Dell Advanced Projector 7760

User’s Guide

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make

better use of your projector

CAUTION: A CAUTION indicates potential damage to hardware or

loss of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written

permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP

and DLP logo are trademarks of TEXAS INSTRUMENTS INCORPORATED; Microsoft and

Windows are either trademarks or registered trademarks of Microsoft Corporation in

the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either

the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model: Dell Advanced Projector 7760

September 2016 Rev. A00

Contents | 3

Contents

1 About Your Dell Projector . . . . . . . . . . . . . . . . . 4

Projector Box Contents . . . . . . . . . . . . . . . . . . . . 4

Projector Top and Bottom View . . . . . . . . . . . . . . . 5

Projector Connections . . . . . . . . . . . . . . . . . . . . . 6

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 9

2 Adjusting Projector Image. . . . . . . . . . . . . . . . 13

Adjusting Projected Zoom. . . . . . . . . . . . . . . . . . 13

Adjusting Projector Focus and Zoom . . . . . . . . . . 14

Adjusting Projector Position . . . . . . . . . . . . . . . . 15

Adjusting Image Corners. . . . . . . . . . . . . . . . . . . 17

Adjusting Image Size . . . . . . . . . . . . . . . . . . . . . 18

3 Connecting Wireless Display Adapter . . . . . . 21

Installing Wireless Display Adapter . . . . . . . . . . . . 21

Setting up the Wireless Display Adapter . . . . . . . . . 23

Setting up the Optional Dell WR517 Wireless Receiver 24

Using LAN Display . . . . . . . . . . . . . . . . . . . . . . . 26

4 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . 34

Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . 34

Guiding Signals . . . . . . . . . . . . . . . . . . . . . . . . . 38

5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Replacing Remote Control Batteries . . . . . . . . . . . 39

6 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 41

7 Additional Information . . . . . . . . . . . . . . . . . 44

8 Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . 45

4About Your Dell Projector

Your projector comes with all the items shown below. Ensure that you have

all the items, and contact Dell if anything is missing.

Projector Box Contents

1About Your Dell Projector

Package Contents

Power cable VGA cable (VGA to VGA)

Remote control AAA Batteries (2)

CD, User’s Guide, and Documentation

Wireless VGA

Freeze

Blank

Screen

Video

Mode

Info

HDMI

AAA

Informacion Importante

Contents:

•User'sGuide

Documentation

P/N V9NG5

Rev.A00

P/N 36.76J01G001

September2016

MadeinChina

Dell

™

Projector 7760

0V9NG5A00

About Your Dell Projector 5

Projector Top and Bottom View

NOTE: Ceiling mount screw hole M3 x 6.5 mm depth.

Recommended torque < 15 kgf-cm.

1IRreceivers

2 Status indicators

3 Power button

4 20W (2 x 10W) speakers

5 Lens

6 Zoom ring

7Focusring

8 Mounting holes for ceiling mount

9 Tilt adjustment wheel

189

82.30

110.00

55.00

Top View Bottom View

6About Your Dell Projector

Projector Connections

CAUTION: Before you begin any of the procedures in this section,

follow the Safety Instructions as described on page 7.

1 RJ45 connector 8 Microphone connector

2 + 5V/1.8A DC out connector 9 Audio output connector

3 Mini USB (mini type B)

connector for firmware upgrade

10 VGA output (monitor loop

through) connector

4 HDMI 2 connector 11 RS232 connector

5 HDMI 1 connector 12 + 12V DC out connector

6 VGA input connector 13 Security cable slot

7 Audio input connector 14 Power cord connector

1 2 3 4 5 6 7 8

14 13 9101112

About Your Dell Projector 7

CAUTION: Safety Instructions

Do not use the projector near appliances that generate a lot of heat.

Do not use the projector in areas where there is an excessive amount of

dust. The dust may cause the system to fail and the projector will

automatically shutdown.

Ensure that the projector is mounted in a well-ventilated area.

Do not block the ventilation slots and openings on the projector.

Ensure the projector operates between ambient temperatures (5 °C to 40

°C).

Do not try to touch the ventilation outlet as it can become very hot after

the projector has been turned on or immediately after it is turned off.

Do not look into the lens while the projector is on as it may cause injury to

your eyes.

Do not place any objects near or in front of the projector or cover its lens

while the projector is on as the heat may cause the object to melt or burn.

Do not use alcohol to wipe the lens.

NOTE:

•

Do not attempt to ceiling mount the projector by yourself. It should be

installed by a qualified technician.

•

Recommended Projector Ceiling Mount Kit (P/N: C3505). For more

information, see the Dell Support website at

dell.com/support

•

For more information, see the Safety Information that shipped with

your projector.

•

The 7760 projector can only be used indoors.

8About Your Dell Projector

WARNING: Laser Safety Notice

•

This projector is a Class 2 laser device that conforms with IEC 60825-

1:2007 and CFR 1040.10 and 1040.11.

•

Class 2 Laser product - Do not stare into the laser beam.

•

This product contains Class-4 laser module. Do not attempt to

dismantle the product.

•

Any operation or adjustment not specifically instructed by the user's

guide creates the risk of hazardous laser radiation exposure.

•

Do not stare into beam when the projector is on. The bright light may

result in permanent eye damage.

•

Without following the control, adjustment or operation procedure

may cause damage by the exposure of laser radiation.

•

Adequate instructions for assembly, operation, and maintenance,

including clear warnings concerning precautions to avoid possible

exposure to laser and collateral radiation in excess of the accessible

emission limits in Class 2.

About Your Dell Projector 9

Remote Control

1 Power Turns the projector on or off.

2 Up Press to navigate through the On-Screen

Display (OSD) Menu items.

3 Right Press to navigate through the On-Screen

Display (OSD) Menu items.

4 Down Press to navigate through the On-Screen

Display (OSD) Menu items.

Wireless VGA

Freeze

Blank

Screen

Video

Mode

Info

HDMI

316

10 About Your Dell Projector

5 Laser Point the remote control at the screen, press

and hold the laser button to activate the laser

light.

WARNING: Do not look at the laser

when it is active. Avoid pointing the

laser at your eyes.

6 Freeze Press to pause the screen image, then press

"Freeze" again to resume normal projection.

7 Brightness + Press to increase the brightness.

8 Keystone adjustment

Press to adjust image distortion caused by

tilting the projector (+/-30 degrees).

9 Brightness - Press to decrease the brightness.

10 Keystone adjustment

Press to adjust image distortion caused by

tilting the projector (+/-30 degrees).

11 Blank screen Press to hide/unhide the image.

12 Info Press to display the projector information.

13 Video mode The projector has preset configurations that

are optimized for displaying data

(presentation slides) or video (movies, games,

etc.).

Press the Video Mode button to toggle

between Presentation mode, Bright mode,

Movie mode, sRGB, or Custom mode.

Pressing the Video Mode button once will

show the current display mode. Pressing the

Video Mode button again will switch

between modes.

14 HDMI Press to choose HDMI 1 or HDMI 2 source.

15 Enter Press to confirm the selection.

16 Left Press to navigate through the On-Screen

Display (OSD) Menu items.

17 Menu Press to activate the OSD.

18 Source Press to switch between sources: VGA, HDMI

1, HDMI 2, Wireless Display, and LAN Display.

19 Volume up Press to increase the volume.
