Daikin BRC1E51 Manuel utilisateur

Remote controller

BRC1E51

QUICK REFERENCE

3 4

1 2 2

120

120 mm

1+2

10 mm

P1 P2

2 2

P1 P2

PCB

PCB PCB

PCB

3 3

8.1 8.2

8.4

8.3

8.4

8.2

8.4

8.1

8.2

8.3 8.4

Quick reference

1BRC1E51

Remote controller

4PW52905-1

INSTALLATION

For the Operation part of this Quick reference refer to

page 12.

The English text is the original instruction. Other

languages are translations of the original instructions.

Refer to the installation cd for more detailed

information.

Contents page

1. Safety Precautions................................................1

2. The kit includes the following parts:......................2

3. Remove the upper part of remote controller.........3

4. Fasten the remote controller.................................3

5. Wire the indoor unit...............................................3

6. Reattach the upper part of the remote controller..4

7. Power on...............................................................4

8. Permission level function.......................................5

9. Field settings.........................................................5

10. Test operation method (SkyAir only)...................8

11. Checking of error records....................................9

12. Registration method of the service contact.......10

13. Clock setting......................................................10

14. Language changeover ......................................11

1. Safety Precautions

Please read these “Safety Precautions” carefully

before installing the remote controller equipment.

Improper installation or attachment of equipment or

accessories could result in electric shock, short-

circuit, leaks, fire or other damage to the equipment

or personal injury.

If unsure of installation procedures or use, always

contact your dealer for advice and information.

Do NOT install the remote controller by yourself.

Improper installation may result in electric shocks or

fire. Consult your Daikin dealer.

BRC1E51 Remote controller Quick reference

NOTE

Read this manual attentively before

starting up or installing the unit. Also see

the installation manual of the outdoor and

indoor unit.

BRC1E51

Remote controller

4PW52905-1

Quick reference

After finishing installation:

■conduct a trial operation to check for faults,

■explain the customer how to operate the remote

controller, using the Operation part of this Quick

Reference,

■ask the customer to store the cd and the quick

reference for future reference. The cd contains

detailed installation and operation information.

Warning

Consult your local dealer regarding relocation and

reinstallation of the remote controller. Improper

installation work may result in electric shocks, leaks

or fire.

2. The kit includes the following parts:

When the remote controller thermo function

is used, select the installation location

considering it should be a place:

• where the average temperature in the

room can be detected,

• that is not exposed to direct sunlight,

• that is not near a heat source,

• that is not affected by outside air or air

draught due to e.g. door opening/closing,

• where the display is kept clean.

• where the front is kept clear.

• where the temperature is between -10°C

and 50°C.

• where the relative humidity is maximum

95%.

Do NOT install the remote controller:

• Near machinery emitting electromagnetic

radiation. Electromagnetic radiation may

disturb the operation of the control system

and result in a malfunction of the unit.

• In moist areas or places where it may be

exposed to water. If water enters the

remote controller, electric shocks may be

caused and the inner electronics may fail.

Remote controller Wood screws

Small screws Clamp

Manual CD Quick Reference

Wiring retainer Wall plugs

Quick reference

3BRC1E51

Remote controller

4PW52905-1

3. Remove the upper part of remote

controller (Refer to figure 1)

Insert a minus screwdriver into the slots (1) in the

lower part of the remote controller (2 places), and

remove the upper part of the remote controller.

4. Fasten the remote controller (Refer to

figure 2)

For the field supplied switch box, use optional accessory

KJB111A or KJB211A.

5. Wire the indoor unit (Refer to figure 8)

Wired from the rear (Refer to figure 8.1).

Wired from the left (Refer to figure 8.2).

Wired from the top (Refer to figure8.3).

Wired from the top center (Refer to figure 8.4).

Connect the terminals on the remote controller (P1,

P2), and the terminals of the indoor unit (P1, P2). (P1

and P2 do not have polarity.)

Wiring specifications

The PCB is mounted in the upper part of the

remote controller. Be careful not to damage

the board with the minus screwdriver.

1for exposed mounting, fasten with the two

included woodscrews (Ø3.5x32) and plugs.

2for flush-mounting, fasten with the two

included machine screws (M4x16).

NOTE Put on a flat surface. Be careful not to

distort the shape of the lower part of the

remote controller by overtightening the

mounting screws.

1indoor unit

2lower part of the remote controller

3upper part of the remote controller

4notch the part for the wiring to pass through

with nippers, etc.

5secure the wiring to the uppercase using

the wiring retainer and clamp.

NOTE When wiring, run the wiring away from

the power supply wiring in order to avoid

receiving electric noise (external noise).

Wiring type Size Max total

length

Sheathedvinyl

cord or cable 0.75–1.25 mm2500 m

NOTE 1. Peel the sheat for the part that has to

pass through the inside of the remote

controller case (L). Refer to figure 4

and the table below. It is important to

keep double isolation up through the

notch of the remote controller case.

2. For easy wiring, it’s better to keep ca.

10 mm difference between the length

of the two wires.

Wiring outlet

Top outlet Ca. 150 mm

Top center outlet Ca. 200 mm

BRC1E51

Remote controller

4PW52905-1

Quick reference

6. Reattach the upper part of the

remote controller

Refer to figure 3:

Align the upper case with the tabs of the lower case

(6 points), inset and install the upper case.

First begin fitting from the clips at the bottom.

7. Power on

1Put on the power.

2Connection under check Please wait for a moment is

displayed.

3After a few seconds, the basic screen is

displayed.

If controlling one indoor unit or one group of

indoor units with two remote controllers

1Put on the power for both remote controllers.

2Determine which one is the sub/main remote

controller.

3When Error code:U5 - Connection under check Please

wait for a moment is displayed on both remote

controllers, push and hold the button of

the sub remote controller for 4 seconds.

4The sub remote controller now displays Sub

remote contrl.

5After a few seconds, the basic screen is

displayed.

Be careful not to pinch the wiring when

attaching.

NOTE 1. The switch box and wiring for

connection are not included.

2. Do not directly touch the PCB with

your hand.

Connection under check

Please wait for a moment

Off reminder Timer

Main remote contrl

NOTE The main remote controller still displays

Main remote contrl.

Connection under check

Please wait for a moment

Error code:U5

Main remote contrl

Connection under check

Please wait for a moment

Sub remote contrl

Quick reference

5BRC1E51

Remote controller

4PW52905-1

8. Permission level function

■If required, you can limit the user action by

restricting the number of operable buttons. (Refer

to the chapter “Field settings” on page 5).

■For switching between level 1 permission and the

selected level in service, proceed as follows

(refer to figure 7):

1Keep the button pressed,

2and push the 3 other indicated keys

simultaneously while keeping the button

pressed.

■If you want to limit the user action on the remote

controller to be defined as “sub”, start with only

connecting this controller to the unit. Make sure

that this controller is set to “main” (factory set)

first, change the permission level to the setting

you prefer and only then set the remote controller

to “sub” (Refer to the chapter “Field settings” on

page 5).

You can now proceed with connecting theremote

controller to be defined as “main”.

9. Field settings

If optional accessories are mounted on the indoor

unit, the indoor unit setting may have to be changed.

Refer to the instruction manual for each optional

accessory.

Procedure

1Press and hold the button for four

seconds to enter the Field setting menu.

2Use the buttons to select Field setting list

and push the button.

Level Operable buttons

1All

2• Up/down button

• On/off button

• Operation mode selector button

3• On/off button

NOTE When pushing a non-operable button,the

icon will be displayed. aUnit No

bFirst Code No

cSecond Code No

dMode

eField set mode

Mode

Unit No

1–00

5–––

9–––

2–00

6–––

a–––

3–00

7–––

b–––

Field setting list

0–01

4–––

8–––

Return Setting

Field setting

Test operation ON/OFF

Field setting list

Group No. setting

Indoor unit Airnet No. set

Outdoor unit Airnet No. set

1/2

BRC1E51

Remote controller

4PW52905-1

Quick reference

3Use the buttons to select the desired

Mode.

4During group control, when setting by each

indoor unit (Mode 20, 21, 22 and 23 have been

selected), push the button to highlight and

buttons to select the INDOOR UNIT NO.

to be set. This operation is unnecessary when

setting by group.

5Highlight the second code No. to be changed

using the buttons, and use the

buttons to select the desired second code No.

6Push the button to display the

confirmation screen.

7Use the buttons to select Yes and push

the button.

8Push the button two times to return to

basic screen.

Notes

NOTE When setting by group, all of the second

code No. that may be set are displayed

as “*”.

NOTE When multiple setting changes are

needed, repeat steps 3 to 7.

Quick reference

7BRC1E51

Remote controller

4PW52905-1

Mode

Note 1

FIRST

CODE

NO. Description of setting SECOND CODE NO. Note 2

01 02 03 04

10(20)

Filter Contamination - Heavy/Light

(Setting for spacing time of display time

to clean air filter)

(Setting for when filter contamination is

heavy, and spacing time of displaytime to

clean air filter is to be halved)

Ultra long

life filter

Approx.

10.000

hrs.

Approx.

5.000

hrs.

——

Long life

filter

Approx.

2.500

hrs.

Approx.

1.250

hrs.

Standard

filter Approx.

200 hrs. Approx.

100 hrs.

Long-lifefilter type (setting of filter sign indication

time). (Change setting when ultra-long filter is

installed)

Long-life

filter Ultra-longlife

filter ——

Thermostat sensor in remote controller

Use Not use — —

Spacing time of display time to clean air filter count

(setting for when the filter sign is not to be displayed)

Display Do not

display ——

11(21) 0

Setting number of connected Sky Air simultaneous

operation system indoor units (setting for

simultaneous operations system)

Pair Twin Triple Double twin

12(22) 1

ON/OFF input from outside (setting for when forced

ON/OFF is to be operated from outside).

Forced OFF ON/OFF

operation ——

Thermostat differential changeover (setting for when

using remote sensor).

1°C 0.5°C — —

13(23)

High air outlet velocity (for high ceiling applications). ≤

2.7 m

2.7

≤

3.0 m

3.0

≤

3.5 m —

Selection of air flow direction (setting for when a

blocking pad kit has been installed).

4-way flow 3-way flow 2-way flow —

Selection of air flow function (setting for when using

a decoration panel for outlet).

Equipped Not

equipped ——

Air flow direction range setting.

Upper Normal Lower —

Setting the external static pressure (setting

according to the connected duct resistance)

Normal High static

pressure Low static

pressure —

15(25) 3

Drain pump operation with humidifying.

Equipped Not

equipped ——

Light

Heavy

Table des matières

Autres manuels Daikin Télécommande

Daikin

Daikin BRC1D61 Manuel utilisateur

Daikin

Daikin OM-5RTBR-0709(0)-DENV Manuel utilisateur

Daikin

Daikin BRC1E62 Manuel utilisateur

Daikin

Daikin BRC1E62 Manuel utilisateur

Daikin

Daikin BRC7EA628 Manuel utilisateur

Daikin

Daikin BRC1H519W7 Guide de l'utilisateur

Daikin

Daikin BRC7F532F Manuel utilisateur

Daikin

Daikin BRC1D528 Manuel utilisateur

Daikin

Daikin BRC1D619 Manuel utilisateur

Daikin

Daikin BRC230Z4 Manuel utilisateur

Daikin

Daikin BRC1H63W Manuel utilisateur

Daikin

Daikin BRC7FA532F Manuel utilisateur

Daikin

Daikin BRC7M675 Manuel utilisateur

Daikin

Daikin ARC417A14 Manuel utilisateur

Daikin

Daikin BRC7CB58 Manuel utilisateur

Daikin

Daikin OM-GS02-02110 Manuel utilisateur

Daikin

Daikin OM-GS02-1011 Manuel utilisateur

Daikin

Daikin BRC1E72 Manuel utilisateur

Daikin

Daikin BRC082A43 Manuel utilisateur

Daikin

Daikin BRC082A41W Manuel utilisateur

Daikin

Daikin BRC52B61 Manuel utilisateur

Daikin

Daikin BRC7E530W8 Manuel utilisateur

Daikin

Daikin DCS302C71 Manuel utilisateur

Daikin

Daikin BRC7E530W8 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
