes for optimum video and graphic settings

LCD display for real time projector status

Self-diagnostic for video troubleshooting

State-of-the-art motion adaptive hardware de-interlacing with 3:2 and 2:2 pull down

180-watt user-replaceable P-VIP 3000-hour lamp

Eco Mode allows end user to extend lamp life to 5000 hours by reducing the lamp wattage and brightness.

Compatibility with Macintosh®computers

Compatibility with NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM, and HDTV (1080i, 720p, 576i/p, 480i/p)

High-definition TV compatibility

User-friendly, multi-language on-screen display (OSD)

Advanced auto vertical electronic keystone correction

Remote projector control from PC via RS232 port

User-friendly control panel with backlight buttons

Drop tested carrying case included

Plug and play for photo image display from the option for memory card reader (Memory card module sold separately)

Equipment

Your projector comes with all the items shown below. Ensure that you have all the items, and contact Dell if anything is missing.



Main unit

3.0m Power cord

1.8m M1-A to D-sub/USB cable

2.0m S-video cable

1.8m M1-A to HDTV cable

1.8m Composite Video cable

Batteries (2)

1.8m RCA to Audio cable

1.8m 1/8" Mini Phone Jack cable

Remote control



Dell 3300MP Projector

User's Guide

Dell 3300MP Projector Quick Start

Card

Warranty Guide

Owner's Manual

Carrying case

Main Unit



Control panel

LCD status display

Zoom tab

Focus ring

Lens

IR Remote control receiver

Elevator button

Control Panel



Power button

Source

Keystone adjustment

Re-sync

Four directional keys

Keystone adjustment

Lamp warning light

Temperature warning light

Connection Ports



Kensington lock hole

RS232 connector

Audio input connector

Composite video connector

S-video connector

M1-DA connector

VGA Out (monitor loop-through)

IR Receiver

Remote Control



Light

Directional Pad

Power button

R-sync button

PU button (page up)

Source button

Laser pointer

PD button (page down)

Hide button

Keystone correction

Mute button

Color Mode button

Volume+-button

Menu button

Freeze button

4:3/16:9 (aspect ratio) button

Normal button

Slide Show button

Preview button

Rotate button

CAUTION: The remote control has a Class II laser that emits radiation. To reduce the risk of injury to the eyes, do

not look directly into the laser light on the remote control and do not point the laser light into anyone's eyes.

Battery Disposal: Your projector remote control uses zinc-manganese batteries. If you need to replace the batteries, see your Dell 3300MP

Projector Quick Start Card.

Do not dispose of used batteries along with household waste. Contact your local waste disposal agency for the address of the nearest battery

deposit site.

Back to Contents Page

Contacting Dell

To contact Dell electronically, you can access the following websites:

lwww.dell.com

lsupport.dell.com (technical support)

lpremiersupport.dell.com (technical support for educational, government, healthcare, and medium/large business customers, including Premier,

Platinum, and Gold customers)

For specific web address for your country, find the appropriate country section in the table below.

NOTE: Toll-free numbers are for use within the country for which they are listed.

When you need to contact Dell, use the electronic addresses, telephone numbers, and codes provided in the following table. If you need assistance in

determining which codes to use, contact a local or an international operator.



Country (City) International Access

Code Country Code City Code

Department Name or Service Area, Website and E-mail

Address

Area

Code

Local Numbers,and Toll-

Free Numbers

Anguilla

General Support

toll free:800-335-0031

Antigua and Barbuda

General Support

1-800-805-5924

Argentina (Buenos Aires)

International Access Code:00

Country Code:54

City Code:11

Technical Support and Customer Care

toll free: 0800 444 0733

Sales

toll free: 0810 444 3355

Tech Support Fax

4515-7139

Customer Care Fax

4515-7138

Website: www.dell.com.ar

toll-free:800-1578

Aruba

General Support



Australia (Sydney)

International Access Code:0011

Country Code:61

City Code:2

E-mail (Australia): [email protected]



E-mail (New Zealand): [email protected]



Home and Small Business

1-300-65-55-33

Government and Business

toll free: 1-800-633-559

Preferred Accounts Division (PAD)

toll free: 1-800-060-889

Customer Care

toll free: 1-800-819-339

Corporate Sales

toll free: 1-800-808-385

Transaction Sales

toll free: 1-800-808-312

Fax

toll free: 1-800-818-341

Austria (Vienna)

International Access Code:900

Country Code:43

City Code:1

Switchboard

491 040

Home/Small Business Sales

795676-02

Home/Small Business Fax

795676-05

Home/Small Business Customer Care

795676-03

Preferred Accounts/Corporate Customer Care

0660-8056

Home/Small Business Technical Support

795676-04

Preferred Accounts/Corporate Technical Support

0660-8779

Website: support.euro.dell.com



E-mail: [email protected]



Bahamas

General Support

toll-free:1-866-278-6818

Barbados

General Support

1-800-534-3142

Belgium (Brussels)

International Access Code:00

Country Code:32

City Code:2

Technical Support

481 92 88

Customer Care

481 91 19

Home/Small Business Sales

toll free: 0800 16884

Corporate Sales

481 91 00

Fax

481 92 99

Switchboard

481 91 00

Website: support.euro.dell.com



E-mail: [email protected]



E-mail for French Speaking Customers:

support.euro.dell.com/be/fr/emaildell/



Bermuda

General Support

1-800-890-0748

Bolivia

General Support

toll free: 800-10-0238

Brazil

International Access Code:00

Country Code:55

City Code:51

Customer Support, Technical Support

toll free: 0800 90 3355

Technical Support Fax

481-5470

Customer Care Fax

481-5480

Sales

toll free: 0800 90 3390

Website: www.dell.com/br



British Virgin Islands

General Support

toll-free:1-866-278-6820

Brunei

Country Code:673

General Support

604

633 4966

Customer Service (Penang, Malaysia)

604

633 4949

Transaction Sales (Penang, Malaysia)

604

633 4955

Canada (North York, Ontario)

International Access Code:011

Automated Order-Status System

toll free: 1-800-433-9014

AutoTech (Automated technical support)

toll free: 1-800-247-9362

Customer Care Home & Home Office & Small Business

1-800-847-4096

Customer Care Medium, Large, Commercial, Government (100+

Employees)

1-800-326-9463

Technical Support Home & Home Office & Small Business

1-800-847-4096

Technical Support Medium, Large, Commercial, Government (100+

Employees)

1-800-387-5757

Sales (direct-from outside Toronto)

1-800-387-5752

Sales (direct-from within Toronto)

416-758-2200

Sales (federal government, education, and medical)

1-800-567-7542

Tech Fax

toll free: 1-800-950-1329

Cayman Islands

General Support

1-800-805-7541

Chile (Santiago)

Country Code:56

City Code:2

Sales, Customer Support, and Technical Support

toll free: 1230-020-4823

China (Xiamen)

Country Code:86

City Code:592

Tech Support website: support.ap.dell.com/china



Tech Support E-mail: [email protected]



Tech Support Fax

818-1350

Projector Technical Support Phone

toll free: 800 858 2920

Customer Experience

toll free: 800 858 2060

Home and Small Business

toll free: 800 858 2222

Preferred Accounts Division

toll free: 800 858 2062

Large Corporate Accounts North

toll free: 800 858 2999

Large Corporate Accounts North Government and Education

toll free: 800 858 2955

Large Corporate Accounts East

toll free: 800 858 2020

Large Corporate Accounts East Government and Education

toll free: 800 858 2669

Large Corporate Accounts Queue Team

toll free: 800 858 2572

Large Corporate Accounts South

toll free: 800 858 2355

Large Corporate Accounts West

toll free: 800 858 2811

Large Corporate Accounts GCP

toll free: 800 858 2055

Large Corporate Account Key Accounts

toll-free:800-858-2628

Large Corporate Accounts Spare Parts



toll free: 800-858--2621

Colombia

General Support



980-9-15-3978

Costa Rica

General Support



0800-012-0435

Czech Republic (Prague)

International Access Code:00

Country Code:420

City Code:2

Technical Support

22 83 27 27

Customer Care

22 83 27 11

Fax

22 83 27 14

TechFax

22 83 27 28

Switchboard

22 83 27 11

Website: support.euro.dell.com



E-mail: [email protected]



Denmark (Horsholm)

International Access Code:00

Country Code:45

Technical Support



70230182

Customer Care(Relational)



70230184

Home/Small Business Customer Care



32875505

Switchboard (Relational)



32871200

Fax Switchboard (Relational)



32871201

Switchboard (Home/Small Business)



32875000

Fax Switchboard (Home/Small Business)



32875001

Website: support.euro.dell.com



E-mail Support (portable computers): [email protected]



E-mail Support (desktop computers): [email protected]



E-mail Support (servers): [email protected]



Dominica

General Support



toll free: 1-866-278-6821

Dominican Republic

General Support



toll free: 1-800-156-1588

Ecuador

General Support



toll-free 999-119

El Salvador

General Support



01-889-753-0777

Finland (Helsinki)

International Access Code:990

Country Code:358

City Code:9

Technical Support

253 313 60

Technical Support Fax

253 313 81

Relational Customer Care

253 313 38

Home/Small Business Customer Care

693 791 94

Fax

253 313 99

Switchboard

253 313 00

Website: support.euro.dell.com



E-mail: [email protected]



France (Paris) (Montpellier)

International Access Code:00

Country Code:33

City Code:(1)(4)

Home and Small Business



Technical Support

0825

387 270

Customer Care

0825

823 833

Switchboard

0825

004700

Switchboard (calls from outside of France)

99 75 40 00

Sales

0825

004 700

Fax (calls from outside of France)

99 75 40 001

Website: support.euro.dell.com



E-mail: support.euro.dell.com/fr/fr/emaildell/



Corporate



Technical Support

0825

004 719

Customer Care

0825

338 339

Fax

55 94 71 01

Switchboard

55 94 71 00

Sales

55 94 71 00

Germany (Langen) International

Access Code:00 Country Code:49

Technical Support

06103

766-7200

Home/Small Business Customer Care



0180-5-224 400

Global Segment Customer Care

06103

766-9570

Preferred Accounts Customer Care

06103

766-9420

Large Accounts Customer Care

06103

766-9560

Public Accounts Customer Care

06103

766-9555

Switchboard

06103

766-7000

Website: support.euro.dell.com



E-mail: [email protected]



Grenada

General Support



toll free:1-866-540-3355

Guatemala

General Support



1-800-999-0136

Guyana

General Support



toll free:1-877-440-6511

Hong Kong

International Access Code:001

Country Code:852

TechnicalSupport(Dimension™andInspiron™)



296-93188

TechnicalSupport(OptiPlex™,Latitude™,andDellPrecision™)



296-93191

Customer Service (non-technical, post-sales issues)



800-93-8291

Transaction Sales



toll free: 800 96 4109

Large Corporate Accounts HK



toll free: 800 96 4108

Large Corporate Accounts GCP HK



toll free: 800 90 3708

India

Technical Support



1600-33-8045

Sales



1600-33-8044

Ireland (Cherrywood)

International Access Code:16

Country Code:353

Ireland Technical Support

1850

543 543

UK Technical Support (dial within UK only)

1870

908 0800

Home User Customer Care

204 4095

Small Business Customer Care

204 4444

Corporate Customer Care

204 4003

UK Customer Care (dial number within UK only)

0870

906 0010

Ireland Sales

204 4444

UK Sales (dial within UK only)

0870

907 4000

Sales Fax

204 0144

Fax

204 5960

Switchboard

204 4444

Website: support.euro.dell.com



E-mail: [email protected]



Italy (Milan)

International Access Code:00

Country Code:39

City Code:2

Home and Small Business



Technical Support

577 826 90

Customer Care

696 821 14

Fax

696 821 13

Switchboard

696 821 12

Website: support.euro.dell.com



E-mail: support.euro.dell.com/it/it/emaildell/



Corporate



Technical Support

577 826 90

Customer Care

577 825 55

Fax

577 035 30

Switchboard

577 821

Website: support.euro.dell.com



E-mail: support.euro.dell.com/it/it/emaildell/



Jamaica

General Support (dial from within Jamaica only)



1-800-404-9205

Japan (Kawasaki)

International Access Code:001

Country Code:81

Web site: support.jp.dell.com



Technical Support

toll free: 0120-981-690

Technical Support Outside of Japan

556-3468

Customer Care

556-4240

Korea (Seoul)

International Access Code:001

Country Code:82

City Code:2

Technical Support



toll free: 080-200-3800

Sales



toll free: 080-200-3600

Customer Service (Penang, Malaysia)



toll free: 604-633-4949

Customer Service (Seoul, Korea)



080-200-3800

Fax



2194-6202

Switchboard



2194-6000

Latin America

Customer Technical Support (Austin, Texas, U.S.A.)

512

728-4093

Customer Service (Austin, Texas, U.S.A.)

512

728-3619

Fax (Technical Support and Customer Service) (Austin, Texas,

U.S.A.)

512

728-3883

Sales (Austin, Texas, U.S.A.)

512

728-4397

Sales Fax (Austin, Texas, U.S.A.)

512

728-4600 or 728-3772

Luxembourg International Access

Code:00 Country Code:352

Technical Support (Brussels, Belgium)

481 92 88

Home/Small Business Sales (Brussels, Belgium)

toll free: 080016884

Corporate Sales (Brussels, Belgium)

481 91 00

Customer Care (Brussels, Belgium)

481 91 19

Switchboard (Brussels, Belgium)

481 91 00

Fax (Brussels, Belgium)

481 92 99

Website: support.euro.dell.com



E-mail: [email protected]



Macao

Country Code:853

Technical Support



toll free: 0800 582

Customer Service (Penang, Malaysia)



604 633 4949

Transaction Sales



toll free: 0800 581

Malaysia (Penang)

International Access Code:00

Country Code:60

City Code: 4

Technical Support



toll free: 1 800 888 298

Customer Service

633 4949

Transaction Sales



toll free: 1 800 888 202

Corporate Sales



toll free: 1 800 888 213

Mexico

International Access Code:00

Country Code:52

Customer Technical Support



001-877-384-8979 or 001-

877-269-3383

Sales



50-81-8800 or 01-800-888-

3355

Customer Service



001-877-384-8979 or 001-

877-269-3383

Main



50-81-8800 or 01-800-888-

3355

Montserrat

General Support



toll free:1-866-278-6822

Netherlands Antilles

General Support



001-800-882-1519

Netherlands (Amsterdam)

International Access Code:00

Country Code:31

City Code:20

Technical Support

674 4500

Home/Small and Medium Business

674 5500

Home/Small and Medium Business Fax

674 4775

Home/Small and Medium Business Customer Care

674 4200

Corporate

674 5000

Corporate Fax

674 4779

Corporate Customer Care

674 4325

Website: support.euro.dell.com



E-mail: support.euro.dell.com/nl/nl/emaildell/



New Zealand

E-mail (New Zealand): [email protected]



E-mail (Australia): [email protected]



Home and Small Business



0800 446 255

Government and Business



0800 444 617

Sales



0800 441 567

Fax



0800 441 566

Nicaragua

General Support



001-800-220-1006

Norway (Lysaker)

International Access Code:00

Technical Support



671 16882

Relational Customer Care



671 17514

Home/Small Business Customer Care



231 62298

Autres manuels pour 3300MP

Table des matières

Autres manuels Dell Projecteur

Dell

Dell 1200MP Manuel utilisateur

Dell

Dell PowerEdge RAID Controller S300 Manuel utilisateur

Dell

Dell M410HD Manuel utilisateur

Dell

Dell S510 Manuel utilisateur

Dell

Dell 4610X - XGA DLP Projector Manuel utilisateur

Dell

Dell 2400MP - XGA DLP Projector Manuel utilisateur

Dell

Dell 1200MP Manuel utilisateur

Dell

Dell S518WL Manuel utilisateur

Dell

Dell PowerEdge RAID Controller S300 Guide de démarrage rapide

Dell

Dell S520 Manuel utilisateur

Dell

Dell 2300MP Manuel utilisateur

Dell

Dell Mobile M900HD Manuel utilisateur

Dell

Dell PowerEdge 4350 Manuel utilisateur

Dell

Dell 1800MP Manuel utilisateur

Dell

Dell M209X Manuel utilisateur

Dell

Dell S520 Manuel utilisateur

Dell

Dell 7700 FullHD Manuel utilisateur

Dell

Dell 2400MP - XGA DLP Projector Manuel utilisateur

Dell

Dell M409WX Manuel utilisateur

Dell

Dell S718QL Manuel utilisateur

Dell

Dell S510 Manuel utilisateur

Dell

Dell 1510X Manuel utilisateur

Dell

Dell 3400MP - XGA DLP Projector Manuel utilisateur

Dell

Dell 1100MP Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
