www.dell.com | support.dell.com

Dell™ Systems

Microprocessor Upgrade

Installation Guide

9D904ebk5.book Page 1 Wednesday, March 5, 2003 1:42 PM

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you

how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury,

or death.

Information in this document is subject to change without notice.

ReproductioninanymannerwhatsoeverwithoutthewrittenpermissionofDellComputerCorporationisstrictlyforbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Computer Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and

names or their products. Dell Computer Corporation disclaims any proprietary interest in trademarks and trade names

other than its own.

March 2003 P/N 9D904 Rev. A05

9D904ebk5.book Page 2 Wednesday, March 5, 2003 1:42 PM

Microprocessor Upgrade Installation Guide 1-1

This document provides instructions about adding or replacing microprocessors. To take

advantage of future options in speed and functionality, you can add secondary

microprocessors or replace microprocessors in your system.

NOTICE: Before you add or replace a microprocessor, check the latest system BIOS

information on the Dell Support website at support.dell.com, and upgrade the BIOS if necessary.

Each microprocessor and its associated cache memory are contained in a pin-grid array

(PGA) package that is installed in a ZIF socket on the system board. The following

subsection describes how to install or replace the microprocessor in either the primary or

secondary microprocessor sockets.

NOTE: In a single microprocessor system, the microprocessor must be installed in the

primary microprocessor socket.

Adding or Replacing a Microprocessor

NOTICE: The secondary microprocessors must be the same speed as the primary

microprocessor.

In addition to the ZIF socket for the primary microprocessor on the system board, other

ZIF sockets might be present to accommodate secondary microprocessors.

The following items are included in the microprocessor upgrade kit:

• A microprocessor

• A heat sink

• Heat-sink retention clip(s)

• A VRM, if applicable

Your upgrade kit may also include a cooling fan.

CAUTION: Before you perform this procedure, read the safety instructions in

your System Information document.

1Turn off the system, including any peripherals, and disconnect the power cable from

the electrical outlet.

2Open the system doors, or remove the system cover (see your Installation and

Troubleshooting Guide).

CAUTION: See "Protecting Against Electrostatic Discharge" in the safety

instructions in the System Information document.

3Remove the cooling shroud, if applicable (see your Installation and Troubleshooting

Guide).

9D904ebk5.book Page 1 Wednesday, March 5, 2003 1:42 PM

1-2 Microprocessor Upgrade Installation Guide

www.dell.com | support.dell.com

4If you are upgrading an existing microprocessor, remove the microprocessor heat sink.

NOTE: If a cooling fan is mounted on the heat sink, you can remove the heat sink without

removing the fan. However, you can remove the fan to provide easier access to the heat-sink

retention clip(s). For information on removing a cooling fan, see your Installation and

Troubleshooting Guide.

aRemove the retention clip(s) securing the heat sink to the microprocessor by

pressing down firmly on the retention clip tab, and then removing the clip from

the heat sink.

CAUTION: The microprocessor and heat sink can become extremely hot. Be sure

they have had sufficient time to cool before handling.

NOTICE: Never remove the heat sink from a microprocessor unless you intend to remove the

microprocessor. The heat sink is necessary to maintain proper thermal conditions.

NOTICE: After removing the heat sink, place it upside down on a flat surface to prevent the

thermal interface material from being damaged or contaminated.

bRemove the heat sink. See your Installation and Troubleshooting Guide for

information on removing the heat sink.

5Swing the socket release lever upward to the fully open position (see Figure 1-1).

NOTICE: Be careful not to bend any of the pins when removing the microprocessor. Bending

the pins can permanently damage the microprocessor.

6Lift the microprocessor out of the socket and leave the release lever in the open

position so that the socket is ready for the new microprocessor.

NOTICE: Be careful not to bend any of the pins when unpacking the microprocessor. Bending

the pins can permanently damage the microprocessor.

7Unpack the new microprocessor.

If any of the pins on the microprocessor appear bent, see "Getting Help" in your

Installation and Troubleshooting Guide.

9D904ebk5.book Page 2 Wednesday, March 5, 2003 1:42 PM

Microprocessor Upgrade Installation Guide 1-3

Figure 1-1. Removing and Replacing the Microprocessor

NOTICE: Positioning the microprocessor incorrectly can permanently damage the

microprocessor and the system when you turn on the system. When placing the microprocessor

in the ZIF socket, be sure that all of the pins on the microprocessor go into the corresponding

holes. Be careful not to bend the pins.

8Install the microprocessor in the socket (see Figure 1-1).

aEnsure that the microprocessor socket release lever is in the fully open position.

bAlign pin 1 on the microprocessor with pin 1 on the microprocessor socket.

cWith pin 1 of the microprocessor and socket aligned, set the microprocessor

lightly in the socket and ensure that all pins are matched with the correct holes in

the socket.

Because the system uses a ZIF microprocessor socket, there is no need to use force

(which could bend the pins if the microprocessor is misaligned). When the

microprocessor is positioned correctly, it should drop down into the socket with

minimal pressure.

dWhen the microprocessor is fully seated in the socket, rotate the socket release

lever back down until it snaps into place, locking the microprocessor in the socket.

pin-1 locators

microprocessor

microprocessor socket

9D904ebk5.book Page 3 Wednesday, March 5, 2003 1:42 PM

1-4 Microprocessor Upgrade Installation Guide

www.dell.com | support.dell.com

9Install the heat sink.

• If the heat sink provided has a protective cover on the underside of the heat sink,

remove and discard the cover to expose the thermal grease or foil thermal interface

material, and then place the heat sink on the microprocessor.

• If heat-sink thermal grease is provided, clean the heat sink and apply the thermal

grease before placing the heat sink on the microprocessor.

NOTICE: To avoid possible damage to the microprocessor, you must align the heat sink so that

the triangular mark on the heat sink points toward the triangular mark on the system board, if

applicable.

10 Orient the heat-sink retention clip as shown in your Installation and Troubleshooting

Guide.

11 Hook the end of the clip without the release tab over the tab on the edge of the socket.

12 Press down on the release tab until the hole on the clip latches onto the ZIF

socket tab.

NOTICE: If a cooling fan is provided with your upgrade kit, you must install the fan on the

microprocessor heat sink to provide proper thermal conditions. For information on installing a

cooling fan, see your Installation and Troubleshooting Guide.

13 If a cooling fan is provided with your upgrade kit or if you removed a cooling fan earlier

in this procedure, install the fan on the microprocessor heat sink.

14 If applicable, install the VRM(s):

aIf you are adding a secondary microprocessor, examine the VRM to ensure that it

is the correct VRM for your system.

bInsert the VRM in the appropriate secondary VRM connector, ensuring that the

latches at each end of the connector engage (see Figure 1-2).

cIf you received two VRMs with the upgrade kit, replace the primary VRM already

installed in the system with one of the VRMs from the upgrade kit.

NOTE: The system does not support mismatched VRMs.

9D904ebk5.book Page 4 Wednesday, March 5, 2003 1:42 PM

Microprocessor Upgrade Installation Guide 1-5

Figure 1-2. Installing a VRM

15 Replace the cooling shroud, if applicable (see your Installation and Troubleshooting

Guide).

16 Close the system doors, or replace the system cover (see your Installation and

Troubleshooting Guide).

17 Reconnect your system and peripherals to their electrical outlets, and turn them on.

As the system boots, it detects the presence of the new processor and automatically

changes the system configuration information in the System Setup program.

NOTE: After you access the inside of the system, the chassis intrusion detector will cause

an alert message to be displayed at the next system startup. This message is stored in the

system’s nonvolatile random-access memory (NVRAM). To clear this message log, see your

systems management software documentation.

18 Enter the System Setup program and ensure that the microprocessor categories match

the new system configuration. For instructions about using the System Setup

program, see your User’s Guide.

19 Run the system diagnostics to verify that the new microprocessor is operating

correctly. See your Installation and Troubleshooting Guide for information about

running the diagnostics and troubleshooting any problems that may occur.

VRM

VRM connector

latches (2)

connector key

9D904ebk5.book Page 5 Wednesday, March 5, 2003 1:42 PM

1-6 Microprocessor Upgrade Installation Guide

www.dell.com | support.dell.com
