OM-DRAGON™ SERIES
QUICK REFERENCE
DATALOGIC S.p.A.
Via Candini 2
40012 - Lippo di Calderara di Reno
Bologna - Italy
OM-DRAGON™
Ed.: 11/2005
ALL RIGHTS RESERVED
Datalogic reserves the right to make modifications and improvements without prior
notification.
Datalogic shall not be liable for technical or editorial errors or omissions contained herein,
nor for incidental or consequential damages resulting from the use of this material.
Product names mentioned herein are for identification purposes only and may be
trademarks and or registered trademarks of their respective companies.
© Datalogic S.p.A. 2002-2005
Preliminary
iii
CONTENTS
Updates and Language Availability.....................................................................iv
Using OM-DRAGON™ Radio Cradle.................................................................. 1
Installation ........................................................................................................... 2
System Connections ........................................................................................... 5
Connecting and Disconnecting the OM-DRAGON™ Interface Cable................. 5
OM-DRAGON™ Configuration ........................................................................... 7
Wedge Keyboard Nationality............................................................................. 11
Operating Test .................................................................................................. 13
OM-DRAGON™ Default Configuration ............................................................. 14
Technical Features............................................................................................ 15
Warranty............................................................................................................ 16
Services And Support ....................................................................................... 16
Compliance ....................................................................................................... 16
iv
UPDATES AND LANGUAGE AVAILABILITY
UK/US
The latest drivers and documentation updates for this product are available on
Internet.
Log on to : www.datalogic.com
I
Su Internet sono disponibili le versioni aggiornate di driver e documentazione di
questo prodotto. Questo manuale è disponibile anche nella versione italiana.
Collegarsi a : www.datalogic.com
F
Les versions mises à jour de drivers et documentation de ce produit sont
disponibles sur Internet. Ce manuel est aussi disponible en version française.
Cliquez sur : www.datalogic.com
D
Im Internet finden Sie die aktuellsten Versionen der Treiber und Dokumentation
von diesem Produkt. Die deutschsprachige Version dieses Handbuches ist
auch verfügbar.
Adresse : www.datalogic.com
E
En Internet están disponibles las versiones actualizadas de los drivers y
documentación de este producto. También está disponible la versión en
español de este manual.
Dirección Internet : www.datalogic.com
OM-DRAGON™
1
USING OM-DRAGON™ RADIO CRADLE
The OM-DRAGON™ cradle, paired with one or more DRAGON™ M series
laser guns, builds a Cordless Reading System for the collection, decoding and
transmission of barcoded data.
It can be connected to a Host PC through an RS232, Wedge or Pen cable and
is suited for both single-cradle and multi-cradle layouts.
It can also be connected to a C-Box and therefore integrated into a fixed
scanner application.
To setup your OM-DRAGON™ cradle you must:
1. Physically install the cradle.
2. Make all system connections.
3. Configure the OM-DRAGON™ cradle.
DATALOGIC
2
INSTALLATION
The OM-DRAGON™ can be mounted for portable or fixed desktop usage, or it
can be fixed to a wall. In all cases, the mounting base must be used.
The OM-DRAGON™ package contains the following:
OM-DRAGON™ 3 screws
This Quick Reference Manual 3 threaded dowels
2 adhesive strips 1 alignment plate
4 rubber feet 1 Antenna
Figure 1 - OM-DRAGON™ Mounting Base bottom view
PORTABLE DESKTOP USE
For desktop use, the OM-DRAGON™ is already correctly positioned on the
base.
1. Referring to Figure 1, carefully clean the rubber feet seat of the base to
remove any impurities that could reduce adhesion.
2. Remove the protective plastic from the rubber feet and stick them onto the
bottom surface of the base.
3. Insert the antenna in the appropriate hole on the body of the cradle and
screw it clockwise until tight.
OM-DRAGON™
3
FIXED DESKTOP USE
For fixed desktop installation use the adhesive strips referring to Figure 1.
1. If you are installing several cradles and you desire to align them, you can
use the alignment plate (see Alignment Plate Installation), otherwise
continue with step 2.
2. Carefully clean the adhesive strip seat of the base to remove any
impurities that could reduce adhesion.
3. Remove the protective plastic from one side of the adhesive strips and
stick them onto the base surface.
4. Remove the plastic from the other side of the strips and affix the base to
the table.
5. Insert the antenna in the appropriate hole on the body of the cradle and
screw it clockwise until tight.
WALL MOUNTING
Since the OM-DRAGON™ is mounted on its base when delivered, before
performing the following operation, unscrew the fixing screw and detach the
cradle from the base by holding the base tight and pushing the cradle
backwards.
Figure 2- OM-DRAGON™ top view
DATALOGIC
4
For wall mounting, the cradle is positioned as shown in Figure 3:
Figure 3 - OM-DRAGON™ Base
1. If you are installing several cradles and you desire to align them, you can use
the alignment plate (see Alignment Plate Installation), otherwise continue
with step 2.
2. Using the mounting holes on the base as a pattern mark the wall where
you desire to mount the OM-DRAGON™.
3. Drill three appropriate size holes.
4. Insert the threaded dowels into the holes.
5. Position the base on the wall and affix it by means of the three screws.
6. Reattach the cradle body by sliding it along the mounting tabs until aligned.
7. Fix the cradle to the base by means of the fixing screw. (See Figure 2).
8. Insert the antenna in the appropriate hole on the body of the cradle and
screw it clockwise until tight.
ALIGNMENT PLATE
1. Referring to Figure 1 and Figure 4, snap the Alignment Plate into the holes
provided on the base so that the plate remains extended from the side of
the base.
2. Snap the next base onto the remaining pins of the Alignment Plate.
Figure 4 - Alignment Plate
OM-DRAGON™
5
SYSTEM CONNECTIONS
CAUTION
Connections should always be made with power off!
You can connect the OM-DRAGON™ cradle to the Host through the dedicated
connector, using the cable corresponding to the desired interface type.
CONNECTING AND DISCONNECTING THE
OM-DRAGON™ INTERFACE CABLE
The OM-DRAGON™ can be connected to a Host by means of an RS232, Wedge
or Pen cable which must be simply plugged into the Host connector, visible on the
rear panel of the cradle.
To disconnect the cable, insert a paper clip or other similar object into the hole
corresponding to the Host connector on the body of the cradle. Push down on the
clip while unplugging the cable. Refer to the following figure:
Figure 5 – Connecting/Disconnecting the cable.
Multi-standard interface
RS232, WEDGE, or PEN
Emulation to Host
Power
DATALOGIC
6
RS232 CONNECTION
WEDGE CONNECTION
PEN CONNECTION
