DB Technologies CROMO 8+ Manuel utilisateur

CROMO 8+

CROMO 10+

CROMO 12Club

CROMO 12+

CROMO 15+

2-Way Active Speakers

Series

2-Way Active

Speakers

2-Way Active

Speakers

Series

The Cromo+ Series offers powered loudspeakers with modern digital technology for ﬁrst

time users, without having to miss out on professional features and outstanding audio

performance.

The Cromo+ Series features the ultra compact digipack digital power ampliﬁers, based on

the successful digipro® amp technology for maximum efﬁciency.

The integrated digital sound processor (DSP) caters for perfect sound calibration of the

individual speaker components. All in all, true professional features, unique in its class

and setting new standards in entry level speaker lines.

The compact multifunctional housing of the Cromo+ speaker line, with asymetrical CD

horns, can be used for many different applications, such as live events, a public address

system for a singer, for monitoring purposes on stage, or for ﬁxed installations in Bars

or lounges.

All Cromo+ models have a microphone input on XLR and jack sockets for maximum

ﬂexibility.

PACK

CROMO 8+ | CROMO 10+ | CROMO 12Club | CROMO 12+ | CROMO 15+

Professional Active Speakers

Series

CR10+

Club

CR CR12CR

Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data

Frequency Response [-10dB]: 68 - 20.000 Hz

Frequency Response [+/- 3dB]: 80 - 19.000 Hz

Max SPL: 118 dB

HF: 1 “

Type HF: Compression driver

Directivity: 90/70 x 60 °

Horn: Asymmetrical CD Horn

LF: 8 “

Ampliﬁer

Amp Technology: Digipack™

Amp Class: Class D

Power PRG: 300 Watt

Processor

Controller: DSP 24bit/48kHz

System Presets: Flat, Processed

Limiter: Dual Active Peak, RMS, Thermal

Mechanics

Housing: Polyporpylen PP

Angles Up: Monitor use 43 °

Width: 270 mm (10.8 in)

Height: 435 mm (17.4 in)

Depth: 252 mm (10.08 in)

Weight: 7,8 kg (15.43 lbs)

CROMO 8+

Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data

Frequency Response [-10dB]: 65 - 20.000 Hz

Frequency Response [+/- 3dB]: 70 - 19.000 Hz

Max SPL: 121 dB

HF: 1 “

Type HF: Compression driver

Directivity: 90/70 x 60 °

Horn: Asymmetrical CD Horn

LF: 10 “

Ampliﬁer

Amp Technology: Digipack™

Amp Class: Class D

Power PRG: 400 Watt

Processor

Controller: DSP 24bit/48kHz

System Presets: Flat, Processed

Limiter: Dual Active Peak, RMS, Thermal

Mechanics

Housing: Polyporpylen PP

Angles Up: Monitor use 43 °

Width: 320 mm (12.8 in)

Height: 508 mm (20.32 in)

Depth: 297 mm (11.88 in)

Weight: 12 kg (26.46 lbs)

CROMO 10+

Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data

Frequency Response [-10dB]: 55 - 20.000 Hz

Frequency Response [+/- 3dB]: 60 - 19.000 Hz

Max SPL: 124 dB

HF: 1 “

Type HF: Compression driver

Directivity: 90/70 x 60 °

Horn: Asymmetrical CD Horn

LF: 12 “

Ampliﬁer

Amp Technology: Digipack™

Amp Class: Class D

Power PRG: 400 Watt

Processor

Controller: DSP 24bit/48kHz

System Presets: Flat, Processed

Limiter: Dual Active Peak, RMS, Thermal

Mechanics

Housing: Polyporpylen PP

Angles Up: Monitor use 43 °

Width: 402 mm (16.08 in)

Height: 615 mm (24.6 in)

Depth: 356 mm (14.24 in)

Weight: 17,7 kg (39.02 lbs)

CROMO 12Club

CR8+

CROMO 8+ | CROMO 10+ | CROMO 12Club | CROMO 12+ | CROMO 15+

More power To Your Power Amp

Series

CR12+CR15+

CR CR

Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data

Frequency Response [-10dB]: 55 - 20.000 Hz

Frequency Response [+/- 3dB]: 60 - 19.000 Hz

Max SPL: 126 dB

HF: 1 “

Type HF: Compression driver

Directivity: 90/70 x 60 °

Horn: Asymmetrical CD Horn

LF: 12 “

Ampliﬁer

Amp Technology: Digipack™

Amp Class: Class D

Power PRG: 600 Watt

Processor

Controller: DSP 24bit/48kHz

System Presets: Flat, Processed

Limiter: Dual Active Peak, RMS, Thermal

Mechanics

Housing: Polyporpylen PP

Angles Up: Monitor use 43 °

Width: 402 mm (16.08 in)

Height: 615 mm (24.6 in)

Depth: 356 mm (14.24 in)

Weight: 18,5 kg (39.68 lbs)

CROMO 12+

Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data

Frequency Response [-10dB]: 45 - 20.000 Hz

Frequency Response [+/- 3dB]: 50 - 19.000 Hz

Max SPL: 128 dB

HF: 1 “

Type HF: Compression driver

Directivity: 90/70 x 60 °

Horn: Asymmetrical CD Horn

LF: 15 “

Ampliﬁer

Amp Technology: Digipack™

Amp Class: Class D

Power PRG: 600 Watt

Processor

Controller: DSP 24bit/48kHz

System Presets: Flat, Processed

Limiter: Dual Active Peak, RMS, Thermal

Mechanics

Housing: Polyporpylen PP

Angles Up: Monitor use 43 °

Width: 470 mm (18.8 in)

Height: 720 mm (28.8 in)

Depth: 405 mm (16.2 in)

Weight: 22.9 kg (50.49 lbs)

CROMO 15+
