MagellanTM 9300i and 9400i

Scanner and Scanner-Scale with Imaging Technology

Quick Reference Guide

Datalogic ADC, Inc.

959 Terry Street

Eugene, OR 97402

USA

Telephone: (541) 683-5700

Fax: (541) 345-7140

procedures described therein may be reproduced or transmitted in any form or by any means with-

out prior written permission of Datalogic ADC, Inc. or its subsidiaries or affiliates ("Datalogic" or

“Datalogic ADC”). Owners of Datalogic products are hereby granted a non-exclusive, revocable

license to reproduce and transmit this documentation for the purchaser's own internal business

purposes. Purchaser shall not remove or alter any proprietary notices, including copyright notices,

contained in this documentation and shall ensure that all notices appear on any reproductions of

the documentation.

Should future revisions of this manual be published, you can acquire printed versions by contacting

your Datalogic representative. Electronic versions may either be downloadable from the Datalogic

website (www.datalogic.com) or provided on appropriate media. If you visit our website and would

like to make comments or suggestions about this or other Datalogic publications, please let us know

via the "Contact Datalogic" page.

Disclaimer

Datalogic has taken reasonable measures to provide information in this manual that is complete

and accurate, however, Datalogic reserves the right to change any specification at any time without

prior notice.

Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries,

including the U.S.A. and the E.U. All other brand and product names may be trademarks of their

respective owners.

Magellan is a registered trademark of Datalogic ADC, Inc. in many countries, including the U.S.A. and

All-Weighs, FirstStrike, SmartSentry and SurroundScan are registered trademarks of Datalogic ADC,

Inc. in the U.S.A. OmegaTek, Produce Rail, Productivity Index Reporting, and ScaleSentry are all

trademarks of Datalogic ADC, Inc.

Patents

See www.patents.datalogic.com for patent list.

See the Regulatory Addendum included

with your product for additional regula-

tory, safety and legal information.

Quick Reference Guide

Table of Contents

INTRODUCTION........................................................................................................................................................................................... 1

Operation .................................................................................................................................................................................................................. 1

Certification Label ........................................................................................................................................................................................... 2

Scanning Items ......................................................................................................................................................................................................... 3

Weighing Items (Scale Models) .............................................................................................................................................................................. 4

Scale Sentry

Option ............................................................................................................................................................................................. 4

Electronic Article Survellance (EAS) Deactivation Options ......................................................................................................................... 4

Sensormatic Coupled Mode .............................................................................................................................................................................................. 4

Sensormatic Decoupled Mode ......................................................................................................................................................................................... 4

Sensormatic Hybrid Mode ................................................................................................................................................................................................. 4

Controls and Indicators ........................................................................................................................................................................................... 5

Cleaning ..................................................................................................................................................................................................................... 6

CSS Option ................................................................................................................................................................................................................. 6

LED and Beeper Indications .................................................................................................................................................................................... 7

Error Codes ............................................................................................................................................................................................................... 8

ScaleSentry

Indications ...................................................................................................................................................................................... 8

Sensormatic® EAS Indications ................................................................................................................................................................................ 8

Label Programming Mode Indications .................................................................................................................................................................. 8

Warranty ................................................................................................................................................................................................................... 9

ii MagellanTM 9300i and 9400i

NOTES

Quick Reference Guide

Introduction

This manual provides user reference information for the following Magellan™ multi-

plane imaging scanners and scanner-scales: Model 939401, Model 939403, Model

939404, Model 939405, and Model 939406.

With digital imagers in all planes, the 9300i/9400i scanner is capable of reading both 1D

and 2D bar codes seamlessly without requiring item orientation by the cashier. This

manual describes basic operation. For more detailed information about setup, installa-

tion and programming, see the Product Reference Guide for this product. These manuals

are provided in Portable Document Format (PDF) for viewing and printing from the web-

site listed on the back cover of this manual. Additionally, printed manuals can be

ordered from your dealer/distributor.

Operation

CAUTION

If applicable, apply power to the EAS Controller box before powering on

the scanner.

2 MagellanTM 9300i and 9400i

Certification Label

At the time the local scale regulatory authority certifies the scanner/scale for use, a cer-

tification label is affixed to the unit. Depending upon the size and shape of the label,

placement can be made in one of the locations shown in Figure 1.

Figure 1. Affixing the Scale Certification Label

1 Left end of scanner bonnet 4 Remote Display Post

2 Right end of scanner bonnet 5 Back of Bonnet on either side of

the logo.

3 Back of Remote Display Head 6

Scanning Items

Quick Reference Guide

Scanning Items

Slide or push items through the scan zone in a right-to-left or left-to-right movement.

The scanner is equally efficient at scanning items in either direction. It is unnecessary to

shift the position of the bar code, as the scanner can ”read” it from the bottom, left,

right, front and back side of an item, as long as it is fully within the scan zone.

Figure 2. Scan Zones

Vertical Window Scan Zone

Preferred Scan Zone "Sweet Spot"

Checker Side Scan Zone

Arrow Guides

Horizontal Window Scan Zone

For best scanning results...

•Keep items in their natural orientation. Don’t favor any of the scan win-

dows.

•Use the arrow guides to (#6 in Figure 2) to center items over the horizontal

window.

•

Push or slide items instead of lifting them. Avoid unnecessary hand and

wrist movements such as rotation, gripping or twisting, as this can cause

repetitive motion injuries. This helpful technique can also allay the possibil-

ity of lifting thousands of pounds per day

NOTE

If a POS terminal holds the scanner in a disabled state, the scanner

enters limited scanning mode which allows reading of programming

labels but ‘chirps’ other labels.

The all-inclusive scan pattern and advanced FirstStrike™ decoding software ensures the

scanner will read most hard-to-read codes quickly and without a need to particularly

reorient items.

4 MagellanTM 9300i and 9400i

Weighing Items (Scale Models)

The unique platter design allows you to place items anywhere on its surface, including

leaning atop its vertical section, to be weighed accurately. In addition, the Produce Rail

allows items to rest above the counter and other non-weighing surfaces. See Figure 3.

Once weighed items have been positioned, enter PLU (price Look-Up) data as described

in your POS system instructions. Item weight is displayed on the Remote Display and/or

the host display.

Figure 3. Weighing Items

Scale SentryTM Option

The optional ScaleSentry feature monitors items placed on the platter to detect and indi-

cate if they are overhanging non-weighing surfaces. If the system’s infrared (IR) beams

sense items encroaching past the sides of the weigh platter at counter level or on the

surface of the weigh platter, the speaker will sound a unique tone and/or the ScaleSentry

LED indicator will illuminate to indicate a ScaleSentry error condition. A scale transaction

cannot be completed until the item(s) are repositioned to rest fully on the platter (move

them towards the center), clearing the condition. Reference the PRG for more ScaleSentry

options and details.

Electronic Article Survellance (EAS) Deactivation Options

Deactivation of Sensormatic®, Nedap® or Checkpoint® EAS tags is an optional function.

The scanner must be expressly enabled to perform in either capacity.

Sensormatic Coupled Mode

When the scanner is configured to use Coupled EAS Deactivation Mode, deactivation of a

given item happens automatically following its bar code being successfully read.

Sensormatic Decoupled Mode

When in Decoupled Mode, the sales associate must press the Manual EAS Deactivation

button in order to deactivate an item. In this mode, deactivation is independent of the

scanning function.

Sensormatic Hybrid Mode

When in Hybrid Mode, deactivation of a given item happens automatically following its

bar code being successfully read, however, deactivation is independent of the scanning

function.

Controls and Indicators

Quick Reference Guide

Controls and Indicators

The scanner features a conspicuous green LED indicator bar atop the control panel side

of its vertical “bonnet” (item #2 in Figure 4). Additionally, a configurable speaker is used

to sound scanning, weighing and EAS deactivation indications, ScaleSentry event, etc.

Figure 4. Top Side LED Indicators

LED Indicator ”Bar”

Manual EAS Deactivation

Button

Scanner Control Button

Scale Sentry Override

Button

Scale Zero Button

Speaker

Camera Button

Table 1. Control Panel

See

LED and Beeper Indications

for more information regarding each of the indicators.

LED Indicator Bar

Manual EAS Deactivation Button

This bar lights/flashes to indicate functions such as a good

read, ScaleSentry event, etc.

When in EAS Manual Deactivation Mode,

push this button to deactivate an item.

The LED illuminates to indicate EAS func-

tions with red, green OR orange color.

Scanner Control Button

ScaleSentry Override Button

-If the scanner is “asleep”, press this button to wake it up.

-Press this button momentarily to enter beeper volume

change state. Select one of five volume settings.

-Press this button between 1 and 4 seconds to enter beeper

tone change state.

-Press this button for 10 seconds to initiate a soft reset.

When configured to do so, a push of this

button will override a detected scale over-

hang condition.

This red LED indicates the current

ScaleSentry condition. See the

LED and

Beeper Indications

section for more

information.

Scale Zero Button

Speaker

With all weight removed from the scale, push this button to

set the scale to zero.

The yellow LED indicates scale functions.

Sounds

beeps, error tones and other audi-

ble signals to indicate good read,

ScaleSentry alert, system error and other

conditions.

Image Capture Button

This button is used to capture images using the vertical

window. See the PRG for more information.

a. Some audible indications are configurable to be on or off, as well as offer their own programmable

options for pitch, volume, etc.

b. Button functions may be disabled for some applications based on user requirements. See the pro-

gramming section of the PRG for details.

6 MagellanTM 9300i and 9400i

Cleaning

Exterior surfaces and scan windows exposed to spills, smudges or debris accumulation

require periodic cleaning to assure best performance during scanning and weighing

operations. Use a clean, lint-free cloth or paper towel dampened with a nonabrasive,

mild, water-based window cleaner to wipe away stains, smudges, fingerprints, spills,

etc. from the scan window and exterior surfaces (Figure 5a).

Figure 5. Cleaning the Scanner

(Models vary)

CAUTION

DO NOT spray

cleaners directly

on the scanner!

CAUTION

DO NOT use abrasive cleaning agents or abrasive pads to clean this

product. Harsh chemicals, disinfectants, and cleansers can cause dam-

age which will adversely affect scanning and weighing performance.

Daily, clean the debris chutes between the platter and the outer housing (Figure 5c).

Most items can be cleared from the debris chutes by carefully running a thin, stiff object

like a credit card along all sides of the weighing surface. If necessary, remove the platter

(Figure 5b) to clean the debris chutes and drip rail.

CSS Option

Figure 6. Customer Service Scanner (CSS)

Coupon

A Customer Service Scanner (CSS) can

be teamed with the system which

enables mobile commerce (see Figure

6). This unit can be positioned sepa-

rately for optimal customer access.

This eliminates the need for an addi-

tional scanner, power supply, outlet,

interface cable, POS port and mounting

hardware. The customer can scan bar

codes from their mobile phone screen

or paper coupons while the cashier

continues to scan regular items in par-

allel.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Datalogic Lecteur de codes-barres

Datalogic

Datalogic Compact 2D Reader Matrix-2000 Manuel utilisateur

Datalogic

Datalogic PowerScan PD7130 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon I GBT4130 Manuel utilisateur

Datalogic

Datalogic Cobalto CO5300 Manuel utilisateur

Datalogic

Datalogic Gryphon I GD4100 Manuel d'installation et d'exploitation

Datalogic

Datalogic QuickScan QBT21 1 Series Manuel utilisateur

Datalogic

Datalogic FireScan D111 Series Manuel utilisateur

Datalogic

Datalogic Magellan 2300HS Manuel utilisateur

Datalogic

Datalogic PowerScan BT8300 Family Manuel utilisateur

Datalogic

Datalogic PowerScan PD7100 Corded Manuel d'installation et d'exploitation

Datalogic

Datalogic Magellan 800i Manuel utilisateur

Datalogic

Datalogic GRYPHON Manuel utilisateur

Datalogic

Datalogic Gryphon D432 Manuel utilisateur

Datalogic

Datalogic Heron HD3100 Manuel d'installation et d'exploitation

Datalogic

Datalogic F732-E Wizard Manuel utilisateur

Datalogic

Datalogic PowerScan PBT950X Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon 2D Series Manuel utilisateur

Datalogic

Datalogic DSE0420 Guide de configuration rapide

Datalogic

Datalogic Gryphon I GD44 Series Manuel utilisateur

Datalogic

Datalogic DS2400N Manuel utilisateur

Datalogic

Datalogic FireScan D141 Manuel utilisateur

Datalogic

Datalogic DH60 Manuel utilisateur

Datalogic

Datalogic RIDA DBT6400 Manuel d'installation et d'exploitation

Datalogic

Datalogic RIDA DBT6400 Manuel de service

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur

Atid

Atid AT188N Plus Manuel utilisateur
