D-Link XStack DGS-3610 Series Manuel

xStack DGS-3610 Series

Hardware Installation Guide

Version 1.2

DGS-3610 Series Hardware Installation Guide

Revision No.:v1.0

Date: 2008/6/13

D-Link Corporation reserves all copyrights of this document. Any reproduction, excerption, backup,

modification, transmission, translation or commercial use of this document or any portion of this document,

in any form or by any means, without the prior written consent of D-Link Corporation is prohibited.

Exemption statement

This document is provided “as is”. The contents of this document are subject to change without any notice.

Please obtain the latest information through the D-Link Corporation website. D-Link Corporation endeavors

to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to

content omissions, inaccuracies or errors.

Preface

Thank you for using our switches. This manual provides you with detailed operation guide

that allows you to easily install and use the switches.

Scope

This manual describes the functions and physical features of the switches, and provides the

installation procedures, troubleshooting procedures, technical specifications, and

specifications and use rules of cables and connectors. It is intended for the users that have

some experience in installing and maintaining network hardware and want to learn the

above information. At the same time, it is assumed that the users of this switch are already

familiar with the related terms and concepts of Ethernet.

Document Structure

Chapter 1 “Product Overview” describes the scope of application, main features,

technical specifications, and related extension modules of the product.

Chapter 2 “Preparation Before Installation” lists the safety, power supply, and site

requirements that must be met before the switch can be installed.

Chapter 3 “Product Installation” describes how to install the switch as a whole and its

various modules, and to connect the power supply and the grounding cables and

configuration port cables.

Chapter 4 “Troubleshooting” describes how to troubleshoot the faults that may occur

during your installation and use of the hardware.

Appendix A “Connectors and Connection Media”.

Related Documents

Software Manual——covering CLI commands, software configuration guide, version release

notes, and system messages.

Obtaining Documentation

You can obtain the documentation you need through the following channels:

Internet:

You can obtain the latest on-line documentation at:

http://www.dlink.com.tw

Documentation CD-ROM:

The documentation of D-Link switches is stored in the CD-ROM package, which is provided

to you together with the product you purchase. The CD-ROM is updated frequently, and may

be more current than the printed documents.

Obtaining Technical Assistance

D-Link Corporation provides excellent technical support services for all our products. You

can obtain the technical assistance you need through any of the following channels:

Technical Assistance

You can obtain the latest technical information, reasons of common faults, problem

analysis, product application solution and software upgrading information on D-Link

Website.

Customer service center of D-Link Corporation, which can provide all customers with

needed technical assistance for:

Products, technologies and solutions. The customer service center provides responsive

technical support for your product installation problems, software configuration

problems, and other network performance problems.

Documentation Conventions

The symbols used in this document are described as below:

Caution

This symbol brings your attention to some helpful suggestions and

references

Warning

This symbol means that you must be extremely careful not to do some

things that may damage the equipment or cause data loss.

Danger

This symbol means danger. You are in a situation that may cause

personal injury, and you should take appropriate measures to prevent

accidents before you use the equipment.

Contents

1Product Overview................................................................................................................................ 1-1

1.1 Product Overview.......................................................................................................................1-1

1.2 Technical Features of DGS-3610 Series ...................................................................................1-2

1.2.1 Product Features...........................................................................................................1-2

1.2.2 Technical Specifications................................................................................................1-4

1.3 Product Appearance ..................................................................................................................1-8

1.4 DGS-3610 10G Extension module ..........................................................................................1-10

2Installation......................................................................................................................................... 2-12

2.1 Prior Preparation......................................................................................................................2-12

2.2 Desktop Mounting....................................................................................................................2-12

2.3 Rack Mounting.........................................................................................................................2-13

2.4 System Connection..................................................................................................................2-14

2.4.1 Connecting the RJ-45 Port..........................................................................................2-14

2.4.2 Connecting Optical Fibers...........................................................................................2-15

2.4.3 Laser Safety................................................................................................................2-15

2.5 Connecting Power Cables to the Switch..................................................................................2-15

2.6 Optional Installation Procedure................................................................................................2-16

3Troubleshooting .................................................................................................................................. 3-1

3.1 Common Troubleshooting Procedures ......................................................................................3-1

AConnectors and Connection Media.....................................................................................................A-1

A.1 1000BASE-T/100BASE-TX/10BASE-T Port.............................................................................A-1

A.2 Optical Fiber Connection ..........................................................................................................A-2

DGS-3610 Series H/W Installation Guide Chapter 1 Product Overview

1-1

1Product Overview

1.1 Product Overview

The DGS-3610 series is a new generation of 10G multi-layer chassis switch developed by

D-Link that features high performance, high-security, intelligence and ease of use. The

DGS-3610 switch provides flexible media interfaces, which accommodate various media for

connection in networking. In addition, this series can be flexibly expanded with various 10G

modules to offer high expandability and meet the needs for large bandwidth. The hardware

of this series supports multi-layer wire-speed switching and provides a full range of perfect

routing protocols to meet the requirement for multi-routing and high performance of

large-scale networks.

The DGS-3610 provides the intelligent service flow classification from layer 2 to layer 7,

perfect QoS and multicast application management feature. While providing high

performance and intelligence, this series features excellent internal safety protection and

user management, which effectively prevent and control virus spreading and network attacks,

prevent illegal users from accessing the network, and ensure that legal users can

reasonably use network resources. This guarantees the safe and reasonable use and

operation of the network. Additionally, this series allow diversified safe control policies to be

implemented according to the actual network environments.

The DGS-3610 switches provide large network convergence and medium-sized network

cores with multi-layer switching, perfect end-to-end QoS, flexible and rich security settings

and policy-based NM, at a high performance-price-ratio, best meeting the requirements of

enterprise networks for high speed, security, and intelligence.

Currently, DGS-3610 series covers three types so as to meet kinds of application of users:

DGS-3610-26: 24 10/100/1000M adaptive RJ45 ports, multiplexing 12 1000M SFP

ports. Two back extended 10G ports.

DGS-3610-26G: 24 1000M SFP ports, multiplexing 12 10/100/1000M adaptive RJ45

ports. Two back extended 10G ports.

DGS-3610-50P: 48 10/100/1000M RJ45 ports, 4 combo 1000M SFP ports and 2 10G

extension slots.

Applications:

Convergence layers of large networks or the backbones of medium-sized networks;

Chapter 1 Product Overview DGS-3610 Series H/W Installation Guide

1-2

Upgrade to the 10G uplink backbone network by simply adding 10G modules for

protecting user investment;

Scenarios where numerous 1000M ports are needed to provide high-performance data

processing;

High-performance multi-layer switching solutions;

Rich security management mechanism to offer network security protection,

high-security access control and effective network access control;

Perfect use of management policies to help the management of bandwidth and ensure

the application of key services such as voice, multicast audio/video service and VOD

1.2 Technical Features of DGS-3610

Series

1.2.1 Product Features

High-performance multilayer switching

High backbone bandwidth provides non-blocking feature to all ports;

Abundant and perfect routing capability as well as super-large routing table can satisfy

dynamic routing of large-scale networks.

The routing forwarding based on LPM hardware makes DGS-3610 Series not only fit for

large-scale networks, but also prevent the attack of network virus. It can ensure the

wire-speed forwarding of telegrams and the security of equipments.

The DGS-3610 series can support multi-layer wire-speed switching in hardware; can

identify the application data flow from layers 2 to 7. All ports have the ability to filter the

packet independently, to distinguish different application flows, to manage and control

according to different flows.

Flexible and perfect security control

It has many internal mechanisms to efficiently protect and control the spread of virus

and attacks of hackers, like the prevention of DoS attack, IP spanning, thus return a

peace space to network;

Flexible binding in hardware between the ports and the MAC address/IP address may

strictly limit the user accesses on the ports.

Isolating the information exchange between users by setting ports as protected ports,

without needing to occupy the VLAN resources.

Source-IP-address-control-based Telnet and Web equipment access control reinforces

the security of the network management and stops the malicious attack and

manipulation of equipment by hackers.

Broadcast storm suppression based on port rate percentage and rate PPS to ensure

network security;

DGS-3610 Series H/W Installation Guide Chapter 1 Product Overview

1-3

In order to ensure the security of devices, prevent hackers’ attack and control devices,

SSH (Secure Shell) and SNMPv3 can encrypt management information in the process

of Telnet and SNMP;

It can control the access of unauthorized users and protect the reasonable usage of

legal users, like port security, port isolation, expert level ACL, time ACL, bandwidth

limitation of speed based on data flow, the binding of six elements and so on, so satisfy

the needs of strengthening access control in enterprise networks and campus

networks.

Rich multicast features

It supports dynamic unicast/multicast routing protocols, can adapt different scales of

networks and the environment where need many multicast services, so realizing the

extension of network and multi-service application;

The support of IGMP and source IP checking function can effectively prevent illegal

multicast source and improve the network security.

Support IGMPv1/v2/v3 all versions, adapt to different multi-cast environment, and

satisfy the necessity of multi-cast security application.

Perfect QoS Strategy

With DiffServ standard as the core, QoS safeguard system supports perfect strategies

such as 802.1P, IP TOS, stream filter from 2 to 7 layer, SP, WRR, etc., so realizing QoS

logic based on the multi-service of whole network system;

Providing multi-layer flow classification and flow control covering MAC flow, IP flow, and

application flow, implementing multiple flow policies including bandwidth control,

forwarding priority, traffic management, and traffic shaping, and providing traffic rate

limiting, at the granularity of 64Kbps for 1000M ports and 1Mbps for 10G ports,

according to various applications and their needed QoS

High Reliability

It supports STP 802.1d, 802.1w, 802.1s, fully ensure fast convergence, enhance fault

tolerance capability and guarantee the stable operation of network as well as

reasonable use of network pipeline.

It supports VRRP Virtual routing redundancy protocol, and effectively ensure network

stability.

The DGS-3610 series support optional redundancy power system (DPS-510), which

provides the switches with excellent power redundancy for higher fault tolerance and

normal running time.

Easy to use and manage

The multiplexing multi-gigabit interface can flexibly meet the connection to many gigabit

copper and many gigabit fiber links. This allows users to flexibly choose and achieve

the network extension;

Chapter 1 Product Overview DGS-3610 Series H/W Installation Guide

1-4

Supporting smooth upgrade to the 10G backbone by simply adding various 10G

modules to meet flexible expansion and high bandwidth transmission needs;

SNTP can ensure the exact timing of switch and can keep the same with time server. It

is convenient to manage the analysis and diagnosis of journal data and flow data;

Syslog can realize the unified collection, maintenance, analysis, error position and

backup of various log info. It is easy for network administrator to maintain and manage;

Synchronous monitoring of multiple ports makes it possible to monitor the data flows

(incoming frames, outgoing frames or both) on multiple ports just through one of them,

greatly increasing the maintenance efficiency.

CLI interface for use by advanced users to configure; providing multiple upload and

upgrade methods such as Xmodem, FTP, and TFTP;

Java-based Web Management allows users to make the visual interface management

and configure switches quickly and efficiently.

1.2.2 Technical Specifications

Table 1-1 Technical Specifications of DGS-3610 Switches

Product model

DGS-3610-26

Fixed port

24 10/100/1000M RJ45 ports and 12 multiplexing SFP interfaces, 2 10G

extension slots

Available module

DEM-310GT (1000Base-LX, Single-mode, 10km)

DEM-311GT (1000ase-SX, Multi-mode, 550m)

DEM-312GT2 (1000Base-SX, Multi-mode, 2km)

DEM-314GT (1000BASE-LX, Single-mode, 50km)

DEM-315GT (1000BASE-LX, Single-mode, 80km)

DEM-330T/R (WDM transceiver, Single-Mode 10km)

DEM-331T/R (WDM transceiver, Single-Mode 40km)

DEM-412X: 1-port XFP interface 10G conversion board

DEM-412CX: Single port 10G stack module.

DEM-421XT (10GBASE-SR, Multi-mode, 300m)

DEM-422XT (10GBASE-LR, Single-mode, 10km)

DEM-423XT (10GBASE-ER, Single-mode, 40km)

Packet forwarding rate

L2: wire speed (66Mpps)

L3: wire speed (66Mpps)

802.1Q VLAN

ACL

Standard IP ACL (IP address based hardware ACL)

Extended IP ACL (IP address based and TCP/UDP port number based

hardware ACL)

MAC extended ACL (source MAC address based, destination MAC

address based and optional Ethernet type based hardware ACL)

Time-based ACL

Expert level ACL (hardware ACL based on the flexible combinations of

VLAN number, Ethernet type, MAC address, IP address, TCP/UDP port

number, protocol type, and time)

Autres manuels pour xStack DGS-3610 Series

Table des matières

Autres manuels D-Link Changer

D-Link

D-Link DAP-1650 Manuel utilisateur

D-Link

D-Link DES-7200 Mode d’emploi

D-Link

D-Link DKVM-IP1 Manuel utilisateur

D-Link

D-Link DMS-3130-30PS Manuel utilisateur

D-Link

D-Link xStack DES-3552 Series Manuel utilisateur

D-Link

D-Link DUB-H7 - Hub - USB Manuel utilisateur

D-Link

D-Link EasySmart DES-1100-16 Mode d’emploi

D-Link

D-Link DES-105 Manuel utilisateur

D-Link

D-Link DKVM-4U Manuel utilisateur

D-Link

D-Link xStack DGS-3600 Series Manuel utilisateur

D-Link

D-Link KVM-410 - Single Port KVM Switch Manuel utilisateur

D-Link

D-Link xStack DGS-3620 Series Manuel utilisateur

D-Link

D-Link DGS-1005D - Switch Manuel utilisateur

D-Link

D-Link DGS-510 Manuel utilisateur

D-Link

D-Link DGS-1005D - Switch Manuel utilisateur

D-Link

D-Link xStack DGS-3400 Series Manuel utilisateur

D-Link

D-Link DGS-3100 SERIES Manuel utilisateur

D-Link

D-Link DGS-1008D - Switch Manuel utilisateur

D-Link

D-Link DES-1024D Manuel utilisateur

D-Link

D-Link DGS-1216T - Switch Manuel utilisateur

D-Link

D-Link DGS-3000-28SC Manuel utilisateur

D-Link

D-Link DE-805TP - 10Mbps Ethernet Mini Hub Manuel utilisateur

D-Link

D-Link DGS-1248T - Switch Manuel utilisateur

D-Link

D-Link DGS-1100-06/ME Mode d’emploi

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur

D-Link xStack DGS-3610 Series Manuel

Manuels Changer populaires d'autres marques
